radiance TAWR-13 Specifications

OWNER & OPERATOR
INSTRUCTION MANUAL
For service contact:
German Knife Inc.
1-800-500-3519
www.turboairinc.com
www.turboairinc.com
IMPORTANT SAFETY NOTICE
THIS MANUAL HAS BEEN PREPARED FOR PERSONNEL QUALIFIED TO INSTALL GAS EQUIPMENT, WHO SHOULD
PERFORM THE INITIAL FIELD START-UP AND ADJUSTMENTS OF THE EQUIPMENT COVERED BY THIS MANUAL.
POST IN A PROMINENT LOCATION THE INSTRUCTIONS TO BE FOLLOWED IN THE EVENT THE SMELL OF GAS IS
DETECTED. THIS INFORMATION CAN BE OBTAINED FROM THE LOCAL GAS SUPPLIER.
IMPORTANT
In the event a gas odor is detected, shut down units at main shutoff valve and contact the local gas company or gas supplier for service.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapors or liquids in the vicinity of this or other appliance.
WARNING
Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. Read the installation,
operating and maintenance instructions thoroughly before installing or servicing this equipment.
Model No.
TAHP-12-2 TAHP-24-4
TAHP-36-6 TAHP-48-4
TARB-12 TARB-24
TARB-36 TARB-48
TAMG-12 TAMG-24
TAMG-36 TAMG-48
TATG-24
TATG-36 TATG-48
TASP-18S TASP-18
TAWR-13 TAWR-13-JB
TAWR-16 TAWR-16-JB

2
TABLE OF CONTENTS
INSTALLATION
OPERATING INSTRUCTION
MAINTENANCE
WARRANTY INFORMATION
3
4 - 5
6
7
PAGE
SHIPPING DAMAGE CLAIM PROCEDURE
The equipment is inspected & crated carefully by skilled personnel before leaving factory. The transportation company
assumes full responsibility for safe delivery upon acceptance of this equipment if shipment arrives damaged ;
1. VISIBLE LOSS OR DAMAGE : Note on freight bill or express delivery and have signed by person making delivery.
2. FILE CLAIM FOR DAMAGES IMMEDIATELY : regardless of extent of damages.
3. CONCEALED LOSS OR DAMAGES : If damages are noticed after unpacking, notify transportation company
immediately and file “Concealed Damage” claim with them. This should be done within fifteen(15) days from date
delivery is made to you. Return container for inspection.
German Knife Inc
4184 E. Conant St., Long Beach, CA 90808
Phone : [phone]
Fax : [phone]
www.turboairinc.com

3
INSTALLATION
UNPACKING :
1. Remove appliance from container.
2. Remove all protective packaging material.
3. Retain container and packaging material until the appliance is operated and found in good
condition.
4. Check appliance for any shipping damage. If appliance shows any external or internal
damage, promptly inform dealer/distributor where you bought your appliance.
GENERAL SAFETY INSTRUCTIONS :
Accidents are always tragic especially because so many of them could have been prevented
with little care and judgment. There are some basic good practices; we hope you will follow for
safe use of the equipment.
IMPORTANT SAFETY INFORMATION
• Always maintain proper clearances from combustible materials.
• Ventilation air supply must be maintained at all times when the equipment is operating.
• Never connect equipment to an unregulated gas supply.
• Gas supply connections should be checked utilizing soap solution. Never use a flame for
gas leak checks.
• Service and repair should be done by a qualified service person. Do not service while hot
or operating.
NOTE: Installation and repair should be done by a qualified service person.
Qualified service person; who have read these instructions and is familiar with
the operation and functions of the equipment.

4
INSTALLATION
INSTALLATION :
CLEARANCES :
SERVICE CLEARANCES :
The installation must conform with local codes, or in the absence of local codes, with the National Fuel
Gas Code, ANSI Z223.1/NFPA54, or the Natural Gas and propane Installation Code, CSA B149.1, as
applicable, including:
1. The appliance and its individual shutoff valve must be disconnected from the gas supply piping
system during any pressure testing of that system at test pressures in excess of ½ psi.
2. The appliance must be isolated from the gas supply piping system by closing its individual manual
shutoff valve during any pressure testing of the gas supply piping system at test pressures equal to or
less than ½ psi.
A manual shutoff valve (to be supplied by user) must be
installed in the gas supply line upstream of the
appliance and gas pressure regulator (supplied with your
appliance) in the supply gas line for safety and ease
of future service or repair. Your equipment operates at 5
inches water column pressure on natural gas
(Regulator supplied with your appliance) and at 10 inches
water column on propane gas (regulator supplied
with your appliance).
NOTE: Ensure the gas supply, gas type, as shown on rating plate agree
(rating plate is located on the backside of the front panel of unit)
Pipe gas supply to unit
Back Sides Back Sides
TAHP
Model Series Combustible Non-Combustible
TARB
TAMG
TASP
TAWR
12”
8”
7”
17”
17”
12”
8”
8”
17”
15”
0”
0”
0”
0”
0”
0”
0”
0”
0” 0”
For installation on a non‐combustible floor (counter top) only.

5
OPERATING INSTRUCTIONS
LIGHTING INSTRUCTIONS :
• Turn all burner valves to “OFF” position.
• Turn on the main gas supply to the unit.
• Turn pilot valve(s) adjusting screw counter clockwise, then light standing pilot and adjust the pilot flame
to approximately 1/4 inch to 1/2 inch high.
• Turn burner valve on by turning counter clockwise to “ON” position. This should light the main burner.
• If the main burner does not light, turn burner valve to “OFF” position. Wait five (5) minutes to clear any
gas. Then smell for gas, if you don’t smell gas, go to next step.
• Repeat the lighting procedure.
SHUTDOWN INSTRUCTIONS :
• Turn burner valve clockwise to “OFF” position.
• For complete shutdown, turn pilot(s) pilot adjusting screw clockwise to shutoff gas to the pilot(s).
PRIOR TO LIGHTING,
CHECK ALL GAS CONNECTIONS FOR LEAKS !!!!!!!

6
MAINTENANCE
At least on weekly basis, the following items must be inspected:
• Clean area surrounding the unit of all combustible material, gasoline and other flammable vapors and liquids.
• Ensure that the free flow of combustion and ventilating air is not obstructed.
Recommended Cleaning Materials: Mild dishwashing liquid detergent, hot water, Nylon cleaning pad,
wire brush, paper clip, scraper, compressed air, stainless steel cleaner.
DO NOT USE CLEANERS THAT CONTAIN ACID, MINERAL SPIRITS OR XYLENE.
Outside Surfaces : Regularly wipe the surfaces with a mild dish washing detergent, hot water solution &
periodically apply stainless steel cleaner with a clean cloth.
Grease Pan : Check frequently, empty and clean as needed.
Grates & Flame Tamers : Regularly clean with a mild dish washing detergent or baking soda, hot water
and wire brush.
Griddle Plates :
Regularly clean with a mild dish washing detergent or baking soda, hot water and scraper.
Main Burners : Periodically remove burners and clean with hot water and wire brush. Clean any clogged
ports with a stiff wire (such as an opened paper clip). Inspect burner for any damage (cracks or holes). If
damage is found, replace with new burner. Reinstall burner; check to ensure that burner valve orifice is
correctly positioned inside burner inlet (venture).
All cleaning and maintenance should be done
when the unit is cool and the gas supply turned off
by turning off the manual shutoff valve.
CAUTION
NOTE: Contact the manufacturer, company representative, dealer or a qualified service
person to perform maintenance and or repairs.
PRESSURE 5W.C
SEA LEVEL 2000 3000 4000 5000 6000 7000
39 40 41 41 42 42 43
45 46 47 47 47 48 48
50 51 51 51 51 52 52
INNER RING 37 38 39 39 40 41 42
OUTER RING 31 32 32 32 33 34 35
PRESSURE 10W.C
SEA LEVEL 2000 3000 4000 5000 6000 7000
51 51 52 52 52 52 53
55 55 55 55 56 56 56
56 56 56 57 57 57 58
INNER RING 50 51 51 51 51 52 52
OUTER RING 47 48 48 49 49 49 50
NATURAL GAS
EQUIVALENT ORIFICE SIZES AT HIGH ALTITUDES
TASP‐
TAHP‐
TAMG‐
TARB‐
LP GAS
TASP‐
TARB‐
TAMG‐
TAHP‐


LIMITED WARRANTY
WARRANTY CLAIM:
PRODUCTS UNDER WARRANTY:
WHATIS NOT COVERED BY THIS WARRANTY:
One Year Warranty:
Radiance Medium Duty Microwaves- ER/MR series (TMW-1100ER, TMW-1100MR)
Radiance Ranges & Countertop cooking series
(All TAR-, TARG-, TAHP-, TARB-, TAMG-, TATG-, TASP-, TAWR-)
Radiance Cheesemelters, Salamanders, Steam Tables, Hand Wrappers, and Food Warmers
(All TACM-, TASM-, RST-, RHW-, RFW-)
German Knife Light Duty Slicer- LD series (GS-10LD, GS-12LD)
Two Year Warranty:
German Knife Heavy Duty Meat Slicer- Automatic & Manual (GS-12A, GS-12M, GS-13A, GS-13M)
German Knife Meat Grinder (All GG-)
German Knife Band Saw (All GBS-)
Three Year Warranty:
Radiance Heavy Duty Microwaves- HD Series (TMW-1200HD, TMW-1800HD)
Any part covered under this warranty that is found by German Knife / Radiance to have been defective within the
above time period is limited to the repair or replacement, including labor charges, of defective parts or assemblies.
The labor charges shall include standard straight time labor charges only and reasonable travel time as determined
by German Knife / Radiance.
German Knife / Radiance warrants that the equipment, as supplied from the factory to the end-user, is free from
defects in materials and workmanship. Should any part be found defective resulting from normal use within the defined
warranty period, German Knife / Radiance will gladly dispatch an authorized service agency to repair and/or replace
necessary parts under the following conditions.
Repairs under this warranty are to be performed by a German Knife / Radiance authorized service agency only.
German Knife / Radiance will not be responsible for service parts and labor charges performed by non-authorized
service companies. All claims should include the model number, serial number, proof of purchase, date of installation,
and all pertinent information supporting the alleged defect.
German Knife / Radiance’s sole obligation under this warranty is limited to either repair or replacement of parts,
subject to the additional limitations below. This warranty neither assumes nor authorizes any person to assume
obligations other than those expressly covered by this warranty.
Equipment failure resulting from improper installation will not be honored under warranty. Examples are
wrong utility connection and improper utility supply problems.
Equipment that has not been maintained accordingly. Examples are calibration of controls, adjustment to
pilots and burners, and damage from improper cleaning.
Equipment that has not been used in an appropriate manner, alteration, neglect, abuse, misuse, accident,
damage during transit or installation, fire, food, acts of God.
Warranty is not transferrable and only applies in favor of the original purchaser.
Equipment failure resulting from electrical power failure, use of extension cords, low voltage, and voltage
drops to the unit.
These warranties are exclusive and in lieu of all other warranties, including implied warranty and merchantability or
fitness for a particular purpose. No consequential damages. German Knife / Radiance is not responsible for economic
loss, profit loss or special, indirect, or consequential damages. There are no warranties which extend beyond the
description on the face hereof.
Outside the U.S., this warranty does not apply to, and German Knife / Radiance is not responsible for, any warranty
claims made on products sold or used outside the continent of the United States.
