Maretti GROUND ROUND 18 User manual

1/2
Maretti Lighting is well-known in the World of interior design. In businesses, homes, store chains, and hospitality facilities all over
the world, Maretti is unmistakable present with its project lighting that does more than just provide light. We make lighting an
essential part of the interior. Maretti stands for stylish top quality and trendsetting design, modern, timeless and most of all, original.
Maretti Lighting works with all the top brands in the lighting industry, but we are especially notable for our own large product line
and introduce our own brand name “Maretti”. Our production team distinguishes itself time and time again with unique innovations
from our own atelier and therefore our projects exude an entirely unique identity.
© Copyright Maretti Projectverlichting.
Our IM was made with the greatest of care. Nevertheless, the colours displayed in the IM may differ slightly from the real colours
because of the printing process. Colour, size and range are subject to change. Nothing from this IM may be copied, reproduced
and/or published by print, photocopy or in any other way without Maretti Lighting’s written permission. All product and design
copyrights belong to Maretti Lighting.
GUARANTEE TERMS AND CONDITIONS
The other party should inspect the delivered items immediately upon receipt with regard to its soundness. Entitlements to repair or replacement
only exist if the other party
- In the case of visible defects, informs MPV of them immediately.
- In the case of defects that are not visible, informs MPV in writing of the defects, within 2 working days after the day the defects were found, or
in all reason could have been found and furthermore demonstrates that the MPV instructions for use, maintenance and operation were followed,
whilst the defects are not the consequence of normal wear and tear, misuse, negligence, accident, exceeding the limits prescribed by the MPV or
by the legal safety regulations, or, in the case of a repair or change without MPV’s consent or the consent of its recognised repairer, there will be
no entitlement to repairs or replacement. The parts that have to be replaced must be made available free of charge to MPV. Noncompliance by
the other party to one or more of its obligations will release MPV of all its guarantee obligations. In the case of assembly of the other party’s own
products by Maretti, MPV will release itself from all guarantee stipulations. Moreover, our general delivery terms and conditions are applicable.
These can be obtained from Maretti or can be downloaded from www.maretti.com
The installation must be done by a competent installer. Maretti recommends that your (outside) lighting and fixtures are inspected and
maintained annually.
DFür garantiebedingungen bitte lesen sie unsere webseite www.maretti.com
EConsulte nuestro sitio web para los condiciones de garantia www.maretti.com
FR Consultez notre site web pour les conditions de garantie www.maretti.com
NL Voor garantievoorwaarden zie onze website www.maretti.com
Maretti Lighting
Bolderweg 7
1332 AX Almere
the Netherlands
T [phone]
F [phone]
E [email protected]
W www.maretti.com
MARETTI
O U T D O O R
L I G H T I N G
14.2300.04.A
2 PINS P&P KABEL 750mm
GROUND
ROUND 18
Outdoor collectie
L750mm
65mm
Ø40mm
ZW
LED
12V
AC
12
VAC VOLTAGE 85mA AMPERAGE OUTDOOR 98% LUMEN- BEHOUD CE MARK
1,3W WATTAGE NIET
DIMBAAR IP65 IP WAARDE <0,5s OPWAMRTIJD TOT 60%
0W STANDBY
POWER RA80 CRI SVM <0.4 25.000 uren
SCHAKEL-
CYCLUS
EXCL.
DRIVER 2700K KELVIN PstLM <1 -25°C ~ 45°C
OMGEVINGS-
TEMPERATUUR
INCL. LED 89 lm LUMEN 15° GRADEN-
BUNDEL INCL. SPLIT- CONNECTOR

MARETTI
O U T D O O R
L I G H T I N G
E[email protected] Wwww.maretti.com
Vloer
Floor
Zand
Sand
Drainagegrind
Drainage gravel
Stroomkabel
Power cable
Minimaal dikte
materiaal 10mm
Ø 35mm
Schakel altijd eerst de stroom uit
voordat u installatie-, onderhoud of
reparatiewerkzaamheden uitvoert.
Always switch o the mains voltage
before carrying out installation,
maintenance and repair work.
OFF
UIT
Armatuur mag niet in de buitenlucht in het beton gestort worden!
Voor binnen toepassing waar geen water is, kan dit wel.
Buiten moet altijd een drainage toegepast worden voor het afwateren.
Fixture should not be in the open air poured into the concrete!
It’s possible for indoor applications where there is no water.
Outside, a drainage must always be used for dewatering.
Aansluiten op de 12V-AC
Splitconnector
Cable / Kabel
Transformator
12V
Drainage grind
Drainage gravel
min. 300mm
Inbouw
behuizing
Recessed
housing
Vloer
Floor
Zand
Sand
Stroomkabel
Power cable
min. 400mm
OKNOT OK OK
GROUND ROUND 18
Outdoor collectie
14.2300.04.A
SPLITCONNECTOR
14.2220.04
ACCESSOIRES (APART TE BESTELLEN !)
14.2233.04 25 M
14.2235.04 40 M
14.2238.04 100 M
14.2240.04 200 M
KABEL
14.6400.04 SPLITCONNECTOR
14.2210.04.A 3 WEG VERDELER
14.2123.04 VERLENGKABEL 2 M
14.2127.04 VERLENGKABEL 5 M
CONNECTORS
14.2105.04 20VA 12V
14.2109.04 80VA 12V
14.2118.04 150VA 12V
150VA te gebruiken i.c.m. kabels 
TRANSFORMATOR
Replaceable control gear
by a professional
Replaceable (LED only) light source
by a professional
LET OP: Volg en bewaar deze gebruiksaanwijzing.
-Zorg ervoor dat de netspanning uitgeschakeld is voor installatie, reparatie of onderhoud. (Installatie, reparatie en onderhoud uitsluitend door gekwalificeerde personen).
-Voor reparatie of onderhoud uitsluitend originele delen gebruiken. Probeer het product niet zelf te demonteren en te repareren, onjuiste reparaties kunnen het
product beschadigen en elektrische schokken veroorzaken wat tot ernstig letsel kan leiden.
-Om waterdichtheid te verzekeren dient u alle onderdelen handvast aan te draaien.
-Dit armatuur niet openen of installeren tijdens regen of hoge luchtvochtigheid.
-Uitsluitend op het etiket aangegeven lichtbronnen gebruiken.
De fabrikant aanvaardt geen enkele aansprakelijkheid voor letsel of schade als gevolg van een verkeerde toepassing van het armatuur.
De fabrikant aanvaardt geen garantie in geval van het niet behandelen van de lampen volgens de richtlijnen van de fabrikant.
Als er schade aan elektrische onderdelen te vinden zijn, vraag dan een elektricien om het te vervangen.
Onderhoud is behoud:
Een goede instandhouding van het armatuur is sterk afhankelijk van omgevings- en onderhoudsfactoren. Hierop kunnen wij geen invloed uitoefenen.
Alle producten hebben onderhoud nodig, zo ook uw buitenlamp.
-Schakel voor de zekerheid de elektriciteit uit!
-Wij adviseren om 2x per jaar de armaturen te reinigen.
-Gebruik geen agressieve, schurende of chemische schoonmaakmiddelen.
-Aan de directe kuststreek en de Waddeneilanden adviseren we minimaal 1x per kwartaal de buitenlampen te reinigen.
-Goed onderhoud verlengt het plezier en levensduur van uw buitenlampen.
NOTE: Follow and keep this instructions manual.
-Make sure that the mains voltage is switched off before installation, reparation or maintenance. (Installation, reparation and maintenance only by qualified persons).
-Use only original parts for repairs or maintenance. Never attempt to disassemble, repair or alter the product in any way, improper repairs could damage the
product causing electrical shocks which may cause serious injury.
-Make sure all parts are turned hand tight to be sure the item is waterproof.
-Do not open or install this luminaire during rain or highly humid condition.
-Use only suitable light sources indicated on the label.
The manufacturer accepts no liability for any injuries or damages resulting from the incorrect use or installation of the fixture.
Any operation performed on the fixture that is not in accordance with instructions will void manufacturer’s warranty.
If you find any damage to the electrical parts, please ask a qualified electrician to replace it.
Maintenance is preservation:
A good preservation of the fixture is highly dependent on environmental factors and maintenance. We cannot exercise any influence on this.
All products require maintenance, including your outdoor fixture.
-Make sure that the mains voltage is switched off before you begin.
-We recommend to clean the fixtures 2x per year.
-Do not use aggressive, abrasive or chemical cleaners.
-On the immediate coast and the Wadden Islands we recommend cleaning the outdoor fixtures at least 1x per quarter.
-Proper maintenance extends the pleasure and lifespan of your outdoor fixtures.
