marinco INVR-1 User manual

User’s Guide For INVR-1 Remote Control
1. Features
Remote ON/OFF inverter operation.
Optional Ignition Lockout Function or Return Override Function
2. Specifications
Input Voltage AUX +12V 10.5 – 15.5 Vdc
Operating Temperature 0 – 40 °C, 32 - 104 °F
Storage Temperature - 30 - 70 °C, -22 - 158 °F
Stand-By Current Draw < 40mA
Applicable Models All Marinco inverters
3. Introduction
＊Steady red LED light indicates the Inverter is ON.
＊Fast flashing red LED light indicates that the Return Override Function is activated.
＊Slow flashing red LED light indicates that it the Ignition Lockout Function is activated.
Return Override Function or Ignition Lockout Function.
＊Jumper “Open” – Return Override Function
＊Jumper “Short” – Ignition Lockout Function
Please note that the default mode is OPEN (Return Override Function).
＊Ignition Lockout function – The Ignition Lockout Function turns the Inverter OFF when
+12 Volt is applied. Typical use: switching Off the inverter during engine starting.
＊Return Override Function – The Return Override Function turns the Inverter ON when
Blinking Slow Ignition Lockout
PUSH
ON/OFF
Inverter Status
Solid Red
Blinking Fast R.O.F Acting
Inverting
PUSH
ON/OFF
3-1. See Figure 1. The Inverter Status LED shows three modes of the Remote Control:
3-3. The JUMPER is placed inside the remote controller and it activates either the
3-2. Open the remote controller by removing the two screws at the back of the housing.
3-4. The AUX. +12V faston cable must carry +12V DC only and contain a 12 Volt 0.5A fuse.
3-5. Connect the wire RJ-11 to the remote port TO INVERTER.
3-6. Optional: install the 12V cable for the Ignition Lockout Function or Return Override Function.
4. Installation Procedure
Check the contents of delivery: INVR-1 Remote panel, 7.5 m [82 ft] RJ-11 cable, user’s manual.
4-1. Refer to the drawing (see Figure 2) for screw hole and cutout dimensions while fixing or
installing the remote control.
4-2. Use the RJ-11 cable to connect the INVR-1 remote control to the inverter.
4-3. Put the inverter main switch into position REMOTE. Refer to the inverter manual.
Figure 1
Overview
plus wiring
+ -
0.5A
RJ11
+12 Volt is applied. Typical use: switching On the inverter together with the electrical system.
+12V

10000006928/01
Figure 2. Dimensions in mm [inch]
Figure 3. Remote Control Cables
5. Drawings of INVR-1 Remote Control Cables
C O N DUCTO R
J A C K E T
INSUL A T I O N
C A B L E S T R U C T U R E (A-A)
WARNING!
DO NOT use standard telephone cable.
57 [2.244]
28.5
[1.122]
8.75
[0.344]
56 [2.205]
45 [1.77]
73.5 [2.894]
2-∅5 [∅0.197]
Blinking Slow Ignition Lockout
PUSH
ON/OFF
Inverter Status
Solid Red
Blinking Fast R.O.F Acting
Inverting
PUSH
ON/OFF
L = 7.5 m [25 ft]
Lmax = 25.0 m [82 ft]
EC DECLARATION OF CONFORMITY
Manufacturer: Marinco
Address : Westbrook Crossing Menomonee Falls, WI 5305155 Paul Mattews Rd
Represented in the EU by: Mastervolt B.V.
Address: Snijdersbergweg 93
1105 AN Amsterdam
The Netherlands
Herewith declares that the product: INVR-1 Remote Control
is in conformity with the provisions of the following EU directives:
•2004/108/EC (EMC Directive)
•2011/65/EU (RoHS Directive)
The following harmonised standards have been applied:
Generic emission standard: EN 55022: 2010
Generic Immunity standard: EN 55024: 2010
Amsterdam 18-04-2013,
H.A. Poppelier
Manager New Product Development
