Marshall Amplification CODE100 User manual

BOOK-80010-01
M3390.054
SERVICE MANUAL
CODE100 &
CODE100H

2CODE100 & CODE100H Service Manual
BOOK-80010-01 | M3390.054
THIS DOCUMENTATION IS NOT FOR PUBLICATION AND IS FOR USE ONLY BY
AUTHORISED DISTRIBUTION AND SERVICE CENTRE PERSONNEL.
This document supports current production units for the specied models in the
document. Units made before this time may vary. Where possible, variations in products
are listed in this document. Units made to previous specication or design should not be
modied to current design unless specied by a company statement.
Marshall Amplication Plc reserve the right to alter and update this documentation or
product without notice.
Marshall Amplication Plc reserve the right to supply equivalent or alternative parts for
spares orders.
Please contact Marshall UK for components not listed in this service manual.

3CODE100 & CODE100H Service Manual
BOOK-80010-01 | M3390.054
CONTENTS
THIS 100W COMBO IS FULLY PROGRAMMABLE SO YOU CAN PERFORM
ANYTHING, ANYWHERE. WANT TO KEEP UNLOCKING YOUR CREATIVITY ON
THE ROAD, EDIT ON THE GO BY CONNECTING TO YOUR PHONE OR COMPUTER.
CODE100
POWER
100W
PRESETS
100 user-editable presets
EFFECTS
24 different built-in effects
(5 simultaneously)
EFFECTS LOOP
Yes, Send/Return
CONNECTIVITY
Bluetooth 4.0 & USB 2.0
SPEAKER CONFIGURATION
2x12”
SPEAKER
Custom Voiced (4Ω 50W)
FOOTSWITCH
4-way programmable footswitch PEDL-
91010 & 2-way footswitch PEDL-91009
Warning! Safety Instructions 4
Country Identication Codes 5
CODE100C Exterior 6
CODE100H Exterior 7
AMP Assembly 8
AMP Assembly Tables 9
PSU Assembly 10
Front Panel Functions 11
Front Panel PCB 13
Rear Panel Functions 15
Rear Panel PCB 16
Mains Input Details & Bridge 17
Power Supply Unit & Output PCB 18
Digital Signal Processor PCB 19
Headphones PCB 20
Bluetooth PCB 21
Component Identication PCBP 22
Component Side Track PCBP 24
Solder Side Track PCBP 26
Spares List CODE100C 28
Spares List CODE100H 29
Revisions 30
CODE100H
POWER
100W
PRESETS
100 user-editable presets
EFFECTS
24 different built-in effects
(5 simultaneously)
EFFECTS LOOP
Yes, Send/Return
CONNECTIVITY
Bluetooth 4.0 & USB 2.0
FOOTSWITCH
4-way programmable footswitch PEDL-
91010 & 2-way footswitch PEDL-91009

4CODE100 & CODE100H Service Manual
BOOK-80010-01 | M3390.054
WARNING! SAFETY INSTRUCTIONS
PLEASE READ THE FOLLOWING NOTICE IN FULL BEFORE ATTEMPTING TO REPAIR, SERVICE OR DISMANTLE ANY ITEM OF MARSHALL AMPLIFICATION PLC.
MAINS INPUT & FUSE
The specic mains input voltage rating
that your amp has been manufactured for
is indicated on the rear panel of the amp.
Your amp is provided with a detachable
mains (power) lead, which should be
connected to the mains input socket on the
rear panel of the amp. The correct value
and type of mains fuse is specied on the
rear panel of the amp.
Never attempt to bypass the fuse or t one
of the incorrect value or type.
PLEASE NOTE THAT FAILURE TO OBSERVE
THE CONDITIONS SET OUT IN THIS NOTICE
MAY RESULT IN DEATH OR SERIOUS INJURY
TO YOURSELF AND/OR OTHERS. IT MAY
ALSO INVALIDATE THE MANUFACTURER’S
WARRANTY IN RESPECT OF THE ITEM OF
EQUIPMENT CONCERNED.
1. The information contained in this
Service Manual (and in all annexes,
diagrams and documents attached
to or accompanying this Service
Manual) is intended to be used by
authorised Marshall Amplication Plc
service centres or by approved waste
electrical and electronic equipment
reprocessing and recycling centres
only.
2. All repairs and servicing of Marshall
Amplication Plc equipment (‘Marshall
Equipment’) should only be carried
out by suitably trained and qualied
personnel at an authorisd Marshall
Amplication Plc service centre. For
details of your nearest authorised
service centres please contact the
‘Service Department’ at Marshall
Amplication Plc.
3. All reprocessing and recycling of
Marshall Equipment at the end of
its useful life should only be carried
out by suitably trained and qualied
personnel at properly approved waste
electrical and electronic equipment
reprocessing and recycling centres.
4. Marshall Equipment should always
be fully disconnected from the mains
electricity supply before attempting
to carry out any repair, servicing or
disassembly.
5. Even when Marshall Equipment has
been disconnected from the mains
electricity supply it may still retain
high voltage electrical charges that
are potentially hazardous to life and
health. Marshall Equipment may
also contain parts that remain at a
high temperature for a considerable
period of time after use. Extreme
caution should always therefore be
exercised when carrying out any
repairs, servicing or disassembly of
any Marshall Equipment.
6. All Marshall Equipment (including
its component parts) conform and
comply with relevant laws applicable
at the time of manufacture (including
but not limited to laws relating to
electrical safety, electromagnetic
compatibility and the presence of
hazardous substances.) Furthermore
all components are specic for their
intended use and have undergone
appropriate conformity approval.
In the event that during the repair
or servicing of any Marshall
Equipment it is necessary to replace
any component, part or material,
it is therefore essential that only
components, parts or materials that
have been approved by Marshall
Amplication Plc should be used.
7. Any safety warnings attached to
an item of Marshall Equipment
will comply with laws and industry
standards applicable at the time such
item of Marshall Equipment was
manufactured but may not necessarily
reect current law or standards. No
safety warning attached to any item
of Marshall Equipment should be
removed during servicing or repair.
Save as set out below, Marshall Amplication
Plc accepts no responsibility for any death,
injury, loss or damage arising from any non-
observance of the above conditions.
Nothing in these conditions shall limit
Marshall Amplication Plc’s liability
for death or injury to the extent that it
results from their direct negligence or its
employees.

5CODE100 & CODE100H Service Manual
BOOK-80010-01 | M3390.054
COUNTRY IDENTIFICATION CODES
COUNTRY IDENTIFICATION CODES LISTED BELOW ARE USED THROUGHOUT THIS SERVICE MANUAL.
CODE COUNTRY CABLE (UK/VT) VOLTAGE POWER
A Australia, New Zealand CBLM-00007 / CBLM-90004 230V 50HZ
BBrazil CBLM-00011 / CBLM-90005 127V 60HZ
C Canada CBLM-00002 / CBLM-90003 120V 60HZ
D Argentina CBLM-00010 / CBLM-90007 220V 50HZ
E Andorra, Armenia, Austria, Bolivia, Bulgaria, Chile, Croatia, Cyprus, Czech Republic,
Gran Canaria, Egypt, Estonia, France, French Polynesia, Germany, Ghana., Greece,
Guadeloupe, Hungary, Iceland, India, Iran, Italy, Jordan, Kuwait, Lebanon, Malta,
Martinique, Netherlands, New Caledonia, Nigeria, Poland, Portugal, Reunion Island,
Russia, Singapore, Slovenia, South Africa, Spain, Tenerife, Thailand, Tunisia, Turkey,
Uruguay
CBLM-00003 / CBLM-90002 230V 50HZ
FColumbia, Costa Rica, Dominican Republic, Equador, El Salvador, Panama, Venezuela CBLM-00005 / CBLM-90003 120V 60HZ
H Home Market (UK), Ireland, Malaysia, Gibraltar, UAE, Bangladesh, Northern Cyprus CBLM-00006 / CBLM-90001 230V 50HZ
I Israel CBLM-00015 / CBLM-90009 230V 50HZ
J Japan CBLM-00012 / CBLM-90010 100V 50/60HZ
K Korea CBLM-00014 / CBLM-90011 220V 60HZ
L Indonesia CBLM-00003 / CBLM-90002 230V 50HZ
M Mexico CBLM-00005 / CBLM-90003 130V 60HZ
Q China CBLM-00013 / CBLM-90013 220V 50HZ
S Semko Denmark, Sweden, Finland, Norway CBLM-00003 / CBLM-90002 230V 50HZ
T Taiwan CBLM-00009 / CBLM-90003 120V 60HZ
UUSA CBLM-00005 / CBLM-90003 120V 60HZ
XHong Kong CBLM-00006 / CBLM-90001 220V 50HZ

6CODE100 & CODE100H Service Manual
BOOK-80010-01 | M3390.054
CODE100 EXTERIOR
PARTS LIST
ITEM QTY DESCRIPTION STOCK NO.
1 1 MARSHALL LOGO, WHITE LOGO-01210
2 1.0 FRET CLOTH, BLACK FRET-90041
3 1 HANDLE ASSSEMBLY HNDL-91004
4 2 12” CUSTOM SPEAKER SPKR-00110
5 1.0 BLACK LEVANT COVERING CVER-00209
64RUBBERT FEET (BIG) FEET-90026
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
A A
B B
C C
D D
SHEET 1 OF 1
DRAWN
CHECKED
QA
MFG
APPROVED
MPoderys 03/03/2020
DWG NO
MD116D100-00-00 FOR SERVICE MANUAL
TITLE
SIZE
D
SCALE
REV
1:2.3
1
1
2
1.0
3
1
4
2
5
1.0
6
4

7CODE100 & CODE100H Service Manual
BOOK-80010-01 | M3390.054
CODE100H EXTERIOR
PARTS LIST
ITEM QTY DESCRIPTION STOCK NO.
1 1 MARSHALL LOGO, WHITE LOGO-01210
2 1.0 BLACK LEVANT COVERING CVER-00209
3 1 HANDLE ASSEMBLY HNDL-91004
4 1.0 BLACK LEVANT COVERING CVER-00209
5 4 RUBBER FEET (BIG) FEET-90026
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
A A
B B
C C
D D
SHEET 1 OF 1
DRAWN
CHECKED
QA
MFG
APPROVED
MPoderys 03/03/2020
DWG NO
MD116D100-00-00 HEAD FOR SERVICE MANUAL
TITLE
SIZE
D
SCALE
REV
1:2
1
1
2
1.0
3
1
4
1.0
5
4

8CODE100 & CODE100H Service Manual
BOOK-80010-01 | M3390.054
AMP ASSEMBLY
PARTS LIST
ITEM QTY DESCRIPTION STOCK NO.
2 1 LCD WINDOW LENS LCDW-00002
3 1 POWER SWITCH PS8A REF. TABLE 6
4 1 FRONT PANEL PCB PCBA-90049
5 1 BIG LCM WITH FFC LCDD-00002
15 6 BROWN BODY, GOLD CAP KNOB REF. TABLE 4
16 2BROWN BODY, GOLD CAP KNOB, ENCODER REF. TABLE 4
17 1FS HEADPHONE PCB PCBA-90008
18 1 DSP PCB PCBA-90033
19 1 BLUETOOTH PCB PCBA-90034
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
A A
B B
C C
D D
SHEET 1 OF 2
DRAWN
CHECKED
QA
MFG
APPROVED
MPoderys 03/03/2020
DWG NO
MD116D100-10-00 FOR SERVICE MANUAL
TITLE
SIZE
D
SCALE
REV
1
15
6
16
2
3
1
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
A A
B B
C C
D D
SHEET 2 OF 2
DRAWN
CHECKED
QA
MFG
APPROVED
MPoderys 03/03/2020
DWG NO
MD116D100-10-00 FOR SERVICE MANUAL
TITLE
SIZE
D
SCALE
REV
1
19
1
18
1
4
1
5
1
2
117
1

9CODE100 & CODE100H Service Manual
BOOK-80010-01 | M3390.054
AMP ASSEMBLY TABLES
TABLE 1 - MAINS TRANSFORMERS
VOLTAGE SPEC QTY DESCRIPTION STOCK NO.
A, D, E, H, I, K, L, Q, S, X 1MAINS 230V ASSEMBLY TXMA-90053-01
BLUE BROWN
B, C, F, M, T, U 1MAINS 120V ASSEMBLY TXMA-90053-01
BLUE BLACK
J1MAINS 100V ASSEMBLY TXMA-90053-01
BLUE WHITE
TABLE 2 - FRONT PANELS
MODEL QTY DESCRIPTION STOCK NO.
CODE100 N/A
TABLE - 5 MAINS INPUT FUSES
VOLTAGE SPEC QTY DESCRIPTION STOCK NO.
A, D, E, H, I, K, L, Q,
S, X
2FUSE 0219.315MXAP FUSE-90024
B, C, F, K, M, T, U 2FUSE 0219.630MXAP FUSE-90025
TABLE 4 - KNOBS
MODEL QTY DESCRIPTION STOCK NO.
CODE100 2SHORT, BROWN BODY, GOLD CAP
ENCODER
KNOB-90017
CODE100 6 SHORT, BROWN BODY, GOLD CAP KNOB-90018
TABLE - 6 MAIN SWITCH
VOLTAGE SPEC QTY DESCRIPTION STOCK NO.
UNIVERSAL 1POWER SWITCH PS8A SWTM-90006
TABLE 3 - REAR PANELS
MODEL QTY DESCRIPTION STOCK NO.
CODE100 N/A

10CODE100 & CODE100H Service Manual
BOOK-80010-01 | M3390.054
PSU ASSEMBLY
PARTS LIST
ITEM QTY DESCRIPTION STOCK NO.
3 1 3 POLE IEC FULSED MAILS INLET SKTM-90002
5 1 MAINS TRANSFORMER REF. TABLE 1
8 1 POWER AMP PCB PCBA-90008
11 1 SPEAKER OUTPUT PCB PCBA-90032
14 1 BRIDGE PCB PCBA-90031
21 2 MAINS INLET FUSE MXAP TO FIT SKTM-90002 REF. TABLE 5
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
A A
B B
C C
D D
SHEET 3 OF 3
DRAWN
CHECKED
QA
MFG
APPROVED
MPoderys 03/03/2020
DWG NO
MD116D100-10-00 FOR SERVICE MANUAL
TITLE
SIZE
D
SCALE
REV
1
3
1
21
2
14
1
5
1
8
1
11
1

11CODE100 & CODE100H Service Manual
BOOK-80010-01 | M3390.054
FRONT PANEL FUNCTIONS
1. USB
Connect via USB to use CODE as a DAW
interface, to play tracks from your music
library, to get rmware updates and
control via MIDI.
To get CODE rmware updates:
hp://my.marshall.com/Downloads
Follow this link to quickly and easily keep
your CODE amplier’s rmware up to date.
2. INPUT
Use this jack socket to connect your
guitar to the amplier. Use a good quality
screened/shielded guitar cable to help
prevent noise interference.
3. GAIN
Controls the amount of gain introduced to
a preset. The higher the gain, the harder
the preamp is driven.
4. BASS
Turning the bass control will adjust the
warmth and low-end depth of your sound.
5. MIDDLE
Adjusting the middle control will vary the
amount of body in your sound by boosting
or cutting midrange frequencies.
6. TREBLE
Increasing the treble will make your sound
brighter and more cutting. Turning the
treble down will decrease tonal edge and
make the sound softer.
7. VOLUME
Controls the volume level within a selected
preset.
Because gain, bass, middle, treble &
volume are stored as part of a preset,
these panel tone controls only become
active when they are used.
8. MASTER
Controls the overall volume level of your
CODE amplier.
9. PRESET
A preset is a combination of preamp,
power amp & speaker models, with tonal
settings and FX: chorus, anger, tremolo,
delay etc, stored to a single location within
your CODE amplier’s memory.
10. EDIT
Use the EDIT selector to deep edit a
Preset. Push the EDIT selector to preview
the stored gain, bass, middle, treble &
volume settings.
11. F/C
Use this jack socket to connect the CODE
footcontroller.
12. AUX INPUT
Use this dedicated mini-jack socket to
connect an external music player to
practice with or jam along to music.
13. HEADPHONE OUTPUT
Use this mini-jack socket to connect
headphones for ‘silent’ practice. This can
also be used as a line out.
14. ON/OFF
This is the mains power on/off switch.
1
2
3 4 5 6
15 16 17 18 19 20
7810 13 1412
21 23 22 119

12CODE100 & CODE100H Service Manual
BOOK-80010-01 | M3390.054
FRONT PANEL FUNCTIONS (CONTINUED)
15. PRE FX
This is where you will nd FX that would
typically plug into a conventional amplier
between the guitar and the amplier’s
input. These FX would typically be in pedal
form, and also known as ‘stompboxes’.
16. AMP
AMP is short for preamp. MST modelling
faithfully recreates classic and modern
Marshall valve tones as well as other
famous valve amp tones. Each AMP model
creates an authentic preamp setting. The
MST preamp models are classied into
three groups: clean, crunch & overdrive.
17. MOD
MOD is short for Modulation. Modulation
FX in a conventional setup can be in
stompbox or rack form and often connect
via amplier’s FX loop.
18. DEL
DEL is short for delay. Delay FX in a
conventional setup can be in stompbox
or rack form and often connect via an
amplier’s FX loop. When you select DEL
the switch’s LED will remain lit red for two
seconds before ashing to indicate the
current delay tempo.
19. REV
REV is short for reverb. Reverb FX in a
conventional amplier setup can be in
stompbox form, rack form or integrated
within an amplier.
20. POWER
This is the section of a conventional
amplier that provides power to drive
the speaker(s). The power valves are an
integral part of how an all-valve amplier
sounds. MST modelling faithfully recreates
the four valve power amps models in
CODE.
21. CAB
CAB is short for speaker cabinet. A cab’s
speaker conguration and its size play
a signicant role in the overall sound
produced by the whole amplier setup.
The MST modelled speaker cabinets
in your CODE amplier are faithful
recreations of classic Marshall cabs.
22. EXIT/STORE
While on any screen pressing EXIT/STORE
returns you to the main preset screen.
Press and hold EXIT/STORE while on any
screen to QUICK STORE your edited
settings. Your edited settings will store
over the current preset and the display will
return you to the main preset screen.
23. DISPLAY
The display screen shows a preset’s name,
number, parameter settings and the tuner
display.
1
2
3 4 5 6
15 16 17 18 19 20
7810 13 1412
21 23 22 119

13CODE100 & CODE100H Service Manual
BOOK-80010-01 | M3390.054
FRONT PANEL PCB
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
D D
C C
B B
A A
1 1
50W-100W FRONT PANEL
CODE100-60-02-V3 3
13/02/2017CODE100-60-02-V3.SchDoc
TITLE
DWG. No.
Date:File:
ISS Sheet
of
C MARSHALL AMPLIFICATION PLC
TEL [phone] FAX [phone]
DENBIGH ROAD, BLETCHLEY, MILTON KEYNES, MK1 1DQ.
CODE100-60-02-V3
DWG. No.
DIMENSIONS IN
TOLERANCE (UNLESS OTHERWISE STATED)
MODEL
mm
CODE 50/100
MATERIAL
MATERIAL THICKNESS
DRAWN
CHECKED
APPROVED
SA
?
?
DATE
DATE
DATE
16.6.14
?
?
ISS ECO NUMBER DATE
HOLE DIA = +/-
? ? ?
DIMENSIONAL = +/-
Cannot open file C:\altium files\Templates\logo.JPG
DGND_FP
P0
P1
P2
P3
P4
GAIN
BASS
MIDDLE
TREBLE
VOLUME
CH1 CH2
PROGRAM
TAP
UI_SPI_CS_SW
S/L 1
CLK INH 15
CLK 2
SI 10
A11
B12
C13
D14
E3
F4
G5
H6
QH
9
QH
7
VCC
16
GND 8
IC3
74HC165D
DGND_FP
DGND_FP
FX
LOOP
DAMPING
REVERB
UI_SPI_SCK
DGND_FP
OE
13
RCLK
12
SER
14
SRCLR
10
SRCLK
11
QA 15
QB 1
QC 2
QD 3
QE 4
QF 5
QG 6
QH 7
QH' 9
VCC 16
GND
8
IC2
74HC595
DGND_FP
+3V3_FP
DGND_FP
+3V3_FP
+3V3_FP
+3V3_FP
+3V3_FP
R25
10R
R30
100R
R31
100R
R32
100R
R33
100R
R34
100R
C1
100n
C2
100n
R24
10k
R10
10k
R12
10k
R14
10k
R16
10k
R18
10k
R20
10k
R22
10k
SW1
SW2
SW3 SW4 SW5 SW6 SW7 SW8
UI_SPI_SCK
UI_SPI_MOSI
R1 220R
R2 220R
R3 220R
R4 220R
R5 220R
R6 220R
R7 220R
R8 220R
DGND_FP
C8 100n
C9 100n
C10
100n
C13
100n
C11
100n
CW VR1:1
10kB
VR1:2
10kB
CW VR2:1
10kB
VR2:2
10kB
CW VR3:1
10kB
VR3:2
10kB
CW VR4:1
10kB
VR4:2
10kB
CW VR5:1
10kB
VR5:2
10kB
UI_SPI_CS_LRD
UI_SPI_CS_LGN/EN2SW
UI_SPI_MISO
ENC2_A/LCD_RSENC2_B/LCD_E
UI_SPI_CS_LCD
VR6:3
B100k
UI_LCD_A0 R35
10k
DGND_FP
R23 220R
BT_LED
Rd LED1
Rd LED2
Rd LED3
Rd LED4
Rd LED5
Rd LED6
Rd LED7
Rd LED8
Bl
LED16
MASTER
CW
VR6:1
B100k
CW
VR6:2
B100k
CN1:9
CN1:1 CN1:2
CN1:3 CN1:4
CN1:5
CN1:6
CN1:7
CN1:8
CN1:10
FC_TX
FC_RX
HPHONES
PA_MUTE
DGND_FP
P0
P1
P2
P3
P4
DGND_FP
ENC2_A/LCD_RS
ENC2_B/LCD_E
ENC1_A
ENC1_B
ENC1_SW
UI_SPI_MISO
UI_SPI_MOSI
UI_SPI_CS_SW
UI_SPI_SCK
UI_SPI_CS_LGN/EN2SW
BT_LED
UI_LCD_A0
UI_SPI_CS_LRD
DGND_FP
DGND_FP
+3V3_FP
+3V3_FP
FC_TX
FC_RX
PA_MUTE
HPHONES
CN2:1
CN2:2
CN2:3
CN2:4
CN2:5
CN2:6
CN2:7
CN2:8
CN2:9
CN2:10
CN2:11
CN2:12
CN2:13
CN2:14
CN2:15
CN2:16
CN2:17
CN2:18
CN2:19
CN2:20
CN2:21
CN2:22
CN2:23
CN2:24
CN2:25
CN2:26
CN2:27
CN2:28
CN2:29
CN2:30
DGND_FP
UI_SPI_CS_LCD
+3V3_FP
+
35V
C4
4.7u
R13
10k
R11
10k
C5
100n
C3
100n
DGND_FP
+3V3_FP
C6
100n
R9
10k
DGND_FP
COM
B A
SHD
ENC2:1
ENC2:2
R36
10k
R29
10k
C12
100n
C7
100n
DGND_FP
+3V3_FP
ENC1_AENC1_B
C14
NF
R37
NF
DGND_FP
ENC1_SW
COM
B A
SHD
ENC1:1
ENC1:2
CN3:1
CN3:2
CN3:3
CN3:4
CN3:5
CN3:6
CN3:7
CN3:8
UI_SPI_MOSI
UI_SPI_SCK
DGND_FP
+3V3_FP
DGND_FP
R28 10R
UI_LCD_A0
C15
100n
R15
100k
+3V3_FP
DGND_FP
DGND_FP
DGND_FP DGND_FP
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
D D
C C
B B
A A
1 1
50W-100W FRONT PANEL
CODE100-60-02-V3 3
13/02/2017CODE100-60-02-V3.SchDoc
TITLE
DWG. No.
Date:File:
ISS Sheet
of
C MARSHALL AMPLIFICATION PLC
TEL [phone] FAX [phone]
DENBIGH ROAD, BLETCHLEY, MILTON KEYNES, MK1 1DQ.
CODE100-60-02-V3
DWG. No.
DIMENSIONS IN
TOLERANCE (UNLESS OTHERWISE STATED)
MODEL
mm
CODE 50/100
MATERIAL
MATERIAL THICKNESS
DRAWN
CHECKED
APPROVED
SA
?
?
DATE
DATE
DATE
16.6.14
?
?
ISS ECO NUMBER DATE
HOLE DIA = +/-
? ? ?
DIMENSIONAL = +/-
Cannot open file C:\altium files\Templates\logo.JPG
DGND_FP
P0
P1
P2
P3
P4
GAIN
BASS
MIDDLE
TREBLE
VOLUME
CH1 CH2
PROGRAM
TAP
UI_SPI_CS_SW
S/L 1
CLK INH 15
CLK 2
SI 10
A11
B12
C13
D14
E3
F4
G5
H6
QH
9
QH
7
VCC
16
GND 8
IC3
74HC165D
DGND_FP
DGND_FP
FX
LOOP
DAMPING
REVERB
UI_SPI_SCK
DGND_FP
OE
13
RCLK
12
SER
14
SRCLR
10
SRCLK
11
QA 15
QB 1
QC 2
QD 3
QE 4
QF 5
QG 6
QH 7
QH' 9
VCC 16
GND
8
IC2
74HC595
DGND_FP
+3V3_FP
DGND_FP
+3V3_FP
+3V3_FP
+3V3_FP
+3V3_FP
R25
10R
R30
100R
R31
100R
R32
100R
R33
100R
R34
100R
C1
100n
C2
100n
R24
10k
R10
10k
R12
10k
R14
10k
R16
10k
R18
10k
R20
10k
R22
10k
SW1
SW2
SW3 SW4 SW5 SW6 SW7 SW8
UI_SPI_SCK
UI_SPI_MOSI
R1 220R
R2 220R
R3 220R
R4 220R
R5 220R
R6 220R
R7 220R
R8 220R
DGND_FP
C8 100n
C9 100n
C10
100n
C13
100n
C11
100n
CW VR1:1
10kB
VR1:2
10kB
CW VR2:1
10kB
VR2:2
10kB
CW VR3:1
10kB
VR3:2
10kB
CW VR4:1
10kB
VR4:2
10kB
CW VR5:1
10kB
VR5:2
10kB
UI_SPI_CS_LRD
UI_SPI_CS_LGN/EN2SW
UI_SPI_MISO
ENC2_A/LCD_RSENC2_B/LCD_E
UI_SPI_CS_LCD
VR6:3
B100k
UI_LCD_A0 R35
10k
DGND_FP
R23 220R
BT_LED
Rd LED1
Rd LED2
Rd LED3
Rd LED4
Rd LED5
Rd LED6
Rd LED7
Rd LED8
Bl
LED16
MASTER
CW
VR6:1
B100k
CW
VR6:2
B100k
CN1:9
CN1:1 CN1:2
CN1:3 CN1:4
CN1:5
CN1:6
CN1:7
CN1:8
CN1:10
FC_TX
FC_RX
HPHONES
PA_MUTE
DGND_FP
P0
P1
P2
P3
P4
DGND_FP
ENC2_A/LCD_RS
ENC2_B/LCD_E
ENC1_A
ENC1_B
ENC1_SW
UI_SPI_MISO
UI_SPI_MOSI
UI_SPI_CS_SW
UI_SPI_SCK
UI_SPI_CS_LGN/EN2SW
BT_LED
UI_LCD_A0
UI_SPI_CS_LRD
DGND_FP
DGND_FP
+3V3_FP
+3V3_FP
FC_TX
FC_RX
PA_MUTE
HPHONES
CN2:1
CN2:2
CN2:3
CN2:4
CN2:5
CN2:6
CN2:7
CN2:8
CN2:9
CN2:10
CN2:11
CN2:12
CN2:13
CN2:14
CN2:15
CN2:16
CN2:17
CN2:18
CN2:19
CN2:20
CN2:21
CN2:22
CN2:23
CN2:24
CN2:25
CN2:26
CN2:27
CN2:28
CN2:29
CN2:30
DGND_FP
UI_SPI_CS_LCD
+3V3_FP
+
35V
C4
4.7u
R13
10k
R11
10k
C5
100n
C3
100n
DGND_FP
+3V3_FP
C6
100n
R9
10k
DGND_FP
COM
B A
SHD
ENC2:1
ENC2:2
R36
10k
R29
10k
C12
100n
C7
100n
DGND_FP
+3V3_FP
ENC1_AENC1_B
C14
NF
R37
NF
DGND_FP
ENC1_SW
COM
B A
SHD
ENC1:1
ENC1:2
CN3:1
CN3:2
CN3:3
CN3:4
CN3:5
CN3:6
CN3:7
CN3:8
UI_SPI_MOSI
UI_SPI_SCK
DGND_FP
+3V3_FP
DGND_FP
R28 10R
UI_LCD_A0
C15
100n
R15
100k
+3V3_FP
DGND_FP
DGND_FP
DGND_FP DGND_FP
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
D D
C C
B B
A A
1 1
50W-100W FRONT PANEL
CODE100-60-02-V3 3
13/02/2017CODE100-60-02-V3.SchDoc
TITLE
DWG. No.
Date:File:
ISS Sheet
of
C MARSHALL AMPLIFICATION PLC
TEL [phone] FAX [phone]
DENBIGH ROAD, BLETCHLEY, MILTON KEYNES, MK1 1DQ.
CODE100-60-02-V3
DWG. No.
DIMENSIONS IN
TOLERANCE (UNLESS OTHERWISE STATED)
MODEL
mm
CODE 50/100
MATERIAL
MATERIAL THICKNESS
DRAWN
CHECKED
APPROVED
SA
?
?
DATE
DATE
DATE
16.6.14
?
?
ISS ECO NUMBER DATE
HOLE DIA = +/-
? ? ?
DIMENSIONAL = +/-
Cannot open file C:\altium files\Templates\logo.JPG
DGND_FP
P0
P1
P2
P3
P4
GAIN
BASS
MIDDLE
TREBLE
VOLUME
CH1 CH2
PROGRAM
TAP
UI_SPI_CS_SW
S/L 1
CLK INH 15
CLK 2
SI 10
A11
B12
C13
D14
E3
F4
G5
H6
QH
9
QH
7
VCC
16
GND 8
IC3
74HC165D
DGND_FP
DGND_FP
FX
LOOP
DAMPING
REVERB
UI_SPI_SCK
DGND_FP
OE
13
RCLK
12
SER
14
SRCLR
10
SRCLK
11
QA 15
QB 1
QC 2
QD 3
QE 4
QF 5
QG 6
QH 7
QH' 9
VCC 16
GND
8
IC2
74HC595
DGND_FP
+3V3_FP
DGND_FP
+3V3_FP
+3V3_FP
+3V3_FP
+3V3_FP
R25
10R
R30
100R
R31
100R
R32
100R
R33
100R
R34
100R
C1
100n
C2
100n
R24
10k
R10
10k
R12
10k
R14
10k
R16
10k
R18
10k
R20
10k
R22
10k
SW1
SW2
SW3 SW4 SW5 SW6 SW7 SW8
UI_SPI_SCK
UI_SPI_MOSI
R1 220R
R2 220R
R3 220R
R4 220R
R5 220R
R6 220R
R7 220R
R8 220R
DGND_FP
C8 100n
C9 100n
C10
100n
C13
100n
C11
100n
CW VR1:1
10kB
VR1:2
10kB
CW VR2:1
10kB
VR2:2
10kB
CW VR3:1
10kB
VR3:2
10kB
CW VR4:1
10kB
VR4:2
10kB
CW VR5:1
10kB
VR5:2
10kB
UI_SPI_CS_LRD
UI_SPI_CS_LGN/EN2SW
UI_SPI_MISO
ENC2_A/LCD_RSENC2_B/LCD_E
UI_SPI_CS_LCD
VR6:3
B100k
UI_LCD_A0 R35
10k
DGND_FP
R23 220R
BT_LED
Rd LED1
Rd LED2
Rd LED3
Rd LED4
Rd LED5
Rd LED6
Rd LED7
Rd LED8
Bl
LED16
MASTER
CW
VR6:1
B100k
CW
VR6:2
B100k
CN1:9
CN1:1 CN1:2
CN1:3 CN1:4
CN1:5
CN1:6
CN1:7
CN1:8
CN1:10
FC_TX
FC_RX
HPHONES
PA_MUTE
DGND_FP
P0
P1
P2
P3
P4
DGND_FP
ENC2_A/LCD_RS
ENC2_B/LCD_E
ENC1_A
ENC1_B
ENC1_SW
UI_SPI_MISO
UI_SPI_MOSI
UI_SPI_CS_SW
UI_SPI_SCK
UI_SPI_CS_LGN/EN2SW
BT_LED
UI_LCD_A0
UI_SPI_CS_LRD
DGND_FP
DGND_FP
+3V3_FP
+3V3_FP
FC_TX
FC_RX
PA_MUTE
HPHONES
CN2:1
CN2:2
CN2:3
CN2:4
CN2:5
CN2:6
CN2:7
CN2:8
CN2:9
CN2:10
CN2:11
CN2:12
CN2:13
CN2:14
CN2:15
CN2:16
CN2:17
CN2:18
CN2:19
CN2:20
CN2:21
CN2:22
CN2:23
CN2:24
CN2:25
CN2:26
CN2:27
CN2:28
CN2:29
CN2:30
DGND_FP
UI_SPI_CS_LCD
+3V3_FP
+
35V
C4
4.7u
R13
10k
R11
10k
C5
100n
C3
100n
DGND_FP
+3V3_FP
C6
100n
R9
10k
DGND_FP
COM
B A
SHD
ENC2:1
ENC2:2
R36
10k
R29
10k
C12
100n
C7
100n
DGND_FP
+3V3_FP
ENC1_AENC1_B
C14
NF
R37
NF
DGND_FP
ENC1_SW
COM
B A
SHD
ENC1:1
ENC1:2
CN3:1
CN3:2
CN3:3
CN3:4
CN3:5
CN3:6
CN3:7
CN3:8
UI_SPI_MOSI
UI_SPI_SCK
DGND_FP
+3V3_FP
DGND_FP
R28 10R
UI_LCD_A0
C15
100n
R15
100k
+3V3_FP
DGND_FP
DGND_FP
DGND_FP DGND_FP
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
D D
C C
B B
A A
1 1
50W-100W FRONT PANEL
CODE100-60-02-V3 3
13/02/2017CODE100-60-02-V3.SchDoc
TITLE
DWG. No.
Date:File:
ISS Sheet
of
C MARSHALL AMPLIFICATION PLC
TEL [phone] FAX [phone]
DENBIGH ROAD, BLETCHLEY, MILTON KEYNES, MK1 1DQ.
CODE100-60-02-V3
DWG. No.
DIMENSIONS IN
TOLERANCE (UNLESS OTHERWISE STATED)
MODEL
mm
CODE 50/100
MATERIAL
MATERIAL THICKNESS
DRAWN
CHECKED
APPROVED
SA
?
?
DATE
DATE
DATE
16.6.14
?
?
ISS ECO NUMBER DATE
HOLE DIA = +/-
? ? ?
DIMENSIONAL = +/-
Cannot open file C:\altium files\Templates\logo.JPG
DGND_FP
P0
P1
P2
P3
P4
GAIN
BASS
MIDDLE
TREBLE
VOLUME
CH1 CH2
PROGRAM
TAP
UI_SPI_CS_SW
S/L 1
CLK INH 15
CLK 2
SI 10
A11
B12
C13
D14
E3
F4
G5
H6
QH
9
QH
7
VCC
16
GND 8
IC3
74HC165D
DGND_FP
DGND_FP
FX
LOOP
DAMPING
REVERB
UI_SPI_SCK
DGND_FP
OE
13
RCLK
12
SER
14
SRCLR
10
SRCLK
11
QA 15
QB 1
QC 2
QD 3
QE 4
QF 5
QG 6
QH 7
QH' 9
VCC 16
GND
8
IC2
74HC595
DGND_FP
+3V3_FP
DGND_FP
+3V3_FP
+3V3_FP
+3V3_FP
+3V3_FP
R25
10R
R30
100R
R31
100R
R32
100R
R33
100R
R34
100R
C1
100n
C2
100n
R24
10k
R10
10k
R12
10k
R14
10k
R16
10k
R18
10k
R20
10k
R22
10k
SW1
SW2
SW3 SW4 SW5 SW6 SW7 SW8
UI_SPI_SCK
UI_SPI_MOSI
R1 220R
R2 220R
R3 220R
R4 220R
R5 220R
R6 220R
R7 220R
R8 220R
DGND_FP
C8 100n
C9 100n
C10
100n
C13
100n
C11
100n
CW VR1:1
10kB
VR1:2
10kB
CW VR2:1
10kB
VR2:2
10kB
CW VR3:1
10kB
VR3:2
10kB
CW VR4:1
10kB
VR4:2
10kB
CW VR5:1
10kB
VR5:2
10kB
UI_SPI_CS_LRD
UI_SPI_CS_LGN/EN2SW
UI_SPI_MISO
ENC2_A/LCD_RSENC2_B/LCD_E
UI_SPI_CS_LCD
VR6:3
B100k
UI_LCD_A0 R35
10k
DGND_FP
R23 220R
BT_LED
Rd LED1
Rd LED2
Rd LED3
Rd LED4
Rd LED5
Rd LED6
Rd LED7
Rd LED8
Bl
LED16
MASTER
CW
VR6:1
B100k
CW
VR6:2
B100k
CN1:9
CN1:1 CN1:2
CN1:3 CN1:4
CN1:5
CN1:6
CN1:7
CN1:8
CN1:10
FC_TX
FC_RX
HPHONES
PA_MUTE
DGND_FP
P0
P1
P2
P3
P4
DGND_FP
ENC2_A/LCD_RS
ENC2_B/LCD_E
ENC1_A
ENC1_B
ENC1_SW
UI_SPI_MISO
UI_SPI_MOSI
UI_SPI_CS_SW
UI_SPI_SCK
UI_SPI_CS_LGN/EN2SW
BT_LED
UI_LCD_A0
UI_SPI_CS_LRD
DGND_FP
DGND_FP
+3V3_FP
+3V3_FP
FC_TX
FC_RX
PA_MUTE
HPHONES
CN2:1
CN2:2
CN2:3
CN2:4
CN2:5
CN2:6
CN2:7
CN2:8
CN2:9
CN2:10
CN2:11
CN2:12
CN2:13
CN2:14
CN2:15
CN2:16
CN2:17
CN2:18
CN2:19
CN2:20
CN2:21
CN2:22
CN2:23
CN2:24
CN2:25
CN2:26
CN2:27
CN2:28
CN2:29
CN2:30
DGND_FP
UI_SPI_CS_LCD
+3V3_FP
+
35V
C4
4.7u
R13
10k
R11
10k
C5
100n
C3
100n
DGND_FP
+3V3_FP
C6
100n
R9
10k
DGND_FP
COM
B A
SHD
ENC2:1
ENC2:2
R36
10k
R29
10k
C12
100n
C7
100n
DGND_FP
+3V3_FP
ENC1_AENC1_B
C14
NF
R37
NF
DGND_FP
ENC1_SW
COM
B A
SHD
ENC1:1
ENC1:2
CN3:1
CN3:2
CN3:3
CN3:4
CN3:5
CN3:6
CN3:7
CN3:8
UI_SPI_MOSI
UI_SPI_SCK
DGND_FP
+3V3_FP
DGND_FP
R28 10R
UI_LCD_A0
C15
100n
R15
100k
+3V3_FP
DGND_FP
DGND_FP
DGND_FP DGND_FP
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
D D
C C
B B
A A
1 1
50W-100W FRONT PANEL
CODE100-60-02-V3 3
13/02/2017CODE100-60-02-V3.SchDoc
TITLE
DWG. No.
Date:File:
ISS Sheet
of
C MARSHALL AMPLIFICATION PLC
TEL [phone] FAX [phone]
DENBIGH ROAD, BLETCHLEY, MILTON KEYNES, MK1 1DQ.
CODE100-60-02-V3
DWG. No.
DIMENSIONS IN
TOLERANCE (UNLESS OTHERWISE STATED)
MODEL
mm
CODE 50/100
MATERIAL
MATERIAL THICKNESS
DRAWN
CHECKED
APPROVED
SA
?
?
DATE
DATE
DATE
16.6.14
?
?
ISS ECO NUMBER DATE
HOLE DIA = +/-
? ? ?
DIMENSIONAL = +/-
Cannot open file C:\altium files\Templates\logo.JPG
DGND_FP
P0
P1
P2
P3
P4
GAIN
BASS
MIDDLE
TREBLE
VOLUME
CH1 CH2
PROGRAM
TAP
UI_SPI_CS_SW
S/L 1
CLK INH 15
CLK 2
SI 10
A11
B12
C13
D14
E3
F4
G5
H6
QH
9
QH
7
VCC
16
GND 8
IC3
74HC165D
DGND_FP
DGND_FP
FX
LOOP
DAMPING
REVERB
UI_SPI_SCK
DGND_FP
OE
13
RCLK
12
SER
14
SRCLR
10
SRCLK
11
QA 15
QB 1
QC 2
QD 3
QE 4
QF 5
QG 6
QH 7
QH' 9
VCC 16
GND
8
IC2
74HC595
DGND_FP
+3V3_FP
DGND_FP
+3V3_FP
+3V3_FP
+3V3_FP
+3V3_FP
R25
10R
R30
100R
R31
100R
R32
100R
R33
100R
R34
100R
C1
100n
C2
100n
R24
10k
R10
10k
R12
10k
R14
10k
R16
10k
R18
10k
R20
10k
R22
10k
SW1
SW2
SW3 SW4 SW5 SW6 SW7 SW8
UI_SPI_SCK
UI_SPI_MOSI
R1 220R
R2 220R
R3 220R
R4 220R
R5 220R
R6 220R
R7 220R
R8 220R
DGND_FP
C8 100n
C9 100n
C10
100n
C13
100n
C11
100n
CW VR1:1
10kB
VR1:2
10kB
CW VR2:1
10kB
VR2:2
10kB
CW VR3:1
10kB
VR3:2
10kB
CW VR4:1
10kB
VR4:2
10kB
CW VR5:1
10kB
VR5:2
10kB
UI_SPI_CS_LRD
UI_SPI_CS_LGN/EN2SW
UI_SPI_MISO
ENC2_A/LCD_RSENC2_B/LCD_E
UI_SPI_CS_LCD
VR6:3
B100k
UI_LCD_A0 R35
10k
DGND_FP
R23 220R
BT_LED
Rd LED1
Rd LED2
Rd LED3
Rd LED4
Rd LED5
Rd LED6
Rd LED7
Rd LED8
Bl
LED16
MASTER
CW
VR6:1
B100k
CW
VR6:2
B100k
CN1:9
CN1:1 CN1:2
CN1:3 CN1:4
CN1:5
CN1:6
CN1:7
CN1:8
CN1:10
FC_TX
FC_RX
HPHONES
PA_MUTE
DGND_FP
P0
P1
P2
P3
P4
DGND_FP
ENC2_A/LCD_RS
ENC2_B/LCD_E
ENC1_A
ENC1_B
ENC1_SW
UI_SPI_MISO
UI_SPI_MOSI
UI_SPI_CS_SW
UI_SPI_SCK
UI_SPI_CS_LGN/EN2SW
BT_LED
UI_LCD_A0
UI_SPI_CS_LRD
DGND_FP
DGND_FP
+3V3_FP
+3V3_FP
FC_TX
FC_RX
PA_MUTE
HPHONES
CN2:1
CN2:2
CN2:3
CN2:4
CN2:5
CN2:6
CN2:7
CN2:8
CN2:9
CN2:10
CN2:11
CN2:12
CN2:13
CN2:14
CN2:15
CN2:16
CN2:17
CN2:18
CN2:19
CN2:20
CN2:21
CN2:22
CN2:23
CN2:24
CN2:25
CN2:26
CN2:27
CN2:28
CN2:29
CN2:30
DGND_FP
UI_SPI_CS_LCD
+3V3_FP
+
35V
C4
4.7u
R13
10k
R11
10k
C5
100n
C3
100n
DGND_FP
+3V3_FP
C6
100n
R9
10k
DGND_FP
COM
B A
SHD
ENC2:1
ENC2:2
R36
10k
R29
10k
C12
100n
C7
100n
DGND_FP
+3V3_FP
ENC1_AENC1_B
C14
NF
R37
NF
DGND_FP
ENC1_SW
COM
B A
SHD
ENC1:1
ENC1:2
CN3:1
CN3:2
CN3:3
CN3:4
CN3:5
CN3:6
CN3:7
CN3:8
UI_SPI_MOSI
UI_SPI_SCK
DGND_FP
+3V3_FP
DGND_FP
R28 10R
UI_LCD_A0
C15
100n
R15
100k
+3V3_FP
DGND_FP
DGND_FP
DGND_FP DGND_FP
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
D D
C C
B B
A A
1 1
50W-100W FRONT PANEL
CODE100-60-02-V3 3
13/02/2017CODE100-60-02-V3.SchDoc
TITLE
DWG. No.
Date:File:
ISS Sheet
of
C MARSHALL AMPLIFICATION PLC
TEL [phone] FAX [phone]
DENBIGH ROAD, BLETCHLEY, MILTON KEYNES, MK1 1DQ.
CODE100-60-02-V3
DWG. No.
DIMENSIONS IN
TOLERANCE (UNLESS OTHERWISE STATED)
MODEL
mm
CODE 50/100
MATERIAL
MATERIAL THICKNESS
DRAWN
CHECKED
APPROVED
SA
?
?
DATE
DATE
DATE
16.6.14
?
?
ISS ECO NUMBER DATE
HOLE DIA = +/-
? ? ?
DIMENSIONAL = +/-
Cannot open file C:\altium files\Templates\logo.JPG
DGND_FP
P0
P1
P2
P3
P4
GAIN
BASS
MIDDLE
TREBLE
VOLUME
CH1 CH2
PROGRAM
TAP
UI_SPI_CS_SW
S/L 1
CLK INH 15
CLK 2
SI 10
A11
B12
C13
D14
E3
F4
G5
H6
QH
9
QH
7
VCC
16
GND 8
IC3
74HC165D
DGND_FP
DGND_FP
FX
LOOP
DAMPING
REVERB
UI_SPI_SCK
DGND_FP
OE
13
RCLK
12
SER
14
SRCLR
10
SRCLK
11
QA 15
QB 1
QC 2
QD 3
QE 4
QF 5
QG 6
QH 7
QH' 9
VCC 16
GND
8
IC2
74HC595
DGND_FP
+3V3_FP
DGND_FP
+3V3_FP
+3V3_FP
+3V3_FP
+3V3_FP
R25
10R
R30
100R
R31
100R
R32
100R
R33
100R
R34
100R
C1
100n
C2
100n
R24
10k
R10
10k
R12
10k
R14
10k
R16
10k
R18
10k
R20
10k
R22
10k
SW1
SW2
SW3 SW4 SW5 SW6 SW7 SW8
UI_SPI_SCK
UI_SPI_MOSI
R1 220R
R2 220R
R3 220R
R4 220R
R5 220R
R6 220R
R7 220R
R8 220R
DGND_FP
C8 100n
C9 100n
C10
100n
C13
100n
C11
100n
CW VR1:1
10kB
VR1:2
10kB
CW VR2:1
10kB
VR2:2
10kB
CW VR3:1
10kB
VR3:2
10kB
CW VR4:1
10kB
VR4:2
10kB
CW VR5:1
10kB
VR5:2
10kB
UI_SPI_CS_LRD
UI_SPI_CS_LGN/EN2SW
UI_SPI_MISO
ENC2_A/LCD_RSENC2_B/LCD_E
UI_SPI_CS_LCD
VR6:3
B100k
UI_LCD_A0 R35
10k
DGND_FP
R23 220R
BT_LED
Rd LED1
Rd LED2
Rd LED3
Rd LED4
Rd LED5
Rd LED6
Rd LED7
Rd LED8
Bl
LED16
MASTER
CW
VR6:1
B100k
CW
VR6:2
B100k
CN1:9
CN1:1 CN1:2
CN1:3 CN1:4
CN1:5
CN1:6
CN1:7
CN1:8
CN1:10
FC_TX
FC_RX
HPHONES
PA_MUTE
DGND_FP
P0
P1
P2
P3
P4
DGND_FP
ENC2_A/LCD_RS
ENC2_B/LCD_E
ENC1_A
ENC1_B
ENC1_SW
UI_SPI_MISO
UI_SPI_MOSI
UI_SPI_CS_SW
UI_SPI_SCK
UI_SPI_CS_LGN/EN2SW
BT_LED
UI_LCD_A0
UI_SPI_CS_LRD
DGND_FP
DGND_FP
+3V3_FP
+3V3_FP
FC_TX
FC_RX
PA_MUTE
HPHONES
CN2:1
CN2:2
CN2:3
CN2:4
CN2:5
CN2:6
CN2:7
CN2:8
CN2:9
CN2:10
CN2:11
CN2:12
CN2:13
CN2:14
CN2:15
CN2:16
CN2:17
CN2:18
CN2:19
CN2:20
CN2:21
CN2:22
CN2:23
CN2:24
CN2:25
CN2:26
CN2:27
CN2:28
CN2:29
CN2:30
DGND_FP
UI_SPI_CS_LCD
+3V3_FP
+
35V
C4
4.7u
R13
10k
R11
10k
C5
100n
C3
100n
DGND_FP
+3V3_FP
C6
100n
R9
10k
DGND_FP
COM
B A
SHD
ENC2:1
ENC2:2
R36
10k
R29
10k
C12
100n
C7
100n
DGND_FP
+3V3_FP
ENC1_AENC1_B
C14
NF
R37
NF
DGND_FP
ENC1_SW
COM
B A
SHD
ENC1:1
ENC1:2
CN3:1
CN3:2
CN3:3
CN3:4
CN3:5
CN3:6
CN3:7
CN3:8
UI_SPI_MOSI
UI_SPI_SCK
DGND_FP
+3V3_FP
DGND_FP
R28 10R
UI_LCD_A0
C15
100n
R15
100k
+3V3_FP
DGND_FP
DGND_FP
DGND_FP DGND_FP
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
D D
C C
B B
A A
1 1
50W-100W FRONT PANEL
CODE100-60-02-V3 3
13/02/2017CODE100-60-02-V3.SchDoc
TITLE
DWG. No.
Date:File:
ISS Sheet
of
C MARSHALL AMPLIFICATION PLC
TEL [phone] FAX [phone]
DENBIGH ROAD, BLETCHLEY, MILTON KEYNES, MK1 1DQ.
CODE100-60-02-V3
DWG. No.
DIMENSIONS IN
TOLERANCE (UNLESS OTHERWISE STATED)
MODEL
mm
CODE 50/100
MATERIAL
MATERIAL THICKNESS
DRAWN
CHECKED
APPROVED
SA
?
?
DATE
DATE
DATE
16.6.14
?
?
ISS ECO NUMBER DATE
HOLE DIA = +/-
? ? ?
DIMENSIONAL = +/-
Cannot open file C:\altium files\Templates\logo.JPG
DGND_FP
P0
P1
P2
P3
P4
GAIN
BASS
MIDDLE
TREBLE
VOLUME
CH1 CH2
PROGRAM
TAP
UI_SPI_CS_SW
S/L 1
CLK INH 15
CLK 2
SI 10
A11
B12
C13
D14
E3
F4
G5
H6
QH
9
QH
7
VCC
16
GND 8
IC3
74HC165D
DGND_FP
DGND_FP
FX
LOOP
DAMPING
REVERB
UI_SPI_SCK
DGND_FP
OE
13
RCLK
12
SER
14
SRCLR
10
SRCLK
11
QA 15
QB 1
QC 2
QD 3
QE 4
QF 5
QG 6
QH 7
QH' 9
VCC 16
GND
8
IC2
74HC595
DGND_FP
+3V3_FP
DGND_FP
+3V3_FP
+3V3_FP
+3V3_FP
+3V3_FP
R25
10R
R30
100R
R31
100R
R32
100R
R33
100R
R34
100R
C1
100n
C2
100n
R24
10k
R10
10k
R12
10k
R14
10k
R16
10k
R18
10k
R20
10k
R22
10k
SW1
SW2
SW3 SW4 SW5 SW6 SW7 SW8
UI_SPI_SCK
UI_SPI_MOSI
R1 220R
R2 220R
R3 220R
R4 220R
R5 220R
R6 220R
R7 220R
R8 220R
DGND_FP
C8 100n
C9 100n
C10
100n
C13
100n
C11
100n
CW VR1:1
10kB
VR1:2
10kB
CW VR2:1
10kB
VR2:2
10kB
CW VR3:1
10kB
VR3:2
10kB
CW VR4:1
10kB
VR4:2
10kB
CW VR5:1
10kB
VR5:2
10kB
UI_SPI_CS_LRD
UI_SPI_CS_LGN/EN2SW
UI_SPI_MISO
ENC2_A/LCD_RSENC2_B/LCD_E
UI_SPI_CS_LCD
VR6:3
B100k
UI_LCD_A0 R35
10k
DGND_FP
R23 220R
BT_LED
Rd LED1
Rd LED2
Rd LED3
Rd LED4
Rd LED5
Rd LED6
Rd LED7
Rd LED8
Bl
LED16
MASTER
CW
VR6:1
B100k
CW
VR6:2
B100k
CN1:9
CN1:1 CN1:2
CN1:3 CN1:4
CN1:5
CN1:6
CN1:7
CN1:8
CN1:10
FC_TX
FC_RX
HPHONES
PA_MUTE
DGND_FP
P0
P1
P2
P3
P4
DGND_FP
ENC2_A/LCD_RS
ENC2_B/LCD_E
ENC1_A
ENC1_B
ENC1_SW
UI_SPI_MISO
UI_SPI_MOSI
UI_SPI_CS_SW
UI_SPI_SCK
UI_SPI_CS_LGN/EN2SW
BT_LED
UI_LCD_A0
UI_SPI_CS_LRD
DGND_FP
DGND_FP
+3V3_FP
+3V3_FP
FC_TX
FC_RX
PA_MUTE
HPHONES
CN2:1
CN2:2
CN2:3
CN2:4
CN2:5
CN2:6
CN2:7
CN2:8
CN2:9
CN2:10
CN2:11
CN2:12
CN2:13
CN2:14
CN2:15
CN2:16
CN2:17
CN2:18
CN2:19
CN2:20
CN2:21
CN2:22
CN2:23
CN2:24
CN2:25
CN2:26
CN2:27
CN2:28
CN2:29
CN2:30
DGND_FP
UI_SPI_CS_LCD
+3V3_FP
+
35V
C4
4.7u
R13
10k
R11
10k
C5
100n
C3
100n
DGND_FP
+3V3_FP
C6
100n
R9
10k
DGND_FP
COM
B A
SHD
ENC2:1
ENC2:2
R36
10k
R29
10k
C12
100n
C7
100n
DGND_FP
+3V3_FP
ENC1_AENC1_B
C14
NF
R37
NF
DGND_FP
ENC1_SW
COM
B A
SHD
ENC1:1
ENC1:2
CN3:1
CN3:2
CN3:3
CN3:4
CN3:5
CN3:6
CN3:7
CN3:8
UI_SPI_MOSI
UI_SPI_SCK
DGND_FP
+3V3_FP
DGND_FP
R28 10R
UI_LCD_A0
C15
100n
R15
100k
+3V3_FP
DGND_FP
DGND_FP
DGND_FP DGND_FP

14CODE100 & CODE100H Service Manual
BOOK-80010-01 | M3390.054
FRONT PANEL PCB (CONTINUED)
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
D D
C C
B B
A A
1 1
50W-100W FRONT PANEL
CODE100-60-02-V3 3
13/02/2017CODE100-60-02-V3.SchDoc
TITLE
DWG. No.
Date:File:
ISS Sheet
of
C MARSHALL AMPLIFICATION PLC
TEL [phone] FAX [phone]
DENBIGH ROAD, BLETCHLEY, MILTON KEYNES, MK1 1DQ.
CODE100-60-02-V3
DWG. No.
DIMENSIONS IN
TOLERANCE (UNLESS OTHERWISE STATED)
MODEL
mm
CODE 50/100
MATERIAL
MATERIAL THICKNESS
DRAWN
CHECKED
APPROVED
SA
?
?
DATE
DATE
DATE
16.6.14
?
?
ISS ECO NUMBER DATE
HOLE DIA = +/-
? ? ?
DIMENSIONAL = +/-
Cannot open file C:\altium files\Templates\logo.JPG
DGND_FP
P0
P1
P2
P3
P4
GAIN
BASS
MIDDLE
TREBLE
VOLUME
CH1 CH2
PROGRAM
TAP
UI_SPI_CS_SW
S/L 1
CLK INH 15
CLK 2
SI 10
A11
B12
C13
D14
E3
F4
G5
H6
QH
9
QH
7
VCC
16
GND 8
IC3
74HC165D
DGND_FP
DGND_FP
FX
LOOP
DAMPING
REVERB
UI_SPI_SCK
DGND_FP
OE
13
RCLK
12
SER
14
SRCLR
10
SRCLK
11
QA 15
QB 1
QC 2
QD 3
QE 4
QF 5
QG 6
QH 7
QH' 9
VCC 16
GND
8
IC2
74HC595
DGND_FP
+3V3_FP
DGND_FP
+3V3_FP
+3V3_FP
+3V3_FP
+3V3_FP
R25
10R
R30
100R
R31
100R
R32
100R
R33
100R
R34
100R
C1
100n
C2
100n
R24
10k
R10
10k
R12
10k
R14
10k
R16
10k
R18
10k
R20
10k
R22
10k
SW1
SW2
SW3 SW4 SW5 SW6 SW7 SW8
UI_SPI_SCK
UI_SPI_MOSI
R1 220R
R2 220R
R3 220R
R4 220R
R5 220R
R6 220R
R7 220R
R8 220R
DGND_FP
C8 100n
C9 100n
C10
100n
C13
100n
C11
100n
CW VR1:1
10kB
VR1:2
10kB
CW VR2:1
10kB
VR2:2
10kB
CW VR3:1
10kB
VR3:2
10kB
CW VR4:1
10kB
VR4:2
10kB
CW VR5:1
10kB
VR5:2
10kB
UI_SPI_CS_LRD
UI_SPI_CS_LGN/EN2SW
UI_SPI_MISO
ENC2_A/LCD_RSENC2_B/LCD_E
UI_SPI_CS_LCD
VR6:3
B100k
UI_LCD_A0 R35
10k
DGND_FP
R23 220R
BT_LED
Rd LED1
Rd LED2
Rd LED3
Rd LED4
Rd LED5
Rd LED6
Rd LED7
Rd LED8
Bl
LED16
MASTER
CW
VR6:1
B100k
CW
VR6:2
B100k
CN1:9
CN1:1 CN1:2
CN1:3 CN1:4
CN1:5
CN1:6
CN1:7
CN1:8
CN1:10
FC_TX
FC_RX
HPHONES
PA_MUTE
DGND_FP
P0
P1
P2
P3
P4
DGND_FP
ENC2_A/LCD_RS
ENC2_B/LCD_E
ENC1_A
ENC1_B
ENC1_SW
UI_SPI_MISO
UI_SPI_MOSI
UI_SPI_CS_SW
UI_SPI_SCK
UI_SPI_CS_LGN/EN2SW
BT_LED
UI_LCD_A0
UI_SPI_CS_LRD
DGND_FP
DGND_FP
+3V3_FP
+3V3_FP
FC_TX
FC_RX
PA_MUTE
HPHONES
CN2:1
CN2:2
CN2:3
CN2:4
CN2:5
CN2:6
CN2:7
CN2:8
CN2:9
CN2:10
CN2:11
CN2:12
CN2:13
CN2:14
CN2:15
CN2:16
CN2:17
CN2:18
CN2:19
CN2:20
CN2:21
CN2:22
CN2:23
CN2:24
CN2:25
CN2:26
CN2:27
CN2:28
CN2:29
CN2:30
DGND_FP
UI_SPI_CS_LCD
+3V3_FP
+
35V
C4
4.7u
R13
10k
R11
10k
C5
100n
C3
100n
DGND_FP
+3V3_FP
C6
100n
R9
10k
DGND_FP
COM
B A
SHD
ENC2:1
ENC2:2
R36
10k
R29
10k
C12
100n
C7
100n
DGND_FP
+3V3_FP
ENC1_AENC1_B
C14
NF
R37
NF
DGND_FP
ENC1_SW
COM
B A
SHD
ENC1:1
ENC1:2
CN3:1
CN3:2
CN3:3
CN3:4
CN3:5
CN3:6
CN3:7
CN3:8
UI_SPI_MOSI
UI_SPI_SCK
DGND_FP
+3V3_FP
DGND_FP
R28 10R
UI_LCD_A0
C15
100n
R15
100k
+3V3_FP
DGND_FP
DGND_FP
DGND_FP DGND_FP

15CODE100 & CODE100H Service Manual
BOOK-80010-01 | M3390.054
REAR PANEL FUNCTIONS
24. MAINS INPUT
Connects the amplier to the mains power
supply.
25. FX LOOP
Connect external FX pedals or a signal
processor here. The FX loop is post DSP in
the signal chain.
26. SPEAKER OUTPUT (CODE100H ONLY)
Connect a speaker cabinet here.
IMPORTANT - Do NOT connect a speaker
cabinet of less than 8 Ohm, and never use
CODE100H without a speaker cabinet
connected.
2624 25

16CODE100 & CODE100H Service Manual
BOOK-80010-01 | M3390.054
REAR PANEL PCB
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
D D
C C
B B
A A
1 1
CODE 100 REAR
CODE100-63-02-V2 3
13/02/2017CODE100-63-02-V3.SchDoc
TITLE
DWG. No.
Date:File:
ISS Sheet
of
C MARSHALL AMPLIFICATION PLC
TEL [phone] FAX [phone]
DENBIGH ROAD, BLETCHLEY, MILTON KEYNES, MK1 1DQ.
CODE100-63-02-V2
DWG. No.
DIMENSIONS IN
TOLERANCE (UNLESS OTHERWISE STATED)
MODEL
mm
CODE 100
MATERIAL
MATERIAL THICKNESS
DRAWN
CHECKED
APPROVED
A.C.S.
?
DATE
DATE
DATE
22.09.2016
?
ISS ECO NUMBER DATE
HOLE DIA = +/-
DIMENSIONAL = +/-
Cannot open file C:\altium files\Templates\logo.JPG
CN5:1
JS1
JS3
JS2
CN4
R14
10k
R15
100k
C24
100n
CN5:2
C18
100n
PA SEND
PA RETURN
+
50V
C21
10u
L2 G471
C22
470p
C23
470p
L3 G471
L4 G471
CN5:3
CN13
CN14
EXT SPK
CN2
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
D D
C C
B B
A A
1 1
CODE 100 REAR
CODE100-63-02-V2 3
13/02/2017CODE100-63-02-V3.SchDoc
TITLE
DWG. No.
Date:File:
ISS Sheet
of
C MARSHALL AMPLIFICATION PLC
TEL [phone] FAX [phone]
DENBIGH ROAD, BLETCHLEY, MILTON KEYNES, MK1 1DQ.
CODE100-63-02-V2
DWG. No.
DIMENSIONS IN
TOLERANCE (UNLESS OTHERWISE STATED)
MODEL
mm
CODE 100
MATERIAL
MATERIAL THICKNESS
DRAWN
CHECKED
APPROVED
A.C.S.
?
DATE
DATE
DATE
22.09.2016
?
ISS ECO NUMBER DATE
HOLE DIA = +/-
DIMENSIONAL = +/-
Cannot open file C:\altium files\Templates\logo.JPG
CN5:1
JS1
JS3
JS2
CN4
R14
10k
R15
100k
C24
100n
CN5:2
C18
100n
PA SEND
PA RETURN
+
50V
C21
10u
L2 G471
C22
470p
C23
470p
L3 G471
L4 G471
CN5:3
CN13
CN14
EXT SPK
CN2
2624 25

17CODE100 & CODE100H Service Manual
BOOK-80010-01 | M3390.054
MAINS INPUT DETAILS & BRIDGE
1
1
2
2
3
3
4
4
D D
C C
B B
A A
1 1
Mains Input Detail
CODE100-70-02-V2 1
16/08/2017CODE100-70-02-V2.SchDoc
TITLE
DWG. No.
Date:File:
ISS Sheet
of
C MARSHALL AMPLIFICATION PLC
TEL [phone] FAX [phone]
DENBIGH ROAD, BLETCHLEY, MILTON KEYNES, MK1 1DQ.
CODE100-70-02-V2
DWG. No.
DIMENSIONS IN
TOLERANCE (UNLESS OTHERWISE STATED)
MODEL
mm
CODE100
MATERIAL
MATERIAL THICKNESS
DRAWN
CHECKED
APPROVED
ACS
?
?
DATE
DATE
DATE
13-02-17
?
?
ISS ECO NUMBER DATE
HOLE DIA = +/-
1 ? ?
DIMENSIONAL = +/-
Cannot open file C:\altium files\Templates\logo.JPG
MT1MT2
CN1
CN3
CN4
CN2
INTEGRATED
MAINS FUSE
I.E.C.
INLET
!
!
LEN
230V0219011.6MXAP
02193.15MXAP 120V
100V
130V
MAINS FUSE
16-08-17
POWER
SWITCH
(See table)
02193.15MXAP
02193.15MXAP
!
230V
120V
100V
0V
21V
21V
6.5V
0V
0V
!
(SWTM-90006)
DONGNAM PS8A
(SKTM-90002)
DONGNAN ST-A01-004L-W-7260
CN1
CN3
CN4
CN2
CN1
CN3
CN4
CN2
100V Wiring 120V Wiring
(TXMA-90053)
MD116D 100W GT 16 09
MAINS
TRANSFORMER
To CN8
To CN6
To CN7
To CN9
To CN10
To LIN PSU PCB
1
1
2
2
3
3
4
4
D D
C C
B B
A A
1 1
Mains Helper PCB
CODE100-64-02-V1 1
13/02/2017CODE100-64-02-V1.SchDoc
TITLE
DWG. No.
Date:File:
ISS Sheet
of
C MARSHALL AMPLIFICATION PLC
TEL [phone] FAX [phone]
DENBIGH ROAD, BLETCHLEY, MILTON KEYNES, MK1 1DQ.
CODE100-64-02-V1
DWG. No.
DIMENSIONS IN
TOLERANCE (UNLESS OTHERWISE STATED)
MODEL
mm
CODE100
MATERIAL
MATERIAL THICKNESS
DRAWN
CHECKED
APPROVED
ACS
?
?
DATE
DATE
DATE
13-02-17
?
?
ISS ECO NUMBER DATE
HOLE DIA = +/-
1 ? ?
DIMENSIONAL = +/-
Cannot open file C:\altium files\Templates\logo.JPG
MT1
MT2
CN1
CN3
CN4
CN2
!
SAFETY CRITICAL COMPONENT
REPLACE ONLY WITH SAME TYPE
& RATING

18CODE100 & CODE100H Service Manual
BOOK-80010-01 | M3390.054
POWER SUPPLY UNIT & OUTPUT PCB
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
D D
C C
B B
A A
1 1
100W PSU + OUTPUT
CODE100-62-02-V3 4
02/11/2017CODE100-62-02-V4.SchDoc
TITLE
DWG. No.
Date:File:
ISS Sheet
of
C MARSHALL AMPLIFICATION PLC
TEL [phone] FAX [phone]
DENBIGH ROAD, BLETCHLEY, MILTON KEYNES, MK1 1DQ.
CODE100-62-02-V3
DWG. No.
DIMENSIONS IN
TOLERANCE (UNLESS OTHERWISE STATED)
MODEL
mm
CODE 100
MATERIAL
MATERIAL THICKNESS
DRAWN
CHECKED
APPROVED
ACS
?
DATE
DATE
DATE
07.02.17
?
ISS ECO NUMBER DATE
HOLE DIA = +/-
4Value Change R21 02-11-17
DIMENSIONAL = +/-
Cannot open file C:\altium files\Templates\logo.JPG
IN1P
2
IN1M
3
SGND
19
IN2P
22
IN2M
21
VDDA 20
VSSA
18
STABI
12
PROT
7
VSSD
17
VDDP2
16
VSSP2
13
OUT2 14
BOOT2 15
BOOT1 9
OUT1 10
VSSP1 11
VDDP1 8
MODE
23
OSC
1
IC1
R9
30k C12
100p
C16
100n
C17
100n
C14
100n
C1 100n
C13
470n
AGND
C6
15n
C25
220p
C26
220p
+24V -24V
C5 220n
C7 220n
MT1
MT4
MT2
SEND
CN15:2
CN15:3
CN15:1
HS1
C3
15n
CN12:1
CN12:2
CN12:3
CN12:4
C10
220p
C11
220p
+24V -24V
CN3
CN1
TDA8950
35V
+
C55
100u
PVCC
35V
+
C57
4700u
CN8
T500mAE250V
FS2
CN9
CN10
AGND
D5 MRA4005T3
PA+
C2 220n
C4 220n
AGND
AGND
AGND
+3V3
C30
100n
PA+
PA-
AGNDDGND
+3V3
AGND
TO DSP PCB
CN12:5
AGND
C35 100n
C34 100n
+24V
-24V
+24V
+24V
-24V
-24V
~
~
+-
BR2
2KBP10M
GND
I O
O
IC3
LM1117-3.3
NF
GND
I O
O
IC4
NF
CN16:1
CN16:2
AGND
NF
+
C37
3V3BT
3V3BT
AGND
NF
C36
PA-
R3
10k
R4
10k
PVCC/2
C39
100n
AGND
PVCC
OI
ADJ
IC2
LM317T
R27
220R
R28
2k7
C43
100n
MT3
BTGND
R8
5k6
PA_MUTE
R7
5k6
R12
1k0
5V6
D10
AGND
C27
100n
TR1
847
TR3
847
PVCC
R19
10k
C8
680n
C9
100n
C20
100n
R6
10R
R1
10R
R2
10R
R13
10R
R5
4K7
R10
39R
AGND
16V
+
C29
2200u
+
35V
C42
47u
R25
1k0
3V9
D1
ZM4734A
R29
39R
R16
39R
R30
39R
FS1
T3.15AL250V
CN6
CN7
L1
22u
L5
22u
LL4148
D7
CN17
CN18
R20
47k
R18
10k
R31
4k7
LL4148
D8
PVCC
PVCC/2
PVCC/2
IC6:1
NE5532
IC6:2
NE5532
V+V-
IC6:3
NE5532
C44
100n
C80
1u0
C81
1u0
R80
10k
R81
10k
R82
10k
R83
10k
R84
330R
IC5:2
NE5532
V+V-
IC5:3
NE5532
C31
330p
C45
330p
AGND
35V
+
C58
4700u
C56
1u0
C63
1u0
+24V
-24V
35V
+
C59
4700u
35V
+
C60
4700u
AGND
AGND
AGND
~
~
+-
BR1
KBU1003
IC5:1
NE5532
PA_MUTE
CN11:1
CN11:2
CN11:3
CN11:4
PVCC
AGND
FROM HEADPHONE PCB
C32
1u0
R26
10k SEND
C49
100n
PVCC/2
C46
10u
+
50V
C47
22u
+
50V
C48
22u
R22
10k
C19
680n
C50
100n
16V
+
C28
2200u
C15
1u0
C51
100n
R11
1k0
35V
+
C40
47u
50V
+
C41
10u
R86
5k6
R87
5k6
R88
5k6
R89
5k6
R69
1k0
R70
10k
R71
100k
C52
1u0
AGND
R85
330R
TO REAR BOARD
C54
100n
C53
100n
D2:1
BAV99
D2:2
BAV99
D3:1
BAV99
D3:2
BAV99
NF
+
C33
!
SAFETY CRITICAL COMPONENT
REPLACE ONLY WITH SAME TYPE
& RATING
!
!
R21
2k2
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
D D
C C
B B
A A
1 1
100W PSU + OUTPUT
CODE100-62-02-V3 4
02/11/2017CODE100-62-02-V4.SchDoc
TITLE
DWG. No.
Date:File:
ISS Sheet
of
C MARSHALL AMPLIFICATION PLC
TEL [phone] FAX [phone]
DENBIGH ROAD, BLETCHLEY, MILTON KEYNES, MK1 1DQ.
CODE100-62-02-V3
DWG. No.
DIMENSIONS IN
TOLERANCE (UNLESS OTHERWISE STATED)
MODEL
mm
CODE 100
MATERIAL
MATERIAL THICKNESS
DRAWN
CHECKED
APPROVED
ACS
?
DATE
DATE
DATE
07.02.17
?
ISS ECO NUMBER DATE
HOLE DIA = +/-
4Value Change R21 02-11-17
DIMENSIONAL = +/-
Cannot open file C:\altium files\Templates\logo.JPG
IN1P
2
IN1M
3
SGND
19
IN2P
22
IN2M
21
VDDA 20
VSSA
18
STABI
12
PROT
7
VSSD
17
VDDP2
16
VSSP2
13
OUT2 14
BOOT2 15
BOOT1 9
OUT1 10
VSSP1 11
VDDP1 8
MODE
23
OSC
1
IC1
R9
30k C12
100p
C16
100n
C17
100n
C14
100n
C1 100n
C13
470n
AGND
C6
15n
C25
220p
C26
220p
+24V -24V
C5 220n
C7 220n
MT1
MT4
MT2
SEND
CN15:2
CN15:3
CN15:1
HS1
C3
15n
CN12:1
CN12:2
CN12:3
CN12:4
C10
220p
C11
220p
+24V -24V
CN3
CN1
TDA8950
35V
+
C55
100u
PVCC
35V
+
C57
4700u
CN8
T500mAE250V
FS2
CN9
CN10
AGND
D5 MRA4005T3
PA+
C2 220n
C4 220n
AGND
AGND
AGND
+3V3
C30
100n
PA+
PA-
AGNDDGND
+3V3
AGND
TO DSP PCB
CN12:5
AGND
C35 100n
C34 100n
+24V
-24V
+24V
+24V
-24V
-24V
~
~
+-
BR2
2KBP10M
GND
I O
O
IC3
LM1117-3.3
NF
GND
I O
O
IC4
NF
CN16:1
CN16:2
AGND
NF
+
C37
3V3BT
3V3BT
AGND
NF
C36
PA-
R3
10k
R4
10k
PVCC/2
C39
100n
AGND
PVCC
OI
ADJ
IC2
LM317T
R27
220R
R28
2k7
C43
100n
MT3
BTGND
R8
5k6
PA_MUTE
R7
5k6
R12
1k0
5V6
D10
AGND
C27
100n
TR1
847
TR3
847
PVCC
R19
10k
C8
680n
C9
100n
C20
100n
R6
10R
R1
10R
R2
10R
R13
10R
R5
4K7
R10
39R
AGND
16V
+
C29
2200u
+
35V
C42
47u
R25
1k0
3V9
D1
ZM4734A
R29
39R
R16
39R
R30
39R
FS1
T3.15AL250V
CN6
CN7
L1
22u
L5
22u
LL4148
D7
CN17
CN18
R20
47k
R18
10k
R31
4k7
LL4148
D8
PVCC
PVCC/2
PVCC/2
IC6:1
NE5532
IC6:2
NE5532
V+V-
IC6:3
NE5532
C44
100n
C80
1u0
C81
1u0
R80
10k
R81
10k
R82
10k
R83
10k
R84
330R
IC5:2
NE5532
V+V-
IC5:3
NE5532
C31
330p
C45
330p
AGND
35V
+
C58
4700u
C56
1u0
C63
1u0
+24V
-24V
35V
+
C59
4700u
35V
+
C60
4700u
AGND
AGND
AGND
~
~
+-
BR1
KBU1003
IC5:1
NE5532
PA_MUTE
CN11:1
CN11:2
CN11:3
CN11:4
PVCC
AGND
FROM HEADPHONE PCB
C32
1u0
R26
10k SEND
C49
100n
PVCC/2
C46
10u
+
50V
C47
22u
+
50V
C48
22u
R22
10k
C19
680n
C50
100n
16V
+
C28
2200u
C15
1u0
C51
100n
R11
1k0
35V
+
C40
47u
50V
+
C41
10u
R86
5k6
R87
5k6
R88
5k6
R89
5k6
R69
1k0
R70
10k
R71
100k
C52
1u0
AGND
R85
330R
TO REAR BOARD
C54
100n
C53
100n
D2:1
BAV99
D2:2
BAV99
D3:1
BAV99
D3:2
BAV99
NF
+
C33
!
SAFETY CRITICAL COMPONENT
REPLACE ONLY WITH SAME TYPE
& RATING
!
!
R21
2k2
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
D D
C C
B B
A A
1 1
100W PSU + OUTPUT
CODE100-62-02-V3 4
02/11/2017CODE100-62-02-V4.SchDoc
TITLE
DWG. No.
Date:File:
ISS Sheet
of
C MARSHALL AMPLIFICATION PLC
TEL [phone] FAX [phone]
DENBIGH ROAD, BLETCHLEY, MILTON KEYNES, MK1 1DQ.
CODE100-62-02-V3
DWG. No.
DIMENSIONS IN
TOLERANCE (UNLESS OTHERWISE STATED)
MODEL
mm
CODE 100
MATERIAL
MATERIAL THICKNESS
DRAWN
CHECKED
APPROVED
ACS
?
DATE
DATE
DATE
07.02.17
?
ISS ECO NUMBER DATE
HOLE DIA = +/-
4Value Change R21 02-11-17
DIMENSIONAL = +/-
Cannot open file C:\altium files\Templates\logo.JPG
IN1P
2
IN1M
3
SGND
19
IN2P
22
IN2M
21
VDDA 20
VSSA
18
STABI
12
PROT
7
VSSD
17
VDDP2
16
VSSP2
13
OUT2 14
BOOT2 15
BOOT1 9
OUT1 10
VSSP1 11
VDDP1 8
MODE
23
OSC
1
IC1
R9
30k C12
100p
C16
100n
C17
100n
C14
100n
C1 100n
C13
470n
AGND
C6
15n
C25
220p
C26
220p
+24V -24V
C5 220n
C7 220n
MT1
MT4
MT2
SEND
CN15:2
CN15:3
CN15:1
HS1
C3
15n
CN12:1
CN12:2
CN12:3
CN12:4
C10
220p
C11
220p
+24V -24V
CN3
CN1
TDA8950
35V
+
C55
100u
PVCC
35V
+
C57
4700u
CN8
T500mAE250V
FS2
CN9
CN10
AGND
D5 MRA4005T3
PA+
C2 220n
C4 220n
AGND
AGND
AGND
+3V3
C30
100n
PA+
PA-
AGNDDGND
+3V3
AGND
TO DSP PCB
CN12:5
AGND
C35 100n
C34 100n
+24V
-24V
+24V
+24V
-24V
-24V
~
~
+-
BR2
2KBP10M
GND
I O
O
IC3
LM1117-3.3
NF
GND
I O
O
IC4
NF
CN16:1
CN16:2
AGND
NF
+
C37
3V3BT
3V3BT
AGND
NF
C36
PA-
R3
10k
R4
10k
PVCC/2
C39
100n
AGND
PVCC
OI
ADJ
IC2
LM317T
R27
220R
R28
2k7
C43
100n
MT3
BTGND
R8
5k6
PA_MUTE
R7
5k6
R12
1k0
5V6
D10
AGND
C27
100n
TR1
847
TR3
847
PVCC
R19
10k
C8
680n
C9
100n
C20
100n
R6
10R
R1
10R
R2
10R
R13
10R
R5
4K7
R10
39R
AGND
16V
+
C29
2200u
+
35V
C42
47u
R25
1k0
3V9
D1
ZM4734A
R29
39R
R16
39R
R30
39R
FS1
T3.15AL250V
CN6
CN7
L1
22u
L5
22u
LL4148
D7
CN17
CN18
R20
47k
R18
10k
R31
4k7
LL4148
D8
PVCC
PVCC/2
PVCC/2
IC6:1
NE5532
IC6:2
NE5532
V+V-
IC6:3
NE5532
C44
100n
C80
1u0
C81
1u0
R80
10k
R81
10k
R82
10k
R83
10k
R84
330R
IC5:2
NE5532
V+V-
IC5:3
NE5532
C31
330p
C45
330p
AGND
35V
+
C58
4700u
C56
1u0
C63
1u0
+24V
-24V
35V
+
C59
4700u
35V
+
C60
4700u
AGND
AGND
AGND
~
~
+-
BR1
KBU1003
IC5:1
NE5532
PA_MUTE
CN11:1
CN11:2
CN11:3
CN11:4
PVCC
AGND
FROM HEADPHONE PCB
C32
1u0
R26
10k SEND
C49
100n
PVCC/2
C46
10u
+
50V
C47
22u
+
50V
C48
22u
R22
10k
C19
680n
C50
100n
16V
+
C28
2200u
C15
1u0
C51
100n
R11
1k0
35V
+
C40
47u
50V
+
C41
10u
R86
5k6
R87
5k6
R88
5k6
R89
5k6
R69
1k0
R70
10k
R71
100k
C52
1u0
AGND
R85
330R
TO REAR BOARD
C54
100n
C53
100n
D2:1
BAV99
D2:2
BAV99
D3:1
BAV99
D3:2
BAV99
NF
+
C33
!
SAFETY CRITICAL COMPONENT
REPLACE ONLY WITH SAME TYPE
& RATING
!
!
R21
2k2
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
D D
C C
B B
A A
1 1
100W PSU + OUTPUT
CODE100-62-02-V3 4
02/11/2017CODE100-62-02-V4.SchDoc
TITLE
DWG. No.
Date:File:
ISS Sheet
of
C MARSHALL AMPLIFICATION PLC
TEL [phone] FAX [phone]
DENBIGH ROAD, BLETCHLEY, MILTON KEYNES, MK1 1DQ.
CODE100-62-02-V3
DWG. No.
DIMENSIONS IN
TOLERANCE (UNLESS OTHERWISE STATED)
MODEL
mm
CODE 100
MATERIAL
MATERIAL THICKNESS
DRAWN
CHECKED
APPROVED
ACS
?
DATE
DATE
DATE
07.02.17
?
ISS ECO NUMBER DATE
HOLE DIA = +/-
4Value Change R21 02-11-17
DIMENSIONAL = +/-
Cannot open file C:\altium files\Templates\logo.JPG
IN1P
2
IN1M
3
SGND
19
IN2P
22
IN2M
21
VDDA 20
VSSA
18
STABI
12
PROT
7
VSSD
17
VDDP2
16
VSSP2
13
OUT2 14
BOOT2 15
BOOT1 9
OUT1 10
VSSP1 11
VDDP1 8
MODE
23
OSC
1
IC1
R9
30k C12
100p
C16
100n
C17
100n
C14
100n
C1 100n
C13
470n
AGND
C6
15n
C25
220p
C26
220p
+24V -24V
C5 220n
C7 220n
MT1
MT4
MT2
SEND
CN15:2
CN15:3
CN15:1
HS1
C3
15n
CN12:1
CN12:2
CN12:3
CN12:4
C10
220p
C11
220p
+24V -24V
CN3
CN1
TDA8950
35V
+
C55
100u
PVCC
35V
+
C57
4700u
CN8
T500mAE250V
FS2
CN9
CN10
AGND
D5 MRA4005T3
PA+
C2 220n
C4 220n
AGND
AGND
AGND
+3V3
C30
100n
PA+
PA-
AGND
DGND
+3V3
AGND
TO DSP PCB
CN12:5
AGND
C35 100n
C34 100n
+24V
-24V
+24V
+24V
-24V
-24V
~
~
+-
BR2
2KBP10M
GND
I O
O
IC3
LM1117-3.3
NF
GND
I O
O
IC4
NF
CN16:1
CN16:2
AGND
NF
+
C37
3V3BT
3V3BT
AGND
NF
C36
PA-
R3
10k
R4
10k
PVCC/2
C39
100n
AGND
PVCC
OI
ADJ
IC2
LM317T
R27
220R
R28
2k7
C43
100n
MT3
BTGND
R8
5k6
PA_MUTE
R7
5k6
R12
1k0
5V6
D10
AGND
C27
100n
TR1
847
TR3
847
PVCC
R19
10k
C8
680n
C9
100n
C20
100n
R6
10R
R1
10R
R2
10R
R13
10R
R5
4K7
R10
39R
AGND
16V
+
C29
2200u
+
35V
C42
47u
R25
1k0
3V9
D1
ZM4734A
R29
39R
R16
39R
R30
39R
FS1
T3.15AL250V
CN6
CN7
L1
22u
L5
22u
LL4148
D7
CN17
CN18
R20
47k
R18
10k
R31
4k7
LL4148
D8
PVCC
PVCC/2
PVCC/2
IC6:1
NE5532
IC6:2
NE5532
V+V-
IC6:3
NE5532
C44
100n
C80
1u0
C81
1u0
R80
10k
R81
10k
R82
10k
R83
10k
R84
330R
IC5:2
NE5532
V+V-
IC5:3
NE5532
C31
330p
C45
330p
AGND
35V
+
C58
4700u
C56
1u0
C63
1u0
+24V
-24V
35V
+
C59
4700u
35V
+
C60
4700u
AGND
AGND
AGND
~
~
+-
BR1
KBU1003
IC5:1
NE5532
PA_MUTE
CN11:1
CN11:2
CN11:3
CN11:4
PVCC
AGND
FROM HEADPHONE PCB
C32
1u0
R26
10k SEND
C49
100n
PVCC/2
C46
10u
+
50V
C47
22u
+
50V
C48
22u
R22
10k
C19
680n
C50
100n
16V
+
C28
2200u
C15
1u0
C51
100n
R11
1k0
35V
+
C40
47u
50V
+
C41
10u
R86
5k6
R87
5k6
R88
5k6
R89
5k6
R69
1k0
R70
10k
R71
100k
C52
1u0
AGND
R85
330R
TO REAR BOARD
C54
100n
C53
100n
D2:1
BAV99
D2:2
BAV99
D3:1
BAV99
D3:2
BAV99
NF
+
C33
!
SAFETY CRITICAL COMPONENT
REPLACE ONLY WITH SAME TYPE
& RATING
!
!
R21
2k2
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
D D
C C
B B
A A
1 1
100W PSU + OUTPUT
CODE100-62-02-V3 4
02/11/2017CODE100-62-02-V4.SchDoc
TITLE
DWG. No.
Date:File:
ISS Sheet
of
C MARSHALL AMPLIFICATION PLC
TEL [phone] FAX [phone]
DENBIGH ROAD, BLETCHLEY, MILTON KEYNES, MK1 1DQ.
CODE100-62-02-V3
DWG. No.
DIMENSIONS IN
TOLERANCE (UNLESS OTHERWISE STATED)
MODEL
mm
CODE 100
MATERIAL
MATERIAL THICKNESS
DRAWN
CHECKED
APPROVED
ACS
?
DATE
DATE
DATE
07.02.17
?
ISS ECO NUMBER DATE
HOLE DIA = +/-
4Value Change R21 02-11-17
DIMENSIONAL = +/-
Cannot open file C:\altium files\Templates\logo.JPG
IN1P
2
IN1M
3
SGND
19
IN2P
22
IN2M
21
VDDA 20
VSSA
18
STABI
12
PROT
7
VSSD
17
VDDP2
16
VSSP2
13
OUT2 14
BOOT2 15
BOOT1 9
OUT1 10
VSSP1 11
VDDP1 8
MODE
23
OSC
1
IC1
R9
30k C12
100p
C16
100n
C17
100n
C14
100n
C1 100n
C13
470n
AGND
C6
15n
C25
220p
C26
220p
+24V -24V
C5 220n
C7 220n
MT1
MT4
MT2
SEND
CN15:2
CN15:3
CN15:1
HS1
C3
15n
CN12:1
CN12:2
CN12:3
CN12:4
C10
220p
C11
220p
+24V -24V
CN3
CN1
TDA8950
35V
+
C55
100u
PVCC
35V
+
C57
4700u
CN8
T500mAE250V
FS2
CN9
CN10
AGND
D5 MRA4005T3
PA+
C2 220n
C4 220n
AGND
AGND
AGND
+3V3
C30
100n
PA+
PA-
AGNDDGND
+3V3
AGND
TO DSP PCB
CN12:5
AGND
C35 100n
C34 100n
+24V
-24V
+24V
+24V
-24V
-24V
~
~
+-
BR2
2KBP10M
GND
I O
O
IC3
LM1117-3.3
NF
GND
I O
O
IC4
NF
CN16:1
CN16:2
AGND
NF
+
C37
3V3BT
3V3BT
AGND
NF
C36
PA-
R3
10k
R4
10k
PVCC/2
C39
100n
AGND
PVCC
OI
ADJ
IC2
LM317T
R27
220R
R28
2k7
C43
100n
MT3
BTGND
R8
5k6
PA_MUTE
R7
5k6
R12
1k0
5V6
D10
AGND
C27
100n
TR1
847
TR3
847
PVCC
R19
10k
C8
680n
C9
100n
C20
100n
R6
10R
R1
10R
R2
10R
R13
10R
R5
4K7
R10
39R
AGND
16V
+
C29
2200u
+
35V
C42
47u
R25
1k0
3V9
D1
ZM4734A
R29
39R
R16
39R
R30
39R
FS1
T3.15AL250V
CN6
CN7
L1
22u
L5
22u
LL4148
D7
CN17
CN18
R20
47k
R18
10k
R31
4k7
LL4148
D8
PVCC
PVCC/2
PVCC/2
IC6:1
NE5532
IC6:2
NE5532
V+V-
IC6:3
NE5532
C44
100n
C80
1u0
C81
1u0
R80
10k
R81
10k
R82
10k
R83
10k
R84
330R
IC5:2
NE5532
V+V-
IC5:3
NE5532
C31
330p
C45
330p
AGND
35V
+
C58
4700u
C56
1u0
C63
1u0
+24V
-24V
35V
+
C59
4700u
35V
+
C60
4700u
AGND
AGND
AGND
~
~
+-
BR1
KBU1003
IC5:1
NE5532
PA_MUTE
CN11:1
CN11:2
CN11:3
CN11:4
PVCC
AGND
FROM HEADPHONE PCB
C32
1u0
R26
10k SEND
C49
100n
PVCC/2
C46
10u
+
50V
C47
22u
+
50V
C48
22u
R22
10k
C19
680n
C50
100n
16V
+
C28
2200u
C15
1u0
C51
100n
R11
1k0
35V
+
C40
47u
50V
+
C41
10u
R86
5k6
R87
5k6
R88
5k6
R89
5k6
R69
1k0
R70
10k
R71
100k
C52
1u0
AGND
R85
330R
TO REAR BOARD
C54
100n
C53
100n
D2:1
BAV99
D2:2
BAV99
D3:1
BAV99
D3:2
BAV99
NF
+
C33
!
SAFETY CRITICAL COMPONENT
REPLACE ONLY WITH SAME TYPE
& RATING
!
!
R21
2k2
!
SAFETY CRITICAL COMPONENT
REPLACE ONLY WITH SAME TYPE
& RATING

19CODE100 & CODE100H Service Manual
BOOK-80010-01 | M3390.054
DIGITAL SIGNAL PROCESSOR PCB
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
D D
C C
B B
A A
1 1
DSP PCB
CODE-60-02-V8 8
13/02/2017CODE-60-02-V8.SchDoc
TITLE
DWG. No.
Date:File:
ISS Sheet
of
C MARSHALL AMPLIFICATION PLC
TEL [phone] FAX [phone]
DENBIGH ROAD, BLETCHLEY, MILTON KEYNES, MK1 1DQ.
CODE-60-02-V8
DWG. No.
DIMENSIONS IN
TOLERANCE (UNLESS OTHERWISE STATED)
MODEL
CODE 100
MATERIAL
MATERIAL THICKNESS
DRAWN
CHECKED
APPROVED
AC DATE
DATE
DATE
13.6.2016
ISS ECO NUMBER DATE
HOLE DIA = +/-
DIMENSIONAL = +/-
Cannot open file C:\altium files\Templates\logo.JPG
AD1 L02
AD2 L01
AD3 K01
AD4 J02
AD5 J01
AD6 H01
AD7 G01
AD8 N06
AD9 P06
AD10 P05
AD11 P04
AD12 P03
AD13 P02
AD14 P01
AD15 N01
CLKIN B04
RESET B10
CLK_CFG0
A01
TCK A04
TMSA03
TDI A05
TRST B05
EMUA08
TDO A07 FLAG0
F02
FLAG1
F01
CLKOUT/RSTOUT A06 FLAG2
F13
FLAG3
E14
XTAL A02
DAI_P15 (SD4A)
K14
DAI_P16 (SD4B)
J14
DAI_P17 (SD5A)
H14
DAI_P18 (SD5B)
H13
DAI_P19 (SCLK45)
G14
DAI_P20 (SFS45)
F14
SPICLK
B09
AD0 M01
SPIDS
A11
MISO
A10
MOSI
A09
BOOT_CFG0
C02
BOOT_CFG1
C01
ALE N02
WR M02
RD N03
DAI_P14 (SFS23)
L14 DAI_P13 (SCLK23)
M14 DAI_P12 (SD3B)
M13 DAI_P11 (SD3A)
P14 DAI_P10 (SD2B)
N14 DAI_P9 (SD2A)
P13 DAI_P8 (SFS1)
P12 DAI_P7 (SCLK1)
P11 DAI_P6 (SD1B)
P10 DAI_P5 (SD1A)
P09 DAI_P4 (SFS0)
N10 DAI_P3 (SCLK0)
P08 DAI_P2 (SD0B)
N08 DAI_P1 (SD0A)
P07
CLK_CFG1
B01
IC8:1
ADSP-21261SKBCZ150
VDDINT A12 VDDINT B11 VDDINT C14 VDDINT D14 VDDINT J13 VDDINT K02 VDDINT N04 VDDINT N07 VDDINT N11 VDDINT N12
VDDEXT B03 VDDEXT B08 VDDEXT G13 VDDEXT H02 VDDEXT N05 VDDEXT N09
VDDINT G02
AVDD B07
AVSS
B06
GND
A13
GND
A14
GND
B02
GND
B12
GND
B13
GND
B14
GND
F04
GND
F05
GND
F06
GND
F09
GND
F10
GND
F11
GND
C03
GND
C12
GND
C13
GND
D02
GND
D04
GND
D05
GND
D06
VDDINT D01
GND
D09
GND
D10
GND
D11
GND
D13
GND
E02
GND
E04
GND
E05
GND
E06
GND
E09
GND
E10
GND
E11
GND
E13
GND
J04
GND
J05
GND
J06
GND
J09
GND
J10
GND
J11
GND
K04
GND
K05
GND
K06
GND
K09
GND
K10
GND
K11
GND
K13
GND
L04
GND
L05
GND
L06
GND
L09
GND
L10
GND
L11
GND
L13
GND
M03
GND
M12
GND
N13
VDDINT E01
IC8:2 ADSP-21261SKBCZ150
A0
3
A1
4
A2
5
A3
6
A4
7
A5
16
A6
17
A7
18
A8
19
A9
20
A10
26
A11
27
A12
28
A13
29
A14
30
A15
38
A16
39
A17
40
A18
41
IO0 9
IO1 10
IO2 13
IO3 14
IO4 31
IO5 32
IO6 35
IO7 36
CE
8
WE
15
OE
37
VCC 11
VCC 33
VSS 12
VSS 34
IC5
CY7C1049DV33
OE
1
D0
2
D1
3
D2
4
D3
5
D4
6
D5
7
D6
8
D7
9
GND
10
LE
11
Q7 12
Q6 13
Q5 14
Q4 15
Q3 16
Q2 17
Q1 18
Q0 19
VCC 20
IC2
74LVC573
OE
1
D0
2
D1
3
D2
4
D3
5
D4
6
D5
7
D6
8
D7
9
GND
10
LE
11
Q7 12
Q6 13
Q5 14
Q4 15
Q3 16
Q2 17
Q1 18
Q0 19
VCC 20
IC7
74LVC573
AD0
AD1
AD2
AD3
AD4
AD5
AD6
AD7
AD8
AD9
AD10
AD11
AD12
AD13
AD14
AD15
RD
WR
ALE
DGND
DGND
ALE
ALE
AD0
AD1
AD2
AD3
AD4
AD5
AD6
AD7
AD8
AD9
AD10
AD11
AD12
AD13
AD14
AD15
C33
100n
C7
100n
DGND
DGND
3V3D
3V3D
A8
A9
A10
A11
A12
A13
A14
A15
A16
A17
A18
AD0
AD1
AD2
AD3
AD4
AD5
AD6
AD7
AD8
AD9
AD10
AD11
AD12
AD13
AD14
AD15
A8
A9
A10
A11
A12
A13
A14
A15
A16
A17
A18
RD
WR
DGND
C30
100n
C3
100n
DGND
DGND
C15
10n
C45
10n
C47
10n
C16
10n
C50
10n
C13
10n
C24
100n
C29
100n
C46
100n
C48
100n
C37
100n
C36
100n
C49
100n
C35
10n
C34
10n
C14
10n
C31
100n
C17
100n
C26
100n
3V3D
3V3D 1V2
1V2
C27
100n
C25
1n0
C18
10n
DGND
R8
10R
D1
SK12
RIN
1
LIN
2
VSS
3
VA
4
VD
5
DEM06
DEM17
SDTO 8
SDTI 9
LRCK 10
MCLK 11
BCLK 12
PDN 13
VCOM
14
LOUT 15
ROUT 16
IC4 AK4552
DSP_SPI1_NSS
DSP_SPI1_SCK
DSP_SPI1_MISO
DSP_SPI1_MOSI
DSP_SYNCH
DSP_FLASH
DSP_RESET
SDTO
SDTI
LRCK
MCLK
BCK
PDN
SDTO
SDTI
LRCK
MCLK
BCK
PDN
AGNDAGND
C23
100n
C10
100n
R4
10R
3V3A
DGND
C22
100n
C21
1u0
VCOM
CS
1
S0/SIO1
2
WP
3
GND 4
SI/SIO0
5
SCLK
6
HOLD
7
VCC 8
IC9
MX25L4006E 3V3D
DGND
C38
100n
DSP_FLASH
DSP_SPI1_MISO
DSP_SPI1_SCK
DSP_SPI1_MOSI
Y1
24.576MHz
C1
22p
C2
22p
DGND
DGND
DGND
EMU
TMS
TCK
TRST
TDI
TDO
CN3:1 CN3:2
CN3:3 CN3:4
CN3:5 CN3:6
CN3:7 CN3:8
CN3:9 CN3:10
CN3:11 CN3:12
CN3:13 CN3:14
DGND
DGND
EMU
TMS
TCK R16 10k
DGND
TDI
TRST
R124k7
DGND
TDO
R13
4k7
3V3D
VIN
4
EN
1
SW 3
VFB 5
GND
2
IC3 FT441AA L3
2u5 R6
200k
R7
200k
C28
22p
DGND DGND
1V2
C19
100n
DGND DGND DGND
3V3D 3V3A
AGND
C41
100n
R1
1M0
ROUT
LOUT
RESET
USB_D-
USB_D+
JTMS
JTCK
JTDI
BOOT1
JTDO
JTRST
USB_Pwr_Detect
BT_USART2_TX
BT_USART2_RX
PC_USART1_TX
PC_USART1_RX
FC_USART3_TX
FC_USART3_RX
USB_Disconnect
BT_USART2_CTS
BT_USART2_RTS
DSP_SPI1_NSS
DSP_SPI1_SCK
DSP_SPI1_MISO
DSP_SPI1_MOSI
DSP_SYNCH
PA_MUTE
DSP_FLASH
HPHONES
PC_USART1_TX
PC_USART1_RX
UI_LCD_A0
UI_SPI_SCK
UI_SPI_MISO
UI_SPI_MOSI
UI_SPI_CS_LCD
I2C1_SCL
I2C1_SDA
JTMS
JTCK
JTDO
RESET
I2C1_SCL I2C1_SDA
UI_SPI_SCK
UI_SPI_MOSI
UI_SPI_CS_OUT
BT_Reset
ENC1_A
ENC1_B
ENC1_SW
ENC2_A/LCD_RS
ENC2_B/LCD_E
BT_LED
UI_SPI_CS_LRD
UI_SPI_CS_LGN/EN2SW
BT_State
UI_SPI_CS_OUT
JTDI
BT_P24
BT_EAN
JTRST
VBAT
1
Tamper-RTC/PC13*
2
OSC32_IN/PC14*
3
OSC32_OUT/PC15*
4
OSC_IN/PD0
5
OSC_OUT/PD1
6
RST
7
PC0
8
PC1
9
PC2
10
PC3
11
VSSA
12
VDDA 13
PA0 14
PA1 15
PA2 16
PA3 17
VSS_4
18
VDD_4 19
PA4 20
PA5 21
PA6 22
PA7 23
PC4
24
PC5
25
PB0 26
PB1 27
PB2/BOOT1 28
PB10 29
PB11 30
VSS_1
31 VDD _1 32
PB12 33
PB13 34
PB14 35
PB15 36
PC6
37
PC7
38
PC8
39
PC9
40
PA8 41
PA9 42
PA10 43
PA11/USB_DM 44
PA12/USB_DP 45
PA13/JTMS46
VSS_2
47 VDD _2 48
PA14/JTCK 49
PA15/JTDI 50
PC10
51
PC11
52
PC12
53
PD2
54
PB3/JTDO 55
PB4/JTRST 56
PB5 57
PB6 58
PB7 59
BOOT0
60
PB8 61
PB9 62
VSS_3
63 VDD _3 64
IC11
STM32F103RB
C62
100n
C57
100n
C54
100n
C61
100n
C44
100n
C52100n
C63
100n
R36
10k
3V3D 3V3D
3V3D
3V3D
3V3D 3V3D3V3D
3V3D
3V3D
3V3D
DGND
DGND
DGND
DGND
DGND
3V3D
DGND
DGND
DGND
Y2
8MHz
R30
4k7
R31
4k7
C59 33p
C58 33p
R20
47k
R24
47k
C55
1u0
3V3D
DGND
C51
10n
DGND
LIN
RIN
DSP_RESET
BT_USART2_TX
BT_USART2_RX
BT_USART2_CTS
BT_USART2_RTS
BT_Reset
BT_State
BT_P24
BT_EAN
R19
10k
DGND
R34
10k R35
10k
DGND
3V3D
CN4:1 CN4:2
CN4:3 CN4:4
CN4:5 CN4:6
CN4:7 CN4:8
CN4:9 CN4:10
P0
P1
P2
P3
P4
UI_SPI_CS_SW
FC_USART3_RX
OE
13
RCLK
12
SER
14
SRCLR
10
SRCLK
11
QA 15
QB 1
QC 2
QD 3
QE 4
QF 5
QG 6
QH 7
QH' 9
VCC 16
GND
8
IC10
74HC595
E0
1
E1
2
E2
3
GND
4
SDA 5 SCL
6
WC
7
VCC 8
IC12
M24C64DW
PWR_SHDWN
BT_P20
GPIO1
BT_P20
GPIO1
3V3D
+
C6
47u
6V3
+
C11
220u
+
35V
C9
10u
C64
100n
DGND
3V3D
DGND
AGND
3V3A
63V
C43
22n
AGND
R15
4k7
AGND
3V3A
C32
2n2
AGND
R10
2k2
R11
4k7
C40 22p
R5
4k7
C20
2n2
AGND
R9
12k
AGND
C53
100p R18
10k
R17
330k
L4
G471
L5
G471
D2:1
BAV99
D2:2
BAV99
LIN
RIN
INPUT
C65
100n
3V3A
AGND
TR3
847
R28
10k
R29
1k0
R23
220k
DGND
3V3D
FC_USART3_TX
FC_USART3_RX
+
35V
C39
10u
AGND
MT1
FC_TX
FC_RX
5V_USB
USB_D-
USB_D+
R25 22R
R26 22R
C60
47p C56
47p
DGND DGND
DGND
5V_USB
USB_Pwr_Detect
R33
15k
R32
22k
DGND
C66
100n
DGND
VBUS 1
D- 2
D+ 3
ID 4
GND 5
SHLD
CN7
USB_Disconnect
3V3D 3V3D
R27
1k5
TR2
857
R21
10k
R22
1k0
P0
P1
P2
P3
P4
DGND
ENC2_A/LCD_RS
ENC2_B/LCD_E
ENC1_A
ENC1_B
ENC1_SW
UI_SPI_MISO
UI_SPI_MOSI
UI_SPI_CS_SW
UI_SPI_SCK
UI_SPI_CS_LGN/EN2SW
BT_LED
UI_LCD_A0
UI_SPI_CS_LRD
DGND
DGND
3V3D
AGND
3V3D
CN1:1
CN1:2
CN1:3
CN1:4
FC_TX
FC_RX
PA_MUTE
HPHONES
CN6:1
CN6:2
CN6:3
CN6:4
CN6:5
CN6:6
CN6:7
CN6:8
CN6:9
CN6:10
CN6:11
CN6:12
CN6:13
CN6:14
CN6:15
CN6:16
CN6:17
CN6:18
CN6:19
CN6:20
CN6:21
CN6:22
CN6:23
CN6:24
CN6:25
CN6:26
CN6:27
CN6:28
CN6:29
CN6:30
DGND
UI_SPI_CS_LCD
3V3D
CN5:1
CN5:2
CN5:3
CN5:4
CN5:5
CN5:6
CN5:7
CN5:8
CN5:9
CN5:10
CN5:11
CN5:12
CN5:13
CN5:14
CN5:15
CN5:16
PWR_SHDWN
CN2:1
CN2:2
CN2:3
CN2:4
CN2:5 TR1
847 R14
2k2
DGND
DGND
TR4
847
DGND
R37
22k
3V3D
3V3D
3V3A
R2
10k
AGND
+
6V3
C4
220u
R3 100R
R38 100R
R39 100R
C5
47p
C42
47p
C8
47p
DGNDDGNDDGND
R40
10R
R41
20R
+
6V3
C12
220u
3V3D
DSP_BOOT_CFG0
DSP_BOOT_CFG0
IC6:1
LMV358ID
IC6:2
LMV358ID
V+V-
IC6:3
LMV358ID
L1
1R0
L2
1R0
R42
220k R43
1k0
R44
560R
C67
470n
AGND
R45
820R
C68
330n
AGND
DGND
C70 22p
C71
100n
JS1
AGND
CN8

20CODE100 & CODE100H Service Manual
BOOK-80010-01 | M3390.054
HEADPHONES PCB
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
D D
C C
B B
A A
1 1
100W HEADPHONES
CODE100-61-02-V5 5
13/02/2017CODE100-61-02-V5.SchDoc
TITLE
DWG. No.
Date:File:
ISS Sheet
of
C MARSHALL AMPLIFICATION PLC
TEL [phone] FAX [phone]
DENBIGH ROAD, BLETCHLEY, MILTON KEYNES, MK1 1DQ.
CODE100-61-02-V5
DWG. No.
DIMENSIONS IN
TOLERANCE (UNLESS OTHERWISE STATED)
MODEL
CODE100
MATERIAL
MATERIAL THICKNESS
DRAWN
CHECKED
APPROVED
ACS DATE
DATE
DATE
08.02.17
ISS ECO NUMBER DATE
HOLE DIA = +/-
DIMENSIONAL = +/-
Cannot open file C:\altium files\Templates\logo.JPG
R6
100R
R13
100R
AGND
V/2
MP3 IN
V/2
R26
47k
R27
47k
AGNDAGND
R21
10k
R16
10k
JS2 AGND
R5
1k0
R12
1k0
C13
47p
C12
47p
C28
1u0
C23
1u0
IC2:2
NE5532
IC2:1
NE5532
V+V-
IC2:3
NE5532
HEADPHONES
AGND
C27
1u0
C25
1u0
R20
22k
R18
22k
C26
1u0
C24
1u0
R19
10k
R17
10k
ROUT
LOUT
L4 G471
L5 G471
L8
G471
C33
470p
C35
470p
C36
100n
PA_MUTE
HPHONES
BT_LOUT
BT_ROUT
C8
100n
AGNDAGND
AGND
D2
4148
R9
4k7
AGND AGND
L9
G471
L3
G471
C37
1n0
AGND
FOOTSWITCH
D3
4148
C38
100n
C14
100n
AGND AGND
D1
3V3
M1
2N7002K
1W
R2
150R
35V
+
C4
10u
R14
470k
R15
4k7
AGND
FC_TX
FC_RX
CN3:1 CN3:2
CN3:3 CN3:4
CN3:5
CN3:6
CN3:7
CN3:8
CN3:10
CN3:9
HPHONES
PA_MUTE
FC_TX
FC_RX
AGND
JS1
AGND
CN7:1
CN7:2
CN7:3
CN7:4
CN6:1
CN6:2
CN6:3
AGND
MT1
+
25V
C20
47u
+
25V
C9
47u
AGND
R7
10k
R8
10k
AGND AGND
+
35V
C15
10u
+
35V
C21
10u
V/2
PVCC
R1
20R
O
GND
I
IC1 7812
AGND
PVCC
CH_GND
CH_GND
AGND
CN1:1
CN1:2
CN1:3
CN1:4
PA_OUT
PA_OUT
AGND
PVCC
JS6
AGND
CH_GND
CN2
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
D D
C C
B B
A A
1 1
100W HEADPHONES
CODE100-61-02-V5 5
13/02/2017CODE100-61-02-V5.SchDoc
TITLE
DWG. No.
Date:File:
ISS Sheet
of
C MARSHALL AMPLIFICATION PLC
TEL [phone] FAX [phone]
DENBIGH ROAD, BLETCHLEY, MILTON KEYNES, MK1 1DQ.
CODE100-61-02-V5
DWG. No.
DIMENSIONS IN
TOLERANCE (UNLESS OTHERWISE STATED)
MODEL
CODE100
MATERIAL
MATERIAL THICKNESS
DRAWN
CHECKED
APPROVED
ACS DATE
DATE
DATE
08.02.17
ISS ECO NUMBER DATE
HOLE DIA = +/-
DIMENSIONAL = +/-
Cannot open file C:\altium files\Templates\logo.JPG
R6
100R
R13
100R
AGND
V/2
MP3 IN
V/2
R26
47k
R27
47k
AGNDAGND
R21
10k
R16
10k
JS2 AGND
R5
1k0
R12
1k0
C13
47p
C12
47p
C28
1u0
C23
1u0
IC2:2
NE5532
IC2:1
NE5532
V+V-
IC2:3
NE5532
HEADPHONES
AGND
C27
1u0
C25
1u0
R20
22k
R18
22k
C26
1u0
C24
1u0
R19
10k
R17
10k
ROUT
LOUT
L4 G471
L5 G471
L8
G471
C33
470p
C35
470p
C36
100n
PA_MUTE
HPHONES
BT_LOUT
BT_ROUT
C8
100n
AGNDAGND
AGND
D2
4148
R9
4k7
AGND AGND
L9
G471
L3
G471
C37
1n0
AGND
FOOTSWITCH
D3
4148
C38
100n
C14
100n
AGND AGND
D1
3V3
M1
2N7002K
1W
R2
150R
35V
+
C4
10u
R14
470k
R15
4k7
AGND
FC_TX
FC_RX
CN3:1 CN3:2
CN3:3 CN3:4
CN3:5
CN3:6
CN3:7
CN3:8
CN3:10
CN3:9
HPHONES
PA_MUTE
FC_TX
FC_RX
AGND
JS1
AGND
CN7:1
CN7:2
CN7:3
CN7:4
CN6:1
CN6:2
CN6:3
AGND
MT1
+
25V
C20
47u
+
25V
C9
47u
AGND
R7
10k
R8
10k
AGND AGND
+
35V
C15
10u
+
35V
C21
10u
V/2
PVCC
R1
20R
O
GND
I
IC1 7812
AGND
PVCC
CH_GND
CH_GND
AGND
CN1:1
CN1:2
CN1:3
CN1:4
PA_OUT
PA_OUT
AGND
PVCC
JS6
AGND
CH_GND
CN2
