Marshall Radio Telemetry PowerMax H3K No Lights User manual

Introduction
Congratulations on your purchase of a Marshall PowerMax Collar. This high power tracking collar is
designed to give the best range of any hound collar available while being the toughest and most rugged
collar in the world. And best of all, it does all this while using standard AA batteries! The collar’s case
was engineered using aerospace grade aluminum to give the strongest housing possible and is
completely water-proof. It also incorporates an innovative On/Off magnetic switch that allows you to
leave the collar on the dog when not in use, as well as two LED’s on the side of the transmitter that let
you know when it’s running, and when it is time to change the batteries.
This manual will help you get the best results through a better understanding of the design and proper
use in the field. Please take time to read it thoroughly before using your new Marshall Collar.
On/Off Switch
The Marshall key-chain magnet is used to turn the collar on/off.
Simply tap the side of the collar, marked with the on/off symbol, with
the magnet. When the transmitter is turned on with the magnet, it
will send out three rapid pulses along with 3 rapid blinks of the
green indicator. Practice giving it just a quick tap to turn it off.
Unlike most collars on the market, you do not leave the magnet
under the collar to keep the transmitter off, just a simple swipe or
tap of the key chain magnet will do this.
Caution: Do not store the magnet near your transmitters. If you have
other collars with magnets installed to keep them turned off, store them
away from your Marshall collars.
Note: With a severely depleted battery the magnet controls on the transmitter may not work.
Battery
The Marshall collar uses 2 standard 1.5 Volt, AA Alkaline batteries
readily available just about anywhere. We recommend using a good,
name brand battery like Energizer or Duracell.
The batteries are located under the battery lid (marked with the frequency of
the collar) and are accessed be removing the two 4-40 Allen screws using the
3/32 Allen wrench embedded into the end of the key chain magnet. Insert the
batteries with care as to their polarity. The “+” and “-“ ends are marked on the
case.
Note: Energizer E2 Lithium 1.5V AA batteries can also be used. They will provide a
bit more life and will save about 1oz of weight. Recommended when running the
collar on smaller dogs.
Caution: Do not use the 3.6 Volt Lithium batteries (green and white). This will run the collar at 7.2 Volts,
which can damage the circuitry and void the warranty. Also, do not use rechargeable (NiCad) batteries in a
Marshall collar, they will not provide good performance.
Caution: to prevent possible battery leakage and corrosion, do not store collars for extended periods with the
batteries installed. Batteries should be removed from collars if they are not going to be used for over 1
month.

Battery Life
The Marshall collar incorporates unique technology that causes the collar to conserve battery
power if your dog gets lost. A pair of new batteries will transmit for about 6 weeks*
continuously! Under normal usage, if you hunt every night for about 4 hours, the batteries will be
good for about 4 months* or so.
Low Battery Indicator
When the battery starts getting low, the red indicator LED on the collar flashes, instead of the
normal green one. It also gives you two quick beeps every tenth beep that you can hear on your
receiver. Either of these conditions means that it is time to change the batteries. The transmitter
will continue to run for 5 days or so after the double beep and the red indicator LED come on.
Low temperatures also affect the battery life and may trigger the red low battery warning, but
when they warm up they may recover somewhat. After the batteries rest and warm up, turn the
transmitter off and back on with your magnet. If the green light comes back on, you can keep
using them safely. Just be aware that they are getting close to where you should replace them.
Activity Modes
:
The Marshall collar uses a sophisticated activity switch to determine what your dog is doing.
The three activity modes are:
Running: When the dog is walking briskly or running, the collar should send out a medium paced signal
– 55 pulses-per-minute (roughly one pulse every second).
Treed: When the dog has treed or is upright, the transmitter will send out a fast paced signal –
110 pulses-per-minute (roughly two pulses every second).
Down Dog: When the dog has not moved for a period of 7 minutes or more, the transmitter will send out
a slow paced signal – 32 pulses per minute (roughly one pulse every 2 seconds).
Care and Maintenance:
The Marshall collar is designed to be rugged and provide years of care free service. We do
recommend that you periodically check the condition of your antenna and the O-ring seal on the
battery lid.
Antenna: made out of high strength industrial stainless steel cable and is very tough. In the event that
the antenna becomes damaged, a replacement antenna may be installed in the field.
O-Ring: we recommend that you check the condition of the O-ring each time you change batteries. If the
O-ring is cracked or missing, install a replacement. It is advised to periodically lubricate the O-ring with a
petroleum jelly (Vaseline) to help prevent binding and cracking.
Replacement parts are available from your dealer or from Marshall Radio Telemetry direct.
*Times and distances are approximate. Your actual performance will vary depending on many factors, including temperature, dog
motion patterns, how long you keep them on at a time, and battery differences. Batteries will last much longer if not used for long
periods of time. They will go longer overall with lots of short hunts than with a few long hunts.

Range
The Marshall tracking collar was designed to be the most powerful transmitter on the market. It should
provide up to twice the range of most competitive high output models under most hunting conditions.
Like any radio tracking collar, the range of the Marshall collar varies with the terrain. Tests have shown
its range in the mountains of the western United States to be anywhere from 25 to 100 miles,
depending on the height of the transmitter, the height of the receiver, and the type of terrain and
obstructions. Typical eastern, forested hunting conditions give 5 to 20 miles.
If you want to compare the Marshall collar with another transmitter, you must test them at the same
time. The easiest way to do this is to hang the Marshall collar and the collar you are comparing, on a
fence rail or level tree branch and do a drive off test. It is important that both collars be at the same
height off of the ground, and that the antennas on both collars are facing vertically. A quick test can be
done a short distance away judging the relative signal strengths on your receiver, but the best test is to
drive off until you loose the first collar completely, then check the signal of your Marshall collar. As you
are testing, be sure to rotate the yagi antenna on your receiver to the vertical position matching that of
the collar's antenna to find the best signal strength for each collar.
Remember that tests done in different places will always give different results. Even testing at different
times of day can give different results. This is why you must always compare two transmitters by testing
them together at the same time in the same place.
Using the Receiver
The normal way to hold your receiver is with the antenna horizontal. Horizontal gives more pinpoint
accuracy, but if you are tracking a very weak signal, the vertical orientation might be better, so try both.
The signal is strongest if the receiver
antenna is lined up in the same orientation
as the collar’s antenna. Since the collar’s
orientation on the dog and the terrain can
change, always try rotating your yagi from
horizontal to vertical to attain the best
signal possible.
Whatever range you get, you can be sure that the Marshall collar gives you the best signal you can possibly get
under those specific conditions.
Warranty
Marshall Radio Telemetry warrants that the PowerMax Collar will be free from defects of workmanship and materials for THREE YEARS from
date of purchase. If you have a defective transmitter, return it to your distributor or Marshall Radio Telemetry and we will repair or replace it
and return it free of charge. However, we will not be responsible for damage from misuse, normal damage incurred during use, and damage
due to wear and tear. Under no circumstances will Marshall Radio be responsible for damages or loss beyond the value of the transmitter
itself, including the loss of a dog or lost time.
FCC Notice: This device does not interfere with TV reception or Federal Government radar.
MARSHALL RADIO TELEMETRY
896 West 100 North, North Salt Lake, UT 84054
[phone] or [phone]
VerticalHorizontal
Note for Tracker Maxima
, Wildlife TRX1000, and Scanner
users
:
Be sure to always tune the receiver up and down 1-2 KHz to make sure you are tuned in to the best signal.
Example: for a 217.025 collar, try listening at 217.023,.024,.025,.026,.027. Select the frequency that gives
you the best signal. Also, if the temperature changes drastically, you may want to re-tune in the collar as
the receiver’s frequency may drift.

Hound Collar
User Manual
Revision Nov-2008
