Martec Sonar MLXS34510M User manual

SONAR
12W TRICOLOUR LED BUNKER LIGHT
Model No.: MLXS34510M

Contents
01. Warranty Page
02. General Information
03. Warnings
04.
05. Installation Instructions
07. Cleaning and Maintenance
06. Switching color temperature
08. Product Disposal
www.martecaustralia.com.au | 02 8778 7500 | [email protected] Page 2

12W TRICOLOUR LED BUNKER LIGHT
YEAR REPLACEMENT
WARRANTY
IMPORTANT PRODUCT INFORMATION

General Information
General Information and Safety Instructions
local, state and national electrical codes. Any alterations or additions to building wiring must be completed by a licensed
breaker, to ensure all pole isolation of the electrical supply.
This is not a DIY product.
This is an outdoor domestic product and should not be used for commercial, trade or industrial purposes.
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
Application
This product is intended for outdoor use.
Important Note
The important safeguards and instructions given in this manual are not meant to cover all possible conditions and situations
that may occur. It must be understood that common sense, caution and care are factors which cannot be built into any
product. The persons caring for and using the unit must supply these factors.
Compliance
AS/NZS 60598.2.1:2014 & AS/NZS 60598.1:2013 Luminaires – Particular requirements – Fixed general purpose luminaires.
AS/NZS 61347.2.11:2003 Lamp control gear - Particular requirements for miscellaneous electronic circuits used with luminaires.
IEC 82079-1 : 2012 Standards. Preparation of instructions for use – Structuring content and presentation - part1: general principles and
detailed requirements.
AS/NZS CISPR 15: 2011 Limits and methods of measurement of radio disturbance characteristics of electrical lighting and similar equipment.
Congratulations on choosing to buy a Martec product.
All products brought to you by Martec are manufactured to the highest standards of
performance and safety, and, as part of our philosophy of customer service and
satisfaction, are backed by our warranty .
We hope you will enjoy using your purchase for many years to come.
www.martecaustralia.com.au | 02 8778 7500 | [email protected] Page 4
THIS LED BUNKER LIGHT SENSOR MUST BE INSTALLED BY A QUALIFIED ELECTRICIAN, AND AN
ELECTRICAL SAFETY CERTIFICATE MUST BE ISSUED ON COMPLETION OF THE INSTALLATION.
you feel you are quite familiar with this product. Keep this document in a safe place for future reference.
bunker light

5
Parts List
1. Light cover
2. Main body
3. Wall mount plate xing knob
4. Wall mount plate screw
5. Wall mount screw
Model No.: MLXS34510M
Material: PC+PP
Dimension: 239x113x74mm
Voltage: 220-240V~ 50/60Hz
Light Source: 80x0.15W Samsung LED; 3000K
80x0.15W Samsung LED; 5000K
Color temperature: 3000K - 5000K
Lumen: 3000K-700lm
4000/5000K - 800lm
With non-isolated driver
IP44
Warnings
•
• This is an outdoor domestic product and should not be used for commercial, trade or
industrial purposes.
•
• Do not install on surfaces which can move or vibrate.
•
• Do not look directly into the LED light .
•
• Dispose of packaging thoughtfully.
www.martecaustralia.com.au | 02 8778 7500 | [email protected] Page 5
•Caution, risk of electric shock
The light source of this luminaire is not replaceable; when the light source reaches its
end of life the whole luminaire shall be replaced.
The light cover is not replaceable, do not try to take down the light cover.
43
1
2

Product Installation
NOTE: This product must be installed by a licensed electrician.
NOTE: For best performance install at a height between 2 and 2.5 metres.
1. Ensure the Mains Supply is switched ‘OFF’.
2.
wired to its own wall switch.
3. Remove the mounting plate‘A’ from light body ‘B’by unscrewing the front screw ‘C’and pressing the
wall mount plate xing knob ‘H’.
4. Drill two holes in the wall using the mounting holes ‘D’ on the mounting plate‘A’ as a template.
Note: exercise caution to avoid drilling into existing electrical wiring.
5. Feed mains supply cable through the wall and weatherproof holes as appropriate. and pass the
mains supply cable through the grommet 'F'.
6.
7.
8.
9. Apply silicone if required around the base plate and grommet ‘F’ to maintain IP rating.
10. Reconnect the mains supply.
11. Turn on the bunker light.
BEFORE COMMENCING INSTALLATION
For the best performance we suggest you take into account the following:
light into its own circuit with its own switch.
The recommended mounting height is 2 to 2.5 metres.
Do not install on surfaces which can move or vibrate.
Installation Instructions
E
www.martecaustralia.com.au | 02 8778 7500 | [email protected] Page
bunker
bunker
E
Connect the Live (L), Neutral (N) cording to the markings on the terminal block‘G’.ac
D
G
F
A
C
B
the screw and
and the wall mount plate xing knob 'H',
H

•
thentakedown the lightbody.(Refertoinstallationinstructions).
Switching color temperature
www.martecaustralia.com.au | 02 8778 7500 | [email protected] Page 7
with a soft cloth approximately every 3 months.
Do not use chemicals.
Cleaning and Maintenance
•In side the LED light body,thereisCCTswitchwhichallowsyouto switchthe color temperature ofthe light
among 3000K(WW), 4000K(NW), 5000K(CW).
WW NW CW
3000K 5000K
4000K
