MAC Encore Performance
FIELD ENGINEERING CHANGE ORDER
How to replace the animation wheel, number 15122017, date 15-12-2017, revision A

Field engineering change order
2 of 7MAC Encore Performance - How to replace the animation wheel, number 15122017,
date 15-12-2017, revision A
Field engineering change order, number 15122017:
PRODUCT
Type/model: MAC Encore Performance
Description: Moving head
Serial number: All units before serial number 15029579147
Date introduced 15 December 2017
CHANGES
Problem: Field reports indicate that the animation wheel can warp under special usage patterns. The warping
can potentially cause an animation error that will turn the light off as a safety precaution.
There is no risk of personal injury.
Typical fault signs: The animation wheel moves in and out of focus when it is rotated. An animation and gobo error may
appear.
Solution: Replace the animation wheel with the new type. Follow the instructions in “Procedure on replacing the
animation wheel” on page 4 on how to remove the multimodule and replace the animation wheel.
Terms: This document only applies to the MAC Encore Performance xtures that were delivered with the rst
type of animation wheel that does not have the positioning notch.
ENCLOSED
Document: See the procedure in “Procedure on replacing the animation wheel” on page 4.
Components: -
APPROVAL
Date: 15 December 2017
Approved by: Senior Manager, Global Product Support, Henrik Christensen

Field engineering change order
3 of 7MAC Encore Performance - How to replace the animation wheel, number 15122017,
date 15-12-2017, revision A
Before you start
• During the repair, take precautions to prevent
damage due to static electricity.
• Read the instructions in this document.
• Before you start the repair, make sure that you
have all the necessary tools and materials ready.
• All repairs and electrical isolation tests must be
performed in accordance with local regulations.
• You can order the new animation wheel (P/N
5094038-00) via a warranty claim on MyMartin
or by contacting your local Martin®by Harman
distributor or service partner.
• If you need materials, more information or
support, call Global Technical Support on
[phone].

Field engineering change order
4 of 7MAC Encore Performance - How to replace the animation wheel, number 15122017,
date 15-12-2017, revision A
Figure 1: Tools
Tools
• ESD mat and wristband.
• Gloves.
• TX20 screwdriver.
• Small atheaded screwdriver.
Spare parts
• Animation wheel, P/N 5094038-00.
Figure 3: ESD mat and wristband
Take the necessary precautions
to prevent static electricity from
damaging the product during
modication or repair.
Figure 2: Safety instructions
Procedure on replacing
the animation wheel
General information
Safety instructions
Before you carry out service work, read this document.
Installation and service work must comply with local
regulations and accepted codes of good practice.
Observe the safety instructions in the user manual for
the product.

Field engineering change order
5 of 7MAC Encore Performance - How to replace the animation wheel, number 15122017,
date 15-12-2017, revision A
Removing the multimodule
1. Remove the head covers.
2. Remove the front side covers.
3. Place the xture with the front lens pointing
downwards the base.
4. Lock the tilt function (1) in this position.
NOTE! The focus lens will slide out of the
multimodule and down towards the front lens
which make it possible to remove the multimodule.
Figure 4: Locking the tilt function
1
1. Loosen the four screws (2) that hold the
multimodule.
2. Disconnect the CAN BUS and the DC power to
the distribution board (3).
Figure 5: Disconnecting CAN BUS and DC power
2
2
2
3
Figure 6: Replacing the multimodule
1. Replace the multimodule (4).
2. Follow the procedure in reverse order. 4

Field engineering change order
6 of 7MAC Encore Performance - How to replace the animation wheel, number 15122017,
date 15-12-2017, revision A
Figure 7: Loosening the ve Torx20 screws
Figure 8: Placing the framing module
Figure 9: Aligning indexing marks
Replacing the animation wheel
1. Remove the head covers.
2. Remove the front side covers.
3. Remove the multimodule. See “Removing the
multimodule” on page 5.
4. Loosen the ve Torx20 screws (1).
5. Place the framing module (2) next to the gobo and
effect module (3).
6. Gently loosen the magnetic holder (4) with a small
atheaded screwdriver.
7. Replace the animation wheel (5).
NOTE! Make sure that the indexing marks (6) are
aligned.
8. Follow the procedure reverse order.
1
2
3
4
5
5
6
6

Field engineering change order
7 of 7MAC Encore Performance - How to replace the animation wheel, number 15122017,
date 15-12-2017, revision A
