MARXON PETC-S100 User manual

www.marxon.net
Portable Solar Panel
User Manual

DISCLAIMER
To use the product correctly and properly, make sure you have read the user manual, all safety
tips, instructions, warning messages, terms of use, and disclaimers carefully before using. The
inappropriate operation could result in serious injury to the user or others, or damage to
property or products. All terms and content of this document are considered understood,
recognized, and accepted once you begin using this product. Users take full responsibility for
all usage and operations. In the event the user fails to use the product in accordance with the
User Manual, the company(“Marxon”) is not liable for any damages caused. In compliance with
laws and regulations, Marxon holds the final explanation right of this document and all related
documents of the product. For the latest product information, please visit Marxon's official
website at www.marxon.net. Products may be updated, revised, or discontinued without prior
notice.

CONTENTS
1. Safety Guide
3. Connection Methods
2. Specifications
4. FAQs
5. What’s in the Box
1
3
6
6
2
3
4
5
3.1. Connecting Single Solar Panel to the
Power Station
3.2. Parallel Connection
3.3. Series Connection

1. Safety Guide
Don't contact with strong corrosive substances.
Avoid hard or sharp objects hitting and scratching the surface during use or storage.
Don’t step on it.
Don't bend during transportation, assembly, or operation.
Don’t immerse the product in water.
When using the product, please strictly follow the operating environment temperature
specified in this user manual. Do not use or store the product near a heat source, such as
a fire source or a heating furnace.
Do not clean the solar panel with water, with wet cloth gently scrub it.
Do not attempt to disassemble the Solar Panel in any way.
Do not charge the automotive batteries directly.
1.1
1.2
1.3
1.4
1.5
1.6
1.7
1.8
1.9
1

2. Specifications
100W Technical Specifications
Product Model NO.
Peak Power
Tolerance
Cell Type
Conversion Efficiency
Power Voltage (Vmp)
Power Current (Imp)
Open Circuit Voltage (Voc)
Short Circuit Voltage (Isc)
Output Port
Operating Temperature Range
Storage Ambient Temperature
Maximum Power Temperature Coefficient
Open Circuit Voltage Temperature Coefficient
Temperature Coefficient of Short Circuit Current
Total Transmittance
Moisture Permeability
Water Absorption Rate
Test Standard Conditions
Folded Size
Unfolded Size
Net Weight
Remarks
PETC-S100
100W
±10%
MONO
21.5-23.5%
18V
5.5A
24.5V
6.1A
MC4
-10°C~65°C
-20°C~60°C
-0.45%/°C
-0.35%/°C
+0.05%/°C
97%
40°C/90%RH g/M² .Day
2.5%(24H)
2
Am1.5 25°C 1000W/m
582*577*50MM
1154*582*5.5MM
4.45KG
Testing Environment (STC):
2
Spectral Energy: 1KW/m
Air Pressure: AM=1.5 The light conditions
are 38000W Lux (Lighting Unit)
Electronic Load Test: 38000W Lux
2

3. Connection Methods
3.1Connecting Single Solar Panel to the Power Station
Connect the positive pole of the Solar MC4 Connection Cable to the negative pole of the
MC4 to Anderson Connection Cable.
Connect the negative pole of the Solar MC4 Connection Cable to the positive pole of the
MC4 to Anderson Connection Cable.
Connect the MC4 to Anderson Connection Cable to the Anderson Input Port on the Marxon
portable power station.
Step 1:
Step 2:
Step 3:
Solar Panel
Solar MC4
Connection Cable
MC4 to Anderson
Connection Cable
Power Station
-
-
+
+
3

3.2Parallel Connection
Connect the positive poles of A & B solar panels to the negative poles of the MC4 to
Anderson Connection Cable.
Connect the negative poles of A & B solar panels to the positive poles of the MC4 to
Anderson Connection Cable.
Connect the MC4 to Anderson Connection Cable to the Anderson Input Port on the Marxon
portable power station.
Note:For the parallel use of two or more solar panels, please confirm the output power, voltage, and
current requirements of the solar panel charging that your device supports.
Step 1:
Step 2:
Step 3:
Solar Panel (A)
Solar Panel (B)
Solar MC4
Connection Cable
MC4 to Anderson
Connection Cable
Power Station
-
-
-
-
+
+
+
+
4

3.3Series Connection
Connect the negative pole of A solar panel to the positive pole of B solar panel.
Connect the positive pole of A solar panel to the negative pole of the MC4 to Anderson
Connection Cable.
Connect the negative pole of B solar panel to the positive pole of the MC4 to Anderson
Connection Cable.
Connect the MC4 to Anderson Connection Cable to the Anderson Input Port on the Marxon
portable power station.
Note:For the series use of two or more solar panels, please confirm the output power, voltage, and
current requirements of the solar panel charging that your device supports.
Step 1:
Step 2:
Step 3:
Step 4:
Solar Panel (A)
Solar Panel (B)
MC4 to AndersonConnection Cable
Power Station
-
-
-
+
+
+
