PV-ezRack DFendr User manual

DFendr Solar Skirt
Installation Guide V 1.0
Last Updated - Mar. 2022

Installation Guide / DFendr Solar Skirt
1Installation Guide V 1.0
Introduction
Complying with all applicable local or national
building codes, including any updates that may
supersede this manual;
Ensuring that PV-ezRack® and other products are
appropriate for the particular installation and the
installation environment;
Using only PV-ezRack® parts and installer- supplied
parts as specified by PV-ezRack® project plan
(substitution of parts may void the warranty and
invalidate the letter of certification);
Recycling: Recycle according to the local relative
statute;
Removal: Reverse installation process.
•
•
•
•
•
The installer is solely responsible for:
List of contents
Introduction
Tools & Component list
System Overview
Installation Instruction
01
02
03
04
PV-ezRack® DFendr - Solar Skirt is a universal mounting
accessory to keep birds and wind-blown debris and
leaves away from the solar PV system on roofs.
Please review this manual thoroughly before installing
Solar Skirt. This manual provides:
1) Simple introduction of the installation relating to Solar
Skirt;
2) Planning and installation instructions for Solar Skirt.
- Introduction -
The Solar Skirt parts, when installed in accordance
with this guide. During installation, and especially
when working on the roof, please comply with the
appropriate Occupational Health and Safety regulations.
Please also pay attention to any other relevant State or
Federal regulations. Please check that you are using the
latest version of the Installation Manual, which you can
do by contacting Clenergy via www.clenergy.com or
contacting your local distributor.
Product Warranty:
Please refer PV-ezRack® Product Warranty on our
website.

Installation Guide / DFendr Solar Skirt
2
Installation Guide V 1.0
Tools and Components
Tools
Plier Tape Marker Pen
- Tools and Components -
Components
EZ-SC-PV
PV-ezRack® DFendr -
Solar Skirt Clip for
PV Panels
EZ-SS-PV
PV-ezRack® DFendr -
Solar Skirt for
PV Panels

Installation Guide / DFendr Solar Skirt
3Installation Guide V 1.0
System Overview
- System Overview -
❶
❶
❷
❷
Clip
Solar Skirt
❶❷
Note:
Considering the height (130 mm) and flexibility of Solar Skirt, it is recommended to solar skirt only for the gap 100 to
130 mm between underside of the PV panel and roof.
Most of PV-ezRack interfaces can provide required gap.
Here are the interfaces list below:
Tile Roof Interfaces: ER-I-01, ER-I-01/EZC/ECO, ER-I-01/CS, ER-I-51, ER-I-23, ER-I-26
Penetrative Tin Roof Interfaces: ER-I-05/EZC/ECO, ER-I-25
Non-penetrative Tin Roof Interfaces: Klip-lok bracket with Cross Connection Clamp (EZ-AD-C43)

Installation Guide / DFendr Solar Skirt
4
Installation Guide V 1.0
Installation Instructions
Clip Installation
Attach spring clips to the underside of the PV panel frame
with the small lip facing up.
Note:
minimum frame width (D) is 12 mm
- Installation Instructions -
Number of Clip
≥ 1.2 mm Frame
Thickness
≥ 1.85 mm Frame
Thickness
Wind Region A 4 3
Wind Region B 6 5
Wind Region C 10 6
Wind Region D 14 9
For installations up to 10 m building height and at terrain
category not less than 2.5, please refer the table on the right
for number of clips per 1 m long Solar Skirt.
Solar Skirt Installation
1) Bend the Solar Skirt strips so that it can give room for a
hand to reach and hold clip.

Installation Guide / DFendr Solar Skirt
5Installation Guide V 1.0
3) At the PV solar panel corner, cut a “V” shaped 45 degree notch and bend into 90 degree shape, install the Solar Skirt
following steps 1) and 2).
2) Insert the upper frame of the Solar Skirt into the clip mounted on the PV
panel frame and push the clip against Solar Skirt till it is fully in place.
- Installation Instructions -
Note:
If clip is pushed off from panel frame, it is recommended to press it again
with the plier to maintain a good strength.
4) At the place of having ECO-Rail obstruction, cut about 35 mm long opening of the Solar Skirt to fit it in.
