Massimo Motor Y540125715 User manual

Owners Manual
Mini Jeep
Please read and understand all instructions before use.
Retain this manual for future reference.
This vehicle is an All-Terrain Vehicle (ATV) and is NOT intended for use on
public roads or highways.
Operation of thisATV by children under the age of 16 increases the risk of
SEVERE INJURY or DEATH. Never permit children under age 16 to operate
thisATV.
Always using an approved helmet and protective gear COULD SAVE YOUR
LIFE!
Provincial / Municipal governments have different regulations pertaining to
owning and operating an off-road vehicle, learn and follow the regulations in
your area.
Copyright © Oct 2022Massimo Motor

V 2.0
Mini Jeep
For technical questions contact your distributor
SPECIFICATIONS
Length (in) 78
Width (in) 36
Height (in) 29
Ground Clearance (in) 3.9
Wheel Base (in) 49
Dry Weight (lb) 350
Steering Bar Angle
≥30 deg
Max Speed (mph) 28
Max. Weight
Capacity *
300 lbs (136 kg)
Front Brake Type
Disc-Brake
Rear Brake Type
Disc-Brake
Front/Rear Tire Size
18x7.00-8
(180/70-8)
Displacement
125 cc
Compression Ratio
9.5 : 1
Ignition Mode
CDI
Model
PAZ125-1
Fuel Tank
Capacity (US Gal) 1.05
Engine Type
4-Stroke, Forced Air
Cooled, Single Cyl.
Max Power
9hp@7500 rpm
Max Torque
6.5lb-ft@6500 rpm
Idle Speed
1500±100 rpm
Start Mode
Electric
Clutch
Centrifugal, Oil
dipped, segmented
Spark plug type
C7HSANGK
Engine Oil
Capacity
0.9 Qt
Engine Oil
10W/40-SE
Oil Pump
Inner-Outer Rotor
Type
Magneto
Permanent magnet
Lubrication
Forced/Splash
INTRODUCTION
This off-road product IS NOT A TOY AND CAN BE HAZARDOUS TO OPERATE. This product handles
differently from other vehicles including ATV’s and motorcycles. A collision or rollover can occur quickly, even
during routine maneuvers such as turning and riding on hills or over obstacles.
To help you make informed decisions about safety, you will find provided in this manual operating procedures
and other safety procedures which must be followed.
*Maximum weight capacity includes the operator, passenger, and any cargo or accessories.
2

V 2.0
Contact your distributor for more information
In addition to the safety information in this manual, you will find safety labels on the product. FOLLOW ALL
WARNINGS BOTH IN THIS MANUAL AND ON THE PRODUCT.
SAFETY
WARNING! Read and understand all instructions before using this device. The operator must follow
basic precautions to reduce the risk of personal injury and/or damage to the equipment.
Keep this manual for safety warnings, precautions, operating or inspection and maintenance instructions.
Information which is particularly important is distinguished in this manual by the following notations:
FAILURE TO FOLLOW WARNING INSTRUCTIONS COULD RESULT IN
SEVERE INJURY OR DEATH TO THE OPERATOR OR PASSENGER, A
BYSTANDER OR A PERSON INSPECTING OR REPAIRING THE PRODUCT.
CAUTION INSTRUCTIONS ARE PROCEDURES TO PREVENT DAMAGE TO
THE VEHICLE OR INJURY TO THE OPERATOR OR PASSENGER, A
BYSTANDER OR A PERSON INSPECTING OR REPAIRING THE PRODUCT.
A NOTE provides key information to make procedures easier or clearer.NOTE:
IMPORTANT RULES FOR SAFE OPERATION
1. This vehicle is not licensable. IT IS NOT TO BE OPERATED ON ANY PUBLIC ROAD, STREET,
HIGHWAY, PARKING LOT, SIDEWALK, OR ALLEY. To do so would be in violation of local law. This vehicle
may be operated only on private property and upon areas approved by local law. Avoid operating this
vehicle in any area with stationary objects that the vehicle could travel under. Do not ride in areas where
other recreational vehicles are being operated. Be respectful of landowners and the environment.
2. This vehicle should NEVER be operated indoors. The exhaust from the engine contains carbon monoxide,
which is a tasteless, odorless, and poisonous gas.
3. Unless otherwise specified in this manual, all screws, nuts, and bolts must be kept tight to ensure that the
vehicle is in safe operating condition. The engine must be kept free of all dirt and other accumulations,
paying particular attention to throttle linkage area.
4. The tire pressure should be checked prior to each use. The recommended inflation pressure is the
maximum tire pressure as printed on the tire’s sidewall. IMPROPER TIRE PRESSURE MAY CAUSE
INSTABILITY AND MAY PREVENT PROPER BRAKING OR STEERING.
5. Modifications of this vehicle or removal of any original equipment or safety decal may render the vehicle
unsafe or illegal. NEVER REMOVE ANY PROTECTIVE GUARDS, BELT GUARDS, OR SEAT BELTS.
These devices are for operator/passenger/service provider’s protection. If any guards are removed for
maintenance or servicing of the vehicle, ensure that they are secured in place prior to operating the
vehicle.
6. THE VEHICLE SHOULD NEVER BE STARTED WITHOUT FIRST CHECKING TO SEE THAT THE
THROTTLE IS IN IDLE POSITION. Do not start engine without verifying proper function of the throttle.
Never attempt to start this vehicle without having the operator seated in the proper position. When starting
with the operator in the seat, the operator should have their left foot on the brake.
3

V 2.0
For technical questions contact your distributor
7. This vehicle is not designed or intended for racing, or any other form of competition.
8. The operator’s ability to operate this off-road vehicle safely is largely dependent upon the operator’s ability
to exercise proper judgment. An operator also must not be too small or too large for controlled operation.
The operator must be of sufficient age, understanding, mental capacity, and physical capability to safely
operate this vehicle. This vehicle should only be operated after mature, supervised instruction and sufficient
practice. Safe operation includes responsibility for the safety of a passenger (if any).
9. A DOUBLE SEAT VEHICLE IS DESIGNED FOR ONE OPERATOR AND ONE PASSENGER. No one
should ever attempt to ride on this vehicle without being seated, with the seat belt properly secured. For
double seat vehicles ridden without passenger, the passenger seat belt must be secure to prevent it from
getting caught up in operating components. Passengers must be of sufficient age, understanding, mental
capacity, and physical capability to act to protect himself/herself. ALWAYS FOLLOW THE RECOMMENDED
AGE RESTRICTION OF 16 YEARS FOR OPERATORS AND PASSENGERS.
10. The engine should be stopped when the vehicle is not in use.
11. The operator and passenger (if any) of this vehicle should always wear a helmet approved by agencies such
as Department of Transportation (DOT), Safety Helmet Council of America (SHCA), or Snell Memorial
Foundation (SNELL). Most off-road vehicle accident fatalities are due to head injuries. The operator should
also wear face shields or goggles, boots or closed-toe shoes, gloves, and other appropriate protective
clothing.
12. LOOSE CLOTHING, LONG HAIR, OR ARTICLES WORN BY ANY OPERATOR OR PASSENGER MUST
BE FULLY CONTAINED OR COVERED TO PREVENT THEM FROM POSSIBLY BEING CAUGHT IN
ROTATING PARTS OF THE VEHICLE OR THE SURROUNDING ENVIRONMENT WHILE RIDING.
FAILURE TO OBEY COULD ENDANGER THE PERSONAL SAFETY OF THE OPERATOR OR
PASSENGER.
13. DO NOT PLACE HANDS, FEET, OR ANY OTHER PART OF THE BODY OR ANY CLOTHING NEAR THE
ENGINE, MUFFLER, WHEELS, CHAIN AND OTHER ROTATING PARTS OF THE VEHICLE WHILE
RIDING OR RUNNING THE ENGINE. Caution must be used in performing required maintenance on or near
an operating engine. Special caution should be taken after the engine has been running, since the engine
and other drive components may be extremely hot.
14. Wet, slippery, rough, or steep terrain is potentially dangerous and may result in injury if proper caution in not
observed. Slow speeds are required to safely operate this vehicle under these conditions. The operator
must use mature judgment, skill, and experience to choose a speed suitable for terrain and riding
conditions.
15. The governor settings for this vehicle’s engine must not be tampered with, altered, or changed. The
governor is set by the engine manufacturer and limits the maximum speed of the engine (and vehicle) and
protects the engine from damage. Excessive speeds are potentially dangerous to the operator/ passenger,
and the engine.
16. Each time before using this vehicle, the fuel supply should checked. NEVER REFUEL THE FUEL TANK
WHILE THE ENGINE IS RUNNING OR WHILE THE ENGINE IS HOT. Do not refuel the tank in a closed
area such as a garage, while smoking, or in the vicinity of an open flame. Do not overfill the tank. There
should not be any fuel in the filler neck. Replace cap tightly to prevent spillage of fuel and potential fire
hazard. After filling tank, move the vehicle at least 15 feet away from the spot of filling before starting.
4

V 2.0
Contact your distributor for more information
17. If the vehicle should start making unusual noise or vibrating abnormally, the engine should be stopped and
the spark plug wire disconnected. The vehicle should then be checked for damage. Excessive noise or
vibration is generally a warning of loose or worn parts.
18. When making repairs or adjustments to the vehicle which do not involve adjustments to the engine, the
spark plug wire must be disconnected and kept away from the spark plug to prevent accidental starting.
When working on or around, or when restarting engine, use extreme caution to avoid contact with the
muffler, cylinder head, or any other potentially hot area on or around the engine.
19. Always perform a pre-ride inspection before starting the engine. See the Pre-Ride Inspection section in this
manual.
20. When storing the vehicle, it must be kept in a place where gasoline fumes will not reach an open flame or
spark. For long period storage, such as for winter, the fuel tank should be drained in an open, cool area. The
engine must be allowed to cool before storage in any enclosure. Read and keep all printed material supplied
with this vehicle. If any printed material is unclear, contact the manufacturer or distributor.
21. NEVER OPERATE OR RIDE IN THIS VEHICLE WHILE UNDER THE INFLUENCE OF ALCOHOL,
DRUGS, OR MEDICATION OF ANY KIND. SUCH OPERATION COULD BE DANGEROUS TO YOURSELF
AND/OR OTHERS.
22. Always slow down when turning. High speed turning may cause loss of control, possible turnover of the
vehicle, and/or possible injury to the operator or passenger.
23. While making a turn, knobby tires may increase the risk of loss of control. ALWAYS SLOW DOWN! A
collision or rollover can occur quickly, even during routine maneuvers such as turning and riding on a hill or
over obstacles.
24. DO NOT RACE, JUMP, PERFORM "STUNT" RIDING, “DONUTS”, OR "SPIN OUTS" WHEN OPERATING
THIS VEHICLE. THIS VEHICLE IS NOT DESIGNED OR INTENDED FOR SUCH OPERATION.
25. This manual, along with the other supplements provided with your vehicle, provide guidelines for the
assembly, maintenance, and operation of this vehicle and is not intended as a service manual.
26. Assembly, maintenance, and/or repair of this vehicle should only be performed by persons of sufficient
mechanical skill, experience, and judgment (such as outdoor equipment dealers, motorcycle dealer/shops,
or small engine dealers) so that no unsafe condition or modification is made.
27. Always use extreme caution when starting the engine. Avoid touching the engine, muffler, or drive
components. These areas could cause burns on contact.
28. The battery contains sulfuric acid and must not come in contact with skin, eyes, or clothing since this will
cause severe burns possibly causing disfigurement. Also, battery may generate explosive gases and must
not be exposed to sparks, flame, cigarettes, or anything flammable or an explosion may result causing
severe injury. Protective gloves and face protection must be worn when servicing the battery.
29. ANY OPERATOR OR PASSENGER UNDER 18 YEARS OF AGE MUST ALWAYS BE APPROPRIATELY
SUPERVISED BY AN ADULT AT ALL TIMES WHILE OPERATING THE VEHICLE.
30. Operating this vehicle requires skills acquired through practice over a period of time. Take the time to learn
the basic techniques well before attempting to operate the vehicle.
31. Operate only on safe and familiar terrain. Avoid loose gravel and rocks. Be careful on wet surfaces and
allow for extra braking distance.
