Master Forge MFA350BNP User manual

ITEM #0221380
MODEL #MFA350BNP
2-BURNER LP GAS GRILL
Français p. XX
Español p. XX
1
Français p. 24
Español p. 47
ATTACH YOUR RECEIPT HERE
Serial Number Purchase Date
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-800-963-0211, 8:00 a.m. – 6:00 p.m., EST, Monday – Thursday,
8:00 a.m. – 5:00 p.m., EST, Friday.
ANS Z21.58a-2008
CSA 1.6a-2008
Outdoor Cooking
Gas Appliance
Master Forge & M Design® is a registered trademark
of LF, LLC. All rights reserved.
®

2
TABLE OF CONTENTS
Safety Information ......................................................................................................................... 3
Package Contents ......................................................................................................................... 5
Hardware Contents ....................................................................................................................... 6
Preparation ................................................................................................................................... 6
Assembly Instructions ................................................................................................................... 7
Operation Instructions ................................................................................................................... 13
Care and Maintenance .................................................................................................................. 16
Troubleshooting ............................................................................................................................ 19
Warranty ....................................................................................................................................... 21
Replacement Parts List ................................................................................................................ 22
WARNING:
1. Do not store or use gasoline or other
of this or any other appliance.
2. An LP cylinder not connected for use shall
not be stored in the vicinity of this or any
other appliance.
3. This grill is for outdoor use onlyand shall
not be used in a building, garage, under
overhangs or any other enclosed area.
4. Do not leave a lit grill unattended.
Keep children and pets away from
the grill at all times.
DANGER:
If you smell gas:
1. Shut off gas to the appliance.
3. Open lid.
4. If odor continues, keep away from the
appliance and immediately call your
Assembler/Installer: This manual contains important information necessary for the proper
assembly and safe use of this appliance. Read and follow all warnings and instructions before
assembling and using this appliance. Leave these instructions with the consumer.
Consumer/User: Follow all warnings and instructions when using this appliance.
Retain these instructions for future reference.

3
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble, operate or install the
product. If you have any questions regarding the product, please call customer service at:
1-800-963-0211, 8:00 a.m. – 6:00 p.m., EST, Monday – Thursday, 8:00 a.m. – 5:00 p.m., EST, Friday.
CAUTION
1HYHUXVHFKDUFRDORUOLJKWHUIOXLGZLWKWKHJULOO
'RQRWXVHJDVROLQHNHURVHQHRUDOFRKROIRUOLJKWLQJ
7KH/3JDVVXSSO\F\OLQGHUXVHGZLWKWKLVDSSOLDQFHPXVWEH
(a) Constructed and marked in accordance with the Specifications for LP-Gas Cylinders
of the U.S. Department of Transportation (D.O.T.) or the National Standard of Canada,
CAN/CSA-B339, Cylinders, Spheres and Tubes for Transportation of Dangerous Goods;
and Commission, as applicable; and
(b) Provided with a listed overfilling prevention device.
(c) Provided with a cylinder connection device compatible with the connector for outdoor
cooking appliances. This grill is not intended to be used in or installed on recreational
vehicles and/or boats.
1HYHUNHHSDILOOHGFRQWDLQHULQDKRWFDURUFDUWUXQN+HDWZLOOFDXVHWKHJDVSUHVVXUHWR
increase, which may open the relief valve and allow gas to escape.
$OZD\VRSHQJULOOOLGVORZO\DQGFDUHIXOO\DVKHDWDQGVWHDPWUDSSHGZLWKLQWKHJULOOFDQEXUQ
you severely.
CALIFORNIA PROPOSITION 65
DANGER
'RQRWXVHLQDQH[SORVLYHDWPRVSKHUH.HHSJULOODUHDFOHDUDQGIUHHIURPFRPEXVWLEOH
materials, gasoline and other flammable vapors and liquids.
Fuels used in gas or oil fired appliances and the products of combustion of such fuels contain
chemicals known to the State of California to cause cancer, birth defects or other reproductive
harm. This product contains chemicals, including lead and lead compounds, known to the State of
California to cause cancer, birth defects or other reproductive harm. Wash hands after handling.

CAUTION
'RQRWVWRUHRUXVHJDVROLQHRURWKHUIODPPDEOHOLTXLGVRUYDSRUVLQWKHYLFLQLW\RIWKLVRUDQ\
other appliance.
$Q/3F\OLQGHUQRWFRQQHFWHGIRUXVHVKDOOQRWEHVWRUHGLQWKHYLFLQLW\RIWKLVRUDQ\RWKHU
appliance.
7KLVJULOOLVIRUXVHZLWKSURSDQHJDVRQO\SURSDQHJDVF\OLQGHUQRWLQFOXGHG
1HYHUDWWHPSWWRDWWDFKWKLVJULOOWRWKHVHOIFRQWDLQHGSURSDQHV\VWHPRIDERDWFDPSHU
trailer, motor home or house.
'RQRWDWWHPSWWRPRYHWKHJULOOZKLOHLWLVOLWRUZKHQLWLVKRW7KHFDVWHUVVKRXOGEHORFNHG
when not moving the grill.
'RQRWXVHWKHJULOOXQOHVVLWLVFRPSOHWHO\DVVHPEOHGDQGDOOSDUWVDUHVHFXUHO\IDVWHQHGDQG
tightened.
.HHSDOOFRPEXVWLEOHLWHPVDQGVXUIDFHVDWOHDVWLQFKHVFPDZD\IURPWKHJULOODW
all times.
'RQRWWRXFKPHWDOSDUWVRIJULOOXQWLOLWKDVFRPSOHWHO\FRROHGDERXWPLQXWHVWRDYRLG
burns, unless you are wearing protective gear (pot holders, gloves, BBQ mittens, etc…).
'RQRWDOWHUWKLVJULOOLQDQ\PDQQHU
&OHDQDQGLQVSHFWWKHKRVHEHIRUHHDFKXVH,IWKHUHLVHYLGHQFHRIDEUDVLRQZHDUFXWVRU
leaks, the hose must be replaced prior to operating the appliance. The replacement hose
assembly will be that which is specified by the manufacturer, listed in the repair parts list in this
manual.
0RYHJDVKRVHVDVIDUDZD\DVSRVVLEOHIURPKRWVXUIDFHVDQGGULSSLQJKRWJUHDVH
.HHSWKHJULOO¶VYDOYHFRPSDUWPHQWEXUQHUVDQGFLUFXODWLQJDLUSDVVDJHVFOHDQ,QVSHFWWKH
grill before each use. Do not obstruct the flow of gas or ventilation air.
7KHXVHRIDOFRKROSUHVFULSWLRQRUQRQSUHVFULSWLRQGUXJVPD\LPSDLUWKHRSHUDWRU¶VDELOLW\
to properly assemble or safely operate the grill.
'RQRWOHDYHDOLWJULOOXQDWWHQGHG.HHSFKLOGUHQDQGSHWVDZD\IURPWKHJULOODWDOOWLPHV
'RQRWSODFHWKLVJULOORQDQ\W\SHRIWDEOHWRSVXUIDFH7KHJULOOVKRXOGEHSODFHGRQDIODWDQG
level surface.
'RQRWXVHWKHJULOOLQKLJKZLQGV
SAFETY INFORMATION
WARNING
4
'RQRWSODFHWKHJULOOXQGHURYHUKHDG
combustible construction or awnings.
Minimum clearance from sides and
back of unit to combustible construction,
36 inches (914.4mm) from sides and back.
NOTE: The installation must conform with
local codes or, in the absence of local codes,
with either the National Fuel Gas Code,
ANSI Z223.1/NFPA 54, Natural Gas and
Propane Installation Code, CSA B149.1, or
Propane Storage and Handling Code, B149.2.

3$&.$*(&217(176
5
PART DESCRIPTION QUANTITY
A Bottom Shelf 1
B Locking Caster 2
C Caster 2
D Cart Left Side Panel 1
E Cart Right Side Panel 1
F Cart Rear Panel 1
G Upper Front Door Brace 1
H Door Assembly 1
I Door Handle 1
J Door Handle Bezel 2
K Control Knob 2
L Grill Body 1
M Side Table Support 1 2
N Side Table Support 2 2
O Left Side Table 1
P Right Side Table 1
Q Grease Pan 1
R Grease Cup 1
S Heat Tent 2
T Cooking Grate 2
U Lid Handle 1
V Lid Handle Bezel 2
W Warming Rack 1
X Door Handle Sleeve 2
Y AAA Battery (1.5V) 1
PART DESCRIPTION QUANTITY
J
E
D
B
G
F
H
.
I
C
A
N
O
Q
L
P
M
M
NS
RT
U
V
W
XY

HARDWARE CONTENTS (shown actual size)
0[
Screw
Qty. 28
0[
Screw
Qty. 2
NOTE:
(FF) Hardware
preassembled
in door handle
0[
Screw
Qty. 2
NOTE:
(GG) Hardware
preassembled
in lid handle
0[
Screw
Qty. 4
0[
Screw
Qty. 16
Plain
Washer
Qty. 16
6
AA DD EE HH
CC FF
BB GG
0[
Screw
Qty. 4
Spring
Washer
Qty. 16
Before beginning assembly of product, make sure all parts are present. Compare parts with package
contents list on previous page and hardware contents above. If any part is missing or damaged, do
not attempt to assemble the product. Contact customer service for replacement parts.
Estimated Assembly Time: 50 minutes with 2 people.
Tools Required for Assembly and Leak Testing (not included): Phillips screwdriver, Spray bottle
PREPARATION
THIS UNIT IS HEAVY. TWO PEOPLE REQUIRED FOR SAFE ASSEMBLY.
Two people required for safe assembly. Some parts may contain sharp edges. Wear protective
gloves if necessary. Read and follow all safety statements, warnings, assembly instructions and
use and care instructions before attempting to assemble and use.
CAUTION

ASSEMBLY INSTRUCTIONS
7
1. Locate the two locking casters (B) and the
two non-locking casters (C). Secure the two
locking casters (B) to the rear (area of bottom
shelf with cut away) of the bottom shelf (A)
using four screws (AA) inserted through four
spring washers (EE), then through four plain
washers (HH) and into the threaded holes on
the bottom shelf (A). Secure the two non-
locking casters (C) to the front of the bottom
shelf (A) using four screws (AA) inserted
through four spring washers (EE), then through
four plain washers (HH) and into the threaded
holes on the bottom shelf (A). Tighten all
screws.
Hardware Used
AA [
0[6FUHZ
2. Insert 4 screws (AA) halfway into threaded
holes in bottom shelf (A). Attach the cart left
side panel (D) by placing the panel keyholes
over the screw heads (AA) on left side of
bottom shelf (A). Slide the cart left side panel
(D) so that the screw head is over the smaller
part of the keyhole. Thread the screw (AA)
down snug but do not tighten as a little wiggle
room will be necessary in following assembly
steps. Repeat with cart right side panel (E).
B
E
A
AA
HH
C
1
2
EE
EE [
Spring
Washer
HH [
Plain
Washer
Hardware Used
AA [
0[6FUHZ
AA
D
A
AA
HH
EE

4. Insert 2 screws (AA) halfway into the top
front threaded holes of both the cart left side
panel (D) and the cart right side panel (E).
Attach the upper front door brace (G) by
sliding the cut-outs in the front door brace (G)
over the 4 screws (AA) and tightening all 4
screws (AA).
4
Hardware Used
AA [
0[6FUHZ
E
AA D
G
AA
G
ASSEMBLY INSTRUCTIONS
8
3. Insert one screw (AA) halfway into the middle
rear threaded hole of each of the cart left side
panel (D) and cart right side panel (E). Attach
the cart rear panel (F) by sliding the keyholes
in the cart rear panel (F) over the inserted
screws. Slide the rear cart panel (F) down to
meet bottom shelf (A). Secure the cart rear
panel (F) to the bottom shelf (A) with 2 screws
(AA). Tighten all screws, including the 4
screws in cart side panels (D and E).
AA
F
3E
D
A
Hardware Used
AA [
0[6FUHZ

ASSEMBLY INSTRUCTIONS
9
5. Remove preassembled screws (FF) from the
door handle. Insert the 2 door handle sleeves
(X) into the holes located on the back of the
door assembly (H). Insert 2 screws (FF) into
the door handle sleeves (X), through the door
handle bezels (J) and into the threaded holes
in the door handle (I). Tighten the screws.
6. Attach the door assembly (H) to the assembled
cart body by aligning the holes in the hinge of
the door assembly with the holes in the cart
left side panel (D), inserting 4 screws (BB)
and tightening. Adjust the door assembly (H)
clearance to the cart body by slightly loosening
the 4 screws (BB), aligning the door assembly
(H) with the cart body, then tightening all
screws (BB) securely.
6
5
Hardware Used
FF [
0[6FUHZ
H
FF
X
I
J
Hardware Used
BB [
0[6FUHZ
H
BB
D
E
7. Slip control knobs (K) onto the valve stems
located on the front control panel of the grill
body (L). Remove preassembled screws (GG)
from the lid handle. Attach the lid handle (U)
by inserting two screws (GG) from inside the
lid of the grill body (L), through the lid handle
bezels (V), into the handle (U) and tightening
securely.
7
TT
Hardware Used
GG [
0[6FUHZ
GG
L
U
.
V

ASSEMBLY INSTRUCTIONS
10
Hardware Used
DD [
0[%ROW
8. Carefully place the grill body (L) over the
mounting tabs on the cart side panels (D and E)
and onto the cart. Adjust the grill body (L) so
that the holes in the grill body (L) are aligned
with the holes in the tabs of the cart side panels
(D and E). NOTE: Make sure the gas hose is
inside the cart. Fasten the grill body (L) using
2 screws (CC) on each side.
9. NOTE: Side Table Supports 1 (M) will be used
for both the right side front and left side rear
placement. Side Table Supports 2 (N) will be
used for both the right side rear and left side
front placement.
Install the side table supports 1 (M) and side
table supports 2 (N) on both sides of the grill
body with screws (DD). Arrows cut out of the
supports indicate the correct position of the
support when fastened to the grill body (L).
8
9
B
Hardware Used
CC [
0[6FUHZ
CC
L
DE
L
DD
M
N

ASSEMBLY INSTRUCTIONS
11
WARNING: IT IS VERY IMPORTANT TO CHECK
AND ENSURE THAT EACHAND EVERY BURNER
IS FULLY ENGAGED WITH THEADJACENT VALVE
ORIFICE BEFORE COMPLETING STEP 10.
FAILURE TO DO SO MAY
RESULT IN FIRE OR
EXPLOSION, POSSIBLY
CAUSING SERIOUS
INJURY OR DEATH. REFER TO MAINTENANCE
SECTION INSTRUCTIONS TO PROPERLY CHECK
THE ENGAGEMENT.
10. Open the lid and place the two heat tents (S)
on the brackets directly above the burners.
11. Place cooking grates (T) on the grill body
braces and grill rear panel, then insert the
warming rack (W) into the 2 holes located
on the back edge of the grill body (L).
12. With the left side table (O) in a perpendicular
position, align the slots in the left side table (O)
with the side table supports (M and N) and
insert. To lock the left side table (O) in the
upright position, swing the left side table (O)
90 degrees up, push towards the grill body (L),
and press down on the left side table (O)
near the grill body until it is fully fastened in
place. Repeat with the right side table (P).
12
11
10
S
L
W
T
L
O

L
Q
ASSEMBLY INSTRUCTIONS
12
13. Insert the grease pan (Q) into position by
sliding it in the grill body (L) from the rear,
along the rails located just below the
underside of the grill body (L). Insert the
grease cup (R) into position by sliding it onto
the rails located on the bottom side of the
grease pan (Q).
14. Remove the igniter cap by turning it counter-
clockwise. Insert the AAA battery (Y) into the
 LJQLWHUERG\ZLWK3RVLWLYHµ¶HQGIDFLQJRXW
Replace the igniter cap.
15. Open the cart door and insert the LP gas
cylinder (sold separately) into the nesting hole
located in the bottom shelf. Align the hand
screw coupling of the hose/regulator with the
threaded valve of the cylinder by turning the
LP gas cylinder until positioned correctly.
Hand-tighten the hose/regulator coupling to
the threaded valve of the LP gas cylinder.
Tighten the tank screw until the cylinder is
secure inside the nesting hole of the cart.
15
14
13
R
Y
Tank
screw

13
ASSEMBLY INSTRUCTIONS
&+(&.,1*)25/($.6
After all connections are made, check all connections and fittings on the LP gas tank valve, gas hose
and regulator for leaks with a water and soap solution.
7RSUHYHQWILUHRUH[SORVLRQZKLOHWHVWLQJIRUDOHDN
$OZD\VSHUIRUPOHDNWHVWSULRUWROLJKWLQJWKHJULOO
'RQRWVPRNHZKLOHWHVWLQJIRUDOHDN
$OZD\VSHUIRUPOHDNWHVWVRXWGRRUVLQDZHOOYHQWLODWHGDUHD
'RQRWXVHDQ\VRXUFHRIIODPHZKLOHWHVWLQJIRUOHDNV
'RQRWXVHWKHJULOOXQWLODQ\DQGDOOOHDNVDUHFRUUHFWHG
,I\RXDUHXQDEOHWRFRUUHFWDOHDNGLVFRQQHFWWKHSURSDQHVXSSO\DQGFDOODJDVDSSOLDQFHVHUYLFH
dealer.
3(5)250/($.7(67
3UHSDUHOHDNWHVWVROXWLRQE\FRPELQLQJSDUWOLTXLGGLVKVRDSZLWKSDUWVZDWHU
7RWDOVROXWLRQUHTXLUHGLVDSSUR[LPDWHO\R]PO
Put leak test solution in a spray bottle.
(QVXUHDOOFRQWURONQREVDUHLQWKHµ2))¶SRVLWLRQ
2SHQ/3JDVWDQNYDOYH
6SUD\OHDNWHVWVROXWLRQRQDOOJDVFDUU\LQJFRQQHFWLRQVDQGILWWLQJV3UHVHQFHRIEXEEOHVDWDUHDV
of applied test solution indicates a gas leak. If leaks are detected or you smell or hear gas, shut off
the LP gas tank immediately and repair or replace the defective part. Do not use the grill until all
leaks are corrected.
OPERATION INSTRUCTIONS
Only use the regulator and hose assembly provided! If a replacement is necessary, please
call our customer service center. Do not use replacement parts that are not intended for this grill.
CAUTION
CONNECTING GAS CYLINDER
The propane gas supply cylinder to be used must be constructed and marked in accordance with the
Specifications for LP Gas Cylinders of the U.S. Department of Transportation (D.O.T.) or the National
Standard of Canada, CAN/CSA-B339, Cylinders, Spheres and Tubes for Transportation of Dangerous
Goods; and Commission, as applicable; and Provided with a listed overfilling prevention device.
Use only 20-pound cylinders (Height 18.11 in., Diameter Tank 9.84 in., Diameter foot: 8.03 in.) equipped
with a cylinder connection device compatible with the connection for outdoor cooking appliances. The
cylinder must include a collar to protect the cylinder valve. The gas cylinder should not be dropped or
handled roughly!
If the appliance is not in use, the gas cylinder must be disconnected. Storage of an appliance indoors
is permissible ONLY if the cylinder is disconnected and removed from the appliance. Cylinders must
be stored outdoors out of the reach of children and must not be stored in a building, garage or any
other enclosed area. Your cylinder must never be stored where temperatures can reach over 125°F.
Place dust cap on cylinder valve outlet whenever the cylinder is not in use. Only install the type of
dust cap on the cylinder valve outlet that is provided with the cylinder valve. Other types of caps or
plugs may result in leakage of propane.

14
OPERATION INSTRUCTIONS
Before connection, be sure that there is no debris caught in the outlet of the gas cylinder, outlet of the
regulator valve or in the outlet of the burner and burner ports. Connect regulator valve and hand-tighten
firmly. Keep the propane cylinder valve closed and disconnect the propane cylinder from the regulator
valve when the grill is not in use.
DO NOT obstruct the flow of combustion air and ventilation air to the grill. The propane cylinder must
be arranged for vapor withdrawal and equipped with a listed overfilling prevention device. Please use
the proper cylinder orientation to provide vapor withdrawal. NOTE: The cylinder must be fully upright
for the cylinder to have vapor withdrawal only.
a. Do not store a spare LP-gas cylinder under or near this appliance.
b. Never fill the cylinder beyond 80 percent full.
c. If the information in (a) and (b) is not followed exactly, a fire causing death or serious
injury may occur.
CAUTION
NOTE: Other cylinders may be acceptable for use with this appliance provided they are compatible
with the appliance nesting hole and retention means. Refer to Step 15 of the Assembly Instructions
for correct cylinder to cylinder holder connection.
ALL INSTRUCTIONS AND SAFEGUARDS ON THIS PAGE MUST BE FOLLOWED TO
PREVENT FIRE, DAMAGE AND/OR INJURY.
WARNING
&211(&7,1*7+(/37$1.
1. The knob on the LP tank must be closed. Make sure that the knob is turned clockwise to a
full stop. The cylinder supply system must be arranged for vapor withdrawal.
2. Check that the control knob on the control unit is turned off.
3. Remove the protective cap from the LP tank valve and coupling nut.
4. Hold the regulator in one hand and insert the nipple into the valve
outlet. Be sure the nipple is centered in the valve outlet. The coupling
nut connects to the large outside threads on the valve outlet. Use
care – do not cross thread the connection.
5. Hand-tighten the coupling nut clockwise until it comes to a full
stop. Firmly tighten by hand only. Do not use tools.
To Disconnect: Fully close the tank valve by turning clockwise .
Turn the coupling nut counterclockwise until the regulator assembly detaches.
In the connection process, make sure:
WKHUHJXODWRULQOHWFRQQHFWRUPDWHVZLWKWKHF\OLQGHUYDOYHRXWOHWSURSHUO\VDIHO\DQGILUPO\DQG
WKH/3*DVKRVHGRHVQRWFRPHLQFRQWDFWRUUHPDLQLQFRQWDFWZLWKWKHILUHER[
WARNING
Correct Wrong Wrong

15
LIGHTING THE GRILL
Before first use:
Remove all hangings or plastic straps, if present. Before you cook on your new gas grill, it is important
WRFOHDQ\RXUJULOOZLWKKHDW7RGRWKLVRSHUDWHWKHJULOOIRUDSSUR[LPDWHO\PLQXWHVZLWKWKHOLGFORVHG
and the control knob in the highest position. This will clean the internal parts by burning off any residue
and odor from the manufacturing process.
OPERATION INSTRUCTIONS
If the flame extinguishes accidentally during ignition or operation, immediately TURN OFF
the cylinder valve and then TURN OFF the control knob.
CAUTION
WARNING
1. Check that the control knobs are in the OFF position.
2. Open valve at tank fully by turning counter-clockwise.
3. Open lid during lighting.
4. Push igniter down 3 to 4 seconds while turning right side control knob to the HIGH position. The
burner should ignite.
If ignition does not take place within 5 seconds, immediately turn the control knob to the OFF
position. Wait 5 minutes and repeat step 4 above or refer to match lighting instructions below.
5. Repeat step 4 above to ignite left side burner.
If the burner still does not light, check that there is gas in the cylinder and follow the match lighting
instructions.
LIGHTING THE GRILL WITH A MATCH
Do not lean over grill when lighting. Read instructions before lighting.
1. Insert a match in the end of the match holder that is installed on the inside of the cabinet door.
2. Light the match.
3. Immediately place the lit match through the 20mm (0.75 in.) hole on the side of the grill body,
nearest the left burner. Make sure the lit match is close to the burner ports.
4. Press in the control knob that operates the left burner and rotate counter-clockwise to High
position and burner should light immediately.
5. The other main control can now be turned on the High position and will light via crossover port.
6. Adjust burners to desired cooking settings.
SHUTDOWN INSTRUCTIONS
1. Turn control knobs clockwise to the OFF position.
2. Close valve at tank fully by turning clockwise.
3. Close lid.
Turn off LP supply at cylinder when appliance is not in use.

&22.,1**5$7(6
7KHEHVWWLPHWRµEXUQRII¶WKHFRRNLQJJUDWHVLVDIWHUHYHU\XVHDSSUR[PLQXWHV7KHJULOOLV
DOUHDG\KRWIURPFRRNLQJWKXVUHTXLULQJOHVVIXHOWRREWDLQQHFHVVDU\WHPSHUDWXUHIRUµEXUQRII¶
7RµEXUQRII¶RUKHDWFOHDQ\RXUJULOOWXUQWKHEXUQHUVWRKLJKHVWSRVLWLRQDQGUXQIRUPLQXWHV
ZLWKWKHOLGFORVHG7KHQWXUQRIIWKHEXUQHUVDQGXVHDZLUHEUXVKWRFOHDQH[FHVVIRRGUHVLGXH
from the grates.
The porcelain grates have an enamel finish (similar to glass) and should be handled with care
not to chip.
CARE AND MAINTENANCE
16
Ensure the grill is cool before cleaning and conducting maintenance and with the gas
supply turned off at the LP-Gas cylinder.
CAUTION
RECOMMENDED CLEANING SUPPLIES
Mild liquid dish soap, warm water, nylon cleaning pad, wire brush
DO NOT use cleaners that contain acid, mineral spirits or any abrasive substance.
OUTSIDE SURFACES
It is recommended to use only mild dish soap and hot water to clean grill and grill parts.
Rinse with warm water.
INSIDE BOTTOM PAN OF GRILL BODY
7RDYRLGIODUHXSVWKHERWWRPSDQRIWKHFRRNLQJER[VKRXOGEHNHSWFOHDQRQDUHJXODUEDVLV
Remove residue using a brush, scraper and/or cleaning pad. Wash with mild dish soap and warm
water. Rinse with warm water. Avoid water splashing into venturi tubes of burners.
HEAT TENTS
Clean residue with wire brush and wash with mild dish soap and warm water. Rinse with warm water.
GREASE CUP
Empty the grease cup and clean with mild dish soap and warm water on a regular basis.
&+(&.,1*7+()/$0(
)RUPD[LPXPIXHOHIILFLHQF\DQGFRRNLQJSHUIRUPDQFHIODPHVKRXOGEHDEOXH\HOORZFRORUDQGEH
between 1- 2 inches high.
To check the flame, view the flame through the match
OLJKWLQJKROHLQWKHVLGHRIWKHILUHER[

17
CARE AND MAINTENANCE
BURNER ASSEMBLY
REMOVING THE BURNER ASSEMBLY
1. Make sure all control knobs are in the OFF
position, LP tank valve is closed, and tank
is disconnected from regulator and removed
from grill.
2. Open lid and remove warming rack, cooking
grates, and heat tents.
3. Remove cotter pins at back of burners to detach burners from brackets.
6OLGHEXUQHUVRXWRIILUHER[DVVKRZQ
Warming Rack
Cooking Grates
Heat Tents
5. Detach ignition wire from ignitor as shown.
Burner
Bracket
Cotter Pin
Burner

18
CARE AND MAINTENANCE
CLEANING THE BURNER ASSEMBLY
– Make sure the grill is cool
1. Turn gas off at the control knobs and propane tank.
2. Disconnect LP-Gas cylinder from hose and regulator.
3. Remove warming rack, cooking grates and heat tents.
4. Detach burner by removing the cotter pins at the back of the burners to detach them from the brackets.
5. Detach ignition wire from electrode by hand only. DO NOT use pliers or any other tool as it may
damage the electrode or wire.
6. Lift burner slowly.
7. Ensure all burner ports are clear of clogs. Use of a pin or paper clip works well.
8. Ensure burner is free of any damage. If damage is found, replace with new burner.
9. Ensure the end of the burner and primary air screen are clear from insect nests, dirt or debris.
RE-INSTALLING THE BURNER
Ensure that gas valve orifices are correctly positioned inside burner inlet (venturi).
The use of a flashlight may be necessary to ensure the correct position.
,WLVUHFRPPHQGHGWRYLHZWKHFRUUHFWSRVLWLRQWKURXJKWKHILUHER[YHQWKROHVDVLOOXVWUDWHGEHORZ
WARNING
If the instructions above are not followed, a fire or explosion may result, possibly
causing serious bodily injury or death.
OTHER CARE AND MAINTENANCE
It is recommended that inspection and service on this appliance be conducted annually by a qualified
service person.
It is recommended that you regularly check that the outdoor cooking appliance area is clear and free
from combustible material, gasoline and other flammable vapors and liquids.
It is recommended that you regularly check that the flow of combustion and ventilation air is not
obstructed.
It is recommended that you regularly check that the ventilation openings of the cylinder enclosure
(cabinet) are free and clear from debris.
It is recommended that you regularly check and clean the burner/venturi tubes for insects and insect
nests. A clogged tube can lead to a fire beneath the grill.

PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
The burner will not
light using the
ignitor procedure
(weak or no spark
being generated).
1. The igniter electrode may be
covered with grease or residue.
2. The igniter electrode may have a
loose or disconnected wire.
3. Cracked or broken ignition
electrode.
4. Dead battery or faulty battery
connection.
1. Clean the ignitor electrode.
2. Check the connection
and reconnect any loose or
disconnected wires.
3. Replace ignition electrode (see
Replacement Parts List).
4. Perform any of the following:
a. Replace battery
b. Check to see if battery is
inserted correctly.
c. Check for any corrosion
around battery terminals.
d. Check wire connections as
stated above.
If you have any questions regarding the product, please call customer service at 1-800-963-0211,
8:00 a.m. – 6:00 p.m., EST, Monday – Thursday, 8:00 a.m. – 5:00 p.m., EST, Friday.
19
TROUBLESHOOTING
WARNING
'2127PL[ROGDQGQHZEDWWHULHV
'2127PL[DONDOLQHVWDQGDUG&DUERQ=LQFRUUHFKDUJHDEOH1LFNHO&DGPLXPEDWWHULHV
'2127GLVSRVHRIEDWWHULHVLQILUH,PSURSHUGLVSRVDOPD\FDXVHEDWWHULHVWROHDNRUH[SORGH
CARE AND MAINTENANCE
The electronic ignition requires 1 “AAA” alkaline battery, which is included.
1. The LP-Gas regulator is equipped
ZLWKDQH[FHVVIORZGHYLFHWKDW
allows sufficient gas to the burners
under normal circumstances. Rapid
changes in pressure can trigger this
device and prevent all but minimal
flow of gas to the burner, causing
a low flame and low heat output.
This is typically caused by the
LP-Gas cylinder valve being turned
open when one or more burner
valves (control knobs) is in the
open position causing a surge of
SUHVVXUHWKDWDFWLYDWHVWKHH[FHVV
flow device.
Low Heat. 1. Follow these steps:
a. Close the LP-Gas cylinder
valve on the top of the
cylinder.
b. Make sure the burner valves
are in the “OFF” position.
c. Slowly open the LP-Gas
cylinder valve and wait 10
seconds.
d. Follow the lighting
instructions.

20
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
The burner will not
light with a match. 1. Match not reaching burners (when holding match with hand).
2. Empty tank.
3. Poor connection between valve
regulator and LP cylinder
coupling.
4. Burner inlet blocked.
1. Use match holder found in
cabinet door.
2. Check fuel level and refill tank if
necessary.
3. Turn off grill knobs, close the LP
cylinder valve at top of cylinder
and check the connection
between the regulator valve
and cylinder coupling.
Disconnect and reconnect, if
necessary.
4. Clean the burner inlet (venturi)
and burner as described by the
Care and Maintenance section
in the Manual.
1. Tank valve not on or fully opened.
2. Empty tank.
3. Poor connection between valve
regulator and LP cylinder
coupling.
4. Burner inlet blocked.
No gas flow or an
obstructed gas flow. 1. Fully open tank valve by turning
counterclockwise .
2. Check fuel level and replace
fuel if necessary.
3. Turn off grill knobs, close the LP
cylinder valve at top of cylinder
and check the connection
between the regulator valve
and cylinder coupling.
Disconnect and reconnect, if
necessary.
4. Clean the burner inlet (venturi)
and burner as described by the
Care and Maintenance section
in the Manual.
1. Grease and/or residue build-up
RQKHDWWHQWVRULQILUHER[
([FHVVLYHGULSSLQJRIIDWRU
marinade from food.
3. Cooking temperature too high.
1. Clean the grill components.
2. Trim the fat from meat and use
non-oil based marinades.
3. Lower temperature accordingly.
Excessive
flare-ups.
