Master Spas Trainer 12 User manual

WATER TO THE EXTREME
swimming l tness l therapy l family fun l premium line of jetted swim spas
WATER TO THE EXTREME
by Master Spas
OWNER’S MANUAL

OWNER’S MANUAL
Welcome To Ultimate Relaxation!
Thank you for choosing your new swim spa built by Master Spas. Please read the entire Owner’s Manual
before installing and using your new swim spa. The goal of this manual is to provide you with safety
and operational information plus some tips that will help you enjoy your swim spa to its fullest.
At the time of print, this manual is accurate in its information. Master Spas reserves the right to change
or improve its product without prior notice. To check on updates or for other information, please visit
www.masterspas.com and follow the links to the customer service section.
Record Of Ownership
Name�������������������������������������������������������������������������������������
Address�����������������������������������������������������������������������������������
City ��������������������������������������������������������� State ������ Zip ��������������
Phone # (������)��������-���������� Date Purchased ������ /������ /�������
Model ��������������������������������� Serial #��������������������������������������������
Dealer Name ������������������������������������������������������������������������������
Service Tech Rep ���������������������������������������������������������������������������
*Serial Number Location
The serial number for you swim spa is located on the listing plate on the front skirting panel, on the
swim spa system control pack, and on the frame behind the right front removable corner. It will start
with “H” followed by a 5-digit number. Ex. H12000
1
DO NOT DIVE.
6927 Lincoln Parkway
Fort Wayne, Indiana 46804
800-860-7727
www.masterspas.com

TABLE OF CONTENTS
Important Safety Instructions ............................................................................................................. 3-10
Glossary of Swim Spa Terminology................................................................................................... 11-13
Electrical Installation Requirements.................................................................................................. 14-15
Wiring Schematic............................................................................................................................. 16
Site Preparation / General Guidelines.......................................................................................... 17-18
Installation Instructions .................................................................................................................... 19
Water Chemistry Terms .................................................................................................................... 20-21
Swim Spa Water Maintenance ............................................................................................................... 22
Water Quality Maintenance Start-Up ..................................................................................................... 23
The Advantages of Eco Pur™Mineral Purification ................................................................................... 24
Water Quality Maintenance Schedule..................................................................................................... 25
Swim Spa Water Maintenance Start-Up ............................................................................................ 26-28
Swim Spa Water Maintenance Trouble-Shooting Guide .......................................................................... 29
Why Chemicals are Important................................................................................................................ 30
Maintenance Recommendations ............................................................................................................ 32
Winterizing Your Swim Spa ................................................................................................................... 32
Swim Spa Specifications........................................................................................................................ 33
Optional Exercise Equipment ........................................................................................................... 34
Main Menus .................................................................................................................................... 35
Fill It Up........................................................................................................................................... 36
Swim Spa Behavior.......................................................................................................................... 37
Temperature & Temp Range............................................................................................................ 38
Mode – Ready and Rest................................................................................................................... 39
Mode – Show and Set Time-of-Day ................................................................................................. 40
Flip (Invert Display)........................................................................................................................... 40
Restricting Operation....................................................................................................................... 41
Unlocking........................................................................................................................................ 41
Hold (Standby)................................................................................................................................. 42
Adjusting Filtration .......................................................................................................................... 43
Preferences...................................................................................................................................... 44
General Messages............................................................................................................................ 45
Heater-Related Messages................................................................................................................. 46
Sensor-Related Messages................................................................................................................. 47
Miscellaneous Messages .................................................................................................................. 47
System-Related Messages ................................................................................................................ 48
Reminder Messages.................................................................................................................... 49-50
Deluxe Fusion Audio System............................................................................................................. 51-52
Swim Spa Trouble Shooting Guide.................................................................................................... 53-54
Regular Maintenance Procedures...................................................................................................... 55-56
Swim Spa Care and Maintenance Records......................................................................................... 57-60
2
DO NOT DIVE.

SAFETY INSTRUCTIONS
3
DO NOT DIVE.
SAVE THESE INSTRUCTIONS
Included with your new swim spa is a safety sign. The sign is for you and your guest’s protection
and is suitable for outdoor use in wet locations. The sign should be placed in a location visible
to all users of the swim spa.
Please take time to point out the physical location of the safety sign and the importance of the
safety precautions displayed on the safety sign to all of your guests. Remember, your safety and
the safety of anyone who enjoys the use of your swim spa is our utmost concern.
The sign should be mounted with screws or another type of permanent fastener. Additional or
replacement signs can be obtained from your dealer or direct from the factory.
INTRODUCTION
It’s time to relax! You now have your very own portable swim spa by Master Spas, Inc. By fully under-
standing the operation of each of the features of your new swim spa, you will be assured of many
years of hassle-free, hot water therapy and fun.
Your safety is of paramount importance to the Master Spas family. We urge you to read and become
thoroughly familiar with all safety aspects addressed in this manual.
Through reading and totally understanding the important information in your owner’s manual, you will
realize that you now own THE ULTIMATE RELAXATION MACHINE!

SAFETY INSTRUCTIONS
4
DO NOT DIVE.
IMPORTANT SAFETY INSTRUCTIONS
When installing and using this electrical equipment, basic safety precautions should be
observed including the following:
READ AND FOLLOW ALL
INSTRUCTIONS
WARNING – To reduce the risk of injury, do not permit children to use this product
unless they are closely supervised at all times.
A wire conductor is provided on this unit to connect a minimum 6 AWG (13.302mm2)
solid copper conductor between this unit and any metal equipment, metal enclosures of
electrical equipment, metal water pipe, or conduit within 5 feet (1.5m) of the unit
(For cord-connected/convertible units)
DANGER – Risk of injury.
a) Replace damaged cord immediately.
b) Do not bury cord.
c) Connect to a grounded, grounding type receptacle only.
(For units intended for indoor use only)
WARNING – For indoor use only. This unit is not intended for outdoor use.
(For units intended for outdoor use only)
WARNING – For outdoor use only. This unit is not intended for indoor use.

SAFETY INSTRUCTIONS
5
IMPORTANT SAFETY
INSTRUCTIONS (CONT.)
(For units with GFCI)
WARNING – This product is provided with a ground-fault circuit interrupter
located on the front panel of selected swim spas and on the power cord of 120
volt convertible swim spas. The GFCI must be tested before each use. With the
product operating, open the service door. When the product stops operating, this
merely indicates that the door is equipped with an electrical interlock. Next, push
the test button on the GFCI and close the service door. The product should not
operate. Now open the service door, push the reset button on the GFCI and close
the service door. The product should now operate normally. When the product
fails to operate in this manner, there is a ground current flowing indicating the
possibility of an electric shock. Disconnect the power until the fault has been iden-
tified and corrected.
DANGER – Risk of Accidental Drowning. Extreme caution must be exercised to prevent
unauthorized access by children. To avoid accidents, ensure that children cannot use
this swim spa unless they are supervised at all times.
DANGER – Risk of Injury. The suction fittings in this swim spa are sized to match the
specific water flow created by the pump. Should the need arise to replace the suction
fittings or the pump, be sure that the flow rates are compatible.
Never operate swim spa if the suction fittings are broken or missing. Never replace a suc-
tion fitting with one rated less than the flow rate marked on the original suction fitting.
DANGER – Risk of Electric Shock. Install at least 5 feet (1.5m) from all metal surfaces.
As an alternative, a swim spa may be installed within 5 feet of metal surfaces if each
metal surface is permanently connected by a minimum 8AWG (8.4mm2) solid copper
conductor to the wire connector on the terminal box that is provided for this purpose.
DANGER – Risk of Electric Shock. Do not permit any electric appliance, such as a light,
telephone, radio, or television, within 5 feet (1.5 m) of a swim spa.
WARNING – To reduce the risk of injury:
a) The water in a swim spa should never exceed 40˚C (104˚F). Water tempera-
tures between 38˚C (100˚F) and 40˚C are considered safe for a healthy adult.
Lower water temperatures are recommended for young children and when
swim spa use exceeds 10 minutes.
DO NOT DIVE.

SAFETY INSTRUCTIONS
6
DO NOT DIVE.
IMPORTANT SAFETY INSTRUCTIONS
(CONT.)
b) Since excessive water temperatures have a high potential for causing fetal
damage during the early months of pregnancy, pregnant or possibly pregnant
women should limit swim spa water temperatures to 38˚C (100˚F).
c) Before entering a swim spa, the user should measure the water temperature
since the tolerance of water temperature- regulating devices varies.
d) The use of alcohol, drugs, or medication before or during swim spa use may
lead to unconsciousness with the possibility of drowning.
e) Obese persons and persons with a history of heart disease, low or high blood
pressure, circulatory system problems, or diabetes should consult a physician
before using a swim spa.
f) Persons using medication should consult a physician before using a swim spa
since some medication may induce drowsiness while other medication may
affect heart rate, blood pressure, and circulation.
(For swim spas with a gas heater)
WARNING – Risk of Suffocation. This swim spa is equipped with a gas heater
and is intended for outdoor use only unless proper ventilation can be provided for
an indoor installation.
HYPERTHERMIA
Hyperthermia occurs when the internal temperature of the body reaches a level
several degrees above the normal body temperature of 98.6° F.
THE SYMPTOMS OF HYPERTHERMIA INCLUDE:
• Dizziness • Fainting • Drowsiness • Lethargy
• Increase in Internal Body Temperature
THE EFFECTS OF HYPERTHERMIA INCLUDE:
Unawareness of Impending Hazard • Failure to Perceive Heat • Failure to
Recognize the Need to Exit Swim Spa • Physical Inability to Exit Swim Spa •
Fetal Damage in Pregnant Women • Unconsciousness Resulting in a Danger of
Drowning

SAFETY INSTRUCTIONS
7
DO NOT DIVE.
IMPORTANT SAFETY INSTRUCTIONS
(CONT.)
DANGER – To reduce the risk of injury to persons, do not remove the suction grate.
Suction through drains and skimmers is powerful when the jets in the swim spa are in
use. Damaged covers can be hazardous to small children and adults with long hair.
Should any part of the body be drawn into these fittings, turn off the swim spa imme-
diately. As a precaution, long hair should not be allowed to float in the swim spa.
WARNING – Install the swim spa so that water can be easily drained out of the com-
partment containing electrical components so as not to damage equipment. When
installing the swim spa make sure to allow for an adequate drainage system to deal
with any overflow water. Please allow for at least 2 feet of clearance around the
perimeter of the swim spa to provide enough room to access for servicing. Contact
your local dealer for their specific requirements.
WARNING – The swim spa should be covered with an approved locking cover when not
in use, to prevent unauthorized entry and injuries.
WARNING – People with infections, sores or the like should not use the swim spa.
Warm and hot water temperatures may allow the growth of infectious bacteria if not
properly disinfected.
CAUTION – Safe temperatures for swimming or aquatic exercise is around 80˚F.
CAUTION – Risk of Electrical Shock. Do not leave audio compartment open.
Audio controls are not to be operated while inside the swim spa.
CAUTION – Replace components only with identical components.
WARNING – Risk of Electric Shock. Do not connect any auxiliary components (for
example, additional speakers, headphones, additional audio/ video components etc.)
to the system. These units are not provided with an outdoor antenna.
Do not service this product yourself as opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
If the power supply cord(s) are damaged, water is entering the speaker, audio
compartment, or any other component in the electrical equipment compartment
area, the protective shield is showing signs of deterioration, or there are signs of
other potentially hazardous damage to the unit, turn off the circuit breaker from
the wall and refer servicing to qualified personnel.

SAFETY INSTRUCTIONS
8
DO NOT DIVE.
IMPORTANT SAFETY INSTRUCTIONS
(CONT.)
The unit should be subjected to periodic routine maintenance once every quarter to
make sure that the it is operating properly.
DANGER – Risk of Electric Shock. A green colored terminal or a terminal marked G,
GR, Ground, Grounding or the symbol shown in Figure 14.1 of UL 1563 is located
inside the supply terminal box or compartment. To reduce the risk of electric shock,
this terminal must be connected to the grounding means provided in the electric supply
service panel with a continuous copper wire equivalent in size to the circuit conductors
supplying this equipment.
At least two lugs marked “Bonding Lugs” are provided on the external surface or on
the inside of the supply terminal box or compartment. To reduce the risk of electric
shock, connect the local common bonding grid in the area of the swim spa to these
terminals with an insulated or bare copper conductor not smaller than 8AWG.
All field installed metal components such as rails, ladders, drains, or other similar hard-
ware within 3m of the swim spa shall be bonded to the equipment grounding bus
with copper conductors not smaller than 8AWG.
SAVE THESE INSTRUCTIONS

SAFETY INSTRUCTIONS
9
DO NOT DIVE.
WARNING: CHILDREN SHOULD NOT USE SWIM SPAS OR HOT TUBS WITHOUT ADULT SUPERVI-
SION
AVERTISSEMENT: NE PAS LAISSER LES ENFANTS UTILISER UNE CUVE DE RELAXATION
SANS SURVEILLANCE
WARNING: DO NOT USE SWIM SPAS OR HOT TUBS UNLESS ALL SUCTION GUARDS ARE
INSTALLED TO PREVENT BODY AND HAIR ENTRAPMENT.
AVERTISSEMENT: POUR ÉVITER QUE LES CHEVEUX OU UNE PARTIE DU CORPS PUISSENT
ÊTRE ASPIRES, NE PAS UTILISER UNE CUVE DE RELAXATION SI LES GRILLES DI PRISE D’ASPIRATION NE
SONT PAS TOUTES EN PLACE
WARNING: PEOPLE USING MEDICATIONS AND/OR HAVING AN ADVERSE MEDICAL HISTORY
SHOULD CONSULT A PHYSICIAN BEFORE USING A SWIM SPA OR HOT TUB.
AVERTISSEMENT: LES PERSONNES QUI PRENNENT DES MÉDICAMENTS OU ONT
DES PROBLÉMES DE SANTÉ DEVRAIENT CONSULTER UN MÉDECIN AVANT D’UTILISER UNE CUVE
DE RELAXATION
WARNING: PEOPLE WITH INFECTIOUS DISEASES SHOULD NOT USE A SWIM SPA OR HOT TUB
AVERTISSEMENT: LES PERSONNES ATTEINTES DE MALADIES INFECTIEUSES NE DEVRAIENT
PAS UTILISER UNE CUVE DE RELAXATION
WARNING: TO AVOID INJURY EXERCISE CARE WHEN ENTERING OR EXITING THE SWIM SPA OR
HOT TUB.
AVERTISSEMENT: POUR ÉVITER DES BLESSURES, USER DE PRUDENCE EN ENTRANT DANS
UNE CUVE DE RELAXATION ET EN SORTANT
WARNING: DO NOT USE DRUGS OR ALCOHOL BEFORE OR DURING THE USE OF A SWIM SPA
OR HOT TUB TO AVOID UNCONSCIOUSNESS AND POSSIBLE DROWNING
AVERTISSEMENT: POUR ÉVITER L’ÉVANOUISSEMENT ET LA NOYADE ÉVENTUELLE, NE
PRENDE NI DROGUE NI ALCOOL AVANT D’UTILISER UNE CUVE DE RELAXATION NI QUAND ON S’Y
TROUVE
WARNING: PREGNANT OR POSSIBLY PREGNANT WOMEN SHOULD CONSULT A PHYSICIAN
BEFORE USING A SWIM SPA OR HOT TUB.
AVERTISSEMENT: LES FEMMES ENCEINTES, QUE LEUR GROSSESSE SOIT CONFIRMÉE OU
NON, DEVRAIENT CONSULTER UN MÉDECIN AVANT D’UTILISER UNE CUVE DE RELAXATION
WARNING: WATER TEMPERATURE IN EXCESS OF 38˚C MAY BE INJURIOUS TO YOUR HEALTH
AVERTISSEMENT: IL PEUT ÊTRE DANGEREUX POUR LA SANTÉ DE SE PLONGER DANS DE
L’EAU A PLUS DE 38˚C
WARNING: BEFORE ENTERING THE SWIM SPA OR HOT TUB MEASURE THE WATER TEMPERA-
TURE WITH AN ACCURATE THERMOMETER
AVERTISSEMENT: AVANT D’UTILISER UNE CUVE DE RELAXATION MESURER LA
TEMPÉRATURE DE L’EAU À L’AIDE D’UN THERMOMÉTRE PRÉCIS

SAFETY INSTRUCTIONS
10
DO NOT DIVE.
WARNING: DO NOT USE A SWIM SPA OR HOT TUB IMMEDIATELY FOLLOWING STRENUOUS
EXERCISE
AVERTISSEMENT: NE PAS UTILISER UNE CUVE DE RELAXATION IMMÉDIATEMENT APRÉS
UN EXERCISE FATIGANT
WARNING: PROLONGED IMMERSION IN A SWIM SPA OR HOT TUB MAY BE INJUROUS TO
YOUR HEALTH
AVERTISSEMENT: L’UTILISATION PROLONGÉE D’UNE CUVE DE RELAXATION PEUT ÊTRE
DANGEREUSE POUR LA SANTÉ
WARNING: DO NOT PERMIT ELECTRIC APPLIANCES (SUCH AS LIGHT, TELEPHONE, RADIO, OR
TELEVISION) WITHIN 1.5 M OF THIS SWIM SPA OR HOT TUB
AVERTISSEMENT: NE PAS PLACER D’APPAREIL ÉLECTRIQUE (LUMINAIRE, TÉLÉPHONE,
RADIO, TÉLÉVISEUR, ETC) À MOINS DE 1.5 M DE CETTE CUVE DE RELAXATION
CAUTION: MAINTAIN WATER CHEMISTRY IN ACCORDANCE WITH MANUFACTURER’S
INSTRUCTION
ATTENTION: LA TENEUR DE L’EAU EN MATIÉRES DISSOUTES DOIT ÊTRE CONFORME AUX
DIRECTIVES DU FABRICANT
Hyperthermia occurs when the internal temperature of the body reaches a level several degrees above
the normal body temperature of 37˚C. The symtoms of hyperthermia include drowsiness, lethargy, and
an increase in the internal temperature of the body. The effects of hyperthermia include
(a) unawareness of impending hazard;
(b) failure to perceive heat;
(c) failure to recognize the need to exit swim spa;
(d) physical inability to exit swim spa;
(e) fetal damage in pregnant women; and
(f) unconsciousness and danger of drowning.
WARNING: THE USE OF ALCOHOL OR DRUGS CAN GREATLY INCREASE THE RISK OF FATAL
HYPERTHERMIA IN HOT TUBS AND SWIM SPAS
LA CONSOMMATION D’ALCOOL OU DE DROGUE AUGMENTE CONSIDÉRABLEMENT LES
RISQUES D’HYPERTHERMIE MORTELLE DANS UNE CUVE DE RELAXATION.

GLOSSARY OF SWIM SPA TERMINOLOGY
1. THERAPY JETS
Your new swim spa features a variety of jet styles. All jets, regardless of style return
the water to the swim spa. Air is mixed with the water by using the air controls
creating a gentle to most vigorous massage. Water flow is adjusted by simply turn-
ing the outer face of the jet.
2. JET DIVERTER VALVE
Located on the topside of the swim spa, this valve physically diverts the flow
of water from one jet zone of the swim spa to another jet zone. Be sure that
no sand or particles are brought into the swim spa as they can cause the
diverter to seize up. It is best to turn the diverter valve only when the pump
is turned off.
3. AIR CONTROL VALVES
These are located around the top of your swim spa. You may increase or
decrease the force of your jets by opening or closing the air control valves.
Typically, one dial controls the air to water ratio and mix to one group of
jets. When not in use the air controls should be kept in the closed position,
as air bubbles tend to cool the water.
4. TOPSIDE CONTROL PANEL
You may safely control all functions from inside or outside your swim spa using the
Topside Control Panel. This Panel is used to control the water temperature, pumps, the swim spa
light, automatic filtration cycles and other advanced functions. The digital display will give you
a constant temperature readout and will notify you in case of certain malfunctions. Several
user programmable functions are also available.
5. SWIM JETS
The swim jets are operated by directing the water flow from the pumps to the jets located in the
swim end of the swim spa by turning the diverter valves.
6. PERSONAL REMOTE CONTROL
Your swim spa has an additional remote which allows the user to control the
stand up jet therapy cove. By pressing the control one time, you will activate
the pump. Press the pad again to turn the pump off.
7. EQUIPMENT ACCESS PANEL
Located behind the side panel below the Topside Control Panel, this area houses the major
components responsible for the swim spas operation. Those components include the pumps,
heater, control panel box, Ozonator, and LED light system. Pump and equipment placement
may vary by model.
11
DO NOT DIVE.

GLOSSARY OF SWIM SPA TERMINOLOGY
8. ACCESS PANELS
These are located on all four sides of the swim spa. All of the panels are removable should service
be required.
12
DO NOT DIVE.
NOTE: Note: The above drawing illustrates the panel placement on the swim spa.
WARNING: Do Not Remove Access Panels Without Turning Off Power To The Swim Spa.
9. DRAINING YOUR SWIM SPA
Due to the physical size of the swim spa, we recommend draining your swim spa with a
submersable sump pump. Draining your swim spa with a conventional swim spa drain is not a
reasonable option.
10. WEIR GATE
The weir gate is the horizontal door located in front of the filters that trap debris in the filter area.
11. SWIM SPA LIGHT
Your swim spa lights are designed for safety and are located on the interior walls of your swim
spa. The on/off switch is located on the topside control panel.
12. EQUIPMENT CONTROL SYSTEM
This houses the wiring and electrical components necessary to operate the swim spa.
13. SWIM SPA HEATER
This element is an electric heater housed in a stainless steel tube. It is thermostatically controlled
and equipped with a high-limit temperature safety shut-off sensor. The high-limit sensor cannot
be reset until the temperature within the heater assembly drops several degrees below the shut-off
temperature of 108° - 110° F. Should the high-limit switch trip repeatedly, contact your dealer or
qualified service representative to diagnose the problem. Your swim spa will heat approximately
1˚- 2˚ per hour, on average when the cover is closed. These times may vary and the swim spa
should have a cover installed.
Panel “B”
Panel “H” Panel “G” Panel “F”
Panel “E”
Panel “A”
Panel “C” Panel “D”

GLOSSARY OF SWIM SPA TERMINOLOGY
13
DO NOT DIVE.
14. SLICE VALVES
These valves are used by service personnel to shut off water to the heat-
er, main pump system and secondary pump system so that the water
does not need to be drained should the swim spa require service.
*NOTE: Slice valves must be completely open during normal
operation.
15. MAIN PUMP
The main pump produces water flow through the jets and has a high and low speed. Low speed
will produce efficient water circulation during filtration and gentle jet action. High speed should be
used for maximum jet action. The water flow may be directed to different areas of the swim spa
depending on the position of the diverter controls.
16. SECONDARY PUMP
This pump produces water flow through the stand up jet system.It also supplies water flow
to the swim jets or therapy jets depending on the position of the diverter valve. The second
pump can be controlled by the topside panel and also the personal remote mounted on the
surface of the swim spa.
17. PUMP UNION
These are used by service personnel to easily service the pumps.
18. HEATER UNION
These are used by service personnel to easily service the heater.
19. OZONATOR
Your onzonator will operate in conjunction with the filter system. Ozone is a powerful gas that
oxidizes contaminates in the water.

ELECTRICAL INSTALLATION REQUIREMENTS
14
DO NOT DIVE.
ELECTRICAL INSTALLATION REQUIREMENTS
!! TRAINER 12, 14, 17 !!
HAVE YOUR ELECTRICIAN READ THE FOLLOWING INFORMATION
BEFORE INSTALLATION BEGINS
Electrical connections made improperly, or the use of wire gauge sizes for incurring
power which are too small, may continually blow fuses in the electrical equipment
box, may damage the internal electrical controls and components, may be unsafe and
in any case will void your warranty.
It is the responsibility of the swim spa owner to ensure that electrical connections are
made by a qualified electrician in accordance with the National Electrical Code and any
local and state electrical codes in force at the time of installation.
These connections must be made in accordance with the wiring diagrams found inside
the control box. This equipment has been designed to operate on 60Hz.
alternating current only, 240 volts are required. Make sure that power is not applied
while performing any electrical installation. A copper bonding lug has been provided
on the electrical equipment pack to allow connection to local ground points. The
ground wire must be at least 8 AWG copper wire and must be connected securely to a
grounded metal structure such as a cold water pipe. All Master Spas equipment packs
are wired for 240 VAC only. The only electrical supply for your swim spa must include
a 50 AMP switch or circuit breaker to open all non-grounded supply conductors to
comply with section 422-20 of the National Electrical Code. The disconnect must
be readily accessible to the swim spa occupants, but installed at least five feet from the
swim spa. A Ground-Fault Circuit Interrupter (GFCI) must be used to comply with
section 680-42 of the National Electrical Code. A ground fault is a current leak from
any one of the supply conductors to ground. A GFCI is designed to automatically shut
off power to a piece of equipment when a ground fault is detected.
Power hook-up to the swim spa must be 240 volt 3 wire plus ground (6 AWG copper)
8 AWG copper ground.
Route the cable into the equipment area for final hook-up to terminals inside the
control panel. The swim spa must be hooked up to a “dedicated” 240 volt, 50 amp
breaker and GFCI. The term “dedicated” means the electrical circuit for the swim spa
is not being used for any other electrical items (patio lights, appliances, garage circuits,
etc.). If the swim spa is connected to a non-dedicated circuit, overloading will result
in “nuisance tripping” which requires resetting of the breaker switch at the house
electrical panel.
Rev. 11/11
Permanently Connected Equipment Assembly with Pump(s), Heaters, Luminaine, Ozone, Swim Spa Side
Control(s), Pump shut off device, and Audio/Video Components.
Note: Some of the above components may be optional or not available with every swim spa model.

15
DO NOT DIVE.
ELECTRICAL INSTALLATION REQUIREMENTS
ELECTRICAL INSTALLATION REQUIREMENTS
!! TRAINER 19 !!
HAVE YOUR ELECTRICIAN READ THE FOLLOWING INFORMATION
BEFORE INSTALLATION BEGINS
The Trainer 19 swim spa requires two separate electrical power supplies.
A 50 amp dedicated electrical service using #6 AWG copper wire with #8 AWG
ground wire should be ran to the Spa Control Pack in the swim spa. This electrical
supply should have an external GFCI installed. (See electrical hook-up diagram on page
16).
A 30 amp dedicated electrical service using #8 AWG copper wire with #10 AWG
ground wire should be ran to the Swim Control Pack in the swim spa. This electrical
supply must be protected by an external GFCI (see electrical hook-up diagram
on page 16).

16
DO NOT DIVE.
WIRING SCHEMATIC
WIRING FOR MODELS THAT REQUIRE A SEPARATE GFCI BREAKER
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
50 5050
TEST
50
1
2
3
4
5
WHITE (NEUTRAL)
BLACK (HOT)
RED (HOT)
GREEN (GROUND)
Instruments
Balboa
Incorporated
Wire Key
House Breaker Box
G.F.C.I Breaker Box
Spa System Box
Green (Ground)
Red (Hot)
Black (Hot)
White (Neutral)
NOTE: For a 240 V
dedicated hook-up, the
white neutral wire is
not required between
the G.F.C.I. and the
system box.
GRN
GRN (GROUND)
RED (HOT)
BLK (HOT)
BLK (HOT)
RED (HOT)
RED (HOT)
WHT (NEUTRAL)
WHT
WHT
BLK (HOT)
GRN (GROUND)
TB1
IDF00007.mac 6/17/97
* Actual wiring of GFCI will vary by manufacturer of GFCI. The GFCI shown is a Square D. Improper
wiring of GFCI may result in permanent damage to swim spa system box. Repair / replacement of
swim spa system box is not covered under warranty when damage results from improper wiring.
Junction Box

SITE PREPARATION / GENERAL GUIDELINES
Swim spa installation is simple when properly planned. It is important that you read the following
information carefully and consult with your Master Spas dealer.
1. Access - The actual dimensions of your new swim spa will determine the amount of space that is
needed in moving the swim spa from curbside to its final installation area. Be sure to measure side
yard dimensions, gates or doors and vertical obstructions such as roof overhangs and overhead
cables. Any other space limiting obstacles such as trees or shrubs must be evaluated.
2. Surface/Pad Requirements - When your new swim spa is filled with water and bathers, it may weigh
as much as several tons. It is imperative that the base beneath the swim spa can support the entire
weight. The swim spa must be on a uniformly firm, continuous, and level surface. The recommended
foundation is a concrete pad with a minimum thickness of four (4) inches with steel reinforcement
bars crossed throughout the pad.
IMPORTANT
Be sure to locate your swim spa so that the equipment remains above grade and is not subject
to flooding.
The equipment side(s) of the swim spa must be accessible in the event that future service is needed. In
the event that service is required, your dealer will need at least 2 feet of clearance around the perimeter
of the swim spa. Periodical maintenance checks require entry into the equipment bay. When possible, it
is wise planning for the future to leave access, to all sides of the swim spa in the event your swim spas
plumbing requires maintenance. Your swim spa warranty does not cover the cost of providing access
for service.
17
DO NOT DIVE.

SITE PREPARATION / GENERAL GUIDELINES
GENERAL CONSIDERATIONS FOR OUTDOOR INSTALLATION
Proper planning will increase your total enjoyment factor with your new swim spa. Listed below are
some additional items to consider when planning your installation.
• How swim spa will complement landscaping and vice versa
• View from inside swim spa and view of swim spa from inside of home
• Exposure to sunlight and shading from trees
• Privacy
• Getting to swim spa from house and return
• Proximity to dressing rooms and bathrooms
• Storage for swim spa chemicals
• Local building codes (if applicable)
• Power cable
NOTE: The Swim Spa is to be used in private, residential use only. Operating an Swim Spa for
commercial use will void the warranty.
18
DO NOT DIVE.
