Master View CS-228 User manual

User Manual
CS-228
2005-11-29

FCC Information
Note: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate
radio frequency energy, and if not installed and used in accordance with the
instruction manual, may cause interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
!Reorient or relocate the receiving antenna.
!Increase the separation between the equipment and receiver.
!Connect the equipment into an outlet on a circuit different from that which
the receiver is connected.
!Consult the dealer or an experienced radio/television technician for help.
All contents of this package, including products, packing materials and docu-
mentation comply with RoHS.
2005-11-29
CS-228 User Manual
ii

User Notice
All information, documentation, and specifications contained in this manual
are subject to change without prior notification by the manufacturer. The
manufacturer makes no representations or warranties, either expressed or
implied, with respect to the contents hereof and specifically disclaims any
warranties as to merchantability or fitness for any particular purpose. Any of
the manufacturer’s software described in this manual is sold or licensed ‘as
is’. Should the programs prove defective following their purchase, the buyer
(and not the manufacturer, its distributor, or its dealer), assumes the entire
cost of all necessary servicing, repair and any incidental or consequential
damages resulting from any defect in the software.
The manufacturer of this system is not responsible for any radio and/or TV
interference caused by unauthorized modifications to this device. It is the
responsibility of the user to correct such interference.
The manufacturer is not responsible for any damage incurred in the operation
of this system if the correct operational voltage setting was not selected prior
to operation. PLEASE VERIFY THAT THE VOLTAGE SETTING IS
CORRECT BEFORE USE.
2005-11-29
CS-228 User Manual
iii

Safety Instructions
General
!Read all of these instructions. Save them for future reference.
!Follow all warnings and instructions marked on the device.
!Do not place the device on any unstable surface (cart, stand, table, etc.). If
the device falls, serious damage will result.
!Do not use the device near water.
!Do not place the device near, or over, radiators or heat registers.
!The device cabinet is provided with slots and openings to allow for
adequate ventilation. To ensure reliable operation, and to protect against
overheating, these openings must never be blocked or covered.
!The device should never be placed on a soft surface (bed, sofa, rug, etc.)
as this will block its ventilation openings. Likewise, the device should not
be placed in a built in enclosure unless adequate ventilation has been
provided.
!Never spill liquid of any kind on the device.
!Unplug the device from the wall outlet before cleaning. Do not use liquid
or aerosol cleaners. Use a damp cloth for cleaning.
!The device should be operated from the type of power source indicated on
the marking label. If you are not sure of the type of power available,
consult your dealer or local power company.
!The device is equipped with a 3-wire grounding type plug. This is a safety
feature. If you are unable to insert the plug into the outlet, contact your
electrician to replace your obsolete outlet. Do not attempt to defeat the
purpose of the grounding-type plug. Always follow your local/national
wiring codes.
!Do not allow anything to rest on the power cord or cables. Route the
power cord and cables so that they cannot be stepped on or tripped over.
!If an extension cord is used with this device make sure that the total of the
ampere ratings of all products used on this cord does not exceed the
extension cord ampere rating. Make sure that the total of all products
plugged into the wall outlet does not exceed 15 amperes.
2005-11-29
CS-228 User Manual
iv

!To help protect your system from sudden, transient increases and
decreases in electrical power, use a surge suppressor, line conditioner, or
un-interruptible power supply (UPS).
!Position system cables and power cables carefully; be sure that nothing
rests on any cables.
!When connecting or disconnecting power to hot-pluggable power
supplies, observe the following guidelines:
!Install the power supply before connecting the power cable to the
power supply.
!Unplug the power cable before removing the power supply.
!If the system has multiple sources of power, disconnect power from
the system by unplugging all power cables from the power supplies.
!Never push objects of any kind into or through cabinet slots. They may
touch dangerous voltage points or short out parts resulting in a risk of fire
or electrical shock.
!Do not attempt to service the device yourself. Refer all servicing to
qualified service personnel.
!If the following conditions occur, unplug the device from the wall outlet
and bring it to qualified service personnel for repair.
!The power cord or plug has become damaged or frayed.
!Liquid has been spilled into the device.
!The device has been exposed to rain or water.
!The device has been dropped, or the cabinet has been damaged.
!The device exhibits a distinct change in performance, indicating a need
for service.
!The device does not operate normally when the operating instructions
are followed.
!Only adjust those controls that are covered in the operating instructions.
Improper adjustment of other controls may result in damage that will
require extensive work by a qualified technician to repair.
2005-11-29
CS-228 User Manual
v

Rack Mounting
!Before working on the rack, make sure that the stabilizers are secured to
the rack, extended to the floor, and that the full weight of the rack rests on
the floor. Install front and side stabilizers on a single rack or front
stabilizers for joined multiple racks before working on the rack.
!Always load the rack from the bottom up, and load the heaviest item in the
rack first.
!Make sure that the rack is level and stable before extending a device from
the rack.
!Use caution when pressing the device rail release latches and sliding a
device into or out of a rack; the slide rails can pinch your fingers.
!After a device is inserted into the rack, carefully extend the rail into a
locking position, and then slide the device into the rack.
!Do not overload the AC supply branch circuit that provides power to the
rack. The total rack load should not exceed 80 percent of the branch
circuit rating.
!Ensure that proper airflow is provided to devices in the rack.
!Do not step on or stand on any device when servicing other devices in a
rack.
2005-11-29
CS-228 User Manual
vi

Package Contents
The complete CS-228 package consists of:
!1 CS-228 KVM Switch with Stacking Pads
!1 Power Adapter
!1 Rack Mounting Kit
!1 User Manual
Check to make sure that all the components are present and that nothing got
damaged in shipping. If you encounter a problem, contact your dealer.
Read this manual thoroughly and follow the installation and operation
procedures carefully to prevent any damage to the unit, and/or any of the
devices connected to it.
Manual Part No. PAPE-0176-1PBG
Printing Date: 11/2005
All brand names and trademarks are the registered property of their respective owners.
2005-11-29
CS-228 User Manual
vii

Contents
FCC Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . ii
User Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iii
Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
Rack Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . vi
Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
About This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . x
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x
Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x
Chapter 1
Introduction
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Hardware Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Consoles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Computers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Front View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Rear View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Chapter 2
Hardware Setup
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Stacking and Rack Mounting . . . . . . . . . . . . . . . . . . . . . . . 7
Stacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Rack Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Single Stage Installation . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Two Stage Installation . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Basic Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Hot Plugging . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Powering Off and Restarting . . . . . . . . . . . . . . . . . . . . 14
Port Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2005-11-29
CS-228 User Manual
viii

Chapter 3
OSD Operation
OSD Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Port Numbering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
OSD Main Menu Headings . . . . . . . . . . . . . . . . . . . . . . . 16
OSD Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
OSD Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
F1 HELP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
F2 EDIT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
F3 LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
F4 SCAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
F5 ADM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
F6 SET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
F7 QV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Appendix
Computer Connection Tables . . . . . . . . . . . . . . . . . . . . . . 27
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
OSD Factory Default Settings . . . . . . . . . . . . . . . . . . . . . . 29
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
2005-11-29
CS-228 User Manual
ix

About This Manual
This User Manual is provided to help you get the most from your CS-228
system. It covers all aspects of installation, configuration and operation. An
overview of the information found in the manual is provided below.
Overview
Chapter 1, Introduction, introduces you to the CS-228 System. Its purpose,
features and benefits are presented, and its front and back panel components are
described.
Chapter 2, Installation, describes stacking and rack mounting, how to set up
a single or multiple stage installation, and the basic operation of the CS-228.
Chapter 3, OSD Operation, provides a complete description of the
CS-228’s OSD (On Screen Display), and how to work with it.
An Appendix at the end of the manual provides specifications and other
technical information regarding the CS-228.
Conventions
This manual uses the following typographical conventions:
Courier Indicates text that you should key in.
[ ] Indicates keys you should press. For example, [Enter] means
to press the Enter key. If keys need to be chorded, they
appear together in the same bracket with a plus sign between
them: [Ctrl+Alt].
1. Numbered lists represent procedures with sequential steps.
!Bullet lists provide information, but do not involve sequential
steps.
→Indicates movement through a series. For example, Start →
Run means to open the Start menu, and then select Run.
Indicates critical information.
2005-11-29
CS-228 User Manual
x

Chapter 1.
Introduction
Overview
The CS-228 KVM Switch is a control unit that allows two independent
keyboard, mouse, and monitor consoles to access eight computers, either
independently or on a multi-user shared basis. A CS-228 can control up to 8
computers directly. By cascading it down to a CS-138A, CS-9138, CS-128A,
or CS-124A, up to 9 units (the CS-228 plus eight cascaded ones), can control
up to 64 computers.
Setup is fast and easy - plugging cables into their appropriate ports is all that
is entailed. There are no installation routines or complex software programs
to configure. Because the CS-228 intercepts keyboard input directly, it works
on most hardware platforms and with most operating systems.
The CS-228 provides a convenient OSD (On Screen Display) function that
allows either of the two consoles to access any computer connected to the
system by means of an on screen, menu-driven interface. A powerful Quick
View Scan feature allows auto scanning and monitoring of the activities of all
operating computers on the installation one-by-one.
For security, two level password protection (administrator and user), prevents
unauthorized access to the computers. Responding to the growing use of
audio input/output in the workstation space, the CS-228 has been designed
with built in microphone and speaker support, as well.
There is no better way to save time and money than with a CS-228
installation. By allowing all the computers to be managed from two separate
consoles, a CS-228 installation: (1) eliminates the expense of having to
purchase a separate keyboard, monitor, and mouse for each computer; (2)
saves all the space those extra components would take up; (3) saves on
energy costs; and (4) eliminates the inconvenience and wasted effort
involved in constantly moving around from one computer to another, while
allowing a single user to access the computers from several different
convenient locations, or for two users to share them.
2005-11-29
1

Features
!2 Consoles Control 8 Computers
!One or Two Users Can Operate Up To 64 Computers (via cascade to
CS-138A, CS-9138, CS-128A, or CS-124A) At The Same Time
!Each Console Has Its Own Access Control
!Port Selection via OSD (On Screen Display)
!Auto Expansion of The OSD Port List For Cascaded Installations
!OSD Automatically Adjusts to Resolution Changes
!Hot Pluggable - Add or Remove any Computer without Powering Off the
Switch
!Auto Scan Function Provides Easy Monitoring of All Computers
!Supports 1920 x 1440 Resolution; DDC2 (Display Data Channel 2)
!PS/2 Compatible Mouse Support: Microsoft Intellimouse Pro, Logitech
FirstMouse, FirstMouse+, Support*
!Audio (Microphone and Speaker) Support
!Special Design For Easy Stacking
*1. PS/2 compatible mouse support is for three button (wheel) mice
2. The Logitech Mouse Ware program’s Change Device procedure
does not work on Microsoft NT systems.
2005-11-29
CS-228 User Manual
2

Hardware Requirements
Consoles
!A VGA, SVGA, or Multisync monitor capable of the highest resolution
that you will be using on any computer in the installation.
Note: If a monitor switches to a computer using a resolution that is
higher than the resolution that the monitor can support, serious
damage to the monitor may result.
!A PS/2 style mouse
!A PS/2 style keyboard
!Microphone and Speakers (Optional)
Computers
The following equipment must be installed on each computer:
!A VGA, SVGA or Multisync card
!Either a 6-pin mini-DIN (PS/2 style), or DB-9 (standard serial), mouse port.
!Either a 6-pin mini-DIN (PS/2 style) keyboard port with +5V DC on pin 4
and Ground on pin 3, or a 5-pin DIN (AT style) keyboard port with +5V
DC on pin 5 and ground on pin 4
2005-11-29
1. Introduction
3

Cables
Use of substandard cables may damage the connected devices or degrade
overall performance. For optimum signal integrity and to simplify the layout,
we strongly recommend that you use the following high quality CS Custom
Cable sets:
Cable Type Length Part Number
PS/2 KVM 1.8m 2L-1701P
PS/2 KVM 3m 2L-1703P
PS/2 KVM 5m 2L-1705P
PS/2 KVM 10m 2L-1710P
Note: 1. If your computer uses a standard AT style keyboard socket you will
need to purchase a PS/2-to-AT keyboard adapter in order to plug
the cable into the computer’s keyboard port.
2. If your computer uses a standard 9 pin serial port for the mouse,
you will need to purchase a PS/2-to-Serial mouse adapter in order
to plug the cable into the computer’s serial port.
2005-11-29
CS-228 User Manual
4

Front View
No. Component Description
1Port LEDs !An On Line LED lights ORANGE to indicate that the
computer attached to its corresponding port is up and
running. If the LED is flashing, it indicates that the Port is
being used for Cascading to another switch.
!A Selected LED lights GREEN to indicate that the
computer attached to its corresponding port is the one
that has the KVM focus.
2K/M Reset If the keyboard and mouse get stuck and need to be reset,
press this semi-recessed switch in with a thin object, such
as a paper clip or a ballpoint pen.
3Power LED Lights BLUE to indicate that the unit is turned on and
receiving power.
1
23
2005-11-29
1. Introduction
5

Rear View
No. Component Description
1Power Switch This is a standard rocker switch that powers the unit On
and Off.
2Power Jack The power adapter cable plugs in here.
3Console 2
Section
The microphone, speakers, monitor, keyboard and mouse
that belong to Console 2 plug in here.
4Console 1
Section
The microphone, speakers, monitor, keyboard and mouse
that belong to Console 1 plug in here.
5KVM Port
Section
Use CS Custom Cables (as specified in the Cables section
on p. 4), to connect any available port to the computers you
are installing, or to cascade second stage CS-228 KVM
switches.
1
3 42 5
2005-11-29
CS-228 User Manual
6

Chapter 2.
Hardware Setup
Before You Begin
Stacking and Rack Mounting
Stacking
1. The unit comes with the stacking brackets already attached. Note that
there is a top and bottom half to each bracket. The top half has a convex
surface; the bottom half has a concave surface.
2. Line up the four bottom brackets of the top unit with the four top brackets
of the bottom unit; then fit the top unit down onto the bottom unit.
1. Important safety information regarding the placement of this
device is provided on p. iv. Please review it before proceeding.
2. Make sure that power to all the devices you will be connecting
up have been turned off. You must unplug the power cords of
any computers that have the Keyboard Power On function.
2005-11-29
7

Rack Mounting
To rack mount the unit do the following:
1. First remove the stacking brackets by unscrewing them from the unit, as
shown in the diagram below:
2. Screw the mounting brackets into the sides of the unit, as shown in the
diagram below
3. Slide the unit into the rack and secure it to the rack.
2005-11-29
CS-228 User Manual
8

Single Stage Installation
The most basic installation is a Single Stage installation, in which no
additional switches are cascaded down from the first unit. To set up a single
stage installation, refer to the diagram on the next page do the following:
1. Plug the monitor, keyboard, and mouse cables for Consoles 1 and 2 into
the port connectors located on the rear panel of the CS-228 unit. Each port
is labeled with an appropriate icon to indicate itself.
2. Plug the microphone and speaker cables (if you are using them), for
Consoles 1 and 2 into the port connectors located on the rear panel of the
CS-228 unit. Each port is labeled with an appropriate icon to indicate
itself.
3. Use PS/2 KVM cables (as described in the Cables section on p. 4), to
connect the monitor, keyboard and mouse ports of the computers to any
available CS-228 KVM Port.
4. Plug the power adapter into an AC power source; plug the power adapter
cable into the CS-228’s Power Jack.
5. Turn on the power to the CS-228.
Note: When you turn the unit on, it undergoes a Power On Self-Test. If
there is a problem, the On Line Port LEDs flash repeatedly
according to a pattern that indicates what the problem is:
Pattern Indication
On Line LEDs 1 - 8 Flash Simultaneously Internal RAM Memory Error
On Line LEDs 1 - 8 Flash One After the Other External RAM Memory Error
On Line LED pairs 1+2, 3+4, 5+6, and 7+8
Flash One After the Other
ROM Test Error
If any of these problems occur, turn the Switch Off, then turn it on again.
(continues on next page)
2005-11-29
2. Hardware Setup
9

6. Plug in the power cords and power on all the computers.
Note: You must turn on the power to the CS-228 before turning on the
power to the computers.
2005-11-29
CS-228 User Manual
10
