Masterbuilt 20030111 Guide

Masterbuilt Manufacturing, Inc.
1 Masterbuilt Ct.
Columbus, GA 31907
Customer Service 1-800-489-1581
www.masterbuilt.com
Manual Code: 9803100003 110410-17JH
Tool needed for assembly: Phillips Head Screwdriver
CARBON MONOXIDE HAZARD WARNING
Burning wood chips gives off carbon
monoxide, which has no odor and
can cause death.
DO NOT burn wood chips inside homes,
vehicles, tents, garages or any enclosed areas.
Use only outdoors where it is
well ventilated.
This manual contains important
information necessary for the proper assembly
and safe use of the appliance.
Read and follow all warnings and
instructions before assembling and using
the appliance.
Follow all warnings and instructions when
using the appliance.
Keep this manual for future reference.
Failure to follow these warnings and instructions properly could result in fire or explosion, which
could cause property damage, personal injury, or death.
ASSEMBLY, CARE & USE MANUAL
WARNING & SAFETY INFORMATION
TABLETOP PROPANE GRILL
MODEL 20030111
THIS PRODUCT IS FOR OUTDOOR USE ONLY
• Unit is for outdoor use only.
• Never use inside enclosed areas such as patios, garages, buildings or tents.
• Never use inside recreational vehicles or on boats.
• Never operate unit under overhead construction such as roof coverings, carports, awnings, or
overhangs.
• Never use unit as a heater.
• Maintain a minimum distance of 10ft (3m) from overhead construction, walls, rails or other
structures.
• Keep a minimum 10ft (3m) clearance of all combustible materials such as wood, dry plants,
grass, brush, paper, or canvas.
• Keep appliance clear and free from combustible materials such as gasoline and other flammable
vapors and liquids.
• Use unit on a level, non-combustible, stable surface such as dirt, concrete, brick or rock.
• Keep children and pets away from unit at all times. Do NOT allow children to use unit.
• Unit has an open flame. Keep hands, hair, and face away from burner flame. Do NOT lean over
burner when lighting. Loose hair and clothing may catch fire.
• Allow unit to cool below 115°F (46°C) before moving or storing.
• Avoid bumping or impacting unit.
• This unit is HOT while in use and during cooling process. Wear protective gloves/mitts.
• Use of alcohol, prescription or non-prescription drugs may impair user’s ability to properly
assemble or safely operate unit.
• Never use glass, plastic or ceramic cookware in unit.
• Do NOT allow anyone to conduct activities around unit during or following its use until it has
cooled.
• Accessory attachments not supplied by Masterbuilt Manufacturing, Inc. are not recommended.
• Never use unit for anything other than its intended use. This unit is NOT for commercial use.
• Use in accordance with local, state and federal fire codes.
GENERAL WARNINGS AND SAFETY INFORMATION
1
DANGER DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, keep away from the
appliance and immediately call your
Fire Department.
1. Never operate this appliance unattended.
2. Never operate this appliance within 10 feet
(3m) of any structure, combustible material
or other gas cylinder.
3. Never operate this appliance within 25 feet
(7.5m) of flammable liquids.
4. If fire should occur keep away from appliance
and immediately call your fire department.
Do not attempt to extinguish an oil/grease
fire with water.
FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN FIRE, EXPLOSION OR BURN
HAZARD, WHICH COULD CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH.
18
LIMITED WARRANTY
Masterbuilt warrants its products to be free from defects in material and workmanship under proper
assembly, normal use and recommended care for 90 days from the date of original retail purchase.
Masterbuilt warranty does not cover paint finish as it may burn off during normal use.
Masterbuilt warranty does not cover rust of the unit.
Masterbuilt requires reasonable proof of purchase for warranty claims and suggests that you keep your
receipt. Upon the expiration of such warranty, all such liability shall terminate.
Within the stated warranty period, Masterbuilt, at its discretion, shall repair or replace defective components
free of charge with owner being responsible for shipping. Should Masterbuilt require return of component(s)
in question for inspection Masterbuilt will be responsible for shipping charges to return requested item.
This warranty excludes property damage sustained due to misuse, abuse, accident, damage arising out of
transportation, or damage incurred by commercial use of this product.
This expressed warranty is the sole warranty given by Masterbuilt and is in lieu of all other warranties,
expressed or implied including implied warranty, merchantability, or fitness for a particular purpose.
Neither Masterbuilt nor the retail establishment selling this product, has authority to make any warranties or
to promise remedies in addition to or inconsistent with those stated above.
Masterbuilt’s maximum liability, in any event, shall not exceed the purchase price of the product paid by
the original consumer/ purchaser. Some states do not allow the exclusion or limitation of incidental or
consequential damages. In such a case, the above limitations or exclusions may not be applicable.
California residents only: Not withstanding this limitation of warranty, the following specific restrictions
apply; if service, repair, or replacement of the product is not commercially practical, the retailer selling the
product or Masterbuilt will refund the purchase price paid for the product, less the amount directly
attributable to use by the original buyer prior to the discovery of the nonconformity. Owner may take the
product to the retail establishment selling this product in order to obtain performance under warranty.
This expressed warranty gives you specific legal rights, and you may also have other rights which vary from
state to state.
Go Online www.masterbuilt.com
or complete and return to
Attn: Warranty Registration
Masterbuilt Mfg. Inc.
1 Masterbuilt Court - Columbus, GA 31907
Name: _________________________________Address :__________________________City:_______________
State/Province: ________ Postal Code: ________________Phone Number: (_____) - ____________
E-mail Address:_______________________________________
Model Number: ____________________ Serial Number: ____________________
Purchase Date: _____- ______-_______ Place of Purchase: ____________________________________
17
RECIPES
TANGY PEANUT-SAUCED RIBS
4 lbs meaty pork spareribs or pork loin back ribs
¼ cup hot water
¼ cup peanut butter
2 tbsp lime juice
2 tbsp sliced green onion
½ tsp grated fresh ginger or ¼ tsp ground ginger
¼ tsp ground red pepper
Trim fat from ribs. Cut ribs into 4-6 serving size pieces.
Place ribs bone side down. Cover and grill for 1 to 1 ¾
hours or until tender. Meanwhile, for sauce, in a small
saucepan gradually stir hot water into peanut butter
(mixture will stiffen at first). Stir in lime juice, green onion,
ginger, and red pepper. Cook and stir over low heat until
heated through. Spoon sauce over ribs.
BBQ BURGERS
¼ cup catsup
2 tbsp steak sauce
1 tbsp water
1 tsp sugar
1 tsp vinegar
1 clove garlic, minced
1 lb lean ground beef
¼ tsp salt
¼ tsp black pepper
4 hamburger buns, split and toasted
For sauce, in small saucepan combine catsup, steak
sauce, water, sugar, vinegar, garlic, and if desired, hot
pepper sauce. Bring to boiling, and reduce heat. In a
medium bowl combine ground beef, salt, and pepper.
Shape meat mixture into four ¾ inch thick patties.
Grill patties on the rack of an uncovered grill directly over
medium heat for 14-18 minutes or until meat reaches 160°
F degrees internally. Turn patties once during cooking
and brush once or twice with sauce during the last five
minutes. Serve burgers on buns.
Optional: few dashes bottled hot pepper sauce, American
cheese slices, lettuce leaves, tomato slices, onion slices,
and pickle slices.
HERB-MUSTARD CHICKEN QUARTERS
2 tbsp creamy Dijon-style mustard blend
1 tbsp snipped fresh parsley
1 tbsp snipped fresh oregano or 1 tsp dried oregano
crushed
1 tbsp water
1/8 tsp ground red pepper
3 to 3 ½ lb whole broiler-fryer chicken, cut into quarters
For sauce, in a small bowl combine mustard, parsley,
oregano, water and red pepper. Cover and chill until ready
to use. Optional to remove skin.
Place chicken bone side down. Cover and grill for 50-60
minutes or until chicken is no longer pink. (170° F degrees
for breast and 180° F degrees for dark meat). Brush the
pieces with sauce occasionally during the last 10 minutes
of grilling.
FOR MORE TANTALIZING RECIPES
AND COOKING TIPS VISIT US
ONLINE AT
WWW.MASTERBUILT.COM
GENERAL WARNINGS AND SAFETY INFORMATION
• Use 1LB (0.45kgs) gas cylinder with unit (cylinder not included with unit).
• Installation of unit must conform with local codes or in the absence of local codes, with National
Fuel Gas Code, ANSIZ223.1/NFPA 54, Storage and Handling of Liquefied Petroleum Gasses,
ANSI/NFPA 58 or CSA B149.1, Natural Gas Installation Code; Propane Storage and Handling, CSA
B149.2; or the Standard for Recreational Vehicles, ANSI A119.2/NFPA 1192; and Recreational
Vehicle Code, CSA Z240 RV Series as applicable.
• LP gas cylinder being used must be constructed and marked in accordance with specifications
for LP gas cylinders of the US Department of Transportation (DOT) or the Standard for Cylinders,
Spheres and Tubes for the Transportation for Dangerous Goods, CAN/CSA-B339.
• Always perform soapy water test (see “Soapy Water Test Instructions” in this manual)
EVERY TIME you use unit.
• Before each use check all nuts, screws and bolts to make sure they are tight and secure.
• Always disconnect gas cylinder from unit when not in use.
• Never attach/disconnect gas cylinder, move or alter gas fittings when unit is in operation.
• Never use gas cylinder if there is evidence of dents, gouges, bulges, fire damage, erosion,
leakage, excessive rust, or other forms of visible external damage. This may be hazardous and
cylinder should be taken to a liquid propane supplier to be checked.
• Regulator supplied with unit MUST be used. For replacement parts, if needed, contact
Masterbuilt Customer Service at 1-800-489-1581.
• When lighting burner remove all inside parts to prevent explosion from gas build up.
• If burner does not ignite, turn off regulator and wait 5 minutes. After time is up, repeat burner
lighting steps.
• Do NOT obstruct flow of combustion and ventilation. Keep ventilation openings of cylinder
enclosure free and clear of debris.
• When use is complete, always turn regulator OFF.
• Gas MUST be turned off at regulator control when not in use.
• Do NOT store spare LP gas cylinder under or near unit. Gas cylinder safety relief valve may
overheat allowing gas to release causing fire which may cause death or serious injury.
• Never fill cylinder over 80% full or cylinder may release gas causing fire which may cause death
or serious injury.
• If you smell, hear or see gas escaping, immediately get away from gas cylinder and call the Fire
Department. Fire may cause death or serious injury.
• Place a dust cap on cylinder valve outlet whenever cylinder is not in use. Only install dust cap
provided with cylinder. Other caps or plugs may cause leaks.
• Cylinder MUST be stored outdoors, out of children’s reach and must NOT be stored in a building,
garage, or any other enclosed area.
• This appliance is not for frying turkeys.
2
3
SOAPY WATER TEST WARNINGS & PROCEDURES
DURING ANY PORTION OF SOAPY WATER TEST IF BUBBLES CONTINUE TO
APPEAR, STOP, DO NOT USE UNIT. CONTACT LOCAL PROPANE DEALER OR
MASTERBUILT CUSTOMER SERVICE @ 1-800-489-1581.
Note: Use 1LB (0.45kgs) gas cylinder with this unit.
Cylinder NOT included with this unit.
Apply solution to
gas cylinder and
regulator assembly.
Regulator Control Knob Failed test will present bubbles as
shown below.
• Soapy Water Test MUST be performed each
time gas cylinder is connected or each time it
is used.
• Soapy Water Test MUST be performed
outdoors in well ventilated area.
• When performing Soapy Water Test keep
smoker away from open flames, sparks or lit
cigarettes.
• Grill is designed to work with propane gas only.
Only use gas cylinders marked propane with
this unit. This product will NOT operate with
natural gas.
• Never use an open flame to test for gas leaks.
• Make sure regulator control knob is in OFF position.
• Prepare soapy water solution: (1) part dish washing liquid (or more if desired), (3) parts water.
• Apply soapy water solution to gas cylinder and regulator assembly.
PREPARATION
1. Turn regulator control knob ON and watch for bubbles. DO NOT LEAVE GAS ON MORE THAN
12 SECONDS. If bubbles appear, stop, turn regulator control knob OFF and retighten the
connection that is leaking gas. Repeat test.
2. When test is complete, and there are no leaks, wait minimum of 5 minutes for gas fumes to
diminish before lighting burner.
TESTING
Reminder: Never operate this grill under any
overhead construction. Maintain a minimum of
10ft (3m) from overhead construction, walls or
rails. See diagram below.
Wall
Rails
Overhead
Construction
10 ft (3m)
10 ft (3m)
16
• When outside temperature is cooler than 65°F and/or altitude is above 3,500 feet, additional
cooking time may be required. To insure that meat is completely cooked use a meat
thermometer to test internal temperature.
• Lifting grill lid during cooking process may extend cooking time due to heat loss.
BEEF SIZE GRILLING TIME INTERNAL TEMP
Steaks 3/4” (2cm) thick 3 to 4 min. /side med rare 145°F (62°C)
4 to 5 min. /side med 160°F (71°C)
Kabobs 1” (2.5cm) cubes 3 to 4 min. /side 145°-160°F (62-71°C)
Hamburger patties 1/2” (12mm) thick 3 to 4 min. /side med 160°F (71°C))
Roast, rolled rump 4-6 lbs. (1.8-2.7kg) 18 to 22 min /lb. 145°-160°F (62-71°C)
Sirloin tip 3 1/2--4 lbs. (1.5-1.8kg) 20 to 25 min. /lb. 145°-160°F (62-71°C)
Ribs, back cut in 1-rib portions 10 min. /side med 160°F (71°C)
half, 2-3 lbs. (0.9-1.3kg) 10 to 12 min. /side med rare 145°F (62°C)
Tenderloin whole, 4-6 lbs. (1.8-2.7kg) 12 to 15 min. /side med 160°F (71°C)
PORK SIZE GRILLING TIME INTERNAL TEMP
Chops, bone-in 3/4” (2cm) thick 3 to 4 min. /side med 160°F (71°C)
Chops, bone-out 1 1/2” (4cm) thick 7 to 8 min. /side med 160°F (71°C)
Tenderloin 1/2-1 1/2lbs. (0.2-0.6kg) 15 to 25 min. total med 160°F (71°C)
Ribs (indirect heat) 2-4 lbs. (0.9-1.8kg) 1 1/2 to 2 hrs. med 160°F (71°C)
Roast, saddle or leg 6-7 lbs. (2.7-3.1kg) 25 to 30 min. /lb. 145°-160°F (62-71°C)
Steaks 3/4” (2cm) thick 6 to 7 min. /side med 160°F (71°C)
CHICKEN SIZE GRILLING TIME INTERNAL TEMP
Broiler fryer (indirect
heat)
3-4 lbs. (1.3-1.8kg) 60 to 75 min. in thigh 180°F (82°C)
Cornish hens 18-24 oz. (510-680g) 45 to 55 min. in thigh 180°F (82°C)
Breast halves, bone-in 6-8 oz. ( 170-226g) each 10 to 15 min. /side 170°F (77°C)
Breast halves, boneless 4 oz. (113g) each 6 to 8 min. /side 170°F (77°C)
Legs or thighs 4-8 oz. (113-226g) 10 to 15 min. /side 180°F (82°C)
Drumsticks 4 oz. (113g) 8 to 12 min. /side 180°F (82°C)
Wings 2-3 oz. (56-85g) 8 to 12 min. /side 180°F (82°C)
APPROXIMATE GRILLING TIMES
VENISON SIZE GRILLING TIME INTERNAL TEMP
15
WARNING
COMBUSTION BY-PRODUCT PRODUCED WHEN USING THIS PRODUCT CONTAINS CHEMICALS
KNOWN TO THE STATE OF CALIFORNIA TO CAUSE BIRTH DEFECTS,
OTHER REPRODUCTIVE HARM, OR CANCER.
THE MATERIALS USED IN THIS PRODUCT MAY CONTAIN LEAD A CHEMICAL KNOWN TO THE
STATE OF CALIFORNIA TO CAUSE BIRTH DEFECTS AND OTHER REPRODUCTIVE HARM.
SAFE STORAGE & MAINTENANCE
BEFORE FIRST USE
• Inspect all hardware in assembled parts for tightness on a regular basis to insure unit is in safe working
condition.
• ALWAYS allow unit to cool completely before handling.
• Clean unit, including special surfaces such as cooking grates with mild cleaning agents. Wipe outside of
unit with damp rag. DO NOT use oven cleaner.
• ALWAYS cover and store cold unit in a protected area.
• Unit is made of steel and may rust over time. If rusting occurs on outside surfaces, clean area with sand
paper or steel wool, then cover with heat resistant paint.
• NEVER USE PAINT ON INSIDE SURFACES OF UNIT.
Before cooking with your grill, follow these steps closely to both cure the finish and season the interior of
your grill. Improper preparation of your grill may affect the finish and/or add metallic flavors to your first
foods.
· Brush or wipe all interior surfaces and cooking grate with vegetable cooking oil.
·Perform soapy water test and light grill.
·Close lid.
·Continue burning grill for two hours or more. After at least 2 hours, begin increasing temperature by
about 50-75 degrees. Hold it at that temperature for about 15-30 minutes. Your grill is now ready for
use.
INSTALLING GAS CYLINDER
1. Open lid during lighting.
2. Push regulator control knob to turn ON and push ignitor button to light.
3. If ignition does not take place within 5 seconds, turn gas control valve to
OFF position and wait five minutes and repeat lighting procedures. If
ignition still does not occur, see match light directions below.
4. Place a long lit match or candle lighter through lighting hole close enough
to burner to ignite.
• Regulator control knob adjusts burner flame. Turn control knob
counter-clockwise SLOWLY to increase flame. Turn control knob
clockwise to decrease flame.
• Visually check burner flame. A CORRECT FLAME should be blue
with a small amount of yellow at the tip. An INCORRECT FLAME is
excessively yellow and irregular. If an incorrect flame occurs, turn
regulator control knob to OFF position. Allow unit to cool and then
clean burner. Let burner completely dry before re-lighting.
4. If ignition does not occur wait five minutes and then re-try.
5. After use turn regulator control knob OFF. Always allow unit to cool
completely before touching, moving or storing.
COUNTER
CLOCKWISE
LIGHTING
HOLE
YELLOW
BLUE
1. Inspect burner before each use. Check burner and burner venturi
tube for insects and insect nests. A clogged tube can lead to a fire beneath
appliance.
2. Connect regulator to grill (see Step 4 on pg 8).
3. Make sure regulator control knob on grill is in the “OFF” position.
4. Remove protective cap from gas cylinder if applicable.
5. Center and insert valve outlet into regulator as shown in figure on right.
6. Turn gas cylinder counterclockwise until it stops. DO NOT CROSS THREAD.
7. Perform Soapy Water Test (see pg 3).
INSTALLING GAS CYLINDER
MATCH LIGHTING INSTRUCTIONS
• Fatty foods (hamburgers,etc.) can have excess
grease and cause flare ups. When cooking fatty
foods, use a low setting with lid open.
• Clean base pan before each use. This will
cut down on build-up and flare ups.
CAUTIONCAUTION
Perform “Soapy Water Test” before each use.
See “Soapy Water Test” section in manual.
Extinguish all open flames before connecting
regulator to gas cylinder. Turn gas OFF after
each use.
4
PARTS LIST
ITEM NO QUANTITY DESCRIPTION ITEM NO QUANTITY DESCRIPTION
1 1 Lid 10 2 Heat Plate Support
2 1 Base Pan 11 1 Warming Rack
3 1 Lid Handle 12 1 Cooking Grate
4 4 Leg 13 1 Wind Guard
5 2 Top Hinge 14 1 Regulator Control Knob
6 2 Bottom Hinge 15 1 Regulator/Valve
7 1 Burner 16 2 Base Pan Handle
8 1 Lid Lock 17 1 Ignitor
9 1 Heat Plate 18 1 Temperature Gauge
STOP
DO NOT RETURN TO RETAILER
For Assembly Assistance, Missing or Damaged Parts
Call: MASTERBUILT Customer Service at 1-800-489-1581.
5
1
8
11
12
15
16 13
18
17
2
4
5
6
7
10
3
9
14
14
ADDITIONAL FEATURES
To make grill portable fold legs (4) under and close lid lock (8) as shown.
4
8
13
ASSEMBLY
STEP 13
Insert warming rack (11) into assembled
grill as shown.
11
GRILL IS READY FOR USE.
STEP 14
Place cooking grate (12) into base pan (2)
as shown.
12 2
HARDWARE LIST
REPLACEMENT PARTS LIST
STOP
DO NOT RETURN TO RETAILER
For Assembly Assistance, Missing or Damaged Parts
Call: MASTERBUILT Customer Service at 1-800-489-1581. 6
(A)
M4x8
Phillips Screw
Qty-2
(E)
M4
Lock Washer
Qty-2
(I)
M4
Wing Nut
Qty-2
(F)
M5
Lock Washer
Qty-14
(J)
M5
Wing Nut
Qty-14
(G)
M6
Lock Washer
Qty-7
(K)
M6
Wing Nut
Qty-6
(H)
M6x12
Washer
Qty-17
(M)
1.4x30
Cotter Pin
Qty-2
(O)
Heat Insulation
Washer
Qty-6
(B)
M5x10
Phillips Screw
Qty-14
(D)
M6x10
Phillips Screw
Qty-1
Item No. Part No. Description Item No. Part No. Description
1 9903100010 Lid Kit 11 9003100029 Warming Rack
2 9903100011 Base Pan Kit 12 9003100030 Cooking Grate
3 9903100012 Lid Handle Kit 15 9003100015 Regulator/Valve
4 9903100004 Leg Kit 16 9903100013 Base Pan Handle
5 9903100015 Hinge Kit 17 9903100021 Ignitor Kit
7 9903100016 Burner Kit 18 9903100014 Temperature Gauge Kit
8 9903100018 Lid Lock Kit 9903100017 Ignitor Support Kit
9 9003100031 Heat Plate 9903100019 Hardware Kit
10 9903100020 Heat Plate Support Kit 9803100003 Instruction Manual
(C)
M6x8
Phillips Screw
Qty-1
(L)
5x30
Pin
Qty-2
(N)
M8
Wing Nut
(Packaged with temp gauge)
Qty-1
7
ASSEMBLY
• BEFORE ASSEMBLY READ ALL INSTRUCTIONS CAREFULLY.
• ASSEMBLE UNIT ON A CLEAN, FLAT SURFACE.
STEP 1
Align leg (4) to bottom of base pan (2).
Attach leg using screws (B). Secure with
washers (H) lock washers (F) and wing
nuts (J) as shown.
Repeat step for remaining legs.
STEP 2
Insert burner (7) with ignition wire at
an angle into side hole in base pan (2).
Secure using washer (H) lock washer (G)
and screw (C).
J
F
H
2
2
4
B
H
G
7
CIGNITION WIRE
12
ASSEMBLY
STEP 11
Align lid lock (8) with holes in base pan
(2). Secure using screws (A) lock washers
(E) and wing nuts (I).
STEP 12
Position heat plate (9) on heat plate
supports (10) as shown.
9
10
8
2
A
I
E
11
ASSEMBLY
STEP 9
Insert temperature gauge (18) into lid (1).
Secure in place with temperature guage
support (included with temperature guage
kit) and wing nut (N).
STEP 10
Insert ignition wire into ignitor (17) as
shown.
Using screw (D) attach ignitor (17) to base
pan (2).
17
D
2
18
N
1
IGNITION WIRE
8
ASSEMBLY
STEP 3
Place heat insulation washers (O) on base
pan handle (16). Insert base pan handle
(16) into base pan (2). Attach heat plate
suppport (10) as shown. Secure using
washers (H) lock washers (G) and wing
nuts (K).
Repeat step on opposite side for
remaining base pan handle.
STEP 4
Some parts not shown for clarity.
Place wind guard (13) on burner (7) as
shown. Insert regulator/valve (15) onto
end of burner and twist to secure.
2
O
HGK
16
10
7
15
13
9
ASSEMBLY
STEP 5
Insert screws (B) through lock washers
(F) and into base pan (2). Attach bottom
hinge (6) to back of base pan (2) and
secure with wing nut (J).
Repeat step for remaining bottom hinge.
B
5
1
JF
H
J
6
2
B
F
STEP 6
Align holes on top hinge (5) with holes on
back of lid (1). Insert screw (B) through
top hinge as shown. Secure using washer
(H) lock washer (F) and wing nut (J).
Repeat step for remaining top hinge.
10
ASSEMBLY
STEP 7
Place lid (1) onto base pan (2) as shown.
Make sure top hinge (5) is inside of
bottom hinge (6). Insert pin (L) through
hinge and secure using cotter pin (M).
Repeat step for remaining hinge.
1
2
M
L
STEP 8
Place heat insulation washers (O) on lid
handle (3). Insert lid handle (3) into lid (1)
as shown. Secure with washers (H) lock
washers (G) and wing nuts (K).
3
5
6
1
O
H
G
K

Other Masterbuilt Grill manuals

Masterbuilt GMDCS, GMSSDCS User manual

Masterbuilt

Masterbuilt GMDCS, GMSSDCS User manual

Masterbuilt 070312 Guide

Masterbuilt

Masterbuilt 070312 Guide

Masterbuilt GMDES Quick reference guide

Masterbuilt

Masterbuilt GMDES Quick reference guide

Masterbuilt CGP24G1D User manual

Masterbuilt

Masterbuilt CGP24G1D User manual

Masterbuilt 20042011 Guide

Masterbuilt

Masterbuilt 20042011 Guide

Masterbuilt MB20042219 User manual

Masterbuilt

Masterbuilt MB20042219 User manual

Masterbuilt 20040211 Guide

Masterbuilt

Masterbuilt 20040211 Guide

Masterbuilt KingsFord 10040106 Guide

Masterbuilt

Masterbuilt KingsFord 10040106 Guide

Masterbuilt MB20040819 User manual

Masterbuilt

Masterbuilt MB20040819 User manual

Masterbuilt SQPGD User manual

Masterbuilt

Masterbuilt SQPGD User manual

Masterbuilt GRAVITY GRIDDLE MB20043622 User manual

Masterbuilt

Masterbuilt GRAVITY GRIDDLE MB20043622 User manual

Masterbuilt 20072912 Guide

Masterbuilt

Masterbuilt 20072912 Guide

Masterbuilt 20042111 Guide

Masterbuilt

Masterbuilt 20042111 Guide

Masterbuilt 20075315 Guide

Masterbuilt

Masterbuilt 20075315 Guide

Masterbuilt sportsman elite 20051313 Guide

Masterbuilt

Masterbuilt sportsman elite 20051313 Guide

Masterbuilt 20040116 KE22.5MBS Guide

Masterbuilt

Masterbuilt 20040116 KE22.5MBS Guide

Masterbuilt AutoIgnite 545 Series User manual

Masterbuilt

Masterbuilt AutoIgnite 545 Series User manual

Masterbuilt MB20042119 User manual

Masterbuilt

Masterbuilt MB20042119 User manual

Masterbuilt 20070409 Guide

Masterbuilt

Masterbuilt 20070409 Guide

Masterbuilt MEG 130B User manual

Masterbuilt

Masterbuilt MEG 130B User manual

Masterbuilt M7P User manual

Masterbuilt

Masterbuilt M7P User manual

Masterbuilt 20042211 Guide

Masterbuilt

Masterbuilt 20042211 Guide

Masterbuilt SSSMPG User manual

Masterbuilt

Masterbuilt SSSMPG User manual

Masterbuilt Outdoor LP Gas Double Cooker MDCL User manual

Masterbuilt

Masterbuilt Outdoor LP Gas Double Cooker MDCL User manual

Popular Grill manuals by other brands

Char-Broil 463270610 Product guide

Char-Broil

Char-Broil 463270610 Product guide

Weber genesis II LX E-340 GBS owner's manual

Weber

Weber genesis II LX E-340 GBS owner's manual

RM Gastro SE-40 S Instructions for installation and use

RM Gastro

RM Gastro SE-40 S Instructions for installation and use

Whirlpool AKT 325 Operation

Whirlpool

Whirlpool AKT 325 Operation

Teka EFX 30 instruction manual

Teka

Teka EFX 30 instruction manual

Goldair GBQC300 operating instructions

Goldair

Goldair GBQC300 operating instructions

NECESSITIES CBT1414A instructions

NECESSITIES

NECESSITIES CBT1414A instructions

Bosch TCG4104 instruction manual

Bosch

Bosch TCG4104 instruction manual

Char-Broil 466742111 Product guide

Char-Broil

Char-Broil 466742111 Product guide

Bosch TFB?33 series instruction manual

Bosch

Bosch TFB?33 series instruction manual

Char-Broil Patio Caddie 4654870 Assembling manual

Char-Broil

Char-Broil Patio Caddie 4654870 Assembling manual

CURRON ChimneyBend GM9000 instructions

CURRON

CURRON ChimneyBend GM9000 instructions

Huntington 6666-64 Assembly manual & parts list

Huntington

Huntington 6666-64 Assembly manual & parts list

Weber 2000 owner's manual

Weber

Weber 2000 owner's manual

Fuego F21C Quick assembly guide

Fuego

Fuego F21C Quick assembly guide

Napoleon LD325SB user manual

Napoleon

Napoleon LD325SB user manual

Traeger HOMESTEAD TFB52Q Assembly guide

Traeger

Traeger HOMESTEAD TFB52Q Assembly guide

EXPERT GRILL 720-0988EC Assembly instructions

EXPERT GRILL

EXPERT GRILL 720-0988EC Assembly instructions

manuals.online logo
manuals.online logoBrands
  • About & Mission
  • Contact us
  • Privacy Policy
  • Terms and Conditions

Copyright 2025 Manuals.Online. All Rights Reserved.
