Masterbuilt Sportsman Elite 20076115 Guide

CARBON MONOXIDE
HAZARD WARNING
Burning wood chips gives off carbon
monoxide, which has no odor and
can cause death.
DO NOT burn wood chips inside homes,
vehicles, tents, garages or any enclosed areas.
Use only outdoors where it is
well ventilated.
This manual contains important
information necessary for the proper
assembly and safe use of the appliance.
Read and follow all warnings and
instructions before assembling and using
the appliance.
Follow all warnings and instructions when
using the appliance.
Keep this manual for future reference.
Failure to follow these warnings and instructions properly could result in fire or explosion,
which could cause property damage, personal injury, or death.
THIS PRODUCT IS FOR OUTDOOR USE ONLY
ASSEMBLY, CARE & USE MANUAL
WARNING & SAFETY INFORMATION
40” DIGITAL ELECTRIC SMOKER MODEL 20076115
Tools needed for assembly: Adjustable Wrench and Phillips Head Screwdriver
Approximate assembly time: 25 minutes *Actual product may differ from picture shown
(Model 20076115 220-240V, 50 Hz, 1200 W )

1
READ ALL INSTRUCTIONS
Unit is for OUTDOOR USE ONLY.
T
CONTINUED ON AGE 2
GENERAL ARNINGS Y ATION
A
r
2.
r
ARNING

2
GENERAL WARNINGS AND SAFETY INFORMATION
WARNINGS & IMPORTANT SAFEGUARDS
CONTINUED FROM PAGE 1
When using electrical appliances, basicsafety precautionsshould always befollowed including
the following:
Do not plug in electric smoker until fullyassembled and ready for use.
Use only approved grounded electrical outlet.
Do not use during an electrical storm.
Do notexposeelectricsmokerto rain or wateratanytime.
To protectagainst electrical shock do not immersecord, plug or control panel in water or other liquid.
Do not operateany appliance with a damaged cord or plug, or afterappliancemalfunctions or has
been damaged in anymanner. ContactMasterbuiltCustomer Serviceforassistance at
61 414 984 956.
Longer detachable power-supply cords orextension cordsareavailableand may be used ifcare is
exercised in their use.
If a longer detachable power-supply cord or extension cord is used: 1. Themarked electrical rating of
the cord set orextension cord should beat leastas greatastheelectrical rating ofthe appliance;and
2. Thecord should be arranged so that it will not drape overthecountertop ortabletop where it can
be pulled bychildren ortripped over unintentionally.
Theextension cord must bea grounding -type 3-wire cord.
Outdoorextension cordsmust be used with outdoor use productsand aremarked with suffix
“W” and with thestatement“SuitableforUse with OutdoorAppliances.”
CAUTION - To reduce the risk ofelectric shock, keep extension cord connection dry and offthe ground.
Do not let cord hang touch hot surfaces.
Do not place on or near a hot gas or electric burner, or in a heated oven.
Fuel, such ascharcoal briquettes or heat pellets, are not to be used in electricsmoker.
To disconnect, turn control panel “OFF”then remove plug from outlet.
Unplug from outlet when not in useand beforecleaning. Allow unitto cool completely before
adding/removing grates, tray or water bowl.
Drip tray is onlyforthe bottom ofelectricsmoker. Do not put drip tray on rackthismay
damageelectricsmoker.
Do not coverracks with metal foil. This will trap heatand causesevere damage to
electricsmoker.
Do not clean this product with a watersprayer or the like.
SAVE THESE INSTRUCTIONS
STRUCTURAL PROXIMITY AND SAFETY USAGE RECOMMENDATIONS
REMINDER:
NEVER OPERATE THIS SMOKER UNDER
ANY OVERHEAD CONSTRUCTION.
MAINTAIN A MINIMUM DISTANCE OF 10
FEET FROM OVERHEAD CONSTRUCTION,
WALLS OR RAILS.
WARNING:
ELECTRIC POWER CORD IS
A TRIP HAZARD
Rails
Walls
Overhead Construction
10 Feet
10 Feet

3
LET’S GET STARTED!
• This is a slow smoker… allow suffi cient time for cooking. Smoker is for OUTDOOR USE ONLY.
• “Pre-season” smoker prior to fi rst use. See page 12.
• Pre-heat smoker for 30 to 45 minutes at max temperature before loading food.
• DO NOT cover racks with aluminum foil as this will not allow heat to circulate properly.
• Do not overload smoker with food. Extra large amounts of food may trap heat, extend cooking
time and cause uneven cooking. Leave space between food on racks and smoker sides to
ensure proper heat circulation. If utilizing cooking pans, place pans on center of rack to ensure
even cooking. Never use glass, plastic or ceramic cookware in unit. Please see manual for
more detail.
• Close air damper on top of unit to retain moisture and heat. If cooking foods such as fi sh or
jerky, open air damper to release moisture.
• Store smoker in a dry area after use.
• Extreme cold temperatures may extend cooking times.
• CLEAN AFTER EVERY USE. This will extend the life of your smoker and prevent mold
and mildew.
ENJOY!
For rack supports, racks, water bowl and drip pan use a mild dish detergent. Rinse and dry
thoroughly.
For wood chip tray and wood chip loader, clean frequently to remove ash build up, residue and
dust.
Dispose of cold ashes by placing them in aluminum foil, soaking with water and discarding in a
non-combustible container.
For the interior, glass in door, meat probe, and exterior of smoker simply wipe down with a damp
cloth. Do not use a cleaning agent. Make sure to dry thoroughly.
Door seal and inside seam that seal attaches to MUST be cleaned with a damp cloth after each
use to keep seal in proper working condition.
ALWAYS MAKE SURE UNIT IS COOL
TO THE TOUCH BEFORE CLEANING AND STORING.
HOW TO CLEAN SMOKER

4
PARTS LIST
27
7
5
8
9
3
6
4
10
12
13
22
23
28
14
11
21
20
24
24
15
17
16
18
2
26
25
1
19
NO QTY NOITPIRCSED NO QTY NOITPIRCSED
ydoBrekomS11
2 1 Control Panel
eldnaHraeR13
kcaR44
5 1 Drip Deflector
stroppuSkcaR46
hctaLrooD17
lwoBretaW18
9 1 Wood Chip Tray
10 1 Drip Pan
geLwercSelbatsujdA211
12 1 Wood Chip Loader
yarTesaerG131
leehW241
tnemelE151
16 1 Wood Chip Housing
17 1 Meat Probe
repmaDriA181
rooDrekomS191
eldnaHrooD102
)R(tooFtnorF112
22 2 Grease Tray Bracket
)thgir(lenaPediS132
egniHrooD242
25 1 Control Panel Housing
thgiLDEL162
lortnoCetomeR172
)tfel(lenaPediS182
)L(tooFtno
rF192
(L) (R)
29

5
PARTS LIST
ONMETITRAPTNEMECALPER ONMETITRAPTNEMECALPER
Body Kit, Black9907140032
Digital Smoker Control9007140014
Rear Handle Kit 9907120028
Rack 9007120012
Drip Deflector 9007120013
Rack Support9007120011
Door LatchKit, Black9907120004
Water Bowl9007120014
Wood Chip Tray9007130026
Drip Pan 9007120016
Adjustable Screw Leg910050006
Wood Chip Loader9007130028
Grease Tray9007140015
Wheel Kit 9907120017
Element Kit, 1200 Watt 9907120027
Wood Chip Housing Kit 9907130009
Meat Probe Kit 9907140024
Air Damper Kit 990060221
40” Door Kit, SS9907120020
Door Handle Kit 9907120012
Right Front Foot Kit 9907120023
Left Front Foot Kit 9907120024
Grease Tray Bracket Kit 9907140019
Right Trim Panel Kit 9907120025
Left Trim Panel Kit 9907120026
Door Hinge Kit 9907120013
Hinge Cover Kit 9907120008
Control Panel Housing Kit 9907120021
LED Light Kit 9907140016
Digital Remote 9007120008
Power Circuit Board Kit 9907140048
High Temperature Limiter Kit 9907140015
Hardware Kit 9907140020
Instruction Manual9807140111
Troubleshooting Guide9807140122
STOP!
DO NOT RETURN TO RETAILER For Assembly Assistance, Missing or Damaged Parts
Call: MASTERBUILT Customer Service at 61 414 984956.
Please have Model Number and Serial Number available when calling.
These numbers are located on the silver label on the back of unit.
(A)
M6x25
Qty: 16
(B)
ST4x10
Qty: 12
(C)
M6 X 9
Qty: 8
HARDWARE LIST

6
ASSEMBLY
B
1x4
B
B
B
B
22
A
A
21
28 (L)
(R)
A
2x12

ASSEMBLY
BB
BB
BBBB
23
29
11
11
(L)
(R)
B
3x8
C
4x8
C
C
C
C
C
C
C
C
7

ASSEMBLY
11
11
5
3
A
A
6Ax4
8

ASSEMBLY
9
7
13
22
6
6
8

ASSEMBLY
9
4
5
10
10

ASSEMBLY
11
12
9
10
8
11

12
PRE-SEASON INSTRUCTIONS
PRE-SEASON SMOKER PRIOR TO FIRST USE.
Some smoke may appear during this time, this is normal.
1. Make sure water pan is in place with NO WATER.
2. Set temperature to 275°F (135°C) and run unit for 3 hours.
3. To complete pre-seasoning, during last 45 minutes, add ½ cup of wood chips in wood chip loader
and unload wood chips into the wood chip tray. This amount is equal to the contents of a filled
wood chip loader.
4. Shut down and allow to cool.
NOTE: Never add more than ½ cup (1 filled chip loader) at a time. Additional chips should not be
added until any previously added chips have ceased generating smoke.
CAUTION
When door is opened a flare up may occur. Should wood chips
flare up, immediately close door and vent, wait for wood chips to
burn down, then open door again. Do not spray with water.
How to use wood chip loader:
• Before starting unit, place ½ cup of wood chips in chip loader.
• Never use more than ½ cup of wood chips at a time. Never use wood chunks or wood pellets.
• Insert wood chip loader into smoker. Wood chips should be level with top rim of wood chip loader.
• Turn handle clockwise in direction of arrow mark on smoker to unload wood. Wood will drop into
wood chip tray. Turn handle counterclockwise, to upright position, and leave wood chip loader in
place.
• Check wood chip tray periodically to see if wood has burned down by removing wood chip loader and
looking into smoker through hole. Add more chips as needed.
•Wood chip loader must be pulled out completely from smoker when checking wood chip level.
Adding more wood during smoking process:
•Pull wood chip loader from smoker.
•Place wood chips in wood chip loader and insert into smoker.
• Turn handle clockwise in direction of arrow mark on smoker to unload wood. Wood will drop into wood
chip tray.
•Temperature may spike briefly after wood is added. It will stabilize after a short time. Do not adjust
temperature setting.
Caution:
• Keep smoker door closed when adding wood chips.
• Wood chip loader will be HOT even if handle is not.
• Never use wood pellets or wood chunks.
HOW TO USE WOOD CHIP LOADER

13
Note: Direct sunlight may interfere with ability to read LED display, block light if needed.
To set temperature:
• Press ON button.
• Press SET TEMPbutton once-LED display will blink.
• Use +/- to set temperature.
• Press SET TEMPbutton again to lock in temperature.
Note: Heating will not begin until timer is set.
To set timer:
• Press SET TIME button once-LED display for hours will blink.
• Use +/- to set hours.
• Press SET TIME button again to lock in hours. The minutes LED will start blinking.
• Use +/- to set minutes.
• Press SET TIME to lock in minutes and start cook cycle.
Heat will turn off when time has expired.
To use meat probe:
• Insert meat probe into center of meat to get most accurate reading.
• Press and hold MEAT PROBE button-LED display will show internal temperature of meat.
• Once MEAT PROBE button is released-LED display will return to set temperature or set time.
To use light:
• Press LIGHT button to turn light on.
• Press LIGHT button to turn light off.
To RESET control panel:
If control panel shows an error message, turn electric smoker off, unplug unit from outlet, wait
ten seconds, plug unit back into outlet, then turn electric smoker on. This will reset control panel.
HOW TO USE CONTROL PANEL & REMOTE CONTROL

14
r
, to ensure proper installation.
.
To replace batteries:
• Slide belt clip to the left to remove.
• Press tab down on battery cover and pull out.
• Install 2 “AAA” Alkaline batteries. Check positive (+) and negative (-) symbols, on the case and
battery
• Replace the battery cove
• Remove batteries before storing remote control.
To test frequency range:
• Turn unit on.
• Use remote to turn light on and off as you move away from unit.
• Remote control is out of frequency range when light will no longer turn on and off.
IMPORTANT
• Do not leave remote control exposed to sunlight for prolonged periods of time.
• Remote control has frequency range of up to 100ft (30m).
• Test frequency range before and during use.
TROUBLESHOOTING
If the remote is not working properly or not interfacing correctly with the controller, it may be due to
weak batteries, batteries being incorrectly installed or the remote is not correctly linked to controller.
Possible solutions
• Replace batteries and install according to image in battery housing.
• Link remote and controller by:
a. Turn Controller & Remote “OFF”.
b. Press and HOLD “SET TEMP” on controller for 3 seconds.
c. On the Remote press “MEAT PROBE”, “LIGHT”, “MEAT PROBE”, “LIGHT” (all buttons must
be pressed within 5 seconds of each other) A short beep will occur after each button press.
• Keep batteries away from small children. If battery is swallowed consult a physician immediately.
• Be sure to insert batteries correctly. Improper installation may result in leaks and/or
possible explosion.
• Do not dispose of batteries in fi re.
• Do not mix old and new batteries.
• Do not mix alkaline, standard (carbon-zinc), or rechargeable (ni-cad, ni-mh,etc) batteries.
*Batteries not
included
( Hold for 2 seconds for wireless remote function )
HOW TO USE CONTROL PANEL & REMOTE CONTROL
CAUTION

15
• Maximum temperature setting is 275°F (135°C).
• Do NOT move unit across uneven surfaces.
• Rear handle is NOT for lifting.
• Wood chip loader and wood chip tray MUST be in place when using smoker. This minimizes the
chance of wood fl are ups.
• Wood chips must be used in order to produce smoke and create the smoke fl avor.
• Check grease tray often during cooking. Empty grease tray before it gets full. Grease tray may
need to be emptied periodically during cooking.
• Do not open smoker door unless necessary. Opening smoker door causes heat to escape and may
cause wood to fl are up. Closing the door will re-stabilize the temperature and stop fl are up.
• Do not leave old wood ashes in the wood chip tray. Once ashes are cold, empty tray. Tray should
be cleaned out prior to, and after each use to prevent ash buildup.
• Glass in door is tempered and will not break under normal operation.
• This is a smoker. There will be a lot of smoke produced when using
wood chips. Smoke will escape through seams and turn the inside
of smoker black. This is normal. To minimize smoke loss around
door, door latch can be adjusted to further tighten door seal
against body.
• Opening smoker door during cooking process may extend cooking
time due to heat loss.
• When outside temperature is cooler than 65°F (18°C) and/or altitude
is above 3,500 feet (1067m), additional cooking time may be required. To insure that meat is
completely cooked use a meat thermometer to test internal temperature.
For rack supports, racks, water bowl and drip pan use a mild dish detergent. Rinse and dry
thoroughly.
For wood chip tray and wood chip loader, clean frequently to remove ash build up, residue and dust.
Dispose of cold ashes by placing them in aluminum foil, soaking with water and discarding in a
non-combustible container.
For the interior, glass in door, meat probe, and exterior of smoker simply wipe down with a damp
cloth. Do not use a cleaning agent. Make sure to dry thoroughly.
Door seal and inside seam that seal attaches to MUST be cleaned with a damp cloth after each use
to keep seal in proper working condition.
ALWAYS MAKE SURE UNIT IS UNPLUGGED AND COOL
TO THE TOUCH BEFORE CLEANING AND STORING.
HOW TO CLEAN SMOKER
• To adjust door latch, loosen hex nut on door latch. Turn hook clockwise to tighten as shown. Secure
hex nut fi rmly against door latch. (see diagram)
IMPORTANT FACTS ABOUT USING SMOKER

5-7 lbs Ham Shank or Butt (fully cooked, bone in)
1 1/2 cup Maple Syrup
1 tsp Ginger
1/4 tsp Nutmeg
1/2 tsp Allspice
16 whole Cloves
1 can Pineapple Slices (canned)
1 jar Maraschino Cherries
Hickory or Mesquite Chips
Remove thick skin and trim fat leaving no more
than 1/2” thick covering on ham. Score ham.
Combine syrup, ginger, nutmeg, and allspice
in a small bowl. Place ham in large dish and
baste with syrup mixture. Let ham stand in syrup
mixture for 1 or 2 hours basting frequently until at
room temperature.
When ready to smoke remove ham from dish and
stud with cloves. Place ham in preheated 225°F
(107°C) smoker. Cook for about 2-3 hours. Baste
with syrup mixture at least 2 times during cooking
time. Before last hour of smoking decorate
ham with canned pineapple and cherries and
baste. Internal temperature of ham should be at
130°F-140°F (54°C-60°C) when heated thru.
MAPLE GLAZED HAM
2-4 lbs Pork or Baby Back Ribs
1/2 tbsp Salt
1/4 cup Brown Sugar
2 1/2 tbsp Chili Powder
1 1/2 tbsp Ground Cumin
2 tsp Cayenne Pepper
2 tsp Black Pepper (freshly ground)
2 tsp Garlic Powder
2 tsp Onion Powder
Hickory Chips
Mix ingredients and rub mixture on meat for 2
hours before cooking. Allow meat to reach room
temperature.
Cook ribs for 3 hours at 225°F (107°C) in
preheated smoker using hickory chips during the
rst 2 hours.
After 3 hours remove the ribs and wrap in heavy
foil.
Cook for an additional 1- 1 1/2 hours.
Pork or Baby Back Ribs
Prepare the brine by dissolving enough salt in cold
water to oat an egg. (The amount given is approx.)
Add the sugar and the granulated garlic.
Brine the sh for one hour. (You can use frozen
red snapper and put in the brine for about 2-2 1/2
hours.) Combine the olive oil, brown sugar, garlic
and pepper to make a rub. Rub the mixed dry
ingredients into the sh. Oil the skin side of the sh
lightly, so it won’t stick to the smoking racks. Smoke
the sh for 60-75 minutes, depending on thickness
at 225°F (107°C). Optional: Paint the sh with
maple syrup for glaze before serving.
SMOKED RED SNAPPER
Ingredients
1 1/2 lb Red Snapper
Filet (skin on)
2 tbs Olive Oil
1 tbs Brown Sugar
1 tbs Garlic, Chopped
1 tsp Pepper Black-
freshly ground
1 tbs Maple Syrup
6 oz Moistened Wood
Chips for smoking
1 foil Pie Plate
Brine
2 qts Water
12 oz Kosher Salt-approx
2 tbs. Brown Sugar
1 tbs Garlic, granulated
MASTERBUILT SMOKIN’ RECIPES
16

Masterbuilt USA warrants its products to be free from defects in materialandworkmanshipun-
der proper assembly, normal use and recommendedcarefor 90 days from the date of original
retailpurchase. An Australian 12 monthwarrantyapplies as standard.
The followingwarranty clausesand exclusions apply.
Masterbuiltwarranty does not cover paintfinish as it may burn off duringnormaluse.
Masterbuiltwarranty does not cover rust of the unit.
Masterbuilt warranty does not cover the meat probe. The probe is replaceable.
Thisappliancemust be keptunder coverwhen in use. It must not be housed in an ex-
posed area.The smokermust be kept dry. Allowingyour smoker to get wet willvoid the
warranty.
Masterbuilt & Misty Gully requiresreasonable proofofpurchaseforwarranty claims and
suggests thatyoukeep your receipt.Uponthe expiration of suchwarranty, all such liabil-
ity shallterminate.
Within the stated warranty period, Masterbuilt/Misty Gully, at its discretion, shall repair or
replacedefective componentsfree of charge with theowner being responsible for
shipping the smoker to Misty Gully service department. Once the smokerhasbeen
assessedand a fault is provenMisty Gully will repairthe smoker and will be responsible
for the cost of shipping to returnthe smoker to the customer. If no fault is discovered the
customerwill be responsiblefor the return shipping as well.
In manycasesanyproblems will be solved by replacing the defective component, thiscan
usually be sorted out by going through a troubleshooting process.Shouldthe customer
not wish to pay the shipping of the complete smoker to MistyGully we arehappytosend
the required part to the customerfree of charge for fitting by a qualified electricianfor
the cost of the postage.
Thiswarranty excludes propertydamagesustained due to misuse, abuse, accident, damage arising out
of transportation, or damage incurred by commercial use of thisproduct. Ifareturned smoker is found
to be in a condition of misuse,has not beenkeptclean or has beenmodified in some way the warranty
will be void.
This expressedwarranty is thesole warranty given by Masterbuiltand is in lieu of all otherwarran-
ties, expressed or implied including implied warranty, merchantability, or fitnessforaparticular
purpose.
Neither Masterbuiltnor the retailestablishment selling this product,has authority to make any warran-
ties or to promise remedies in addition to or inconsistent with those stated above.
Masterbuilt’s & Misty Gully’s maximum liability, in any event, shall not exceed the purchaseprice of
theproductpaidbythe originalconsumer/ purchaser.
PLEASE CONTACTMISTYGULLY SERVICE DEPARTMENT VIA THE CONTACT US PAGE ON THE WEB-
SITE, VIA EMAIL [e-mail] OR PHONE [phone] WITH FULL DE-
TAILS ON THE PROBLEM AND WHAT YOU HAVE TRIED TO RECTIFY IT.
LIMITED WARRANTY
17

WARNING:
1. During use the appliance becomes hot. Care should be taken to avoid touching heating
elements inside the oven.
2. Accessible parts may become hot during use. Young children should be kept away.
3. Do not use harsh abrasive cleaners or sharp metalscrapers to clean theoven door
glass since they can scratch the surface, which may result in shattering of the glass.
4. Only use the temperature probe recommended for this oven.
5. A steam cleaner is not to be used.
6. The appliance must not be installed behind a decorative door in order to avoid overheating.
7.
This appliance is not intended foruse by persons (including children) with reducedphysical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety. Children should be supervised to ensure that they do not play with the appliance.
8. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent
or similarly qualified persons in order to avoidahazard.

Manufactured by:
MasterbuiltUSA, Georgia.
For
Misty Gully Enterprises P/L
P.O Box 96
Mansfield, Victoria 3724
Australia
www.mistygully.com.au
Phone:[phone]
Email: [email protected]om.au
