MasterCraft 058-6553-2 User manual

30” 1-Drawer Tool Cart
model no. 058-6553-2

4
6
8
10
9
9
PARTS LIST
ASSEMBLY INSTRUCTIONS
OPERATING INSTRUCTIONS
MAINTENANCE
WARRANTY
SAFETY
3

4model no. 058-6553-2 I contact us 1-800-689-9928
This manual contains information that relates to PROTECTING PERSONAL SAFETY
and PREVENTING EQUIPMENT PROBLEMS. It is very important to read this manual
carefully and understand it thoroughly before using the tool cart.
• The maximum weight for each drawer should be no more than 75 lb (34 kg). DO NOT OVERLOAD DRAWERS.
• The maximum product weight, including contents, should be no more than 450 lb (204.5 kg) for the cart.• DO NOT attempt to lift the cart using chains, ropes or other lifting devices if two persons cannot lift the cart by the side handles. Use a forklift placed under the bottom of the cart if this situation occurs. The side handles may fail, which maycause personal injury or damage to the product.
• DO NOT stand on this product. You may fall, which may cause personal injury.• WEAR SAFETY GLASSES when removing or repositioning the slides.• When moving this product, do not pull it. Push the product to prevent personal injury.
• Handle and swivel castors must be attached on the same side of the product.• USE THE BRAKES when not moving this product. This will prevent the product from rolling, which may cause personal injury or product damage.• DO NOT open more than one drawer at a time. The product may become unstable and tip, which may cause personal injury or product damage.• DO NOT mount this product on a truck bed or any other moving object. This may cause personal injury or product damage.
• Secure this product properly before moving it with a forklift.• DO NOT tow with power equipment. The product could tip, which may cause personal injury or product damage.
• DO NOT alter this product in any manner. For example, do not weld external lock bars or attach electrical equipment. This may cause product damage or personal injury.
• Keep the product on level surfaces. The product may become unstable and tip if stored or moved on an uneven surface, which may cause personal injury or product damage.
• When the cover is open, be sure the cover stop is in the locked position. This willprevent accidental closure and personal injury.
• BE CAREFUL when closing the cover. Remove hands before the cover closes

5
completely to prevent personal injury.
• Close the cover and lock the drawers before moving this product. The drawers could come open and make the product unstable and tip, which may causepersonal injury or product damage.
• Remove the liner from the product, if necessary, before installing the product. Otherwise, the product could slip, be damaged and cause injuries.• When locking the product, close the drawer for lock bars to work properly.• IMPORTANT: Do not attach or mount this product to a vehicle. Mounting this product to any vehicle in any manner will void warranty.

TOOL CART 058-6553-2
PARTS LIST
Drawer pull
Drawer assembly 02-601321-01
M6 hex flange nut (for handle)
Handle
Bottom tray
M6x12 bolt (for handle)
Leg frame
M8x35 hex bolt
M8 hex flange nut
Swivel castor without brakes
Swivel castor with brakes
02-471204
02-601321-03
02-601321-05
02-200203-1
02-471605
02-471207
02-601321-02
02-471106
02-200203-2
02-601321-04
1
4
1
1
4
12
1
2
2
16
2
M5x12 bolt (for drawer pull)
Lock assembly (601-610)
Drawer liner
1
2
1
Wrench for castors 1
02-460904
02-471603
02-601321-06
02-601321-07
6model no. 058-6553-2 I contact us 1-800-689-9928
The keys are taped to the top of the castor carton, which is placed in the top tray.

7

Carefully lay down the cart. Position the two swivel castors with brakes (9) close
to the handle side and screw into the legs. Screw the two swivel castors without
brakes (10) onto the other legs.
Tighten them securely with the wrench (15).
Position the cart handle (3) over the
holes and attach with the M6 x 12
bolts (4) and the M6 hex flange nuts (2)
Tighten securely.
8model no. 058-6553-2 I contact us 1-800-689-9928

9
Extend the drawer slides from thetool chest. Insert the brackets oneach side of the drawer into the slots in the slide and ensure that
they are properly in position. Once
properly inserted, completely closethe drawer to set the slides in theirproper positions.

10
This Mastercraft product is guaranteed for a period of one (1) year from the date oforiginal retail purchase against defects in materials and workmanship.This warranty is subject to the following conditions and limitations:
model no. 058-6553-2 I contact us 1-800-689-9928
