Masterlite 81265 User manual

Dakota Brick Light
81265
Fitting / Replacing Bulbs
Commissioning
Waste electrical products should not be disposed of with household waste.
Please recycle where facilities exist. Check with your Local Authority or retailer
for recycling advice.
For your safety, always switch off the supply before cleaning.
This system contains non-replaceable parts and cannot be serviced. If damage occurs the part
should be scrapped.
Care and Cleaning
Recycling Advice
Safety In formation
This system contains non-replaceable parts and cannot be serviced. If damage occurs the part
should be scrapped.
We recommend cleaning with a soft cloth.
Do not use solvents or abrasive cleaners as these could damage the finish.
The shade must be replaced immediately should the shade become
place.
Masterlite BH17 7BY 26/05/17
6. Gently push the product into the wall, taking care not to trap any wiring.
7. Replace fuse or circuit breaker and switch on.Your light is now ready for use.

STEP 1
Thank you for purchasing this light fitting.
Please read the instructions carefully before use to ensure safe and satisfactory operation of
this product. Please retain these instructions for future reference.
Warning
Specification
Installation
Layout
Wiring
Voltage: 240V 50Hz a.c.
Class: II (Double Insulated)
Lamp: 3W LED Module - 6500K/280lm
IP rating: 65
This is a Class 11 product and must not be earthed.
Please read these instructions carefully before commencing any work.
This unit must be fitted by a competent and qualified electrician.
Install in accordance with IEE Wiring regulations and current Building Regulations.
To prevent electrocution switch off at mains supply before installing or maintaining this fitting.
Ensure other persons cannot restore the electrical supply without your knowledge. If you
are in any doubt, please consult a qualified electrician.
This light fitting should be connected to a fused circuit.
If replacing an existing fitting, make a careful note of the connections.
This system contains non-replaceable parts and cannot be serviced. If damage occurs the part
should be scrapped.
Waste electrical products should not be disposed of with household waste. Please recycle
where facilities exist. Check with your local authority or retailer for recycling advice.
This product is rated at IP65
This product is not suitable for location in or near a marine environment.
This product is not suitable for dimming.
•Plan the desired layout of this fitting carefully, ensuring the cables will reach the distance
between the junction box and the light fitting.
•Avoid locating any cables in positions that would cause a hazard. Position cables and
outdoor rated junction boxes (not supplied) away from areas where they may be at risk
from being cut, trapped or damaged.
•We recommend that you use H05RN-F specification cable (not supplied) which is an
outdoor grade, rubber sheathed cable. The mains supply cable must have a minimum
cross sectional area of 1.0mm²
•Cables must be protected using suitable conduit or plastic trunking.
2. Cut the mounting hole for the unit taking care not to damage any pipes or mains cables
beneath the mounting surface.
Cutout Void Depth
3. Fit the housing into position and secure. This surround may be cemented in position.
Wait until the cement has set before continuing with the installation.
Existing fittings must be completely removed before installation of a new product. Before
removing the existing fitting, caref ully note the position of each set of wires.
1. The product comes with a housing unit that must be fitted into the hole prior to any
wiring taking place.
4. Remove the terminal box cover and set
aside for refitting later. Having identified
the wiring from your existing fitting,
connect to the terminals as shown on right:
5. Refit the cover in place and refit the screws.
the cable to suit and tighten the gland
the IP rating of the product.
184mm x 62mm 60mm
Insert and secure the Brick Light
outer casing.
STEP 2 STEP 3
Feed power cables through rubber grommet,
connect to the terminal block inside
Fix in place the clear lens and
metal outer frame using the
screws provided.
STEP 4
Switch on the power supply at the
ON
main fuse box and test fitting.
STEP 5
Adjust
to maintain
Switch off the power supply at the
consumer unit or fuse box.
the fitting. Refer to Wiring below
NEUTRAL
LIVE
BLUE (N)
BROWN (L)
SUPPLY LIGHT FITTING
Check That
You have correctly identified the wires.
The connections are tight.
No loose strands have been left out of the connection block.
Refit the cover and secure the four screws.
