MasterPower Data Logger WiFi Stick Instruction manual

Data Logger WiFi Stick
Quick User Guide
DLS Version: 2.0
Delivery Content
• 1 pc WiFi
• 1 pc WiFi external antenna
• 1 pc Data Logger Wifi Stick Quick User Guide

Introduction
Data Logger WiFi Stick is mainly used in inverters to
realize simple and quick access to Internet. Users can
easily check device information by logging in the
monitoring center. The communication topology is as
shown below:
Description of Symbols
To ensure normal use of the datalogger, before using the
datalogger, be sure that:
The connected wireless router can normally access
to Internet.
The communication address of the inverter MUST
BE “01”, which is default value.
A WiFi-enabled mobile phone is connected to this
device for parameter setting.
a.
b.
c.
Data Logger WiFi Stick
www.masterbattery.es

Data Logger WiFi Stick
www.masterbattery.es
Electrical Connection
Connect WiFi to the corresponding interface on the
inverter. Beta-1P5K-4G is used as an example in this
manual. Please perform relevant operations as indicated
below:
Data Logger WiFi Stick Interface
Data Logger WiFi Stick Installation
1. Insert WiFi Stick to COM port.
2. Fasten the WiFi Stick.
The datalogger must be kept away from large metal
objects and electrical devices with strong magnetic
fields, such as microwave oven, refrigerator, cordless
phone, concrete wall, PV panel and metal wall, to
ensure the communication quality. Communication
quality may be affected in lightning storms.
1.
Corresponding groove
NOTES

Data Logger WiFi Stick
www.masterbattery.es
Create Beta monitoring account
2.
Step 3: Fill in the form as required and click the
“Register”.
Step 1: Mobile phone scan the QR code to download the
APP, or in the APP Store or Google Play search Ginlong
Home or Ginlong Pro.
Step 2: Click on the “Register”.

Data Logger WiFi Stick
www.masterbattery.es
Step 2: Enter the SN of the datalogger.
The datalogger SN can be automatically scanned by
placing the purchased device bar code in the scan box. If
you can´t scan, you can also manually enter the
datalogger SN (just enter the digital serial number).
Create plant
Step 1: In the APP homepage and click “Build Your Plant
Within 1 Minute!” in the middle of the screen.
Or click the “+” in the upper right corner.
3.

Data Logger WiFi Stick
www.masterbattery.es
Note: Please scan the SN number on the datalogger, not
the SN number on the inverter.

Data Logger WiFi Stick
www.masterbattery.es
Step 3: Enter the plant information. Then click the “Next”.
Step 4: Enter the plant name and contact information of
the plant owner. Then click the “Done”.

Data Logger WiFi Stick
www.masterbattery.es
Configure WiFi
Step 1: Click the “Connect” on the Device interface.
4.
Step 2: Make sure phone connected to yourself router
WiFi network. Then click the “Next”.

Data Logger WiFi Stick
www.masterbattery.es
Step 3: Enter WiFi Password and click the “Ensure”.
Tip: if you cannot connect to WiFi, try the
following.
• If the signal strength of the selected network is
<15%, the connection is unstable, please adjust
the router’s antenna position or increase the
relay.
• The router’s SSID and password do not use !@#
$%&*,.; ‘( ) “”? and other special characters.
• Some enterprises may limit the WiFi connection,
so it is recommended closing limit function of the
Qos.
• Support the normal routing encryption
(WEP/WPAPSK WPA2PSK), does not support
mixed multiple encryption methods.
• Open the router’s DHCP function, otherwise
unable to connect to router WiFi.

Data Logger WiFi Stick
www.masterbattery.es
Step 4: Switch to the WLAN interface,connect your phone
to “AP_ XXXXXXXXX”, and switch to the APP interface.
Step 5: Wait 1-3 minutes, until the configuration is
successful.

Data Logger WiFi Stick
www.masterbattery.es
Step 6: Plant registration finished.
Tip: if configuration failure, there may be the
following reasons:
• If the signal strength of the selected network is
less than 15%, the connection is unstable.
Please adjust the position of the router’s antenna
or increase the relay.
• Connect to other network accounts with WiFi, but
not this time.
• The serial number cannot be scanned, and it is
wrong to input the serial number manually.
• 5G WiFi is not supported.
Distributor/Installer create plant
In order to easy registration and easy manage, you can
also let the distributor/installer register the plant, then
Link it to you.
Click the [ ] and tell the “ID” to your distributor/installer
to build the plant for you. (Note: your distributor/installer
must have a Ginlong Pro account)
5.

Data Logger WiFi Stick
www.masterbattery.es
Link distributor/installer
Step 1: In order to easy manage to your plant.
Select the plant and enter Intro. Click the “installer” or
“distributor”.
6.

Data Logger WiFi Stick
www.masterbattery.es
Step 2: Enter the company name of the installer or
distributor. Then click the “Search”.
Step 3: Click the [Bind Distributor/Installer] and the plant
will appear in your installer/distributor monitoring
interface. (Note: your installer/distributor must have a
Ginlong Pro account to appear in the search list)

Contact
If you have any technical questions about our products,
please contact us. Before contacting us, please confirm
the following items:
•Equipment model
•Serial number of the datalogger
•Problem description
•Screenshot of the Status page in the configuration
interface
Master Battery, S.L.
Área Industrial La Dehesa
C/ Dehesa Vieja, 2 - 28052 Madrid (Spain)
Tel.: [phone]
Fax: [phone]
Email: [e-mail]
Web: www.masterbattery.es
