Matco Tools Megajump User manual

Page 1
Warning:This product contains rechargeable lithium ion batteries. Lith-
ium batteries are potentially hazardous and can present a serious FIRE
HAZARD if damaged, defective or improperly used. Larger lithium bat-
teries and those used for industrial use involving high discharge current
and frequent full discharge cycles require special precautions. User as-
sumes all risk associated.
READ THE ENTIRE MANUAL BEFORE USING THIS PRODUCT.
FAILURETO DO SO COULD RESULT IN SERIOUS INJURY OR DEATH.
MEGAJUMP

Page 2
IMPORTANT SAFETY INSTRUCTIONS
WARNING – RISK OF EXPLOSIVE GASES
WORKING WITH, AND IN THE AREA OF A LITHIUM OR LEAD-ACID
BATTERY IS DANGEROUS. BATTERIES GENERATE EXPLOSIVE GASES
DURING NORMAL OPERATION. IT IS IMPORTANT THATYOU FOLLOW
THESE INSTRUCTIONS EACHTIMEYOU USE THE UNIT.
To reduce the risk of battery explosion, follow these instructions and
those published by the battery manufacturer and the manufacturer of
any equipment you intend to use in the vicinity of a battery. Review
cautionary markings on these products and on the engine.
WARNING! RISK OF ELECTRIC SHOCK OR FIRE.
1. Read the entire manual before using this product. Failure to do so
could result in property damage, serious injury or death.
2. Keep out of reach of children.
3.
4. Do not expose the unit to rain or snow.
5. Use only recommended attachments. Use of an attachment not recom-
persons or damage to property.
6. To reduce the risk of damage to the electric plug or cord, pull by the plug
rather than the cord when disconnecting the unit.
7. Do not operate the unit with damaged cables or clamps.
8. Never attempt to modify or alter unit, cables or accessories, this can result
in permanent damage to unit, electric shock, and/or personal injury and
property damage.
9. -
electric shock. WARNING! RISK OF EXPLOSIVE GASES.
10. To reduce the risk of a battery explosion, follow these instructions and
those published by the battery manufacturer and the manufacturer of any
equipment you intend to use in the vicinity of the battery. Review the cau-
tionary markings on these products and on the engine.
11.
paper, cardboard, etc.
12. Do not use the unit to jump start a vehicle while charging the internal bat-
tery.

Page 3
CAUTION AND CARE
WARNING! RISK OF EXPLOSIVE GASES. A SPARK NEAR THE BAT-
TERY MAY CAUSE A BATTERY EXPLOSION.TO REDUCE THE RISK OF A
SPARK NEAR THE BATTERY:
1. -
gine.
2. Remove personal metal items such as rings, bracelets, necklaces and
watches when working with a lithium or lead-acid battery. A battery can
produce a short-circuit current high enough to weld a ring to metal, caus-
ing a severe burn.
3. Be extra cautious, to reduce the risk of dropping a metal tool onto the bat-
tery. It might spark or short-circuit the battery or other electrical part that
may cause an explosion.
4. Do not permit the internal battery of the unit to freeze. Never charge a
frozen battery.
5. To prevent sparking, NEVER allow clamps to touch together or contact the
same piece of metal.
6. Always have someone nearby to come to your aid when you work near a
Lead-acid battery.
7. Have plenty of fresh water, soap and baking soda nearby for use, in case
battery acid contacts your eyes, skin, or clothing.
8. Wear complete eye and body protection, including safety goggles and pro-
tective clothing. Avoid touching your eyes while working near the battery.
9. If battery acid contacts your skin or clothing, immediately wash the area
with cold running water for at least 10 minutes and get medical attention
right away.
10. If battery acid is accidentally swallowed, drink milk, the whites of eggs or
water. DO NOT induce vomiting. Seek medical attention immediately.
11. Neutralize any acid spills thoroughly with baking soda before attempting to
clean up.
BEFORE USE PRECAUTIONS AND PREPARATIONS
WARNING! RISK OF CONTACT WITH BATTERY ACID. BATTERY ACID IS
A HIGHLY CORROSIVE SULFURIC ACID.
1. Make sure the area around the battery is well ventilated while the unit is in
use.
2. Clean the battery terminals before using the jump starter. During cleaning,
keep airborne corrosion from coming into contact with your eyes, nose
and mouth. Use baking soda and water to neutralize the battery acid and
help eliminate airborne corrosion. Do not touch your eyes, nose or mouth.
3. Determine the voltage of the battery by referring to the vehicle owner’s
manual and make sure that the output voltage of the jump starter is cor-
rect.
4. Make sure that the unit’s cable clamps make secure connections.

Page 4
WHEN CONNECTING TO THE BATTERY
WARNING! A SPARK NEARTHE BATTERY MAY CAUSE A BATTERY EXPLO-
SION. TO REDUCE THE RISK OF A SPARK NEAR THE BATTERY:
1. Attach the output cables to the battery and proper ground as indicated below.
Never allow the output clamps to touch each other.
2. Position the DC cables to reduce the risk of damage by the hood, door and mov-
ing or hot engine parts.
3. NOTE: If it is necessary to close the hood during the jump starting process,
ensure that the hood does not touch the metal part of the battery clips or cut the
insulation of the cables.
4. Stay clear of fan blades, belts, pulleys and other parts that can cause injury.
5. Check the polarity of the battery posts.The POSITIVE (POS, P, +) battery post
usually has a larger diameter than the NEGATIVE (NEG, N, -) post. Determine
which post of the battery is grounded (connected) to the chassis. If the negative
post is grounded to the chassis (as in most vehicles), see step 6. If the positive
post is grounded to the chassis, see step 7.
6. For a negative-grounded vehicle, connect the POSITIVE (RED) clamp from the
jump starter to the POSITIVE (POS, P, +) ungrounded post of the battery. Con-
nect the NEGATIVE (BLACK) clamp to the NEGATIVE (NEG, N, -) post of the bat-
tery. Do not connect the clamp to the carburetor, fuel lines or sheet-metal body
parts.
7. For a positive-grounded vehicle, connect the NEGATIVE (BLACK) clamp from
the jump starter to the NEGATIVE (NEG, N, -) ungrounded post of the battery.
Connect the POSITIVE (RED) clamp to the POSITIVE (POS, P, +) grounded post of
the battery. Do not connect the clamp to the carburetor, fuel lines or sheet-metal
body parts.
8. When disconnecting the unit, remove the clamp from the unit, and then remove
the clamps from the battery terminals.
CHARGING THE UNIT
IMPORTANT! NEVER CHARGE UNIT UNATTENDED. CHARGE IMMEDIATELY
AFTER PURCHASE, AND EVERY 3-6 MONTHS, TO KEEPTHE INTERNAL BAT-
TERY FULLY CHARGED AND PROLONG BATTERY LIFE. CHARGE AFTER
USE, IF USED TO JUMP START, ALLOW UNITTO COOL DOWN FOR 15-20
MIN BEFORE CHARGING.
IMPORTANT: DO NOT USE THE UNIT WHILE CHARGING THE INTERNAL BAT-
TERY
1. To reduce the risk of electric shock, unplug the unit’s wall charger from the
outlet before attempting any maintenance or cleaning. Simply turning off the
controls will not reduce this risk.
2. When charging the internal battery, do so in a well ventilated area and do not
leave unattended. Never charge the unit immediately after jump start al-
low, 15-20 min cool down.

Page 5
Package Contents:
• Jump Starter
• Jumper cable with smart clamps
• (2) USB to Micro-USB charging chords
• Dual USB AC wall charger
• Dual USB DC car charger (input)
• 12V DC to Dual USB Adapter
• USB pigtail
• User manual
• Carrying case
Capacity 30000mAh/111Wh
Start Current 8000A
Peak Current 1800A
Charging Port Output
Input 5V/2.1A(max)
Size 8.75" x 7.75" x 2.75"
Weight 4 lbs.
Note: Please be advised that this device will not charge devices with input currents lower than
80mA, including some Bluetooth and GPS devices.
How to Charge Jump Starter
1. Plug both the Micro USB cables into the unit’s input ports.
2. Insert the other end of the USB cables into:
(A) Included AC adaptor connected to the wall socket.
(B) Two powered USB computer ports.
(C) Included DC adaptor socket of cigarette lighter.
The unit will automatically begin to charge and will turn off when the battery of the jump
starter is fully charged.
5V/2.1A (min 80mA),12V/10A
1
2
3
4
5
6
7
8
1.LED Flash Light
2.Jump Start Socket
3.12V/10A Output
4.LED Panel Light
5.Power Button
6.Charge Indicator
7.Dual 5V 2.1A Output
8.Dual 5V 2.1A Input

Page 6
CHARGING THE INTERNAL BATTERY, USINGTHE AC WALL CHARGER
IMPORTANT! NEVER CHARGE UNIT UNATTENDED.
WARNING! Use only the charger included with the unit to charge the
internal battery. Using any other charger could damage the unit.
LED Indicator Display While Charging the Unit
USB Adapter Charging Speed
Adapter Current
Output Charging Time
5V/4A About 7 hours
5V/3A 9-10 hours
5V/2A 13-14 hours
5V/1A About 28 hours
5V/0.5A About 55 hours

Page 7
HowTo Use The Jump Starter
Jump start 12V vehicle Instruction (a)
1. Make sure that the unit is showing no less than 3 lights on the LED charge indi-
cator display before using as a jump-starter.
2. Connect the RED clamp to the vehicle’s battery positive (+) terminal and connect
the BLACK clamp to the vehicle’s negative (-) terminal.
3. Plug the cord of jumper cable into the jump start socket port.
4. Check indicator light on the clamps, Green light means ready to go; then start
the vehicle (otherwise please check the connection).
5. When the vehicle is started, remove the jumper cable from the device and dis-
connect RED and BLACK clamps from vehicle battery terminals.
6. Leave the vehicle’s engine running.
7. DO NOT ATTEMPT TO DRIVE VEHICLE WITH THIS DEVICE CONNECTED
TO THE BATTERY, OR LEAVE ATTACHED TOTHE BATTERY OF A RUN-
NING VEHICLE.
Charging Cell Phone or Tablet Instruction (b):
1. Plug the switch cable to USB 5V/2.1A output port.
2. Select the appropriate connector for your cell phone or tablet and connect it to
any of them.This device can identify and charge your electronic device auto-
matically.The indicators will be on when the device is charging.
C. LED Flashl ight
1. Press the switch 3 seconds to turn on/off the LED Flashlight.
2. There are 3 modes of LED torch: Normal light, Strobe, SOS, which can be shifted in turns
by pressing the switch.
3. Press the switch 3 seconds to turn off the LED Flashlight no matter you are in any mode.
D. LED panel light
1. Press the switch 3 seconds to turn on the LED panel light.
2. There are 2 modes of LED light: Normal light, red and white flashing light, which can be
shifted in turns by pressing the switch.
3. Press the switch 3 seconds to turn off the LED panel light no matter you are in any mode.
E. 12V/10A DC Output Port
1. Plug DC adapter into 12V DC port and connect desired device for use.
2. Disconnect device and DC adapter when not in use.

Page 8
FAQ
Q. How to start a car with a dead vehicle battery or without the vehicle bat-
tery?
A.Thanks to jump starter’s smart-circuitry, the smart clamps can be auto-
matically activated both with dead vehicle battery and without car battery
after being connected to the power terminals. Attach the smart clamps to
the vehicle battery or vehicle power terminals, positive (+) to positive (+),
negative (-) to negative (-), then you can start the vehicle successfully.
Q. How to turn off the device?
A.This device will automatically turn off when not in use, or when charging
is completed.
Q. How many times can this device charge my mobile phone?
A.The battery capacity is 30000 mAh. For example it can give you full
charge up to 10 times for iPhone6 and about 12 times for iPhone5s.
Q. How long will this device take to fully charge my mobile phone?
A.This device will intelligently identify your device and will charge it at its
maximum charging speed. Charging time depends on the battery capacity
in your device.
Q. How many times can this device boost a vehicle on a full charge?
A. Up to 20 times depending on type of vehicle and state of charge on ve-
hicle battery.
Q. How long will the power of jump starter battery hold a charge?
A. 6-12 months, however, we suggest recharging it every 3 months.
TROUBLESHOOTING

Page 9
Usage Notes
1. Always make sure that the blue plug on the jumper cable is tightly inserted
into the jump starter socket before jump starting the vehicle. Otherwise it
will affect the performance of the device and could cause melting on the
blue plug.
2. Always ensure the jumper cable clamps have a good connection, check the
vehicle battery connector for excess buildup and clear any away before
jumping start the vehicle. DO NOT attempt to jump start after 3 failed at-
tempts. Otherwise, it will damage your jump starter. If after 3 failed at-
tempts please check your vehicle for other problems, it is likely that your
vehicle has an underlying issue causing it not to start.
3. DO NOT disassemble the jump starter. It can be dangerous and
will void the warranty.
MAINTENANCE INSTRUCTIONS
1. After use and before performing maintenance, unplug and disconnect the
unit.
2. Use a dry cloth to wipe all battery corrosion and other dirt or oil from the
battery clamps, cords, and the outer case.
3. Do not open the unit, as there are no user-serviceable parts; any
-
sonnel.
STORAGE INSTRUCTIONS
1. Charge battery to full capacity before storage.
2. Store this unit at temperatures between -4°F–+104°F (-20°C–+40°C).
3. Never completely discharge the battery.
4. Charge after each use.
5. Charge at least once every 3 to 6 months if not in frequent use, to prevent
over-discharge.

Page 10
WARRANTY REPAIRS | REPLACEMENTS
For REPAIR OR REPLACEMENT, contact Customer Service at 1-800-537-1077.
DO NOT SHIP UNIT UNTILYOU RECEIVE A RETURN MERCHANDISE AU-
THORIZATION (RMA) number from Customer Service at HorizonTool Inc.
LIMITED WARRANTY INFO LIMITED WARRANTY
NOTE - Save proof of purchase, such as a dated store receipt, to establish warran-
ty period. Without a dated receipt, we will use the manufacturing date code.This
warranty for the Jump Starter is extended to the original purchaser or user, and it
covers defects in materials and workmanship for one year.
For malfunction due to defects in materials or workmanship prior to 6 months
from the purchase date, we will repair or replace the unit at our discretion after
inspection.
NOTE -The Battery is covered under separate terms.The Battery will be prorated
month.
This applies only to batteries which have NOT been misused or abused.Typi-
cal failure modes of misused or abused battery are melted terminals or signs of
overcharging.
This warranty is invalidated if any of the following occurs, but not limited to this
list:
• Failure to follow instructions in the User’s Manual
• Accidental and I or unreasonable use or misuse
• Mishandling
• Over Charging or Overloading
• Extended storage without recharging
•
• Normal wear or accident.
This warranty is in lieu of all other express warranties. HorizonTool, Inc. will not
be liable for consequential or incidental damages. Some states do not allow limi-
tations on warranties. In such case the above limitation may not apply.
SERVICE ADDRESS
HorizonTool, Inc.
7918 Industrial Village Road
Greensboro, NC 27409
NOTE - Whenever returning a product to this address, it must be packaged se-
curely to avoid shipping damage. Horizon Tool, Inc. will not be responsible for any
shipping or handling damage. Also, all postage or transportation must be prepaid.
CUSTOMER SERVICE CONTACT
AllStart LLC.
Service Dept.
TEL: [phone]
FAX: [phone]
Email: [email protected]
Web: ALLSTARTBOOST.COM
