Matco Tools MDMAX4 User manual

Quick Start Guide
Maximus 4.0 Tablet Included Accessory Checklist
Maximus 4.0 Tablet
A tablet for showing
test results.
Power Adapter
To supply power to the
tablet through connection
to AC outlet.
OBD I Adapter Cable
A converting cable for
connecting non-16 pin
connector.
HDMI Cable
To mirror the tablet screen
onto an external projector
or monitor with HD
interface.
MAX4CSCOPE Kit
Type A to Type B USB Cable
Connects the tablet to the VCI
dongle or add-on module
(such as MAX4CSCOPE).
Battery Cable
To provide power to the non-
16pin connector through
connection to the vehicle’s
battery.
Clamps
Type A to Type C USB Cable
Connects the tablet to the PC
for data exchange.
Password Envelope
A piece of paper bearing
Product S/N and Verification
Code, which is required for
your VCI activation. MAXBATTERY
Vehicle Communication
Interface (VCI) Dongle
A device for accessing
vehicle data.
OBD II Extension Cable
To connect the VCI dongle
for extension purpose.
Non-16pin Connector Kit
(including OBD-6 and
OBD-9 adapter cables for
commercial vehicles)
For detailed non-16pin
connectors, please check
the package box.
Front Camera
Handgrip
Charging LED
HDMI-Out Port
Type-A USB Port
Memory Card Slot
Type-C USB Port
DC-IN Port
Microphone
13.3" IPS Touch Screen
Camera Flash
Microphone
POWER Button
Volume Buttons
Rear Camera
Audio Speaker
Foldable Stand
Audio Speaker
(Red means Charging, and
Green means Fully Charged.)
(
)
Flip out it to any angle and work comfortable
at your desk, or hang it on steering wheel.
The tablet acts as the central processing system, which is used to receive and analyze the live
vehicle data from the VCI dongle and then output the test result.
Ambient Light Sensor
2101068-16
MDMAX4
VCI (Vehicle Communication Interface) Working Principle
1. Charging & Turning On
The VCI dongle works as a vehicle communication interface device, which is used to connect
to the vehicle's DLC (Data Link Connector) socket via OBD II extension cable to read the
vehicle data and then send it to the tablet via Wi-Fi. Works with the passenger and commercial
vehicles.
LED Indicators
It is defined as follows:
1. Power: It illuminates solid red when the VCI dongle is
powered on.
2.Vehicle: While the VCI dongle is communicating with
the vehicle, the LED lights up and flashes. Otherwise,
it will not illuminate.
3.BT: It lights up when the VCI dongle is working in
wireless (BT) communication mode.
4. I/O: It lights up when the VCI dongle is connected to
the tablet via data cable.
5. Wireless: It lights up when the VCI dongle is working
in the default Wi-Fi communication mode.
(To connect on vehicle's OBD II DLC port.)
OBD-16 Connector
Data I/O Port
(
vehicle diagnosis via data cable.)
To connect it to the tablet to perform
*Note: When the VCI dongle
is connected to the tablet via
data cable, the system will
switch to USB mode
automatically and the
wireless communication will
be disabled.
*Note: When connecting the non-OBD
II vehicle’s DLC, please check the type
of the DLC and select the
corresponding non-16pin connector or
adapter cable. After use, please
remember to unplug it from the
vehicle’s DLC.
DC-IN Power Jack
(For connecting the power adapter.)
Reset Hole
(To reset the VCI dongle.)
VCI Dongle
Internet
Vehicle
To Vehicle’s DLC Port
Wi-Fi Communication
Wi-Fi Communication*
(The Wi-Fi module 1 enables the tablet
to access the internet. See Section 3 for
WLAN Setup.)
(The Wi-Fi module 2 allows the tablet to
wirelessly communicate with the VCI
dongle.)
The tablet has dual built-in wireless communication modules. One is used to communicate
with the VCI dongle, and the other allows the tablet to get online.
1. Connect one end of the included power adapter to DC-IN port of the tablet, then connect
the other end to the AC outlet.
*Warning: Please use the included power adapter to charge your tablet. No responsibility
can be assumed for any damage or loss caused as a result of using power adapters other
than the one supplied.
2. After charging is complete, disconnect the power adapter from the AC outlet. Press the
[POWER] button on the tablet, the system starts initializing and then enters the home screen.
*Note: If the VCI dongle is successfully
activated, the tablet will automatically obtain the
VCI ID and connect to it. In this case it is not
necessary for the user to manually configure it
again. For details on how to activate the VCI
dongle, refer to Section 4. Register & Update.
Maximus 4.0
Tablet
4.0
2101068-16
Quick Start Guide MDMAX4

2. Changing Language
3. WLAN Setup
4. Register & Update
4. Register & Update(Cont.)
Step 1: On the Home screen, tap on
“Maximus 4.0” to run the App, the
following screen displays. Tap on
“REGISTER UNIT”.
Step 3: Tap on “RUN DIAGNOSTICS”
button to launch diagnostics.
Step 5: Tap on “UPDATE” button (*Note:
Red dot means new software is available).
Step 2: Tap on “ACTIVATE” button after
information* is entered.(*Note: Serial
number is a 12-digit number starting with
98 – you can find it on the back of your tool.
Verification code is an 8-digit number
stored in the Private & Confidential sheet.
Activation code is printed on the receipt, or
ask your dealer for it.)
Step 6: Make sure all brands are selected,
tap on “Install”.
Tap on “OK” button when update is
complete. (*Note: Download and
installation will take approximately 10
minutes depending on the internet
connection.)
Step 4: Tap on on the top left-hand
corner.
Maximus 4.0 supports multiple languages. To change the language of the tool, please do the
following:
1. On the home screen, tap on Settings -> Language & Input -> Languages.
2. Tap on “Add a language”, and then choose the desired language from the list.
3. Tap and hold the desired language and drag it to the top of the screen and then release it,
the system will change into the target language.
Once you're online, you can register your tool, update the diagnostic software and APK, surf
the Internet and send email on your network. Follow the steps below to proceed:
->
, the tablet
, the tablet
1. On the home screen, select Settings WLAN.
2. Slide the WLAN switch to ON will start searching for all available wireless
networks.
3. Select a wireless network. If the chosen network is open will connect
automatically. If the selected network is encrypted, a network password will need to be
entered.
2101068-16
Quick Start Guide MDMAX4
Note:
To enjoy more capabilities and functions, it is
recommended you check for updates on a
frequent basis and keep synchronized with the
latest available software.
Preparation
Before diagnosing, please make sure the following:
s Switch the ignition on.
s
~ 14V or 18V ~ 30V.
s Throttle should be in a closed position.
Vehicle battery voltage range should be 11V
Note: For more detailed operations, please refer to the In-App User Manual stored
under “ (Toolbox)” -> “About” -> “User Manual”.
Pictures illustrated herein are for reference purpose only and this Quick Start Guide
is subject to change without notice.
Maximus 4.0 supports three kinds of diagnosis approaches: Smart Diagnosis (MaxVIN),
Manual Diagnosis and Remote Diagnosis.
Maximus VINSCAN:
Through simple Wi-Fi communication between the Maximus 4.0 tablet and VCI dongle, you
can easily get the VIN (Vehicle Identification Number) information of the currently identified
vehicle. Once the VIN is successfully identified, the system will retrieve it from the remote
server and then guide you to vehicle information page without the necessity of step-by-step
manual menu selection (Early model may need manual selection.).
Remote Diagnosis:
This option aims to help repair shops or professional technicians launch instant messaging
and remote diagnosis, making the repair job getting fixed faster.
Manual Diagnosis:
In this mode, you have to diagnose a vehicle by performing the menu-driven command
manually.
For new users, please follow the operation chart shown below to get familiar with and start
using this tool.
5. Vehicle Connection 6. Start Diagnostics
Launch Maximus 4.0
App
Select vehicle
Select software version
and touch on “OK”
Follow the prompts
on the screen
1). OBD II Vehicle Connection
the vehicle’s OBD II DLC port.
Connect one end of the OBD II extension cable to the OBD-16 connector, and the other end to
A. For Passenger Cars:
B. For Commercial Vehicles:
2). Non-OBD II Vehicle Connection
VCI Dongle
VCI Dongle
OBD I Adapter
Battery Cable Clamps
Battery Cable Clamps
OBD II Extension Cable
Non-16pin Connector
To Vehicle’s Battery
To Vehicle’s Battery
Adapter Cable
To Vehicle’s DLC
To Vehicle’s DLC
If the power supply on vehicle diagnostic socket is insufficient or the power pin is damaged,
you can get power in the following ways:
1. Locate Vehicle’s DLC Port
The DLC (Data Link Connector) is typically a connector
where diagnostic code readers interface with the
vehicle's on-board computer.
For commercial vehicles, it is generally located in the
driver's cab.
For passenger cars, it is usually located on driver’s side,
about 12 inches away from the center of dashboard. See
Figure DLC Location.
2. Vehicle Connection
DLC Location
If the DLC cannot be found, refer to the vehicle’s service manual for the exact location.
