Matheson 6124 User manual

INT-0068 rev C
PARTICLE FILTERS
Instructions
READ AND COMPLY WITH THESE INSTRUCTIONS BEFORE
INSTALLING, OPERATING, OR SERVICING

Table of Contents
I. Service...............................................................1
II. Troubleshooting...............................................2
III. Limited Warranty............................................3
IV. User Responsibility..........................................4
V. Safety Precautions............................................5
VI. General Description.........................................6
VII. Installation ......................................................7
VIII. Operating Instructions .................................9
IX. Maintenance ....................................................9
X. Specifications ................................................11

1
I. SERVICE
General Service
A unit which is not functioning in a normal manner should be removed from service until
such time that repairs or replacement can be made. Upon completion of repair, full testing
should be performed to assure the user that the unit has been returned to its original
operating parameters. Matheson can repair or replace Filters. To arrange for repair or
replacement service, call 1-800-828-4313 and ask for the Warranty Administrator. No
product will be received by Matheson without indication of gas service and without
proper return material authorization provided by the warranty administrator. (All
repairs must be made by Matheson or an assigned and approved facility to maintain
any warranties or guarantees)
If the unit is under an applicable warranty, return the unit to Matheson for repair or
replacement. To arrange for warranty service, call 1-800-828-4313 and ask for the
Warranty Administrator. No product will be received by Matheson without indication
of gas service and without proper return material authorization provided by the
warranty administrator.
If advised by the Warranty Administrator to return the product to Matheson, prepare the
product for shipment and write, in large lettering the RMA Number assigned by the
Warranty Administrator on the outside of the box. Also, if required by the Warranty
Administrator, supply the completed RMA form with the product. Make sure that the
product is adequately packaged, in the original shipping container if possible, and shipped
prepaid (Matheson will not accept COD freight) with a description of the observed
deficiency to the attention of the:
Warranty Administrator
Matheson
166 Keystone Drive
Montgomeryville, PA 18936
The user is expected to periodically inspect the product for leaks, loose or worn parts,
broken or non-functioning components and to address those situations immediately. If the
user would require verbal assistance in ascertaining the potential of a problem with any
Matheson product, contact the local Matheson branch for assistance or your Matheson
Sales Representative.

2
II. TROUBLE SHOOTING
1. Initial Tests
1.1 Remove the Filter unit from the package in which it was shipped. Examine
closely the packaging for signs of abuse during shipment. Make sure that the
end dust plugs are attached to the unit. If the packaging appears to be abused, or
if the end plugs are not installed, arrange for return following the procedure set
forth in the “SERVICE” Section.
1.2 For Filter units having VCR connections, examine the sealing surface for signs
of abuse. If the sealing surfaces are scratched or otherwise damaged, arrange
for return following the procedure set forth in the “SERVICE” Section.
1.3 Examine the packing slip for the unit(s) ordered. Make certain that the unit(s)
shipped matches the unit ordered as verified by the packing slip.
2. After Installation and Operation
2.1 Filters are considered expendable parts. Over periods of use, to be determined
by the user, it will become necessary to exchange the filter for a new one.
Note: If the pressure drop across the filter exceeds a delta of 50% from the
original value, it may be an indication that the filter needs to be replaced.
2.2 Filters should be leak tested periodically, on a schedule provided by the user
based on experience, for degradation of the seals used in installation by using
one of the methods describe in the “INSTALLATION” Section..
2.3 Filters should be visibly inspected periodically, on a schedule provided by the
user based on experience, for signs of corrosion or other abuse to filter housing.
2.4 Filters exhibiting any of the deficiencies listed in this subsection should be
immediately removed from service and replaced.

3
III. LIMITED WARRANTY
This equipment is sold by Matheson Tri-Gas (Matheson) under the warranties set forth in
the following paragraphs. Such warranties are extended only with respect to the purchase
of this equipment directly from Matheson or Matheson's Authorized Agent as new
merchandise and are extended to the first Buyer thereof other for than the purpose of resale.
For a period of one year from date of original delivery (ninety days in corrosive service) to
Buyer or to Buyer's order, this equipment, is warranted tobe free from functional defects in
materials and workmanship and to conform to the description of this equipment contained
in this manual and any accompanying labels and/or inserts, provided that this equipment is
properly operated under the conditions of normal use and that regular and periodic
maintenance and service is performed or replacements are made in accordance with the
instructions provided. Expendable parts of this equipment are similarly warranted to be
free from functional defects in materials and workmanship and to conform to the
description of this equipment contained in this manual and any accompanying labels
and/or inserts. The foregoing warranties shall not apply if the equipment has been
repaired other than by Matheson or a service facility designated by Matheson, or if this
equipment has not been operated and maintained in accordance with written instructions
provided by Matheson, or has been altered by anyone other than Matheson, or if the
equipment has been subject to abuse, misuse, negligence or accident.
Matheson's sole and exclusive obligation and the Buyer's sole and exclusive remedy under
the above warranties is limited to repairing or replacing, free of charge, at Matheson's sole
discretion, the equipment or part which is telephonically reported to be a problem to the
local Matheson Branch Location, and which if so advised, is returned with a written
statement of the observed deficiency, not later than seven days after the expiration of the
applicable warranty, to the Matheson Gas Equipment Technology Center during normal
business hours, transportation charges prepaid, and which, upon examination, is found to
comply with the above warranties. The Buyer shall pay for return trip transportation
charges for the equipment or part.
Matheson shall not be otherwise liable for any damages including but not limited to
incidental damages, consequential damages, or special damages, whether such
damages result from negligence, breach of warranty or otherwise.
There are no express or implied warranties that extend beyond the warranties
hereinabove set forth. Matheson makes no warranty of merchantability or fitness
for a particular purpose with respect to the equipment or parts thereof.
Acceptance of the equipment by the final buyer indicates the final buyer’s acceptance
of all warranties and limitations set forth above.

4
IV. USER RESPONSIBILITY
This equipment will perform in conformity with the description thereof contained in this
manual and accompanying labels and/or inserts when installed, operated, maintained and
repaired in accordance with the instructions provided. This equipment must be checked
periodically, with the frequency of such inspections depending upon the scope of use.
Damaged, worn or contaminated equipment should not be used. Parts that are broken,
missing, plainly worn, distorted or contaminated should be replaced immediately. Should
such repair or replacement become necessary, Matheson Tri-Gas recommends that a
telephonic or written request for service advice be made to the Matheson Equipment
Engineering Group in Montgomeryville Pennsylvania or to the nearest Matheson branch
location.
This equipment or any of its parts should not be altered without the prior written approval
of Matheson Equipment Engineering Group. The user of this equipment shall have the
sole responsibility for any malfunction, which results from improper use, faulty
maintenance, damage, improper repair or alteration by anyone other than Matheson
Tri-Gas or a service facility designated by Matheson Tri-Gas. Further, the ultimate user
of the equipment is responsible for the training and safe operation of the equipment by
personnel in his/her employ.

5
V. SAFETY PRECAUTIONS
1. Many Specialty Gases are hazardous in nature. It is important that the user of the
equipment carefully review the hazards associated with the gas to be used with the
Filter unit. Before installing the Filter unit into any system, refer tothe MSDS
that was shipped with the gas or on file in your facility, as to the specific
hazards associated with the gas to be used in the system. Also, refer to all
applicable inserts contained with the equipment for additional precautions
and operating instructions.
2. Before using any Filter unit on toxic, corrosive, pyrophoric, flammable or other
type of hazardous gas, test the leak integrity of the filter using an inert gas.
3. Make certain that the filter purchased is suitable for the application intended. All
Filter units supplied by Matheson, a model number, and a pressure limitation label
and/or stamping. Carefully review this information to establish the filter fit for
service in the desired application.
4. Make certain that the equipment purchased or delivered to the ultimate end user
conforms to the specifications of the user. The user is responsible for selecting
equipment compatible with gases that are to be used, physical parameters of
operation and performance and normal material compatibilities. Selection
information can be found in Matheson Catalogs, Matheson Tech Briefs and in the
Matheson Gas Data Book. In addition, any Matheson representative would be
pleased to aid in the selection of specific equipment.
5. Before installation of the Filter unit into a system, note the direction of the flow
arrow. Make certain that the arrow is in the same direction as the intended flow.
6. For Filter units supplied with NPT connections, use an approved method of pipe
sealing (such as an approved Teflon tape material) on the connection threads and
tighten no more than one and one-half turn past hand tight.
CAUTION: Do not over tighten. Over tightening may crack the fitting
housing and/or the Filter unit
7. For Filter units supplied with compression tube connections, face and deburr the
tubing to which the unit is to be attached. Following the manufacturer of the fittings
recommendations for tightening the compression tube fitting make the connection.
Most manufacturers of compression tube fittings recommend tightening the
locking nut one quarter turn past hand tight.
CAUTION: Do not over tighten. Over tightening may obstruct the flow of
gas through the tubing or the Filter unit.

6
8. For Filter units supplied with VCR type connections, make certain that the
connection in the system will mate to the connections supplied on the Filter unit,
before attempting installation.
CAUTION: Most VCR type connections require the use of an expendable
gasket. This gasket is to be used once. Make sure that the
material of the gasket used is compatible with the gases to be
used.
VI. GENERAL DESCRIPTION
Matheson Filters are designed for specific services. Make certain that the Filter ordered is
compatible with the application and the gases and/or liquids to be filtered.
Filters function as physical barriers to particulates. The filters marketed by Matheson use
two main methods to accomplish this goal. These methods as well as the series numbers to
which they pertain are listed below.
1. DEPTH FILTERS (Model 6124, 6134, 6164, and 6187)
2. MEMBRANE FILTERS (Model 6190)
Depth Filters generally consist of a fibrous wound material. Some may have a binder to
reduce the amount of fibrous shedding occurring during use. Over time, the relative lower
“depths” of the filter become increasingly more efficient as the particulate material is
trapped. Generally these filters are rated for 0.2 micron particle retention.
Membrane Filters employ a flexible and porous membrane as the physical barrier. The
membrane is either a flat single sheet or a pleated structure encasedin a housing. The pore
size of the unit is determined by physical measurement of the pores. The rating of the
filter also takes into consideration the weak physical forces of attraction associated with
this method of filtration. Generally these filters are rated for 0.01 micron particle
retention.
NOTE: Filters are not purifiers. Filters remove only particulate matter from gases
or liquids and do not remove chemical contaminants.

7
VII. INSTALLATION
For maximum performance and service life, the filter should be installed in a clean,
dry atmosphere, relatively free of shock and vibration. Sufficient room for access to
plumbing should be provided to facilitate maintenance. Fitting dust caps should be
removed just prior to installation
1. Gas Connections
1.1 Ensure that the flow in the system in which the Filter unit(s) is/are to be installed
is in the direction of the arrow indicated on the body of the Filter unit(s).
1.2 Matheson supplies the Filter unit(s) with a variety of end connections. Use an
approved method of sealing on the connection.
CAUTION: Do not over tighten. Over tightening may cause damage to the
Filter unit(s).
1.2.1 For Filter units supplied with NPT connections, use an approved method
of pipe sealing (such as an approved Teflon tape material) on the
connection threads and tighten no more than one and one-half turns past
hand tight.
CAUTION: Do not over tighten. Over tightening may crack the fitting
housing and/or the Filter unit(s).
1.2.2 For Filter units supplied with compression tube connections, face and
deburr the tubing to which the unit is to be attached. Following the
manufacturer of the fittings recommendations for tightening the
compression tube fitting make the connection. Most manufacturer
compression tube fittings recommend tightening the locking nut one
quarter turn past hand tight.
CAUTION: Do not over tighten. Over tightening may obstruct the flow of
gas through the tubing or the Filter unit(s).
1.2.3 For Filter units supplied with VCR type connections, make certain that
the connection in the system will mate to the connections supplied on the
Filter unit, before attempting installation.
CAUTION: Most VCR type connections require the use of an expendable
gasket. This gasket is to be used once. Make sure that the
material of the gasket used is compatible with the gases to be
used.

8
1.3 Use only pre-cleaned tubing or pipe and clean, dry (< 1.0 ppm H2O) gases.
1.4 After Filter unit installation prior to the use of the unit, the plumbing system
should be thoroughly leak tested using either an approved soap solution or by
pressurizing the entire system with Helium and using an approved leak detector
and monitor for a leak rate of less than 1 x 10-5 cc/sec He.
NOTE: This step is required by the user when the Filter unit is to be used
in any hazardous material applications, such as but not limited to,
flammable, toxic, corrosive, or pyrophoric applications.
2. Environmental Requirements
Refer to the “SPECIFICATIONS” section for the applicable Series of Filter.
3. Mounting
3.1 The filter units should be supported by some method compatible with the
application and location of the unit in a gas or liquid line.
3.2 The Filter unit should NOT be supported by only the tube or pipe to which it is
attached. This may cause radial or other stress to the connections securing the
unit in the gas or liquid line.
3.3 The Filter unit will function regardless of the physical position of mounting (eg.
horizontal, vertical or anywhere in between).

9
VIII. OPERATING INSTRUCTIONS
Read the "SAFETY PRECAUTIONS" and "INSTALLATION" sections before
operation of the equipment.
1. After installation in the system and prior to operation, the system should be
thoroughly leak checked (as described in Section VII, 1.4).
2. Begin to apply pressure to the system in acontrolled manner using a regulator or other
approved device for pressure regulation.
3. Within the system note the pressure before the filter in the line and after the filter in
the line. Record this information in a secure place.
NOTE: All Filters experience some pressure drop across the point where they are
installed. This is not uncommon and should be expected.
4. If there is sufficient flow and pressure across the filter, the system is now ready for
operation.
IX. MAINTENANCE
1. Filters are expendable parts. No maintenance is required until the Filter unit exceeds
the parameters listed in the TROUBLE SHOOTING Section. If the parameters are
exceeded, it is time to replace the unit.
2. Filters that are secured in a line with VCR type fittings require additional attention. If
the VCR seals are broken after original installation, the gasket employed is expendable
and must be replaced to ensure leak tight operation.
3. The maintenance period should be established by the user based upon historical
experience in the user's particular application.

10

11
X. SPECIFICATIONS
Model 6124, 6134, and 6164
Materials of Construction
• Body: 316 Stainless Steel
• Filter Elements: Fiberglass
• Filter Screens: 316 Stainless Steel
Specifications
• Maximum Operating Pressure: 250 psig
• Temperature Rating: 0 to165ºF (-18 to 74°C)
• Filtration Rating: 100% efficiency at 0.2 micron level
• Maximum Flow Rate: See chart
Part Number Inlet/Outlet Connections Max. Flow SLPM** Dimensions (D x L)
Filters with Pipe Fittings
SEQ6164P4FF 1/4" FNPT x FNPT 150 1.66” x 3.0”
SEQ6134P8FF 1/2" FNPT x FNPT 400 2.38” x 4.1”
SEQ6124P12FF 3/4" FNPT x FNPT 1000 2.38” x 7.5”
Filters with Standard Swagelok Fittings
SEQ6164T2FF 1/8" x 1/8" 30 1.66” x 4.9”
SEQ6164T4FF 1/4" x 1/4" 100 1.66” x 4.1”
SEQ6164T6FF 3/8" x 3/8" 150 1.66” x 4.3”
SEQ6134T4FF 1/4" x 1/4" 200 2.38” x 4.8”
SEQ6134T6FF 3/8" x 3/8" 400 2.38” x 5.0”
SEQ6134T8FF 1/2" x 1/2" 400 2.38” x 5.3”
SEQ6164T4MM* 1/4"tubing (316 SS) 75 1.66" x 4.95"
Filters with VCR or VCO Fittings
SEQ6164V4MM 1/4" VCR M x M 100 1.66” x 4.11”
SEQ6164O4MM 1/4" VCO M x M 100 1.66” x 3.81”
SEQ6134V8MM 1/2" VCR M x M 150 2.38” x 5.12”
*NOTE: This model is supplied with 1/4" tubing only, welded at each end
** @ 15 psig Inlet, Atmospheric Outlet

12
Model 6187
Materials of Construction
• Body: 316 Stainless Steel
• Filter Elements: Fiberglass
• Filter Screens: 316 Stainless Steel
Specifications
• Maximum Operating Pressure: 2500 psig
• Temperature Rating: 350ºF (176°C) max.
• Maximum Flow Rate: 20 SLPM (5 psi pressure differential)
• Pore Size: 0.2 micron
Model 6190
Materials of Construction
• Body: 316 Stainless Steel
• Membrane: Teflon supported and sealed by polypropylene end caps
• Seal: Teflon encapsulated silicone O-ring
Specifications
• Maximum Operating Pressure: 1000 psig
• Temperature Rating: 100ºF (38°C) max.
• Maximum Flow Rate: 250 SLPM (15 psi pressure differential)
• Pore Size: 0.2 micron
• Filtration Rating: 100% efficiency at 0.01 micron level
• Effective Filter Area: 0.5 ft3

166 Keystone Drive
Montgomeryville, PA 18936
800-828-4313
store.mathesongas.com
INT-0068 rev C
