Matric COSEC ARGO CAE200 User manual

COSEC ARGO
2
Please read this guide first for correct installation and retain it
for future reference. The information in this guide has been
authenticated at the time of publication. However, Matrix
Comsec reserves the right to make changes in product design
and specifications without prior notice.
Know your COSEC ARGO 3
8
Preparation for Installation
23
Connecting the Cables
What your Package Contains 7
Technical Specification 9
Installation Instruction - Wall Mounting
11
Installation Instruction - Flush Mounting 17
Assigning IP Address and Other Network Settings 7
COSEC ARGO FOE212/ FOM212/ FOI212
COSEC ARGO CAE200/ CAM200/ CAI200
Contents
24
Assigning IP Address
25
Technical Specifications

Touch Screen
Display
Mounting Screw Hole
Knock Out Area
Know your COSEC ARGO
34
The COSEC ARGO is available in two series with three
different variants in each series as follows:
1) COSEC ARGO with variants FOE212, FOM212 and
FOI212.
2) COSEC ARGO with variants CAE200, CAM200 and
CAI200.
Finger Sensor
Card Sensing
Area
Touch Screen
Display
Card Sensing
Area
Front View
ARGO (FOE212/ FOM212/
FOI212)
ARGO (CAE200/ CAM200/
CAI200)
Rear View (Common for both Series)
Back Plate or
Wall Mounting Plate
Flush
Mounting
Plate
Bottom View (Common for both Series)
Figure 3
Figure 2
Figure 1a Figure 1b

2
Next
Level
5. Do not install the device in outdoor areas which may be exposed
to rain, cold and dust. You can do indoor installation or on the turnstile
under the roof as shown in Figure 5.
Figure 5
Figure 6
1. Do not install the device in extremely hot temperature or under direct
Sunlight on turnstile or at extra bright places. This may affect the LCD
and finger print sensor of device. You can do indoor installation or on the
turnstile under the roof as shown in Figure 4.
2. You can mount the device on a flat surface such as a wall or near the
elevator, close to the access point (door) with surface wiring or concealed
wiring as shown in Figure 6.
3. Recommended height from ground level is upto 4.5 feet.
4. Do not install on unstable surfaces, near volatile inflammable materials,
areas where volatile gas is created, where ferromagnetic field or noise is
induced, where static is created, such as desks made of plastics, carpets.
Figure 4
Pre-Installation Safety Instruction
56

1) COSEC ARGO Unit
2) Flush Mounting Plate
3) Four Screws M5/25
4) Four Screw Grips
5) Overswing Diode
6) Power Adapter 12VDC,2A
7) Power Supply Cable (with DC Jack)
8) EM Lock Cable
9) External Reader Cable
10) Flush Mounting Template
What your Package Contains
For Concealed wiring in Wall Mounting/Flush Mounting, first draw out
the sufficient length of the cables from the hole of the mounting plate.
For Non-concealed wiring in Wall Mounting; the knock -out area has to be
removed from outside by pressing on the bottom duct as shown
in Figure 3.
The connection of EM Lock must be done using the diode for Back
EMF protection.
Preparation for Installation
78
Before Wall Mounting and Flush Mounting of COSEC ARGO follow below
instructions.
•Remove the mounting screw from mounting screw hole of the bottom
of device as shown in Figure 3. The screw will be required to fix the
device after Wall Mounting or Flush Mounting.
•Slide the back plate downwards to unlock the device from the
mounting hook and then remove it by pulling it outwards. This back
plate server as the Wall Mounting plate. For details see Installation
Instructions for Wall Mounting.
•The Flush Mounting plate is available in the package. This plate will be
required for Flush Mounting of COSEC ARGO. For details see
Installation Instructions for Flush Mounting.
Wall Mounting: Select a location. It must be a flat surface such as wall,
close to the access point (door).
Flush Mounting: Select a wooden door or a location where the duct can be
made. The rectangular duct has to be made in the wooden door in which
Flush Mounting plate will be installed.

Step 2: Drill the screw holes along the traced markings. Fix Wall
Mounting plate with the supplied screws. Tighten the screws with
screw driver.
Step 1: Place the Wall Mounting plate and trace screw holes 1
and 2 on the wall where the device is to be installed.
1
2
Installation Instruction: Wall Mounting
9
10

•Keep all the cables parallel to the side of the COSEC ARGO
body in such a way that it should not cover the back portion
of the unit as illustrated in figure below.
•Radially curve all the cables and lead it through the duct to fit
the wall mounting plate easily with COSEC ARGO.
11 12
Step 3: Connect the cables of the ARGO unit and lead all the cables
through the duct of the Wall Mounting plate into the electrical box
recessed in the wall i.e. concealed wiring or through the bottom of
the device in non-concealed wiring.
Duct for Concealed
Wiring
Cable
Connectors
Knock Out Area
for Non-Concealed Wiring
Mounting
Slots

Mounting
Screw
Step 5: Insert the mounting screw into the mounting screw hole
at the bottom of the device. Tighten the screw to complete the
Wall Mounting.
13 14
Step 4: Align COSEC ARGO on the mounting plate and hook it
into the mounting slot. Press the bottom side inwards to lock it in
place.

Step 2: Place and fix the Flush Mounting plate with the supplied
screws. Tighten the screws with screw driver.
Figure 7
15 16
Installation Instruction: Flush Mounting
Step 1: Place the Flush Mounting Template on the desired
installation surface.
•Mark the area along the dotted line and trace the four screw
holes (say A,B,C,D) on the wall as shown in Figure 7.
•Now drill the dotted line area and four screw holes (say
A,B,C,D) on the wall as illustrated in Figure 8. Flush Mounting
Plate
A
B
C
D
Flush Mounting
Template
Figure 8
A
B
CD

18
Cable
Connectors
Step 3: Connect the cables of the ARGO unit and lead all the
cables through the Flush Mounting plate into the electrical box
recessed in the wall.
Mounting
Slots
Mounting
Screw hole
17
•Keep all the cables parallel to the side of the COSEC ARGO
body in such a way that it should not cover the back portion
of the unit as illustrated in the figure below.
•Radially curve all the cables and lead it through the duct to
fit the flush mounting plate easily with COSEC ARGO.

19 20
Step 4: Align COSEC ARGO with the mounting plate and hook it
into the mounting slot. Press the bottom side inwards to lock it
in place.
Mounting Screw
Step 5: Insert the mounting screw into the mounting screw hole
at the bottom of the device. Tighten the screw to complete the
Flush Mounting.

External Reader Cable
(8 Pin to 15 Pin connector)
Power
Cable
EM Lock Cable
1
2
3
4
5
6
7
8
CN3
9
10
LOCK RLY NO -Yellow
EXIT SWITCH
DOOR STATUS- White
GND- Black
GND- Black
GND LOCK- Black
LOCK RLY NC-Dark Blue
+12V LOCK- Red
-White
GND- Black
EM Lock
Diode
LOCK RLY COM -Light Brown
21
•For Concealed wiring; first draw out sufficient length of the
cables from the hole you have made on the mounting
surface.
•Connect the Power, External Reader and EM Lock cable
assemblies to the 20 PIN connector affixed on the back side
of the ARGO Unit.
•Connect the Ethernet Cable to the LAN port.
•Connect the micro USB port to the Printer or Broadband
dongle. If required, user a micro USB cable extender.
1
2
CN1
Power
GND- Black
+12VDC IN- Red
1
2
3
4
5
6
7
8
CN2
External Reader
DATA 0- Green
DATA 1- White
BEEPER- Yellow
GREEN LED- Orange
GND- Black
RS 232 RX- Pink
RS 232 TX- Grey
+12V RDR- Red
Connecting the Cables
Micro USB
connector cable
Ethernet Cable
G
F
22

23 24
+
-
EM
Lock
Reverse biased
Diode
Power
Diode Connection for Back EMF Protection
GND
Cathode
Anode
Relay
Pin 1
Relay
Pin 2
•Connect the Overswing diode in reverse biased condition
parallel to the EM Lock for better lifetime contact and to
protect the device from inductive kickback.
•Open the Web browser in your computer.
•Enter the IP Address of the COSEC ARGO, default:
http://192.168.50.1 in the address bar of the browser and
press the Enter key on your computer keyboard.
•The Login page appears.
•Select the User Name as Admin.
•You need set the password, hence enter the desired password
in New Password and re-enter the same in Confirm Password.
•Click Login.
Assigning IP Address and Other Network Settings

RF Option(Card)
ARGO
FOE212/ CAE200
ARGO
FOM212/ CAM200
ARGO
FOI212/ CAI200
EM Prox
Desfire and
NFC
MIFARE RHID I Class,
HID Prox,
EM Prox,
Desfire, NFC &
MIFARE R
Technical Specification
Event Buffer
Input Power
Reader Power
Output
Reader Interface
Type
Door Lock
Relay
Door Lock
Power
Built In PoE
Display
5,00,000
12V DC @2A and PoE
RS 232 and Wiegand
Max 30V DC @2A
PoE (IEEE 802.3 af)
3.5 inch Capacitive IPS touch screen
with Gorilla glass 3.0;
Resolution: 480x320 pixels (HVGA)
Max 12V DC @0.250 A
Internal 12V DC @0.5A in PoE supply
mode and 12V DC @1A in Adapter
User Capacity
50,000
Communication
Port
Ethernet and WiFi
Built In
Bluetooth
Yes (IEEE 802.11 b/g/n)
Yes
Built In WiFi
26
Technical Specification
Operating
Temperature
Dimensions
(H x W x D)
Weight
Yes
0 °C to +50 °C
186mm x 74mm x 50mm (Wall Mount)
186mm x 74mm x 16mm (Flush Mount)
0.650 Kg (Product Only)
1.3 Kg (Product with Accessories)
Thermal Sensor
Credential Support
Card, Pin and Finger
Card, Pin and Face
ARGO(FOE212/ FOM212/ FOI212)
ARGO(CAE200/ CAM200/ CAI200)
25

28
27
FCC Compliance
This device complies with part15 of the FCC rules. Operation is subject to
the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits of
Class A digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial
environment.
This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications. Operation of
this equipment in a residential area is likely to cause harmful interference
in which case the user will be required to correct the interference at his
own expense.
Warning
This is a Class A product. In a domestic environment this product may
cause radio interference in which case the user may be required to take
adequate measures.
The product refered is covered by the waste Electrical and
Electronic Equipment (WEEE) directive and must be disposed of
in a responsible manner.
At the end of product life cycle; batteries, soldered boards,
metal components and plastic components must be disposed
through recyclers.
If you are unable to dispose-off the products or unable to locate
e-waste recyclers, you may return the products to Matrix Return
Material Authorization (RMA) department.
WEEE Directive 2002/96/EC
Disposal Of Product After End-Of-Life

V 2, December 2021
Head Office
394-GIDC, Makarpura, Vadodara, Gujarat, 390010, India
Ph: ([phone]
Email: Suppor[email protected]
Website: www.matrixaccesscontrol.com
MATRIX COMSEC PVT LTD
Copyright
All rights reserved. No part of this document may be copied or
reproduced in any form or by any means without the prior written
consent of Matrix Comsec.
Warranty
Limited Warranty. Valid only if primary protection is provided,
mains supply is within limit and protected, and environment
conditions are maintained within product specifications. Complete
warranty statement is available on our website:
www.matrixaccesscontrol.com
29
