Matrix Orbital MX Series User manual
MX Series PC Bay Insert
Installation Manual for the
MX2, MX3, MX4, MX5 or MX6
Contents
Installation and Startup Guide
for the MX2, MX3, MX4, MX5 or MX6 Series ................................................. 3
Installing Your Display ................................................................................ 4
Installing Windows USB Drivers
for the MX2, MX3, MX4, MX5 or MX6 ............................................................. 5
Installing Windows XP USB Drivers ........................................................ 5
Installing LCDC .................................................................................................... 10
Registering LCDC Software .....................................................................10
Installation & Startup of LCDC ............................................................... 12
Notes .......................................................................................................................16
Technical Support
Matrix Orbital tech support is available Monday to Friday, 9:00am to 5:00pm.
Please e-mail your Windows version, display used, what you have tried
and the problem in detail so we can help you faster and more efficiently.
As well, please visit our forums (www.lcdforums.com) where most
common problems have probably been talked about.
For more detailed instructions, please use the supplied eCD.
E-commerce: www.matrixorbital.com
Support: www.matrixorbital.ca
Forums: www.lcdforums.com
LCDC: www.lcdc.cc
Page 2
Installation and Startup Guide for the
MX2, MX3, MX 4, MX5 or MX6 Series
Thank you for purchasing the original and one of the world’s finest
PC bay insert displays. At Matrix Orbital, we are proud to offer quality
products that are easy to install and use. Please note that the MX2,
MX3, MX4, MX5 and MX6 are identical for installation purposes.
They are different only in the technology that they possess. These
instructions are also available on the eCD in full color.
Now please check that everything was correctly shipped to you:
• 1x Display in bay insert
• 1x 3ft USB cable attached to LCD
• 1x eCD (with a LCDC activation code on top)
• 4x screws (they will be attached to the bay insert)
If any items are missing please contact us at 403-229-2737 or email
[email protected] and the problem will be corrected immediately.
Page 3
Installing Your Display
1. Turn off your computer.
2. Remove the cover from an empty 5¼” drive bay and the sides of
the case.
3. Insert the display into the drive bay.
4. Screw the bracket into place.
5. Feed the USB cable through an empty PCI bracket. If you have the
optional Internal USB cable, please refer to the Internal USB
install page.
6. Plug in the USB cable into a free USB port on your computer.
7. Replace the sides of your case. Peel off the protective sticker on the
PC Bay insert face.
8. Turn on your computer. The display should power up and display
“Matrix Orbital MX2xx, MX3xx, MX4xx, MX5xx or MX6xx”.
234
567
Page 4
Installing Windows USB Drivers for
the MX2, MX3, MX4, MX5 or MX6
The MX2/MX3/MX4/MX5/MX6 will require Windows drivers to operate
that can be downloaded from our website or directly from the eCD.
Drivers are located on the eCD under USB_Drivers/. These drivers are
for all the Windows versions. These drivers have been tested with
Windows 98, Windows ME, Windows 2000 and Windows XP. The
drivers will create a “Virtual COM Port” on your computer, allowing
you to use any Display software or utilities. If you are installing for
Windows 2000, please use the instructions on the eCD.
Installing Windows XP USB Drivers
When the display is plugged in, Windows will detect new hardware.
Page 5
1. The Windows Installation Wizard Loads to help with the install.
Press next to continue.
2. Select Search for a suitable driver for my device and press next.
3. Specify a location.
4. Go to your CD-ROM
drive, and to the directory
USB_Drivers.
5. Windows should find a
correct info file. Press OK,
then press next.
Page 6
6. Press “Continue Anyway”.
7. Part I of the install is now completed.
8. Windows will now detect a second new device.
9. Once again, press Search for a suitable driver for my device and
press next.
Page 7
10. Like before, specify a location.
11. Point the Install Wizard to the correct directory.
12. Windows install will find a second info file, press OK and
then next.
13. Press “Continue Anyway”.
Page 8
14. Installation of the drivers is now completed.
15. Lets double check that the device drivers were properly loaded
by going into the Control Panel/Hardware.
Now you are ready to install LCDC!
Page 9
Installing LCDC
Welcome to the exciting world of Matrix Orbital and LCDC. As part
of the MX bundle you have a full copy of LCDC included for your
personal use. LCDC has been developed by Matthew Augier
(aka Mat-d-Rat) for Matrix Orbital displays. LCDC is the worlds most
advanced LCD/VFD software featuring the most advanced plugins
and features. The LCDC software is included on the eCD with your
display and can be found in the LCDC directory or here. If you already
have a copy of LCDC and you are looking for the latest upgrade, click
here. You will require to register your copy of LCDC with the activation
number you received on the front of your eCD. To register your LCDC
please click HERE.
The LCDC manual has been broken up into several sections to cover
the basics of LCDC. For more information, please visit the LCDC
Website manual.
Registering LCDC Software
You will be required to activate your LCDC key, please note that the
key code on the front of the CD IS NOT your LCDC serial key!
Step 1. Activating your LCDC key
Please visit http://www.lcdc.cc/bundled/
Step 2. Fill out the information and your LCDC Serial number will be
e-mailed to you right away
Page 10
Step 3. Entering your LCDC Serial number after the software has
been installed.
Click on Enter Key.
This screen is very straight forward, and from the registration
e-mail you should of received simply copy the details stated for your
“Registered name” and “Keycode”. If you select the area of the e-mail
that includes these two lines and copy them to the clipboard (right
might and select copy or press ctrl-c) then the “Paste” button above
will become available when it sees valid information in the clipboard,
then select it to put the details in for you :-
Make sure you select the whole of the lines, then select “Paste” once
it is active.
When you select “Okay” it will verify the information and either refuse
or accept it.
Page 11
Installation and Startup of LCDC
As part of the MX bundle you have a full copy of LCDC included for
your personal use. You will be required to activate your LCDC key.
Please note that the key code on the front of the CD IS NOT your
LCDC serial key!
1. LCDC is located on the CD under the LCDC directory. Click Next.
2. Accept the agreement and click Next.
3. Select your installation directory if you want something other
then the default.
4. Select a Start Menu name if you want something other then
LCDC.
Page 12
5. Select if you want to create a desktop icon. Click Install.
6. LCDC is now installing.
7. LCDC install will try to detect Winamp to install certain files.
8. Select the MX2, MX3, MX4, MX5 or MX6 this will install examples
files into LCDC.
Page 13
9. If you have activated your
key, enter it now, otherwise
wait until you can continue
and after the install click
on Registering LCDC from
the main LCDC page for
instructions.
10. A quick overview of LCDC.
11. This is Autodetection of the display.
12. This is a 3 step process to Autodetect your
MX2/MX3/ MX4/ MX5/ MX6 on your computer.
Page 14
13. LCDC is now searching for your MX2, MX3, MX4, MX5 or MX6.
14. Your display has been detected, click Select.
15. Click OK.
16. Done! now you can click on Start display to begin!
For Configuration of Email, Plug-ins,
Installing Temperature Probes, Internal
USB, LED indicator and Connecting
Fans, please consult the eCD for detailed
instructions.
The LCDC manual and LCDC screen
gallery are also available on the eCD.
Page 15
