Motorola MVME2401-1 Quick start guide

MVME2400-Series
Single Board Computer
Installation and Use
V2400A/IH1

Notice
While reasonable efforts have been made to assure the accuracy of this document,
Motorola, Inc. assumes no liability resulting from any omissions in this document, or from
the use of the information obtained therein. Motorola reserves the right to revise this
document and to make changes from time to time in the content hereof without obligation
of Motorola to notify any person of such revision or changes.
No part of this material may be reproduced or copied in any tangible medium, or stored in
a retrieval system, or transmitted in any form, or by any means, radio, electronic,
mechanical, photocopying, recording or facsimile, or otherwise, without the prior written
permission of Motorola, Inc.
It is possible that this publication may contain reference to, or information about Motorola
products (machines and programs), programming, or services that are not announced in
your country. Such references or information must not be construed to mean that Motorola
intends to announce such Motorola products, programming, or services in your country.
Restricted Rights Legend
If the documentation contained herein is supplied, directly or indirectly, to the U.S.
Government, the following notice shall apply unless otherwise agreed to in writing by
Motorola, Inc.
Use, duplication, or disclosure by the Government is subject to restrictions as set forth in
subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer Software clause at
DFARS 252.227-7013.
Motorola, Inc.
Computer Group
2900 South Diablo Way
Tempe, Arizona 85282

Preface
The MVME2400-Series VME Processor Module Installation and Use manual provides
information you will need to install and use your MVME2400-series VME processor
module. The MVME2400 VME processor module is based on an MPC750 PowerPC
microprocessor, and features dual PCI Mezzanine Card (PMC) slots with front panel and/
or P2 I/O. The MVME2400 is currently available in the following configurations:
The MVME2400-series module is compatible with optional double-width or single-width
PCI Mezzanine Cards (PMCs) , and the PMCspan PCI expansion mezzanine module. By
utilizing the two onboard PMC slots and stacking PMCspan(s), the MVME2400 provides
support for up to six PMCs.
This manual includes hardware preparation and installation instructions for the
MVME2400-series module, information about using the front panel, a functional
description, information about programming the board, using the PPCBug debugging
firmware, and advanced debugger topics. Other appendices provide the MVME2400-series
specifications, connector pin assignments, and a glossary of terms. Additional manuals you
may wish to obtain are listed in Appendix A, Ordering Related Documentation.
The information in this manual applies principally to the MVME2400-series module. The
PMCspan and PMCs are described briefly here but are documented in detail in separate
publications, furnished with those products. Refer to the individual product documentation
for complete preparation and installation instructions. These manuals are listed in
Appendix A, Ordering Related Documentation.
Model MPC Memory Handles
MVME2401-1 MPC750
@ 233 MHz 32MB ECC SDRAM Scanbe Handles
MVME2401-3 32MB ECC SDRAM 1101 Handles
MVME2402-1 64MB ECC SDRAM Scanbe Handles
MVME2402-3 64MB ECC SDRAM 1101 Handles
MVME2431-1 MPC750
@ 350 MHz 32MB ECC SDRAM Scanbe Handles
MVME2431-3 32MB ECC SDRAM 1101 Handles
MVME2432-1 64MB ECC SDRAM Scanbe Handles
MVME2432-3 64MB ECC SDRAM 1101-1 Handles
MVME2433-1 128MB ECC SDRAM Scanbe Handles
MVME2433-3 128MB ECC SDRAM 1101-1 Handles

This manual is intended for anyone who wants to design OEM systems, supply additional
capability to an existing compatible system, or work in a lab environment for experimental
purposes. A basic knowledge of computers and digital logic is assumed.
Document Terminology
Throughout this manual, a convention is used which precedes data and address parameters
by a character identifying the numeric format as follows:
For example, “12” is the decimalnumber twelve, and “$12” (hexadecimal) is the equivalent
of decimal number eighteen. Unless otherwise specified, all address references are in
hexadecimal.
An asterisk (*) following the signal name for signals which are level-significant denotes
that the signal is true or valid when the signal is low.
An asterisk (*) following the signal name for signals which are edge-significant denotes
that the actions initiated by that signal occur on high-to-low transition.
In this manual, assertion and negation are used to specify forcing a signal to a particular
state. In particular, assertion and assert refer to a signal that is active or true; negation and
negate indicate a signal that is inactive or false. These terms are used independently of the
voltage level (high or low) that they represent.
Data and address sizes are defined as follows:
$ Dollar Specifies a hexadecimal character
0x Zero-x
% Percent Specifies a binary number
& Ampersand Specifies a decimal number
Byte 8 bits, numbered 0 through 7, with bit 0 being the least significant.
Half word 16 bits, numbered 0 through 15, with bit 0 being the least significant.
Word 32 bits, numbered 0 through 31, with bit 0 being the least significant.
Double word 64 bits, numbered 0 through 63, with bit 0 being the least significant.

Safety Summary
Safety Depends On You
The following general safety precautions must be observed during all phases of operation, service, and repair of this
equipment. Failure to comply with these precautions or with specific warnings elsewhere in this manual violates safety
standards of design, manufacture, and intended use of the equipment. Motorola, Inc. assumes no liability for the
customer’s failure to comply with these requirements.
The safety precautions listed below represent warnings of certain dangers of which Motorola is aware. You, as the
user of the product, should follow these warnings and all other safety precautions necessary for the safe operation of
the equipment in your operating environment.
Ground the Instrument.
To minimize shock hazard, the equipment chassis and enclosure must be connected to an electrical ground. The
equipment is supplied with a three-conductor AC power cable. The power cable must be plugged into an approved
three-contact electrical outlet. The power jack and mating plug of the power cable meet International Electrotechnical
Commission (IEC) safety standards.
Do Not Operate in an Explosive Atmosphere.
Do not operate the equipment in the presence of flammable gases or fumes. Operation of any electrical equipment in
such an environment constitutes a definite safety hazard.
Keep Away From Live Circuits.
Operating personnel must not remove equipment covers. Only Factory Authorized Service Personnel or other
qualified maintenance personnel may remove equipment covers for internal subassembly or component replacement
or any internal adjustment. Do not replace components with power cable connected. Under certain conditions,
dangerous voltages may exist even with the power cable removed. To avoid injuries, always disconnect power and
discharge circuits before touching them.
Do Not Service or Adjust Alone.
Do not attempt internal service or adjustment unless another person capable of rendering first aid and resuscitation is
present.
Use Caution When Exposing or Handling the CRT.
Breakage of the Cathode-Ray Tube (CRT) causes a high-velocity scattering of glass fragments (implosion). To
prevent CRT implosion, avoid rough handling or jarring of the equipment. Handling of the CRT should be done only
by qualified maintenance personnel using approved safety mask and gloves.
Do Not Substitute Parts or Modify Equipment.
Because of the danger of introducing additional hazards, do not install substitute parts or perform any unauthorized
modification of the equipment. Contact your local Motorola representative for service and repair to ensure that safety
features are maintained.
Dangerous Procedure Warnings.
Warnings, such as the example below, precede potentially dangerous procedures throughout this manual. Instructions
contained in the warnings must be followed. You should also employ all other safety precautions which you deem
necessary for the operation of the equipment in your operating environment.
!
WARNING
Dangerous voltages, capable of causing death, are present in this
equipment. Use extreme caution when handling, testing, and
adjusting.

!
WARNING
This equipment generates, uses, and can radiate electro-magnetic energy. It may
cause or be susceptible to electro-magnetic interference (EMI) if not installed
and used in a cabinet with adequate EMI protection.
If any modifications are made to the product, the modifier assumes
responsibility for radio frequency interference issues. Changes or modifications
not expressly approved by Motorola Computer Group could void the user’s
authority to operate the equipment.
European Notice: Board products with the CE marking comply with the EMC
Directive (89/336/EEC). Compliance with this directive implies conformity to the
following European Norms:
EN55022 “Limits and Methods of Measurement of Radio Interference Characteristics of Infor-
mation Technology Equipment”. Tested to Equipment Class B.
EN 50082-1:1997 “Electromagnetic Compatibility -- Generic Immunity Standard, Part 1. Res-
idential, Commercial and Light Industry.”
EN 61000-4.2 -- Electrostatic Discharge Immunity Test
EN 61000-4.3 -- Radiated, Radio-Frequency Electromagnetic Field, Immunity Test
EN 61000-4.4 -- Electrical Fast Transient/Burst Immunity Test
EN 61000-4.5 -- Surge Immunity Test
EN 61000-4.6 -- Conducted Disturbances Induced by Radio-Frequency Fields -- Immunity
Test
EN 61000-4.11 -- Voltage Dips, Short Interruptions and Voltage Variations Immunity Test
ENV 50204 -- Radiated Electromagnetic Field from Digital Radio Telephones -- Immunity
Test
In accordance with European Community directives, a “Declaration of Conformity” has been
made and is on file at Motorola, Inc. - Computer Group, 27 Market Street, Maidenhead, United
Kingdom, Sl6 8AE.
This board product was tested in a representative system to show compliance with the above
mentioned requirements. A proper installation in a CE-marked system will maintain the
required EMC/safety performance.
For minimum RF emissions, it is essential that you implement the following conditions:
1. Install shielded cables on all external I/O ports.
2. Connect conductive chassis rails to earth ground to provide a path for connecting shields to
earth ground.
3. Tighten all front panel screws.
The product also fulfills EN60950 (product safety) which is essentially the requirement for the
Low Voltage Directive (73/23/EEC).

All Motorola PWBs (printed wiring boards) are manufactured by UL-recognized
manufacturers, with a flammability rating of 94V-0.
The computer programs stored in the Read Only Memory of this device contain material
copyrighted by Motorola Inc., 1995, and may be used only under a license such as those
contained in Motorola’s software licenses.
The software described herein and thedocumentation appearing herein are furnished under
a license agreement and may be used and/or disclosed only in accordance with the terms of
the agreement.
The software and documentation are copyrighted materials. Making unauthorized copies is
prohibited by law.
No part of the software or documentation may be reproduced, transmitted, transcribed,
stored in a retrieval system, or translated into any language or computer language, in any
form or by any means without the prior written permission of Motorola, Inc.
Motorola®and the Motorola symbol are registered trademarks of Motorola, Inc.
PowerPC™ is a trademark of International Business Machines Corporation and is used by
Motorola with permission.
All other products mentioned in this document are trademarks or registered trademarks of their
respective holders.
© Copyright Motorola 1999
All Rights Reserved
Printed in the United States of America
February 1999

ix
Contents
CHAPTER 1 Preparing and Installing the MVME2400-Series Module
Introduction................................................................................................................1-1
MVME240x Description ...........................................................................................1-1
MVME240x Module...........................................................................................1-2
PMCspan Expansion Mezzanine........................................................................1-3
PCI Mezzanine Cards (PMCs)............................................................................1-3
VMEsystem Enclosure .......................................................................................1-4
System Console Terminal...................................................................................1-4
Overview of Start-Up Procedures..............................................................................1-4
Unpacking the MVME240x Hardware......................................................................1-7
Preparing the MVME240x Hardware........................................................................1-7
MVME240x........................................................................................................1-7
Setting the Flash Memory Bank A/Bank B Reset Vector Header (J8) .....1-10
Setting the VMEbus System Controller Selection Header (J9).................1-10
Setting the General-Purpose Software-Readable Header (SRH)
Switch(S3).................................................................................................1-11
PMCs ................................................................................................................1-12
PMCspan...........................................................................................................1-12
System Console Terminal.................................................................................1-12
Installing the MVME240x Hardware ......................................................................1-13
ESD Precautions...............................................................................................1-13
PMCs ................................................................................................................1-13
Primary PMCspan.............................................................................................1-16
Secondary PMCspan.........................................................................................1-18
MVME240x......................................................................................................1-21
Installation Considerations ...............................................................................1-23
CHAPTER 2 Operating Instructions
Introduction................................................................................................................2-1
Applying Power .........................................................................................................2-1
MVME240x ...............................................................................................................2-2
Switches..............................................................................................................2-2
ABT (S1) .....................................................................................................2-3
RST (S2)......................................................................................................2-3
Status Indicators..................................................................................................2-4

x
BFL (DS1)...................................................................................................2-4
CPU (DS2) ..................................................................................................2-4
PMC2 (DS3)................................................................................................2-4
PMC1 (DS4)................................................................................................2-4
10/100 BASET Port............................................................................................2-4
DEBUG Port.......................................................................................................2-5
PMC Slots...........................................................................................................2-7
PCI MEZZANINE CARD (PMC Slot 1)....................................................2-7
PCI MEZZANINE CARD (PMC Slot 2)....................................................2-7
PMCspan ...................................................................................................................2-8
CHAPTER 3 Functional Description
Introduction ...............................................................................................................3-1
Features......................................................................................................................3-1
General Description...................................................................................................3-4
Block Diagram...........................................................................................................3-4
MPC750 Processor.............................................................................................3-4
L2 Cache .....................................................................................................3-6
Hawk System Memory Controller (SMC)/PCI Host Bridge (PHB) ASIC........3-7
PCI Bus Latency .........................................................................................3-8
PPC Bus Latency.......................................................................................3-10
Assumptions..............................................................................................3-12
Clock Ratios and Operating Frequencies..................................................3-13
PPC60x Originated....................................................................................3-13
PCI Originated ..........................................................................................3-14
SDRAM Memory.............................................................................................3-14
SDRAM Latency.......................................................................................3-15
Flash Memory...................................................................................................3-19
ROM/Flash Performance ..........................................................................3-19
Ethernet Interface .............................................................................................3-22
PCI Mezzanine Card (PMC) Interface.............................................................3-23
PMC Slot 1 (Single-Width PMC) .............................................................3-23
PMC Slot 2 (Single-Width PMC) .............................................................3-24
PMC Slots 1 and 2 (Double-Width PMC) ................................................3-24
PCI Expansion...........................................................................................3-24
VMEbus Interface ............................................................................................3-25
Asynchronous Debug Port................................................................................3-25
PCI-ISA Bridge (PIB) Controller.....................................................................3-26
Real-Time Clock/NVRAM/Timer Function.....................................................3-27
PCI Host Bridge (PHB)....................................................................................3-27

xi
Interrupt Controller (MPIC)..............................................................................3-28
Programmable Timers.......................................................................................3-28
Interval Timers ..........................................................................................3-28
16/32-Bit Timers........................................................................................3-29
CHAPTER 4 Programming the MVME240x
Introduction................................................................................................................4-1
Memory Maps............................................................................................................4-1
Processor Bus Memory Map...............................................................................4-2
Default Processor Memory Map..................................................................4-2
PCI Local Bus Memory Map..............................................................................4-3
VMEbus Memory Map.......................................................................................4-3
Programming Considerations.....................................................................................4-4
PCI Arbitration ...................................................................................................4-4
Interrupt Handling...............................................................................................4-6
DMA Channels...................................................................................................4-8
Sources of Reset..................................................................................................4-8
Endian Issues ....................................................................................................4-10
Processor/Memory Domain.......................................................................4-10
PCI Domain...............................................................................................4-10
VMEbus Domain.......................................................................................4-11
CHAPTER 5 PPCBug
PPCBug Overview.....................................................................................................5-1
PPCBug Basics ..........................................................................................................5-1
Memory Requirements .......................................................................................5-3
PPCBug Implementation ....................................................................................5-3
MPU, Hardware, and Firmware Initialization ...........................................................5-3
Using PPCBug ...........................................................................................................5-5
Debugger Commands .........................................................................................5-6
Diagnostic Tests................................................................................................5-10
CHAPTER 6 Modifying the Environment
Overview....................................................................................................................6-1
CNFG - Configure Board Information Block............................................................6-2
ENV - Set Environment.............................................................................................6-3
Configuring the PPCBug Parameters .................................................................6-3
Configuring the VMEbus Interface ..................................................................6-13

xii
APPENDIX A Ordering Related Documentation
Motorola Computer Group Documents....................................................................A-1
Manufacturers’ Documents ......................................................................................A-2
Related Specifications ..............................................................................................A-5
APPENDIX B Specifications
Specifications............................................................................................................ B-1
Cooling Requirements.............................................................................................. B-3
EMC Regulatory Compliance .................................................................................. B-4
APPENDIX C Connector Pin Assignments
Introduction .............................................................................................................. C-1
Pin Assignments ....................................................................................................... C-1
VMEbus Connector - P1 ................................................................................... C-2
VMEbus Connector - P2 ................................................................................... C-4
Serial Port Connector - DEBUG (J2)................................................................ C-6
Ethernet Connector - 10BASET (J3)................................................................. C-6
CPU Debug Connector - J1............................................................................... C-7
PCI Expansion Connector - J6 ........................................................................ C-12
PCI Mezzanine Card Connectors - J11 through J14 ....................................... C-15
PCI Mezzanine Card Connectors - J21 through J24 ....................................... C-18
APPENDIX D Troubleshooting the MVME240x
Solving Startup Problems.........................................................................................D-1
Glossary
Abbreviations, Acronyms, and Terms to Know .....................................................GL-1
Index

xiii
List of Figures
Figure 1-1. MVME240x Switches, LEDs, Headers, Connectors ..............................1-9
Figure 1-2. General-Purpose Software-Readable Header........................................1-11
Figure 1-3. Typical Single-width PMC Module Placement on MVME240x..........1-15
Figure 1-4. PMCspan-002 Installation on an MVME240x .....................................1-17
Figure 1-5. PMCspan-010 Installation onto a PMCspan-002/MVME240x............1-19
Figure 2-1. MVME240x DEBUG Port Configuration ..............................................2-6
Figure 3-1. MVME240x Block Diagram...................................................................3-5
Figure 3-2. Memory Block Diagram .......................................................................3-10
Figure 4-1. VMEbus Master Mapping.......................................................................4-5
Figure 4-2. MVME240x Interrupt Architecture ........................................................4-7

xiv

xv
List of Tables
Table 1-1. MVME240x Models.................................................................................1-2
Table 1-2. PMCspan Models......................................................................................1-3
Table 1-3. Start-Up Overview ...................................................................................1-4
Table 3-1. MVME240x Features ..............................................................................3-1
Table 3-2. Power Requirements.................................................................................3-6
Table 3-3. PowerPC 60x Bus to PCI Access Timing.................................................3-8
Table 3-4. PCI to ECC Memory Access Timing........................................................3-8
Table 3-1: PowerPC 60x Bus to Dram Access Using 10ns SDRAMs ....................3-11
Table 3-5. PowerPC 60x Bus to FLASH Access Timing for Bank B (16-bit Port).3-14
Table 4-1. Processor Default View of the Memory Map...........................................4-2
Table 4-2. PCI Arbitration Assignments....................................................................4-6
Table 4-3. Classes of Reset and Effectiveness ..........................................................4-9
Table 5-1. Debugger Commands ..............................................................................5-7
Table 5-2. Diagnostic Test Groups ..........................................................................5-12
Table A-1. Motorola Computer Group Documents................................................. A-1
Table A-2. Manufacturers’ Documents ..................................................................A-2
Table A-3. Related Specifications ..........................................................................A-5
Table B-1. MVME240x Specifications ..................................................................B-1
Table C-1. P1 VMEbus Connector Pin Assignments .............................................C-2
Table C-2. P2 Connector Pin Assignment ..............................................................C-4
Table C-3. DEBUG (J2)Connector Pin Assignments ..............................................C-6
Table C-4. 10/100 BASET (J3) Connector Pin Assignments ..................................C-6
Table C-5. Debug Connector Pin Assignments ......................................................C-7
Table C-6. J18 - PCI Expansion Connector Pin Assignments ..............................C-12
Table C-7. J11 - J12 PMC1 Connector Pin Assignments ......................................C-15
Table C-8. J13 - J14 PMC1 Connector Pin Assignments ......................................C-16
Table C-9. J21 and J22 PMC2 Connector Pin Assignments ..................................C-18
Table C-10. J23 and J24 PMC2 Connector Pin Assignments ................................C-19
Table D-1. Troubleshooting MVME240x Modules ...............................................D-1

xvi

1-1
1
1Preparing and Installing the
MVME2400-Series Module
Introduction
This chapter provides a brief description of the MVME2400-Series VME
Processor Module, and instructions for preparing and installing the
hardware.
In this manual, the name MVME240xrefers to all models of the
MVME2400-series boards, unless otherwise specified.
MVME240x Description
The MVME2400-series VME processor module is a PCI Mezzanine Card
(PMC) carrier board. It is based on the PowerPC™ 750 microprocessor,
MPC750.
Two front panel cutouts provide access to PMC I/O. One double-width or
two single-width PMCs can be installed directly on the MVME240x.
Optionally, one or two PMCspan PCI expansion mezzanine modules can
be added to provide the capability of up to four additional PMC modules.
Two RJ45 connectors on the front panel provide the interface to
10/100Base-T Ethernet, and to a debug serial port.
The following list is of equipment that is appropriate for use in an
MVME240x system:
❏PMCspan PCI expansion mezzanine module
❏Peripheral Component Interconnect (PCI) Mezzanine Cards
(PMC)s
❏VMEsystem enclosure
❏System console terminal
❏Disk drives (and/or other I/O) and controllers
❏Operating system (and/or application software)

1-2 Computer Group Literature Center Web Site
Preparing and Installing the MVME2400-Series Module
1
MVME240x Module
The MVME240x module is a powerful, low-cost embedded VME
controller and intelligent PMC carrier board. The MVME240x is currently
available in the configurations shown in Table 1-1.
The MVME240x includes support circuitry such as ECC SDRAM,
PROM/Flash memory, and bridges to the Industry Standard Architecture
(ISA) bus and the VMEbus. The MVME240x’s PMC carrier architecture
allows flexible configuration options and easy upgrades. It is designed to
support one or two PMCs, plus one or two optional PCI expansion
mezzanine modules that each support up to two PMCs. It occupies a single
VMEmodule slot, except when optional PCI expansion mezzanine
modules are also used:
The MVME240x interfaces to the VMEbus via the P1 and P2 connectors,
which use the new 5-row 160-pin connectors as specified in the proposed
VME64 Extension Standard. It also draws +5V, +12V, and -12V power
fromtheVMEbusbackplanethroughthesetwoconnectors.The+3.3V and
2.5V power, used for the PCI bridge chip and possibly for the PMC
mezzanine, is derived onboard from the +5V power.
Table 1-1. MVME240x Models
Model MPC Memory Handles
MVME2401-1 MPC750
@ 233 MHz 32MB ECC SDRAM Scanbe Handles
MVME2401-3 32MB ECC SDRAM 1101 Handles
MVME2402-1 64MB ECC SDRAM Scanbe Handles
MVME2402-3 64MB ECC SDRAM 1101 Handles
MVME2431-1 MPC750
@ 350 MHz 32MB ECC SDRAM Scanbe Handles
MVME2431-3 32MB ECC SDRAM 1101 Handles
MVME2432-1 64MB ECC SDRAM Scanbe Handles
MVME2432-3 64MB ECC SDRAM 1101-1 Handles
MVME2433-1 128MB ECC SDRAM Scanbe Handles
MVME2433-3 128MB ECC SDRAM 1101-1 Handles

MVME240x Description
http://www.mcg.mot.com/literature 1-3
1
Support for two IEEE P1386.1 PCI mezzanine cards is provided via eight
64-pin SMT connectors. Front panel openings are provided on the
MVME240x board for the two PMC slots.
In addition, there are 64 pins of I/O from PMC slot 1 and 46 pins of I/O
from PMC slot2 that are routed to P2. The two PMC slotsmay contain two
single-wide PMCs or one double-wide PMC. There are also two RJ45
connectors on the front panel: one for the Ethernet 10BaseT/100BaseTX
interface, and one for the async serial debug port. The front panel also
includes reset and abort switches and status LEDs.
PMCspan Expansion Mezzanine
An optional PCI expansion mezzanine module or PMC carrier board,
PMCspan, provides the capability of adding two additional PMCs. Two
PMCspans can be stacked on an MVME240x, providing four additional
PMC slots, for a total of six slots including the two onboard the
MVME240x. Table 1-2 lists the PMCspan models that are available for
use with the MVME240x.
PCI Mezzanine Cards (PMCs)
The PMC slots on the MVME240x boardare IEEE P1386.1 compliant. P2
I/O-based PMCs that follow the PMC committee recommendation for PCI
I/O when using the 5-row VME64 extension connector will be pin-out
compatible with the MVME240x.
Table 1-2. PMCspan Models
Expansion Module Description
PMCSPAN-002 Primary PCI expansion mezzanine module. Allows two PMC modules
for the MVME240x. Includes 32-bit PCI bridge.
PMCSPAN-010 Secondary PCI expansion mezzanine module. Allows two additional
PMC modules for the MVME240x. Does not include
32-bit PCI bridge; requires a PMCSPAN-002.

1-4 Computer Group Literature Center Web Site
Preparing and Installing the MVME2400-Series Module
1
The MVME240x board supports both front panel I/Oand rearpanel P2 I/O
through either PMC slot 1 or PMC slot 2. 64 pins of I/O from slot 1 and 46
pins of I/O from slot 2 are routed directly to P2.
VMEsystem Enclosure
Your MVME240x board must be installed in a VMEsystem chassis with
both P1 and P2 backplane connections. It requires a single slot, except
when PMCspan carrier boards are used. Allow one extra slot for each
PMCspan.
System Console Terminal
In normal operation, connection of a debug console terminal is required
only if you intend to use the MVME240x’s debug firmware, PPCBug,
interactively. An RJ45 connector is provided on the front panel of the
MVME240x for this purpose.
Overview of Start-Up Procedures
The following table lists the things you will need to do before you can use
this board, and tells where to find the information you need to perform
each step. Be sure to read this entire chapter and read all Caution and
Warning notes before beginning.
Table 1-3. Start-Up Overview
What you need to do ... Refer to ... On page ...
Unpack the hardware. Unpacking the MVME240x Hardware 1-7
Set jumpers on the MVME240x
module. Preparing the MVME240x Hardware 1-7
MVME240x 1-7
Prepare the PMCs. PMCs 1-13
For additional information on PMCs, refer to
the PMC manuals provided with these cards.
