Duracell DRAC90S User manual

User Guide
DRAC90S
90W Universal Computer Charger

DRAC90S 90W Universal Computer Charger

CONTENTS
Introduction..................................................................................... 1
Product Features............................................................................ 2
Package Contents .......................................................................... 2
Product Specications.................................................................... 3
Duracell® Charger Components ...................................................... 3
Safety Information .......................................................................... 4
Instructions: Using the Computer Charger ..................................... 5
Common Questions........................................................................ 7
Contacting Customer Support ........................................................ 9
Legal Notices................................................................................ 10
Three-Year Limited Warranty.........................................................11
DRAC90S 90W Universal Computer Charger

Introduction
Thank you for purchasing the Duracell® Slim Universal Computer
Charger. This charger plugs into any AC power outlet anywhere in the
world, and provides a reliable power source to run your computer and
charge its internal battery. Duracell® chargers are made using the highest
quality components and feature all of the necessary voltage and heat
protection circuits to ensure maximum levels of safety and efciency.
NOTE: A physical charger plug may be necessary to plug
into some AC power outlets outside of the United States,
but no voltage converter is needed anywhere in the world.
This charger comes with a variety of numbered tips which connect to
the output cable of the charger. Please read the following instructions
and refer to the Tip Compatibility Guide included with this charger to
make sure that you select the correct tip for your computer or visit the Tip
Selector at DuracellPower.com/DRAC90S to make sure you select the
correct tip for your computer.
CAUTION: This charger is not compatible with Apple Mac
computers. Before using this device, please read the
important safety information section found on Page 4.
1 • DRAC90S 90W Universal Computer Charger

Product Features
This Universal Computer Charger offers many features:
1. Provides up to 90 watts of power.
2. Includes protection against over-voltage, over-temperature and
short circuits.
3. Can power computers using a standard AC wall socket.
5. Can be used with multiple tips, allowing the universal computer
charger to power and charge various computer models.
Package Contents
• 90 Watt Universal Computer Charger (output cable attached)
• Five interchangeable charging tips
• Tip Compatibility Guide
• User Guide
DRAC90S 90W Universal Computer Charger • 2

AC input
cable
Five Interchangeable Tips
Charger Body
Output cable
(shown with
tip attached)
Product Specifications
DC power output cable 22.5”
AC input voltage 100~240 Volts AC, 50-60 Hz~ 2.5A
DC output voltage 19 Volts DC
Output current 4.7 Amps max continuous
Output power 90 Watts continuous
Weight 8.5 oz (240 g)
Dimensions (L x W x H) 3.9 x 2.8 x 0.7 inches
(99.1 x 71.1 x 17.8 mm)
90W Universal Computer Charger
3 • DRAC90S 90W Universal Computer Charger

Safety Information
• The charging tips are uniquely designed. If a tip does not fit into the
power socket of your computer a mismatch may have occurred. Do
not force the tip into the socket. Doing so may damage the charger
and/or your computer.
• Do not expose the charger to rain, moisture, or excessive dust. It may
cause shock hazards.
• Do not operate the charger in direct sunlight.
• Operate the charger in a well ventilated area. Maximum ambient
temperature around the charger must not exceed 105° Fahrenheit
(40° Celsius).
• Do not open the charger under any circumstances. The charger is not
intended to be repaired in case of failure or component defect. There
are no internal serviceable parts.
• Discontinue use and contact our toll free Customer Support line for
assistance at [phone] if any of the following should occur:
• The charger shuts down when it is plugged into the device
(LED light turns off).
• The charger’s LED light blinks when the charger is plugged into
an AC power outlet.
• A cord is damaged or frayed.
• Do not use with computers that require more than 90 watts of power.
• Make sure to use the correct tip for your computer listed in the Tip
Compatibility Guide or online at DuracellPower.com/DRAC90S. Do
not use a tip that is not listed for your computer.
• Keep away from children.
DRAC90S 90W Universal Computer Charger • 4

Instructions
To use the Universal Computer Charger:
1. Select your computer manufacturer and model from the Tip
Compatibility Guide included with this charger or visit the Tip
Selector at www.DuracellPower.com/DRAC90S. This will help
you determine the correct tip for your computer.
CAUTION: The use of an incorrect tip may damage your
computer. Do not use this product if you cannot locate
your computer model in the Tip Compatibility Guide
included with this charger; please contact our toll-free
help line for assistance at [phone]. This charger is
not compatible with Apple Mac computers.
NOTE: If the compatible tip for your device is not included
in the charger package, tips can be ordered by contacting
DURACELL customer service at [phone].
2. Locate the specified tip from the tip bundle provided. Each tip is
clearly numbered.
5 • DRAC90S 90W Universal Computer Charger

3. Connect the selected tip to the end of the output cable, making
sure that the pins on the tip are aligned with the holes in the
cable. The ridge on the inside of the tip should align with the
groove in the output cable connector. Also make sure that the tip
is pushed all the way into the output cable’s connector.
4. Plug the AC cord into an AC wall socket or power strip. The LED
on the charger turns on, indicating that the charger is powered
and ready.
IMPORTANT: If the charger’s LED does not turn on, or if it
blinks, discontinue use and contact our toll free help line
for assistance at [phone].
5. Plug the tip connected to the output cable into the matching DC
input jack on the side or back of your computer. The charger
powers the computer and charges its battery.
DRAC90S 90W Universal Computer Charger • 6

Common Questions
1. How can I find out which tip fits my computer?
You can determine the correct tip for your computer by referencing
the Tip Compatibility Guide included with the charger or by visiting
the Tip Selector at DuracellPower.com/DRAC90S to nd additional
model listings. Locate your computer manufacturer and model and
the correct tip will be listed. If you cannot nd your specic computer
model please contact Duracell® customer service at
[phone] for additional assistance.
2. My tip is not included. How can I get the correct
one for my computer?
First review the included Tip Compatibility Guide to locate the
correct tip for your specific computer. You can also go to the Tip
Selector at DuracellPower.com/DRAC90S for a complete listing of
compatible models. If the compatible tip for your computer is not
included in the charger package, one free tip can also be ordered
through the Tip Selector. If you are unable to locate your computer
in the Tip Selector please contact Duracell®customer service at
[phone].
3. How do I connect the tip to the output cable?
Once you have selected the correct tip for your computer, connect
the tip to the output cable, making sure that the ridge on the side of
the tip aligns properly with the groove in the output cable connector.
Additionally, the pins on the inside of the tip should be in line with
the holes in the output cable. The tip should be pushed firmly onto
the cable until the tip and cable meet and there is no gap.
4. What other computers can I use with this charger?
The Duracell®Universal Computer Charger is compatible with
thousands of computer makes and models. A complete list of
compatible computers can be viewed in the Tip Compatibility Guide
included with your charger or by visiting the Tip Selector at
DuracellPower.com/DRAC90S.
7 • DRAC90S 90W Universal Computer Charger

DRAC90S 90W Universal Computer Charger • 8
5. Why can’t I fit the tip into my computer?
The tip should fit snugly inside the DC input jack on the side or back
of your computer. If the tip will not fit into the jack, you may have
selected the incorrect tip. Please do not force the tip. Confirm that
you have chosen the correct tip for your computer by referencing
the included Tip Compatibility Guide.
6. Will using the wrong tip damage my computer?
The tips are engineered to work with specific computer models and
so you should only use the tip that is designed specifically for your
computer. If you’re not sure which tip is correct, a detailed listing
can be found in the included Tip Compatibility Guide or visit the Tip
Selector at DuracellPower.com/DRAC90S to nd additional model
listings. Using an incorrect tip may cause performance issues, such
as inability to charge the internal battery or power the computer,
or an error message appearing on the computer screen. It is also
possible that the use of an incompatible tip could damage your
computer. Therefore, it is vital to use the tip created especially for
your device.
7. My computer is less than 90 watts (e.g. 65 watts).
Will this charger damage my computer?
No, using this charger will not damage your computer.
This charger only supplies as much power as required
by the computer, up to a maximum of 90 watts.
8. My computer is more than 90 watts (e.g. 120 watts).
Will this charger damage my computer?
This is a 90 watt charger and it should NOT be used with
computers that require more than 90 watts of power.
7. The charger often feels warm when I’m using it with
my computer. Is this dangerous?
During standard operation the charger body may feel warm, and
this is normal. The charger should always be placed in a ventilated
area to avoid overheating.

Contacting Customer Support
If you experience any problems or have any questions regarding
your Duracell®Universal Computer Charger, free technical support
is available. Prior to calling, please review the technical support tips
below.
· Call from a phone where you have access to your mobile device
· Be prepared to provide the following information:
- Name, address and telephone number
- Name of the Duracell®product
- Make and model of your computer
- System software and version installed on your computer
- Symptoms of the problem(s) and what led to them
Technical Support is available by telephone
U.S. and Canada [phone]
Le Canada - De langue française Seulement: [phone]
Outside of the US/Canada: [phone]
Written inquires should be directed to:
Battery-Biz Inc.
DURACELL Product Inquiry
1380 Flynn Road,
Camarillo, CA 93012, USA
9 • DRAC90S 90W Universal Computer Charger
8. Does it waste energy to keep the charger plugged
in when I’m not using it?
This Duracell®charger meets EnergyStar and CEC energy
standards, which means that it is an energy-efficient product
designed to conserve power. When plugged in and not in use, the
charger draws less than 0.5W of power.

Legal Notices
FCC Part 15
This device complies with Part 15 of the FCC Rules. Operation of this
product is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired
operation.
This equipment has been tested and found to comply within the limits
for a class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
• Consult the dealer or an experienced technician for help.
FCC Warning
Changes or modifications not expressly approved by the party
responsible for compliance with the FCC Rules could void the user’s
authority to operate this equipment.
DRAC90S 90W Universal Computer Charger • 10

THREE YEAR LIMITED WARRANTY
This PRODUCT carries a limited warranty against defects in material
and workmanship under normal use and service for three years from the
original date of purchase. The manufacturer or distributor, at its option,
shall repair or replace the defective unit covered by this warranty. Please
retain the dated sales receipt as evidence of the date of purchase as it
will be required for any warranty service. In order to keep the warranty in
effect, the product must have been handled and used as described in the
instructions accompanying this warranty. This warranty does not cover
any damage due to accident, misuse, abuse or negligence.
DISCLAIMER OF WARRANTY
The limited warranty described herein is your sole remedy. To the extent
permitted by law, the manufacturer and distributor disclaim all other
implied or express warranties including all warranties of merchantability
and/or tness for any particular purpose.
LIMITATION OF LIABILITY
Except to the extent of repairing or replacing the Universal Computer
Charger as expressly stated in the limited warranty described herein,
the manufacturer and distributor shall not be liable for any damages,
whether direct, indirect, incidental, special, consequential, exemplary, or
otherwise, including lost revenues, lost prots, loss of use of software,
loss or recovery of data, rental of replacement equipment, downtime,
damage to property, and third-party claims, arising out of any theory
of recovery, including statutory, contract or tort. Not withstanding the
term of any limited or implied warranty, or in the event that any limited
warranty fails of its essential purpose, in no event will the manufacturer’s
and distributor’s entire liability exceed the purchase price of this product.
Some states and provinces do not allow the exclusion or limitation
of incidental or consequential damages so the above limitations or
exclusions may not apply to you. This limited warranty gives you specic
legal rights. You may have other rights which vary from state to state and
province to province.
11 • DRAC90S 90W Universal Computer Charger

DRAC90S 90W Universal Computer Charger • 12

UM-DRAC90S
20140128
© 2014 Duracell.
DURACELL is a registered trademark of The Gillette Company,
used under license. All rights reserved.
All logos and trademarks are used for identication purposes only and
may be trademarks or registered trademarks of their respective holders.
