Matrix Orbital HTT Series User manual

HTT Series
For all variants of the HTT50A and HTT70A
Hardware Manual
Revision 1.0

MATRIX ORBITAL 1 Phone: [phone]
Email: [e-mail]
Contents
Introduction ..................................................................................................................................................3
Features ........................................................................................................................................................3
Extended Display Information Data (EDID)...................................................................................................3
Part Numbering Scheme...............................................................................................................................4
Options......................................................................................................................................................4
Power Options ...................................................................................................................................... 4
USB Drivers ...................................................................................................................................................4
HTT50A Technical Specifications .................................................................................................................. 6
Available Headers .....................................................................................................................................6
HDMI Port ................................................................................................................................................. 6
Mini USB....................................................................................................................................................6
Optical Characteristics ..............................................................................................................................7
Environmental Characteristics ..................................................................................................................7
Power ........................................................................................................................................................ 7
Dimensional Drawing................................................................................................................................ 8
HTT70A Technical Specifications .................................................................................................................. 9
Available Headers .....................................................................................................................................9
HDMI Port ................................................................................................................................................. 9
Mini USB....................................................................................................................................................9
Barrel Jack................................................................................................................................................. 9
Optical Characteristics ............................................................................................................................10
Environmental.........................................................................................................................................10
Power ......................................................................................................................................................10
Dimensional Drawing..............................................................................................................................11
Recommended Accessories ........................................................................................................................12
USB Communication ...........................................................................................................................12
HDMI Cable .........................................................................................................................................12
External Power....................................................................................................................................12
Support .......................................................................................................................................................12
Contact........................................................................................................................................................12

MATRIX ORBITAL 2 Phone: [phone]
Email: [e-mail]
Revision History
Revision
Date
Description
Author
1.0
November 6, 2017
First Release
Henry Jakl

MATRIX ORBITAL 3 Phone: [phone]
Email: [e-mail]
Introduction
The HTT series offers full colour TFT displays, with a simple HDMI and USB plug and play interface. The HTT can be
configured with a touch screen, providing control without the need of a mouse or keyboard. Designed with
industrial applications in mind, the HTT is perfect for panel mounted applications and HMI interfaces.
Features
Plug and Play
Works with Raspberry Pi, Windows, Linux and other systems
Available Sizes
o5.0” 800x480 24bit RGB
o7.0” 800x480 24bit RGB
USB for touch screen, HMI mouse interface
Available in:
oNon-touch,
oResistive touch
oCapacitive touch
Upgradable touch driver firmware
DVI/HDMI interface
Automatic resolution detected provided by EDID
Low profile mounting holes
Power through USB (HTT50A)
Industrial 5-35V power input (-VPT) option
Extended Display Information Data (EDID)
The HTT’s on-board EDID comes preconfigured, so users won’t have to worry about setting up their screen
resolution or display timings. Once plugged in, the EDID will automatically detect the HTT display resolution.

MATRIX ORBITAL 4 Phone: [phone]
Email: [e-mail]
Part Numbering Scheme
Table 1: Part Numbering Scheme
HTT
70
A
-TPR
-BLM
-B0
-H1
-CH
-V5
1
2
3
4
5
6
7
8
9
Options
Table 2: Display Options
#
Designator
Options
1
Product Type
HTT: Graphic TFT Display
2
Display Size
50: 5.0”, 70: 7.0"
3
Screen Type
A: A Type
4
Touch
-TPN: No touch panel
-TPR: Resistive touch panel
-TPC: Capacitive touch panel
5
Backlight
-BLM: 300 Nit < Brightness < 600 Nit
-BLH: 600 Nit < Brightness < 1000 Nit
-BLD: Brightness > 1000 Nit
6
Bezel
-B0: None
7
Headers
-H5: Horizontal Connectors
-H6: Vertical Connectors
8
Protocol
-CH: HDMI interface
9
Voltage
-V5: 5.0V Input Voltage
-VPT: Regulated 5V - 35V Input Voltage
Power Options
-V5: Power through the USB port, 4.5-5.5V
-VPT: Power through a 2-pin header, 5–35V, industrial applications
USB Drivers
Once the HTT is properly installed in windows, 3 new devices will be present in Device manager.
HID-Compliant Mouse
USB Composite Device
WinUsb Device
Table 3: HTT Device VID/PID
VID
0x1B3D
PID
0x14C2

MATRIX ORBITAL 5 Phone: [phone]
Email: [e-mail]
Figure 1: HTT USB Driver Listing

MATRIX ORBITAL 6 Phone: [phone]
Email: [e-mail]
HTT50A Technical Specifications
The HTT50 is a 5.0” TFT display with an HDMI interface. The 800x480 resolution offers crisp images, and
video feedback, with 24-bit Full colour capabilities. The HTT can be configured with resistive, capacitive,
or non-touch panels, making this display suitable for any application.
Available Headers
Table 4: HTT50A Headers and Mates
#
Header
Standard Mate
Population
1
HDMI Port, Horizontal, Type A Standard
Type A Standard HDMI
-H5
2
HDMI Port, Vertical, Type A Standard
Type A Standard HDMI
-H6
3
Mini USB, Horizontal: Touch & Power
Mini-B USB
-H5
4
Mini USB, Vertical: Touch & Power
Mini-B USB
-H6
5
Barrel Jack: 2.1mm Center Positive
PWR-ACDC-5V2A
Optional
6
External Power, 2-1445057-2
Micro MATE-N-LOCK 1445022-2
-VPT model
HDMI Port
The HTT uses HDMI/DVI 1.0 and is only compatible with unencrypted video signals. HDCP video signals are not
supported.
Mini USB
Up to 500mA of power can be provided through the Mini-USB header to power the HTT. Touch communication
also occurs over USB.

MATRIX ORBITAL 7 Phone: [phone]
Email: [e-mail]
Optical Characteristics
Table 5: HTT50A Optical Characteristics
Module Size
121.20 x 92.25 x 12.07
mm
Viewing Area
110.70 x 67.40
mm
Active Area
108.00 x 64.80
mm
Pixel Pattern
800 x 480 x 24bit RGB
Pixel Pitch
0.135 x 0.135
mm
Luminance
380
cd/m2
Viewing Angle
70° Left, Right, Up
50° Down
Contrast Ratio
500:1
Backlight Half-Life
20,000 hours
Environmental Characteristics
Table 6: HTT50A Environmental Characteristics
Operating Temperature
0°C to +70°C
Storage Temperature
-30°C to +80°C
Operating Relative Humidity*
90% (T < 60°C)
*Note: No condensation at any temperature
Power
Table 7: HTT50A Maximum Power Characteristics
Parameter
Min
Typ
Max
Unit
Remarks
Supply Voltage
4.75
5.0
5.25
V
Standard Voltage (V5)
9.0
12.0
35.0
V
Wide Voltage (VPT)
Table 8: HTT50A Typical Power Characteristics
Parameter
Min
Typ
Max
Unit
Remarks
Logic
-
275
-
mA
Backlight Off
Backlight
0
-
225
mA
Off, Mid, Max

MATRIX ORBITAL 8 Phone: [phone]
Email: [e-mail]
Dimensional Drawing
Figure 2: HTT50A Dimensional Drawing

MATRIX ORBITAL 9 Phone: [phone]
Email: [e-mail]
HTT70A Technical Specifications
The HTT70A is a HDMI compatible 7.0” Full color TFT, with an 800x480 resolution. Resistive, capacitive,
and non-touch panels are available for the HTT70A, making it suitable for any application.
Available Headers
Table 9: HTT70A Headers and Mates
#
Header
Standard Mate
Population
1
HDMI Port, Horizontal, Type A Standard
Type A Standard HDMI
-H5
2
HDMI Port, Vertical, Type A Standard
Type A Standard HDMI
-H6
3
Mini USB, Horizontal: Touch & Power
Mini-B USB
-H5
4
Mini USB, Vertical: Touch & Power
Mini USB
-H6
5
Barrel Jack: 2.1mm Center Positive
PWR-ACDC-5V2A
-H6
6
External Power, 2-1445057-2
Micro MATE-N-LOCK 1445022-2
-VPT model
HDMI Port
The HTT uses HDMI/DVI 1.0 and is only compatible with unencrypted video signals. HDCP video signals are not
supported.
Mini USB
Up to 500mA of power can be provided through the Mini-USB header to power the HTT. Touch communication
also occurs over USB.
Barrel Jack
Additional 5V power can be applied to the display through the barrel jack header. It is recommended that 900mA
is supplied to the display.

MATRIX ORBITAL 10 Phone: [phone]
Email: [e-mail]
Optical Characteristics
Table 10: HTT70A Optical Characteristics
Module Size
164.90 x 115.88 x 12.77
mm
Viewing Area
157.00 x 89.10
mm
Active Area
153.84 x 85.63
mm
Pixel Pattern
800 x 480 x 24bit RGB
Pixel Pitch
0.1923 x 0.1784
mm
Luminance
520
cd/m2
Viewing Angle
70° Left, Right, Up
60° Down
Contrast Ratio
500:1
Backlight Half-Life
20,000 hours
Environmental
Table 11: HTT70A Environmental Characteristics
Operating Temperature
0°C to +70°C
Storage Temperature
-30°C to +80°C
Operating Relative Humidity*
90% (T < 60°C)
*Note: No condensation at any temperature
Power
Table 12: HTT70A Maximum Power Characteristics
Parameter
Min
Typ
Max
Unit
Remarks
Supply Voltage
4.75
5.0
5.25
V
Standard Voltage (V5)
9.0
12.0
35.0
V
Wide Voltage (VPT)
Table 13: HTT70A Typical Power Characteristics
Parameter
Min
Typ
Max
Unit
Remarks
Logic
-
375
-
mA
Backlight Off
Backlight
0
-
465
mA
Off, Mid, Max

MATRIX ORBITAL 11 Phone: [phone]
Email: [e-mail]
Dimensional Drawing
Figure 3: HTT70A Dimensional Drawing

MATRIX ORBITAL 12 Phone: [phone]
Email: [e-mail]
Recommended Accessories
USB Communication
Figure 4: EXTMUSB3FT
EXTMUSB3FT
3ft (1m) Mini-B USB Cable
HDMI Cable
Figure 5: HDMI Cable
3ft (1m) HDMI Cable
6ft (2m) HDMI Cable
External Power
Figure 6: PWR-ACDC-5V2A
PWR-ACDC-5V2A
Input Voltage: 100-240V AC
Output Voltage: 5V DC @ 2A
Length: 9ft / 2.7m
Barrel Jack: 2.1mm Center Positive
AC Plugs Included: North American (NEMA), Europlug (Type C), UK (Type G),
Australia/China/New Zealand/Argentina (Type I)
Support
Phone: [phone]
Email: [e-mail]
Manuals and Drivers: http://www.matrixorbital.ca
Forums: http://www.lcdforums.com/forums
Contact
Sales
Phone: [phone]
Email: [e-mail]
Support
Phone: [phone]
Email: [e-mail]
Online
Purchasing: www.matrixorbital.com
Support: www.matrixorbital.ca
