Matrix Vision mvBlueCOGAR-P Series Operating and installation instructions

MATRIXVISIONGmbH|Talstrasse16|DE71570Oppenweiler
Telefon:+49719194320|Fax:+4971919432288|www.matrixvision.de
Mail:info@matrixvision.de
Subjecttochangewithoutnotice/TechnischeÄnderungenvorbehalten–08/2009
1
Changingopticalfilter
Thedescriptioncanbeusedforfollowingproducts:
mvBlueCOGARPseries
mvBlueFOXseries
mvBlueLYNXseries
mvBlueLYNXMseries
Youwillneedfollowingutilitiestochangethefilter:
pointedforceps
toremovetherubberlockingring
screwdriverorsimilar
toremovethefilterframe
allenwrench,0.9mm
lens
PCwithinstalleddriver
Pleaseworkunderthecleanairwhilechangingthefilter.Otherwise,dirtontheimage
areacouldbetheconsequence. 
Step1:Demountingofmountringnut 
Fordemountingofthemountringnut,please
1. unfixthe3setscrewsonthefrontplatewiththeaidofthe0.9mmallenwrench
(infigure1).Afterwards
2. turnthemountringnutanticlockwisefromthefrontplate( infigure1). 
Step2:Demountingoffilterframe 
Fordemountingofthefilterframe
1. turnthefilterframeanticlockwisefromthefrontplate(infigure1)usingascrew
driverorasimilartool.Setthescrewdriveratthegrooveofthefilterframe. 
Step3:Changingthefilter 
Arubberlockingringfixesthefilterinthefilterframe.
1. Removetherubberlockingringusingapointedforceps(infigure1).Afterwards,
2. changethefilter(infigure1).Finally,
3. fixtherubberlockingringagain.
I
3
4
5
1
2

MATRIXVISIONGmbH|Talstrasse16|DE71570Oppenweiler
Telefon:+49719194320|Fax:+4971919432288|www.matrixvision.de
Mail:info@matrixvision.de
Subjecttochangewithoutnotice/TechnischeÄnderungenvorbehalten–08/2009
2
Figure1Filtermounting 
Step4:Mountingfilterframe 
1. Turnthefilterframeclockwiseintothefrontplateusingascrewdriverorasimilar
tool. 
Step5:Mountingmountringnut 
1. Turnthemountringnutclockwiseintothefrontplateand
2. screwthesetscrewsusingtheallenwrenchbutwithoutfixingthem. 
Step6:Adjustingsharpnessandfixing 
Inthelaststep,youhavetoadjusttherightdistanceofthemountringnut(thusthe
sharpness).Pleasefollowthesesteps:
1. Mountalensand
2. connectthecameratothePCwiththeinstalleddriver.
3. StarttheGUItool“ wxPropView ”and
4. displayaliveimage.
5. Nowturntheringnutwiththemountedlensinoroutuntilyougetasharpimage.
6. Afterwards,fixthethreesetscrewswiththeallenwrench.
