Matrix MCR5000 Series User manual

MCR METER Manual
MCR5000 SERIES USER MANUAL
MCR5010
MCR5030
MCR5100
MCR5200
MATRIX TECHNOLOGY INC.

MCR METER Manual
1
Chapter 1 Instrument inspection and preparation ---------------------------------2
1.1 The crates ------------------------------------------------------------------2
1.2 Power connection ------------------------------------------------------------3
1.3 Fuse and toggle switch ------------------------------------------------------3
1.4 Environmental requirements --------------------------------------------------3
1.5 Test fixture requirements ---------------------------------------------------3
1.6 Accuracy guarantee ----------------------------------------------------------4
Chapter 2 Introduction ----------------------------------------------------------4
2.1 Front panel description -----------------------------------------------------4
2.2 Rear panel description ------------------------------------------------------5
2.3 Basic operation -------------------------------------------------------------5
2.4 Data storage format ---------------------------------------------------------5
Chapter 3 Function description --------------------------------------------------6
3.1 <MEAS DISP> -----------------------------------------------------------------6
3.2 < BIN DISP > (MCR5010 no this feature) ----------------------------------------7
3.3 <MULTI PARA.DISP> (only MCR5200 has this function) --------------------------7
3.4 <MEAS SETUP> ----------------------------------------------------------------8
3.5 <SYSTEM SETUP> --------------------------------------------------------------8
3.6<COMMSETUP> ----------------------------------------------------------------8
3.7 <ABOUT> ---------------------------------------------------------------------9
3.8 <INTER Files List> , <EXT Files List> ---------------------------------------9
Chapter 4 Performance ----------------------------------------------------------10
4.1 Range ----------------------------------------------------------------------10
4.2 Accuracy ------------------------------------------------------------------11
Chapter 5 HANDLER interface ----------------------------------------------------14
5.1 HANDLER interface introduction ---------------------------------------------14
Chapter 6 Operation example ----------------------------------------------------16
6.1 Clear operation ------------------------------------------------------------16
6.2 Set sorting ----------------------------------------------------------------17
Appendix: list of parameters of various models ---------------------------------18
Statement: in this paper, the content of the instrument. Our company have the right to the
instrument performance, appearance, function, accessories, packing and so on to improve and
improve without further instructions! The resulting manual do not agree with instruments of
confusion, can contact us through the following ways.

MCR METER Manual
2
Chapter 1 Instrument inspection and preparation
Please be sure to check the receipt of the instrument, and must understand and have the
condition before using the instrument.
1.1 The crates
After receiving the product, it is found that the packing is badly damaged. Please keep it until
it is normal for the whole machine and the accessories.
Check the machine, if the instrument is damaged, please contact the dealer or the company
in charge of the business.
Please check the attachment, please check the attachment according to the packing list, if
the attachment is missing or damaged, please contact your dealer or division to protect your
rights and interests.
1.2 Power connection
（1）Power supply voltage range：
100 ～120 Vac（The power supply of the instrument rear panel is selected as 110V display）
198 ～242 Vac（The power supply of the instrument rear panel is selected as 220V display）
（2）Frequency range of power supply：47 ～63 Hz。
（3）Power supply range：>= 30 VA。
（4）Wire-L、Wire-N、Groud-E should be the same as the power plug of
theinstrument.
The instrument has been carefully designed to reduce the interference caused by the input
of the AC power supply side, but still should try to make it in low noise environment, if you
can not avoid, please install the power filter.
Warning: in order to prevent leakage of equipment or artificial damage, the user must
ensure that the power supply to the earth ground reliable.
1.3 Fuse and toggle switch
Instrument factory has been equipped with a fuse, the user should use the company
equipped with a fuse.
Warning: you should pay attention to the position of the toggle switch is consistent with the
power supply voltage range of power on before.
1.4 Environmental requirements
（1）Please do not use in the dust, vibration, direct sunlight, corrosive gases, such as the use of
bad environment.
（2）Instrument is not used for a long time, please put it in the original packing box or similar to
the box in the reservoir is 5 to 40 DEG C temperature, relative humidity is not more than
85% RH of the indoor ventilation, air should not contain harmful impurity in corrosion
measurement instrument and should avoid direct sunlight.
（3）Please ensure that the instrument is in good ventilation condition, do not plug the
instrument cooling and ventilation holes.
（4）In particular, the instrument is connected with the test wire of the test piece to be far away
from the strong electromagnetic field, so as not to interfere with the measurement.
1.5 Test fixture requirements
Please use the company's test fixture or test cable, the instrument test fixture or test cable
should be kept clean, the test device pin to keep clean, to ensure that the test device and the fixture

MCR METER Manual
3
is in good contact. The test fixture or test cable is connected to the HD, HS, LS and LD of the front
panel of the instrument. The shield layer can be connected to the rear panel of the instrument, and
the shield layer can be connected with the rear panel of the instrument.
User homemade or other company test fixtures or test cables may result in incorrect
measurement results.
1.6 Accuracy guarantee
（1）In order to ensure the accurate measurement of the instrument, the heating time should
be no less than 15 minutes.
（2）Do not frequent switching equipment, in order to avoid confusion caused by internal
data.
（3）Correct open circuit and short circuit operation.
Chapter 2 Introduction
A new generation of high precision and high stability of boutique MCR meter is MCR5010,
MCR5100,MCR5200, the 4.3 inch 480*272 TFT display screen, display classical and intuitionistic.
The series of equipment is highly applicable to the majority of manufacturers production
inspection. And the series of equipment has a variety of output impedance model can be used
for different manufacturers needs, its superior performance can be achieved business standards
and military standards of a variety of tests (such as IEC and MIL).

MCR METER Manual
4
2.1 Front panel description
PASS FAIL
MEAS SETUP SYSTEM FILE TRIG
4
GHI
10
5
JKL
6
MNO
2
ABC
3
DEF
7
PQRS
8
TUV
9
WXYZ
+/-
ESC
OK
TOOL
LCR METER
GUOFENG
ELECTRONICS
GF10
1 2 3 54
6 7 9 8 10 11 12 13 14 15
16
17
18
19
1. Power switch 2. Instrument type label
3. USB interface 4. Tool key
5. Test terminal：LD、LS、HS、HD 6. 4.3 inch TFT LCD screen
7. Soft-key
8. Direction key
9. PASS light，Qualified judgment lamp
10. FAIL light，Failure product judgment lamp
11. MEAS, Measurement display page shortcut key
12. SETUP, Measurement set page shortcut key
13. SYSTEM, System settings page shortcut keys
14. FILE, File management page shortcuts
15. TRIG,Triggermeasurekey 16. ESC,Cancelkey
17. ，Backspace key, used to delete the previous input
18. OK，Confirminputkey
19. Alphanumeric keypad symbols
2.2 Rear panel description
EXT
RS-232C
HANDLER
USB
RATING FUSE
～110V/60Hz 30VA
～220V/50Hz 30VA
T1.0AL 250V
T0.5AL 250V
FOOT.C
1 2 3 4 5 6
789
1. RS232C, serial port 2. USB DEVICE
3. Earphone port 4. FOOT.C，Foot switch interface
5. Ground 6. Power switch（110V/220V）
7. Power supply socket
8. Extended interface
9. HANDLER，Sorting interface

MCR METER Manual
5
2.3 Basic operation
1. Direction key: used to move the cursor.
2. Soft keys, used to change the parameters set of features.
3. Shortcut menu: MEAS, SETUP, SYSTEM, FILE, press directly into the < MEAS DISP >, < MEAS
SETUP >, < SYSTEM SETUP >, < INTER/EXT Files List> function page settings.
Reminder: when in < MEAS DISP > page, and the cursor in < MEAS DISP >, press MEAS key,
< MEAS DISP > page test results will be full screen display.
4. TOOL：Tool key，In each function page tool will be different.
When the short press TOOL key, key area will be a corresponding tool operation, short press
TOOL key again, the tools menu disappear.
When long press tool button for one second, the instrument into the key lock state, pressing
other keys invalid; again the press tool button for one second instrument will remove key
lock state.
2.4 Data storage format
USB storage, use the TOOL key in the measurement of the page, there will be data storage
function. The basic form is as follows:
<A>，<B>[，<COMP>]
A, B is the first & second parameter measurement results, scientific counting method to save.
<COMP> is the sorting result, MCR5010 has no sorting function.
COMP
Explain
0
OUT
1
BIN 1
2
BIN 2
3
BIN 3
4
AUX
5
No
comparison
Chapter 3 Function description
3.1 <MEAS DISP>
The page can be set as follows:
MEAS DISP softkey ：press this key into <MEAS DISP> page.
BIN DISP softkey : press this key into <BIN DISP> page.(MCR5010 no such function)
MULTI PARA. Softkey: press this key into <MULTI PARA. DISP> page.(only MCR5200 has this
function)
Quick Clear : press this key to SHORT & OPEN all frequency points.
FUNC：MCR5010/MCR5030/MCR5100/MCR5200 can set parameters：
Cs-D，Cp-D，Ls-Q，Lp-Q，Rs-Q，Rs-D，Rp-Q，Rp-D，R-X，Zs-θ，Zs-r；
Parameter implication:
Cs: Capacitance (series equivalent mode)
Cp: Capacitance (parallel equivalent mode)
Ls: Inductance (series equivalent mode)
Lp: Inductance (parallel equivalent mode)

MCR METER Manual
6
Rs: Series equivalent resistance(ESR))
Rp: Parallel equivalent resistance(EPR)
D : loss
Q : quality factor
R : resistance
X : reactance
Zs: Series equivalent impedance
θ: angle
r : angle
RANGE：AUTO，HOLD，INCR +，DECR -
FREQ：Set frequency
MCR5010 : 100Hz，120Hz，1kHz，10kHz,
MCR5030：100Hz,120Hz,1kHz,10kHz，20kHz，30kHz
MCR5100: 50Hz，60Hz，100Hz，120Hz，1kHz，10kHz, 20kHz，40kHz，50kHz，100kHz
MCR5200: 40Hz、50Hz、60Hz、80Hz、100Hz、120Hz、150Hz、200Hz、250Hz、300Hz、
400Hz、500Hz、600Hz、800Hz、1kHz、1.2kHz、1.5kHz、2kHz、2.5kHz、
3kHz、4kHz、5kHz、6kHz、7.5kHz、10kHz、12kHz、15kHz、20kHz、25kHz、
30kHz、40kHz、50kHz、60kHz、75kHz、100kHz、120kHz、150kHz、200kHz
SPEED ：FAST、MED、SLOW
LEVEL ：1V，0.3V，0.1V
COMP ：ON ，Open the comparison function
OFF，Close comparison function
BIN DISP,press this key into <BIN DISP> page
Test result display area：
FONT SMALL/LARGE,press this key to change the font size.
DISP ON/OFF,press this key to open or close test results display
DEV OFF/ABS/% ：
the deviation function only for the main parameters, there are 3 ways:OFF、ABS、%
（MCR5010 no this feature）
OFF: Normal display mode
ABS: Absolute deviation display mode
The absolute deviation of the measured value of the current component minus the
preset nominal value. The absolute deviation of the calculation formula is as follows:
⊿ABS = X – Y
Among them, X is the measured value of the current measured, Y is set to the
nominal value.
% : Percentage deviation display mode
The percentage deviation is the percentage of the nominal value of the measured
value of the current component and the difference between the predetermined
nominal value. The calculation formula of the percentage deviation is as follows:
⊿% = （X – Y）/ Y×100[%]
Among them, X is the measured value of the current measurement, Y for the set of
the nominal value.

MCR METER Manual
7
Vm ON/OFF ：Open or close voltage monitoring function
Im ON/OFF ：Open or close current monitoring function
3.2 < BIN DISP > (MCR5010 no this feature)
This page can be set as follows:
COMP ON/OFF ：to open or close the comparison function
AUX ON/OFF ：to open or close AUX.
AUX is the main parameter is qualified, and the Deputy parameter is not qualified.
COUT ON/OFF ：to open or close the counting function
NOMINAL ：By using digital key and softkey input. (the reference value for the
comparison of the main parameters)
MODE Δ% / ABS : to choice the comparison mode.
Δ% :Relative percentage mode
ABS :Absolute value comparison mode
LOW and HIGH :Through digital key, the OK key and the softkey input.
Test result display area：DISP ON/OFF;DEV OFF/ABS/%(Same as in 3.1)
3.3 <MULTI PARA.DISP> (only MCR5200 has this function)
This page can be set as follows:
FREQ : Set frequency
LEVEL: Set test voltage
1/2/3/4/5 test parameter: The test parameters required by soft region selection.
3.4 <MEAS SETUP>
This page can be set as follows:
ResSource ：30Ω/100Ω,Select output resistance mode
AVERAGE ：1~255.By using digital key input or softkey "INCR+" and "DECR -".
RangeDwell ：Range delay. 0~6000ms.By using digital key input or softkey "INCR+" and "DECR
-".
TrigSource ：INT,EXT.(Trigger mode)
TrigDelay ：0~6000ms.By using digital key input or softkey "INCR+"
and "DECR -".
TrigEdge ：RISING,FALLING .The rising edge of the trigger; the falling
edge of the trigger
Handler ：CLEAR,HOLD,PULSE. Sorting signal mode
PulseWidth ：1~9999ms.(pulse width)
3.5 <SYSTEM SETUP>
This page can be set as follows:
Theme ：TRAD-BLUE,TRAD BLACK,BLACKISH GREEN.(Display style)
Language ：English、中文 . (Language environment)
Key Tone ：ON,OFF. Open or close button sound
ToneSour ：MASTER,EARPHONE,ALL.(Buzzer mode,EARPHONE socket is optional)
PassTone ：OFF,LONG,SHORT,TWO SHORT
FailTone ：OFF,LONG,SHORT,TWO SHORT
ParaSave ：AUTO SAVE,AUTO LOAD,NO SAVE
AUTO SAVE : This feature will save the settings of the measurement parameters in real time,
the next boot state will be the same as the last shutdown.
AUTO LOAD ：Automatically invokes the last loaded internal file.

MCR METER Manual
8
NO SAVE : Each boot display parameters for the default
configurationoftheinstrument.
PassWord ：OFF,LOCK SYSTEM,LOCK FILE,MODIFY,SAVE TO U_DISK
OFF : No password
LOCK SYSTEM : File and boot need password to perform the operation
LOCK FILE : File requires a password to perform the operation
MODIFY : Modify password.
Factory default password : 0010(MCR5010)
0100(MCR5100)
0200(MCR5200)
SAVE TO U_DISK : Save the password to U disk.For example, the password file named
"0010.STA" (determined by the instrument model).When the instrument operation need to
enter a password, can advance with password U disk plug the USB interface of the
instrument, instrument will automatically detect the password file is valid, so as to achieve
the purpose of lifting passwords.
3.6 <COMM SETUP>
This page can be set as follows:
Bus Mode ：RS232C,GPIB,USBTMC,USBCDC
BaudRate ：INCR+,DECR-（4800,9600,19200,38400,115200）
Data Bit ：6,7,8
Stop Bit ：1,2
Parity ：None,Odd,Even
Tx Term：LF 0x0A,CR 0x0D,LFCR
GpibAddr ：In the 0~31 value through the softkey or the number keys set.
3.7 <ABOUT>
Press [ABOUT SYSTEM] softkey into <ABOUT> page.
This page display instrument ID number and other registered information.
Soft key functions are as follows:
Reset：press it to restart this instrument.
Factory：Instrument returned to the factory status. Need to enter a password to confirm.
Update：Push button upgrade system. Need to insert the U disk with the upgrade file
EXIT：Return to < SYSTEM SETUP> page.
3.8 <INTER Files List> , <EXT Files List>

MCR METER Manual
9
The parameters set by the user in form of a file stored in the instrument internal non-volatile
memory, when the next time you want to use the same settings, users do not need to set these
parameters, only need to load the appropriate file, the last set of parameters are obtained. Thus
greatly saving the time for the user to re set the parameters and improving the production
efficiency.
Press FILE button to enter the < INTER Files List > page. Press the FILE key again to switch
the internal / external file.
Operation procedure description:
A. Review existing files
1) By using the upper and lower keys, one by one look.
2) Use the left and right buttons, can look at the page.
3) Input file number keys corresponding to the serial number, then press the button [OK],
can be directly read the required file.
B. Follow these steps to save the parameter to the file.
1) The number at the cursor to need to save the file, press [STORE] softkey;
2) Select softkey [YES] into the next step, select the key [NO] cancel the save operation;
3) If step 2) select [YES], use the numeric keys to enter the file name and press [OK] to
confirm. If the serial number is already in the file, you can override the file or cancel the
operation according to the screen.
C. Follow these steps to load the parameters set in the corresponding file.
1) Press the FILE key to switch to the file management page.
2) Move the cursor to the file location in the file list, or direct input file serial number.
3) Press LOAD key.
4) Select softkey YES, loading the current file, and return to the current page.
D. Follow the steps for copying files to E (U disk).
1) Insert the U disk into the instrument front panel USB interface.
2) Move the cursor to the file, press the soft key "copy to E:"
3) According to the screen, press the soft key "YES" to copy.
4) If U disk file with the same file name, screen prompt the need to cover, according to the
soft key "YES" to continue copying, press the soft key "NO", cancel the copy.
Chapter 4 Performance
Specific reference to each model parameter table in the appendix.
The following is part of the parameter description:

MCR METER Manual
10
4.1 Range
In 100 ohm source resistance, using a total of 5 range: 31.6Ω，100Ω，1kΩ，10kΩ,100kΩ
In 30 ohm source resistance, using a total of 6 range : 10Ω，30Ω，100Ω，1 kΩ，10 kΩ,100 k
Ω
The effective measurement range of each range is shown in the
following table.
Table 4-1 The range in 100Ωsource resistance
No.
Range
Resistance
Effective
measurement
range
0
100 kΩ
100kΩ-100MΩ
1
10 kΩ
10kΩ-100kΩ
2
1 kΩ
1kΩ-10kΩ
3
100Ω
50Ω-1kΩ
4
30Ω
0Ω-50Ω
Table 4-2 The range in 30Ωsource resistance
No.
Range
Resistance
Effective
measurement
range
0
100 kΩ
100kΩ-100MΩ
1
10 kΩ
10kΩ-100kΩ
2
1 kΩ
1kΩ-10kΩ
3
100Ω
100Ω-1kΩ
4
30Ω
15Ω-100Ω
5
10Ω
0Ω-15Ω
4.2 Accuracy
The accuracy of │Z│，L，C，R，X
The accuracy of Ae about │Z│，L，C，R，X is expressed by the following formula:
Ae= ±[A+（Ka+Kb+Kf）×100+KL]×Kc[%]
A：Basic measurement accuracy (See Figure 4-1)
Ka：Impedance scaling factor (See table 4-4)，when using the impedance is less than 500
ohm .
Kb：Impedance scaling factor (See table 4-4)，when using the impedance is greater than
500 ohm.
Kc：Temperature factor (See table 4-5)
Kf：Calibrated interpolation factor（See table 4-6）
KL：Cable length factor（See table 4-7）
Be careful：According to the impedance size,it is only one valid about Kb and Ka, and
the other one is replaced by 0.
L, C, X accuracy conditions: Dx（Measured value of D）≤0.1
R accuracy conditions: Qx（Measured value of Q ）≤0.1
When Dx≥0.1，Ae of L，C，X: A
e= Ae*
2
1
x
D+
When Qx≥0.1，Ae of R : Ae= Ae*
2
1x Q+

MCR METER Manual
11
Accuracy of D
The accuracy of De about D is expressed by the following formula:
De=
100
e A
±
When Dx≤0.1, De= De
When Dx>0.1 ，De = De*(1+Dx)
Accuracy of Q
The accuracy of Qe about Q is expressed by the following formula：
Q
e=
ex
ex
DQ DQ ×
×
±
1
Here, Qx is the test value of Q.
De is the accuracy of D
It is effective,when Qx×De<1
Accuracy ofθ
The accuracy of θis expressed by the following formula：
θe =
100
180 eA
×
π
[deg]
Accuracy of RP
When Dx≤0.1, the accuracy of Rpis expressed by the following formula：
R
p=
ex
epx
DD DR

×
±
[Ω]
Here,R
px is the test value of Rp. [Ω]
Dxis the test value of D.
Deis the accuracy of D
Accuracy of RS
When Dx≤0.1, the accuracy of Rsis expressed by the following formula：
R
se = Xx×De[Ω]
Xx= 2πfLx=
x fC π 21
Here，Xxis the test value of X. [S]
Cxis the test value of C. [F]
Lxis the test value of L. [H]
Deis the accuracy of D，f is the test frequence.
Accuracy factor

MCR METER Manual
12
10m
100m
1
10
100
1k
10k
100k
1M
10M
100M
1.5
1.5M
[OHM][S]
10n
100n
1u
10u
100u
1m
10m
100m
1
10
100
|Y|,G,B |Z|,R,X
100Hz 1kHz 10kHz 100kHz
50Hz 200kHz
100mF
10mF
1mF
100uF
10uF
1uF
100nF
10nF
1nF
100pF
10pF 1pF 100fF 10fF
10nH
100nH
1uH
10uH
100uH
1mH
10mH
100mH
1H
10H
100H1kH10kH100kH
0.1
0.2
0.25
0.35
0.65
1.0
Figure 4-1 Basic measurement accuracy: A
Figure 4-1, in the junction line, can choose a smaller value. Figure 4-1, the value of the basic
accuracy A selection method
is as follows:
0.1（Smaller value）is the value of A ,when VS=1V and the test speed is MED or SLOW .
0.2（Larger value）is the value of A ,when Vs=1V and the test speed is FAST .
Test level correction factor: ArB（See table 4-3）, According to Figure 4-1 select the basic
accuracy A，A multiplied by Ar to get the level correction of the basic measurement accuracy.
Here, Vs is the test signal voltage.
Test signal voltage:
VS
Accuracy correction
factor: Ar
0.1V
2.5
0.3V
1.5
1V
1
Table 4-3 Basic accuracy level correction factor
Table 4-4 Impedance scaling factor :Ka、Kb

MCR METER Manual
13
spee
d frequency Ka（Zm < 500Ω）Kb（Zm > 500Ω）
MED,
SLO
W
fm<100Hz
)
100
1)(
200
1)(
101
(
3
msm
fVZ ++
×
−
)
100
1)(
70
1)(101( 9
ms
mfV Z++× −
100Hz
≤
fm
≤100kHz
)
200
1)(
101
(
3
sm
VZ +
×
−
)
70
1)(101(
9
s
m
V
Z+×
−
fm>100kH
z
)
200
2)(
101
(
3
sm
VZ +
×
−
)
70
1)(103(
9
s
m
V
Z+×
−
FAST
fm<100Hz
)
100
1)(
400
1)(
1 05.2
(
3
msm
fVZ ++
×
−
)
100
1)(
100
1)(102(
9
ms
m
fV
Z++×
−
100Hz≤fm
≤100kHz
)
400
1)(
1 05.2
(3
sm VZ +
×−
)
100
1)(102(
9
s
m
V
Z+×
−
fm
>
100kH
z
)
400
2)(
1 05.2
(
3
sm
VZ +
×
−
)
100
1)(106(
9
s
m
V
Z+×
−
Here，fm：Test frequency . [Hz]
Zm：Measured impedance. [Ω]
Vs：Test signal voltage .[mVrms]
Table 4-5 Temperature factor: Kc
Temperatur
e（℃）
5 8 18 28
38
K
c
6
4
2
1
2
4
Table 4-6 Calibrated interpolation factor : Kf
Test frequency
Kf
Typical frequency（Direct calibration）
0
Atypical frequency （Interpolation
calibration）
0.0003
Note:At present, all types of frequency point is the typical frequency.
Table 4-7 Cable length factor
Test signal level
Cable length
0m
1m
2m
0.1Vrms ,0.3Vrms
0
2.5
×
10-4(1+0.05fm) 5
×
10-4(1+0.05fm)
1Vrms 0 2.5
×
10-3(1+0.016fm) 5
×
10-3(1+0.05fm)
Here, FM is the test signal frequency. [kHz]
.
Chapter 5 HANDLER interface
5.1 HANDLER interface introduction
The interface is used to output the sorting result to the industrial control machine, so as to

MCR METER Manual
14
realize the automatic sorting test.
Table 5-1 Pin definition table for Handler interface
Pin
number
Signal
name
Described
1
2
3
10
11
/P1
/P2
/P3
/NG
/AUX
Sorting result output.
All signal with pull up resistor collector output. Up pull supply can
c
hoose the internal +5V power supply, or external power supply
EXTV (factory default).
The internal pull resistor is 4.7kΩ.
12,13
/EXT.TRIG
The rising edge of this signal triggers the instrument to measure.
The pulse width is more than 1μs, the low level of a driving current
is about 5-10mA.
16,17,18 +5V
Internal +5V power output:
Users generally do not recommend the use of internal power supply
equipment, if you have to use, please ensure that the use of the
current is less than 0.3A, and the signal line away from the source of
interference.
27,28 EXTV
An external DC power supply for sorting interface signals is
accessed from here.
If you want to use the internal +5V power
supply, need to change the jumper settings.
30 /IDX
/IDX valid after A/D conversion.
When the signal is valid, the automatic test machine is allowed to
move the next element to the position where it is to be measured.
However, the current measurement results have to wait until /EOM
is valid, then it is output.
31 /EOM
End Of Measurement：
When the measured data and the comparison results are valid, the
signal is valid.
34,35,36 COM
Reference to external power EXTV.
When the Handler interface output signal using the internal power
supply, the instrument's internal GND will be connecte
d with the
COM.

MCR METER Manual
15
Figure 5-1 Handler interface pin definition
Figure 5-2 Timing diagram of interface signal
Description:
Time
Minimum
value
Maximum value
T1 : Trigger pulse width
T2 : Measurement start delay time
T3 :Trigger wait time after /EOT output
1us
200us
0us
Display time + 200us
---

MCR METER Manual
16
Figure 5-3 Schematic diagram of Handler interface signal
When the internal power supply is used, the 1 and 2 of the J205 are connected; the 1
and the 2 of the J204 are connected.
When using an external power supply (factory default), the 2 and 3 of the J205 are
connected; the 2 and 3 of the J204 are connected.
Chapter 6 Operation example
6.1 Clear operation
One way to clear：（In this way, the instrument will clear all the frequency points）
Figure 6-1 Measurement display page
Step:
1. As shown above ,when the cursor is in <MEAS DISP> , the [Quick Clear] soft key will be
displayed .
2. Press [Quick Clear] soft key, “To make UNKNOWN short”will be displayed on the screen. At
this time, there are 3 regional soft options: [YES] ,[NO], [CANCEL].
3. Select [CANCEL], then quit the operation of SHORT;
Select "NO", skip the SHORT operation, and enter the fourth step；

MCR METER Manual
17
Select "YES", the instrument will enter a short circuit cleared process, if the short circuit failure,
will jump to the second step to re ask；Note: When performing SHORT operation, must
ensure that the test fixture is short.
4. “To make UNKNOWN open”is displayed on the screen.At this time, there are 3 regional soft
options: [YES] ,[NO], [CANCEL].
5. Select [CANCEL], then quit the operation of OPEN;
Select "NO", skip the OPEN operation, and enter the sixth step；
Select "YES", the instrument will enter a open circuit cleared process, if the open circuit failure,
will jump to the second step to re ask；Note: When performing OPEN operation, must
ensure that the test fixture is open.
6. Clear end.
Another way to clear：（In this way, the instrument will clear current frequency point）
Figure 6-2
1. Press [TOOL] key in <MEAS DISP> page or in <BIN DISP> page ,or in <MULTI PARA. DISP>
page, the [SINGLE SHORT] and [SINGLE OPEN] will displayed .
2. If you need SHORT operation, please make the test fixture short, and then select the [SINGLE
SHORT] softkey, the current test status will be short circuit cleared.
3. If you need OPEN operation, please make the test fixture open, and then select the [SINGLE
OPEN] softkey, the current test status will be open circuit cleared.
6.2 Set sorting
Figure 6-2 <BIN DISP> page
1. Press the "MEAS" button on the panel to enter the < MEAS DISP > page (as shown in Figure
6-1), and press "BIN DISP " softkey to enter < BIN DISP > page (as shown in Figure 6-2).
2. Move the cursor to the "NOMINAL", press the number keys and softkey to input the nominal
value of main parameter.
3. Move the cursor to the lower or upper limit of the BIN1~ BIN3, use digital keys and OK key
to enter the upper and lower limits.
4. Move the cursor to the lower or upper limit of 2nd ，press the number keys and softkey to
input the upper and lower limits of the second parameter.

MCR METER Manual
18
5. Move the cursor to "COMP", open the comparison switch.
Appendix: list of parameters of various models
Measurement function
MCR
test parameters | Z|, |Y|, C, L, X, B, R, G, D, Q, θ
Test frequency
MCR5010 ：100Hz,120Hz,1kHz,10kHz
MCR5030
：100Hz,120Hz,1kHz,10kHz，20kHz，30kHz
MCR5100
：50Hz,60Hz,100Hz,120Hz,1kHz,10kHz, 20kHz,40kHz，
50kHz,1000kHz
MCR5200
：40Hz、50Hz、60Hz、80Hz、100Hz、120Hz、150Hz、200Hz
、
250Hz、300Hz、400Hz、500Hz、600Hz、800Hz、1kHz
、
1.2kHz、1.5kHz、2kHz、2.5kHz、3kHz、4kHz、5kHz、6kHz
、
7.5kHz、10kHz、12kHz、15kHz、20kHz、25kHz、30kHz
、
40kHz、50kHz、60kHz、75kHz、100kHz、120kHz、150kHz
、
200kHz
Basic measurement
accuracy
0.1% (
MCR5010:0.15%)
equivalent circuit
In series, parallel
Mathematics function
Absolute deviation, Percentage deviation
Range mode
AUTO, HOLD, Manual selection
Trigger mode
INT, EXT
Speed
（≥1kHz）
FAST: less than 30 times per second,
MED : 10
times per second,
SLOW: 3 times per second,
Average number
1—255
Delay Time
0—6s, 1ms step
Calibration function
Quick Clear / SINGLE SHORT /SINGLE OPEN
Test terminal
Five terminals
Display mode
Direct display，Δ，Δ%，V/I
Monitor
5 bit resolution, 4.3 inch LCD display
test signal
Output impedance
30 Ω,100Ω
Test signal level
0.1V、0.3V、1V ; Accuracy：5%
Display range
|Z|, R, X
0.01m Ω— 99.999 MΩ
|Y|, G, B
0.0001µS — 99.999 S
C
0.0001 pF — 9.9999 F
L
0.0001 µH — 999.99 H
D
0.0001 — 9.9999
Q
0.0001 — 99999
θ(DEG)
-179.99º — 179.99 º
θ(RAD)
-3.14159 — 3.14159
Other
Multi parameter display
Five parameters can be selected to test and display at the same time
about MCR5200
Comparator function
Five BIN sorting function（BIN1,BIN2,BIN3,AUX,OUT）
storage
Internal: 105; external can save 500
Interface
Standard:RS232C,USB HOST,HANDLER（Except MCR5010 ）、
Optional:USB DEVICE，headphone jack，Foot switch interface ,GPIB

MCR METER Manual
19
