Matrix MTX-ROUTER GPRS User manual

MTX-Router Series
User Manual
Documentation No. Product Version Page
A
Product Name：
Router
Total:
MTX-ROUTER Series User Manual
The user manual is suitable for the following model:
Model Product Type
MTX-ROUTER GPRS GPRS ROUTER
MTX-ROUTER CDMA CDMA ROUTER
MTX-ROUTER 3G HSPA ROUTER
MTX-ROUTER 3G WIFI HSPA WIFI ROUTER
MTX-ROUTER LTE WIFI LTE/WCDMA WIFI ROUTER
Matrix Electroncia S.L
C/Alejandro Sánchez 109.
28019 Madrid. ESPAÑA - SPAIN
Teléfono/Phone: [phone]
Fax: [phone]
http://www.matrix.es

MTX-ROUTER User Manual
Matrix Electronica S.L Page 2 of 87
Add：Alejandro Sanchez 109, 28019 Madrid. ESPAÑA
http：//www.mtx-terminals.com Tel：[phone] Fax：+34+34-91.565.28.65

MTX-ROUTER User Manual
Matrix Electronica S.L Page 3 of 87
Add：Alejandro Sanchez 109, 28019 Madrid. ESPAÑA
http：//www.mtx-terminals.com Tel：[phone] Fax：+34+34-91.565.28.65
Files Revised Record
Date Version Remark Author
2012-09-16 V1.00 Initial Draft ZYL
2012-11-1 V1.01 Add Packet Filter PF

MTX-ROUTER User Manual
Matrix Electronica S.L Page 4 of 87
Add：Alejandro Sanchez 109, 28019 Madrid. ESPAÑA
http：//www.mtx-terminals.com Tel：[phone] Fax：+34+34-91.565.28.65
Copyright Notice
All contents in the files are protected by copyright law, and all copyrights are reserved by Matrix
Electrónica S.L. Without written permission, all commercial use of the files from Matrix are
forbidden, such as copy, distribute, reproduce the files, etc., but non-commercial purpose,
downloaded or printed by individual (all files shall be not revised, and the copyright and other
proprietorship notice shall be reserved) are welcome.
Trademark Notice
MTX-ROUTER, MTX TERMINALS are all registered trademarks of Matrix Electrónica., illegal
use of the name of MTX-ROUTER, trademarks and other marks of Matrix is forbidden, unless
written permission is authorized in advance.

MTX-ROUTER User Manual
Matrix Electronica S.L Page 5 of 87
Add：Alejandro Sanchez 109, 28019 Madrid. ESPAÑA
http：//www.mtx-terminals.com Tel：[phone] Fax：+34+34-91.565.28.65

MTX-ROUTER User Manual
Matrix Electronica S.L Page 6 of 87
Add：Alejandro Sanchez 109, 28019 Madrid. ESPAÑA
http：//www.mtx-terminals.com Tel：[phone] Fax：+34+34-91.565.28.65
C
Co on nt te en nt ts s
Chapter 1 Brief Introduction of Product ...........................................................................................8
1.1 General.............................................................................................................................8
1.2 Features and Benefits.......................................................................................................8
1.3 Working Principle..........................................................................................................10
1.4 Specifications.................................................................................................................10
Chapter 2 Installation Introduction .................................................................................................13
2.1 General...........................................................................................................................13
2.2 Encasement List.............................................................................................................13
2.3 Installation and Cable Connection.................................................................................13
2.4 Power.............................................................................................................................15
2.5 Indicator Lights Introduction.........................................................................................15
2.6 Reset Button Introduction..............................................................................................16
Chapter 3 Configuration and Management.....................................................................................16
3.1 Configuration Connection..............................................................................................17
3.2 Access the Configuration Web Page..............................................................................17
3.3 Management and configuration .....................................................................................19
3.3.1 Setting...........................................................................................................19
3.3.1.1 Basic Setting............................................................................................19
3.3.1.2 Dynamic DNS.........................................................................................24
3.3.1.3 Clone MAC Address ...............................................................................25
3.3.1.4 Advanced Router.....................................................................................25
3.3.1.5 Networking..............................................................................................26
3.3.2 Wireless.........................................................................................................29
3.3.2.1 Basic Settings..........................................................................................29
3.3.2.2 Wireless Security.....................................................................................31
3.3.2.3 Wireless MAC Filter ...............................................................................34
3.3.2.4 Advance Settings.....................................................................................35
3.3.2.5 WDS........................................................................................................39
3.3.3 Services.........................................................................................................41
3.3.3.1 Services...................................................................................................41
3.3.3.2 PPPoE Server..........................................................................................44
3.3.4 VPN...................................................................................................................46
3.3.4.1 PPTP........................................................................................................46
3.3.4.2 L2TP........................................................................................................47
3.3.4.3 OPENVPN ..............................................................................................48
3.3.4.4 IPSEC......................................................................................................53
3.3.4.5 GRE.........................................................................................................55
3.3.5 Security.........................................................................................................56
3.3.5.1 Firewall ...................................................................................................56
3.3.5.2 VPN Passthrough....................................................................................59

MTX-ROUTER User Manual
Matrix Electronica S.L Page 7 of 87
Add：Alejandro Sanchez 109, 28019 Madrid. ESPAÑA
http：//www.mtx-terminals.com Tel：[phone] Fax：+34+34-91.565.28.65
3.3.6 Access Restrictions...................................................................................60
3.3.6.1 WAN Access............................................................................................60
3.3.6.2 Packet Filter ............................................................................................62
3.3.7 NAT...................................................................................................................63
3.3.7.1 Port Forwarding ......................................................................................63
3.3.7.2 Port Range Forward ................................................................................64
3.3.7.3 Port Triggering........................................................................................64
3.3.7.4 DMZ........................................................................................................65
3.3.8 QoS Setting...................................................................................................66
3.3.8.1 Basic........................................................................................................66
3.3.8.2 Classify....................................................................................................66
3.3.9 Applications.................................................................................................67
3.3.9.1 Serial Applications ..................................................................................67
3.3.10 Administration.....................................................................................68
3.3.10.1 Management....................................................................................68
3.3.10.2 Keep Alive.......................................................................................70
3.3.10.3 Commands.......................................................................................71
3.3.10.4 Factory Defaults..............................................................................71
3.3.10.5 Firmware Upgrade...........................................................................72
3.3.10.6 Backup.............................................................................................72
3.3.11 Status.....................................................................................................73
3.3.11.1 Router..............................................................................................73
3.3.11.2 WAN................................................................................................75
3.3.11.3 LAN.................................................................................................77
3.3.11.4 Wireless...........................................................................................80
3.3.11.5 Bandwidth.......................................................................................81
3.3.11.6 Sys-Info...........................................................................................83
Chapter 4 Appendix ........................................................................................................................86

MTX-ROUTER User Manual
Matrix Electronica S.L Page 8 of 87
Add：Alejandro Sanchez 109, 28019 Madrid. ESPAÑA
http：//www.mtx-terminals.com Tel：[phone] Fax：+34+34-91.565.28.65
Chapter 1 Brief Introduction of Product
1.1 General
MTX-ROUTER series is a kind of cellular terminal device that provides data transfer
function by public cellular network.
It adopts high-powered industrial 32-bits CPU and embedded real time operating system. It
supports RS232 (or RS485/RS422), Ethernet and WIFI port that can conveniently and
transparently connect one device to a cellular network, allowing you to connect to your existing
serial, Ethernet and WIFI devices with only basic configuration.
It has been widely used on M2M fields, such as intelligent transportation, smart grid,
industrial automation, telemetry, finance, POS, water supply, environment protection, post,
weather, and so on.
1.2 Features and Benefits
Design for IndustrialApplication
High-powered industrial cellular module
High-powered industrial 32bits CPU
Support low-consumption mode, including sleep mode, scheduled online/offline mode,
scheduled power-on/power-off mode(optional)
Housing: iron, providing IP30 protection.
Power range: DC 5~35V
Stability and Reliability
Support hardware and software WDT
Support auto recovery mechanism, including online detect, auto redial when offline to make
router always online
Ethernet port: 1.5KV magnetic isolation protection
RS232/RS485/RS422 port: 15KV ESD protection
SIM/UIM port: 15KV ESD protection
Power port: reverse-voltage and overvoltage protection

MTX-ROUTER User Manual
Matrix Electronica S.L Page 9 of 87
Add：Alejandro Sanchez 109, 28019 Madrid. ESPAÑA
http：//www.mtx-terminals.com Tel：[phone] Fax：+34+34-91.565.28.65
Antenna port: lightning protection(optional)
Standard and Convenience
Support standard RS232(or RS485/RS422), Ethernet and WIFI port that can connect to serial,
Ethernet and WIFI devices directly
Support intellectual mode, enter into communication state automatically when powered
Provide management software for remote management
Support several work modes
Convenient configuration and maintenance interface（WEB or CLI）
High-performance
Support 3G/HSPA/4G WAN access methods.
Support VPN client(PPTP, L2TP, OPENVPN, IPSEC and GRE)(only for VPN version)
Support VPN server(PPTP, L2TP, OPENVPN, IPSEC and GRE)(only for VPN version)
Support local and remote firmware upgrade,import and export configure file.
Support NTP, RTC embedded.
Support mulitiple DDNS provider service.
Support MAC Address clone, PPPoE Server
WIFI support 802.11b/g/n. support AP, client, Adhoc, Repeater, Repeater Bridge and
WDS(optional) mode.
WIFI support WEP,WPA,WPA2 encryption,Support RADIUS authentication and MAC
address filter.
Support multi online trigger ways, including SMS, ring and data. Support link disconnection
when timeout
SupportAPN/VPDN
Support DHCP server and client, firewall, NAT, DMZ host , URL block, QoS, ttraff,statistics,
real time link speed statistics etc.
Full protocol support , such as TCP/IP, UDP, ICMP, SMTP, HTTP, POP3, OICQ, TELNET,
FTP, SNMP, SSHD, etc.
Schedule Reboot, Schedule Online and Offline,etc.

MTX-ROUTER User Manual
Matrix Electronica S.L Page 10 of 87
Add：Alejandro Sanchez 109, 28019 Madrid. ESPAÑA
http：//www.mtx-terminals.com Tel：[phone] Fax：+34+34-91.565.28.65
1.3 Working Principle
The principle chart of the router is as following:
1.4 Specifications
Cellular Specification
Standard and Band Bandwidth TX power RX
sensitivity
MTX-ROUTER GPRS ROUTER
EGSM900/GSM1800MHz,
GSM850/900/1800/1900MHz
(optional)
Compliant to GSM phase 2/2+
GPRS class 10, class 12(optional)
85.6Kbps GSM850/900：
<33dBm
GSM1800/1900：
<30dBm
<-107
dBm
MTX-ROUTER CDMA
CDMA2000 1xRTT 800MHz
800/1900MHz(optional)
450MHz(optional)
153.6Kbps
<30dBm <-104
dBm
MTX- ROUTER 3G
UMTS/WCDMA/HSDPA/HSUPA
/HSPA+ 850/1900/2100MHz
850/900/1900/2100MHz(optional)
GSM850/900/1800/1900MHz
GPRS/EDGE CLASS 12
HSUPA:5.76Mbps
(Upload speed)
HSDPA:7.2Mbps
(Download speed)
UMTS:384Kbps (DL/UL)
HSPA+:
21 Mbps
<24dBm <-109
dBm
Embedded processing
system
Cellular Module
Power
RS232 serial
Interface
Indicator lights
DATA Interface
User interface
10/100M Ethernet
Interface
WIFI

MTX-ROUTER User Manual
Matrix Electronica S.L Page 11 of 87
Add：Alejandro Sanchez 109, 28019 Madrid. ESPAÑA
http：//www.mtx-terminals.com Tel：[phone] Fax：+34+34-91.565.28.65
(Download speed)
5.76Mbps（Upload speed）
MTX- ROUTER LTE WIFI
LTE FDD
2600/2100/1800/900/800MHz,
700/1700/2100MHz(optional)
HSPA+/HSDPA/HSUPA/WCDM
A /UMTS900/2100MHz,
800/850/1900/2100MHz(optional)
EDGE/GPRS/GSM
900/1800/1900MHz
GPRS CLASS 10
GPRS CLASS 12
LTE(DL:100Mbps,UL
:50Mbps)
HSUPA:5.76Mbps(Up
load speed)
HSDPA:7.2Mbps(Do
wnload speed)
UMTS:384Kbps
(DL/UL)
HSPA+:
21Mbps(Download
speed)
5.76Mbps(Upload
speed)
<32dBm <-93.3dBm
WIFI Specification
Item Content
Standard IEEE802.11b/g/n
Bandwidth IEEE802.11b/g: 54Mbps (max)
IEEE802.11n: 150Mbps (max)
Security WEP, WPA, WPA2, etc.
WPS (optional)
TX power 21.5dBm（11g）， 26dBm（11b）
RX sensitivity <-72dBm@54Mpbs
Hardware System
Item Content
CPU Industrial 32bits CPU
FLASH 8MB(Extendable to 16MB)
RAM 64MB
Interface Type
Item Content
Ethernet 1 10/100 Mbps Ethernet port(RJ45), auto MDI/MDIX, 1.5KV magnetic
isolation protection
Serial 1 RS232(or RS485/RS422) port, 15KV ESD protection
Data bits: 5, 6 ,7, 8
Stop bits: 1, 1.5(optional), 2
Parity: none, even, odd, (space, mark) (optional)
Baud rate: 2400~115200 bps

MTX-ROUTER User Manual
Matrix Electronica S.L Page 12 of 87
Add：Alejandro Sanchez 109, 28019 Madrid. ESPAÑA
http：//www.mtx-terminals.com Tel：[phone] Fax：+34+34-91.565.28.65
Indicator "Power", "System", "Online", "Link/ACT ", "WIFI","Signal Strength"
Antenna Cellular: Standard SMA female interface, 50 ohm, lighting
protection(optional)
WIFI: Standard SMA male interface, 50 ohm, lighting
protection(optional)
SIM/UIM Standard 3V/1.8V user card interface, 15KV ESD protection
Power Standard 3-PIN power jack, reverse-voltage and overvoltage protection
Reset Restore the router to its original factory default settings
Power Input
Item Content
Standard Power DC 12V/1.5A
Power Range DC 5~35V
Consumption <450mA (12V)
Physical Characteristics
Item Content
Housing Iron, providing IP30 protection
Dimensions 157x97x25 mm
Weight 440g
Environmental Limits
Item Content
Operating
Temperature -35~+75ºC（-31~+167℉）
Storage
Temperature
-40~+85ºC（-40~+185℉）
Operating
Humidity
95% ( Non-condensing)

MTX-ROUTER User Manual
Matrix Electronica S.L Page 13 of 87
Add：Alejandro Sanchez 109, 28019 Madrid. ESPAÑA
http：//www.mtx-terminals.com Tel：[phone] Fax：+34+34-91.565.28.65
Chapter 2 Installation Introduction
2.1 General
The router must be installed correctly to make it work properly.
Warning: Forbid to install the router when powered!
2.2 Encasement List
Name Quantity Remark
Router host 1
Cellular antenna (Male SMA) 1
WIFI antenna (Female SMA) 1
Network cable 1
Console cable 1 optional
Power adapter 1
Manual CD 1
Certification card 1
Maintenance card 1
2.3 Installation and Cable Connection
Installation of SIM/UIM card:

MTX-ROUTER User Manual
Matrix Electronica S.L Page 14 of 87
Add：Alejandro Sanchez 109, 28019 Madrid. ESPAÑA
http：//www.mtx-terminals.com Tel：[phone] Fax：+34+34-91.565.28.65
Firstly power off the router, and press the out button of the SIM/UIM card outlet with a needle
object. Then the SIM/UIM card sheath will flick out at once. Put SIM/UIM card into the card
sheath (Pay attention to put the side which has metal point outside), and insert card sheath back to
the SIM/UIM card outlet.
Warning: Forbid to install SIM/UIM card when powered!
Installation of antenna:
Screw the SMA male pin of the cellular antenna to the female SMA interface of the router
with sign “WWAN”.
Screw the SMA female pin of the WIFI antenna to the male SMA interface of the router with
sign “WIFI”.
Warning: The cellular antenna and the WIFI antenna can not be connected wrongly. And the
antennas must be screwed tightly, or the signal quality of antenna will be influenced!
Installation of cable:
Insert one end of the network cable into the switch interface with sign “Local Network”, and
insert the other end into the Ethernet interface of user’s device. The signal connection of network
direct cable is as follows:
RJ45-1 RJ45-2
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
Insert the RJ45 end of the console cable into the RJ45 outlet with sign “console”, and insert
the DB9F end of the console cable into the RS232 serial interface of user’s device.
The signal connection of the console cable is as follows:
RJ45 DB9F
1 8
2 6
3 2
4 1
5 5
6 3
7 4
8 7
The signal definition of the DB9F serial communication interface is as follows:
Pin RS232 signal name The direction for Router

MTX-ROUTER User Manual
Matrix Electronica S.L Page 15 of 87
Add：Alejandro Sanchez 109, 28019 Madrid. ESPAÑA
http：//www.mtx-terminals.com Tel：[phone] Fax：+34+34-91.565.28.65
2.4 Power
The power range of the router is DC 5~35V.
Warning: When we use other power, we should make sure that the power can supply power
above 7W.
We recommend user to use the standard DC 12V/1.5A power.
2.5 Indicator Lights Introduction
The router provides following indicator lights: “Power”, “System”, “Online”,
“Link/ACT”,“WIFI”, “Signal Strength”.
Indicator
Light
State Introduction
Power ON Router is powered on
OFF Router is powered off
System BLINK System works properly
OFF System does not work
Online ON Router has logged on network
OFF Router hasn’t logged on network
Link/ACT OFF The corresponding interface of switch is not
connected
ON /
BLINK
The corresponding interface of switch is connected
/Communicating
WIFI OFF WIFI is not active
ON WIFI is active
Signal
Strength
One Light
ON Signal strength is weak
Two Lights
ON Signal strength is medium
1 DCD output
2 RXD output
3 TXD input
4 DTR input
5 GND
6 DSR output
7 RTS input
8 CTS output

MTX-ROUTER User Manual
Matrix Electronica S.L Page 16 of 87
Add：Alejandro Sanchez 109, 28019 Madrid. ESPAÑA
http：//www.mtx-terminals.com Tel：[phone] Fax：+34+34-91.565.28.65
Three
Lights ON Signal strength is good
2.6 Reset Button Introduction
The router has a “Reset” button to restore it to its original factory default settings. When user
press the “Reset” button for up to 15s, the router will restore to its original factory default settings
and restart automatically.
Chapter 3 Configuration and Management
This chapter describes how to configure and manage the router.

MTX-ROUTER User Manual
Matrix Electronica S.L Page 17 of 87
Add：Alejandro Sanchez 109, 28019 Madrid. ESPAÑA
http：//www.mtx-terminals.com Tel：[phone] Fax：+34+34-91.565.28.65
3.1 Configuration Connection
Before configuration, you should connect the router and your configuration PC with the
supplied network cable. Plug the cable’s one end into the Local Network port of the router, and
another end into your configure PC’s Ethernet port. The connection diagram is as following:
Please modify the IP address of PC as the same network segment address of the router, for
instance, 192.168.1.9. Modify the mask code of PC as 255.255.255.0 and set the default gateway
of PC as the router’s IP address (192.168.1.2).
3.2 Access the Configuration Web Page
The chapter is to present main functions of each page. Users visit page tool via web browser
after connect users' PC to the router. There are eleven main pages: Setting, Wireless, Service, VPN,
Security, Access Restrictions, NAT, QoS Setting, Applications, Management and Status. Users
enable to browse slave pages by click one main page.
Users can open IE or other explorers and enter the router's default IP address of 192.168.1.2
on address bar, then press the botton of Enter to visit page Web management tool of the router.
The users login in the web page at the first name, there will display a page shows as blow to tip
users to modify the default user name and password of the router. Users have to click "change
password" to make it work if they modify user name and password.

MTX-ROUTER User Manual
Matrix Electronica S.L Page 18 of 87
Add：Alejandro Sanchez 109, 28019 Madrid. ESPAÑA
http：//www.mtx-terminals.com Tel：[phone] Fax：+34+34-91.565.28.65
After access to the information main page
Users need to input user name and password if it is their first time to login.

MTX-ROUTER User Manual
Matrix Electronica S.L Page 19 of 87
Add：Alejandro Sanchez 109, 28019 Madrid. ESPAÑA
http：//www.mtx-terminals.com Tel：[phone] Fax：+34+34-91.565.28.65
Input correct user name and password to visit relevant menu page. Default user name is admin,
password is admin. (available to modify user name and password on management page, then click
submit)
3.3 Management and configuration
3.3.1 Setting
The Setup screen is the first screen users will see when accessing the router. Most users will be
able to configure the router and get it work properly using only the settings on this screen. Some
Internet Service Providers (ISPs) will require users to enter specific information, such as User
Name, Password, IP Address, Default Gateway Address, or DNS IP Address. These information
can be obtained from your ISP, if required.
3.3.1.1 Basic Setting
WAN Connection Type
Seven Ways: Disabled, 3G/UNMTS/4G/LTE
Disabled

MTX-ROUTER User Manual
Matrix Electronica S.L Page 20 of 87
Add：Alejandro Sanchez 109, 28019 Madrid. ESPAÑA
http：//www.mtx-terminals.com Tel：[phone] Fax：+34+34-91.565.28.65
Forbid the setting of WAN port connection type
3G/UMTS/4G/LTE
User Name: login users' ISP(Internet Service Provider)
Password: login users' ISP
Dial String: dial number of users' ISP
APN: access point name of users' ISP
PIN: PIN code of users' SIM card
Connection type
Connection type: Auto, Force 3G, Force 2G, Prefer 3G, Prefer 2G options. If using 4G module,
there has 4G network option. Users select different mode depending on their need
Keep Online
This function is used to detect whether the Internet connection is active, if users set it and when
the router detect the connection is inactive, it will redial to users' ISP immediately to make the
connection active.
Detection Method:
None: do not set this function
Ping: Send ping packet to detect the connection, when choose this method, users should also
configure "Detection Interval", "Primary Detection Server IP" and "Backup Detection
Server IP" items.
Route: Detect connection with route method, when choose this method, users should also
configure "Detection Interval", "Primary Detection Server IP" and "Backup Detection
Server IP" items.
PPP: Detect connection with PPP method, when choose this method, users should also
