Matrix UV Series User manual

azonprinter.com MATRIX GETTING STARTED

To ensure correct and safe usage with a full understanding of this product’s performance please be sure to read through this
manual completely and store it in a safe location
Unauthorized copying or transferal in whole or in part of this manual is prohibited
The contents of this operation manual and the specifications of this product are subject to
change without notice
The operation manual and the product have been prepared and tested as much as possible if you find any misprint or error
please inform us
Azonprinter d.o.o. assumes no responsibility for any direct or indirect loss or damage which may occur through use of this
product regardless of any failure to perform on the part of this product
Azonprinter d.o.o. assumes no responsibility for any direct or indirect loss or damage which may occur with respect to any
article made using this product
ABOUT MANUAL
azonprinter.com MATRIX GETTING STARTED

NAVIGATION
ABOUT MANUAL
PAGE 2
ABOUT PRINTER
PAGE 4
GENERAL INFORMATION
[ MATRIX 1206/Cubjet/Monsterjet ]
PAGE 5
GENERAL INFORMATION
[ MATRIX 1806/Cubjet/Monsterjet ]
PAGE 6
GENERAL INFORMATION
[ MATRIX 1211/2511/Cubjet/Monsterjet ]
PAGE 7
PRINT SPEED
PAGE 8
S
AFETY FEATURES & REGULATORY COMPLIANCE
PAGE 10
SITE PREPARATION GUIDE [ MATRIX
1206/Cubjet/Monsterjet ]
PAGE 11
SITE PREPARATION GUIDE [ MATRIX
1806/Cubjet/Monsterjet ]
PAGE 12
SITE PREPARATION GUIDE [ MATRIX
1211/2511/Cubjet/Monsterjet ]
PAGE 13
SITE PREPARATION GUIDE [ ALL ]
PAGE 14
IN THE BOX.... [
ALL ]
PAGE 18
GETTING TO KNOW YOUR PRINTER [ ALL ]
PAGE 21
LCD TOUCH DISPLAY [ ALL ]
PAGE 25
PRINTER CONTROL PANEL
PAGE 30
PRINTER CONTROL PANEL INDICATOR
PAGE 31
INK
PAGE 32
INK BOTTLE LABEL
PAGE 33
SETTING UP YOUR PRINTER
PAGE 34
POWER ON PROCEDURE
PAGE 51
POWER
OFF PROCEDURE
PAGE 53
azonprinter.com MATRIX GETTING STARTED
VACUUM PUMP INSTALATION PAGE 55

AZON MATRIX represents only wide-format UV-
curable inkjet flatbed printer on the market with
the ability to print up to 930mm (36,61in) in
height. With optional S, M and L bed sizes; 700
mm x 1900 mm (27,55 x 74,80in) / 700 mm x 2500
mm (27,55 x 98,42in)/ 1200 mm x 1900 mm (47,24
x 74,80in) / 1200 mm x 3300 mm (47,24 x 129,92in)
which are handling heavy materials up to 100 kg
for indoor, outdoor and industrial applications.
Prints directly onto any type of material like PET,
ABS, polycarbonate, TPU, wood, stone, glass,
canvas, ceramic, aluminum, and leather. Azon
MATRIX represents an ideal solution for gaining
profit from lower running costs. Capable of
robust industrial printing demands including
heavy, rigid materials and high-quality volume
printing requirements (USB drives, smartphone
cases, lighters, pens etc.) Azon MATRIX is
covering a wide variety of business printing
applications. With long-lasting, highly energy-
efficient UV LED lamp curing system instantly and
efficiently adheres ink to any kind of substrates.
Its robust bed, smart vacuum table, Full-featured
Azon RIP software and UV TurboJet ink
technology ensure a perfect result on each and
every print.
ABOUT PRINTER
azonprinter.com MATRIX GETTING STARTED

GENERAL INFORMATION
M A T R I X
1 2 0 6 / 1 2 0 6 C u b e j e t / 1 2 0 6 M o n s t e r j e t
Maximum print size Maximum substrate width 570mm(22,44in)
Maximum substrate length 1200 mm(47,24in)
Maximum substrate height 200mm (7,87in) Matrix1206, 400mm (15,74in) Cubjet1206, 930mm(36,61in)
Monsterjet1206
Print Piezzo inkjet [8 channels 180 nozzles each]
Resolution Adjustable from 720x720 up to 2880x1440 dpi
Ink configuration CMYK+WWCLCL, CMYK+WWWW, Optional
Ink System Bottles system 500ml [refillable]
Ink curing UV-LED adjustable output
Software Azon RIP software
OS Windows 10
Connection Ethernet
Power AC 100/230 V 50-60Hz
Printer size Width 1330 mm (52,36in)
Length 2120 mm (83,46in)
Height 1120 -1750 mm(44,09-68,89in)
Weight 350 - 450kg
azonprinter.com MATRIX GETTING STARTED

GENERAL INFORMATION
M A T R I X
1 8 0 6 / 1 8 0 6 C u b e j e t / 1 8 0 6 M o n s t e r j e t
Maximum print size Maximum substrate width 570mm (22,44in)
Maximum substrate length 1800 mm (70,86in)
Maximum substrate height 200mm (7,87in) Matrix1806, 400mm (15,74in) Cubjet1806, 930mm (36,61in)
Monsterjet1806
Print Piezzo inkjet [8 channels 180 nozzles each]
Resolution Adjustable from 720x720 up to 2880x1440 dpi
Ink configuration CMYK+WWCLCL, CMYK+WWWW, Optional
Ink System Bottles system 500ml [refillable]
Ink curing UV-LED adjustable output
Software Azon RIP software
OS Windows 10
Connection Ethernet
Power AC 100/230 V 50-60Hz
Printer size Width 1330 mm (52,36in)
Length 2720 mm (107,08in)
Height 1120 –1750 mm (44,09-68,89in)
Weight 450 –550 kg
azonprinter.com MATRIX GETTING STARTED

GENERAL INFORMATION
M A T R I X
UV 1211/2511, CUBEJET 1211/2511 MONSTERJET 1211/ 2511
Maximum print size Maximum substrate width 1070 mm (42,12in)
Maximum substrate length 1200 mm(47,24in) for 1211, 2450 mm (96,45in) for 2511
Maximum substrate height 200mm (7,87in) Matrix1211/2511, 400mm (15,74in) Cubjet1211/2511, 930mm
(36,61in) Monsterjet1211/2511
Print Piezzo inkjet [8 channels 180 nozzles each]
Resolution Adjustable from 720x720 up to 2880x1440 dpi
Ink configuration CMYK+WWCLCL, CMYK+WWWW, Optional
Ink System Bottles system 500ml [refillable]
Ink curing UV-LED adjustable output
Software Azon RIP software
OS Windows 10
Connection Ethernet
Power AC 100/230 V 50-60Hz
Printer size Width 1860 mm (73,22in)
Length 2200mm / 3200 mm (86,61 –125,98in)
Height 1120 -1750 mm (44,09 - 68,89in)
Weight 400 kg / 710 kg
azonprinter.com MATRIX GETTING STARTED

UNIDIRECTIONAL
NAME RESOLUTION DIRECTION LAYER TYPE SUBSTRATE TIME
[min/sec] m2/h Ink
FAST 720x360
Unidirectional Color Layer Generic 8:00 4,7 3,36ml
Unidirectional White Layer Generic Not
Supported N/A N/A
Unidirectional White+Color
Inline Generic Not
Supported N/A N/A
SPEED 720x720
Unidirectional Color Layer Generic 20:40 2,3 5,72ml
Unidirectional White Layer Generic 20:40 2,3 1,68ml
Unidirectional White+Color
Inline Generic 26:50 1,8 7,36ml
STANDARD 1440x720
Unidirectional Color Layer Generic 30:10 1,7 7,51ml
Unidirectional White Layer Generic 30:10 1,7 3,36ml
Unidirectional White+Color
Inline Generic 60:10 1 10,83ml
QUALITY 1440x1440
Unidirectional Color Layer Generic 58:10 1 10,23ml
Unidirectional White Layer Generic 58:10 1 6,71ml
Unidirectional White+Color
Inline Generic 130:04 0,5 16,87ml
HIGH
QUALITY 2880x1440
Unidirectional Color Layer Generic 59:10 1 16,58ml
Unidirectional White Layer Generic 59:10 1 13,42ml
PRINT
SPEED
MATRIX UV SERIES
Data was taken when printing maximum print area 580 mm X 1200 mm (22,83 x 47,24in)
Ink consumption is calculated by printing 580 mm x 1200mm (22,83 x 47,24in) black square [RGB]
azonprinter.com MATRIX GETTING STARTED

BIDIRECTIONAL
PRINT
SPEED
NAME RESOLUTION DIRECTION LAYER TYPE SUBSTRATE TIME
[min/sec] m2/h Ink
FAST 720x360
Bidirectional Color Layer Generic 05:10 7,1 3,36ml
Bidirectional White Layer Generic Not
Supported N/A N/A
Bidirectional White+Color
Inline Generic Not
Supported N/A N/A
SPEED 720x720
Bidirectional Color Layer Generic 12:20 3,8 5,72ml
Bidirectional White Layer Generic 12:20 3,8 1,68ml
Bidirectional White+Color
Inline Generic 16:20 2,8 7,36ml
STANDARD 1440x720
Bidirectional Color Layer Generic 17:50 2,5 7,51ml
Bidirectional White Layer Generic 17:50 2,5 3,36ml
Bidirectional White+Color
Inline Generic 35:00 1,5 10,83ml
QUALITY 1440x1440
Bidirectional Color Layer Generic 32:10 1,45 10,23ml
Bidirectional White Layer Generic 32:10 1,45 6,71ml
Bidirectional White+Color
Inline Generic 90:50 0,6 16,87ml
HIGH
QUALITY 2880x1440
Bidirectional Color Layer Generic 32:10 1,45 16,58ml
Bidirectional White Layer Generic 32:10 1,45 13,42ml
azonprinter.com MATRIX GETTING STARTED
MATRIX UV SERIES
Data was taken when printing maximum print area 580 mm X 1200 mm (22,83 x 47,24in)
Ink consumption is calculated by printing 580 mm x 1200mm (22,83 x 47,24in) black square [RGB]

Keep all inks, cleaners and primers out of reach of children
Use promoters in a well-ventilated area
Store inks in a cool dark and dry location
Dispose of all expired and uncured inks in accordance to
local and state laws
All UV inks have a shelf life expiration dates are specified on
each ink cartridge and must be disposed of properly after
expiration
Always wear provided safety glasses and nitrile gloves
whenever there is the possibility of exposure to uncured inks
SAFETY FEATURES & REGULATORY COMPLIANCE
Keep your printer out of direct sunlight which will interfere
with performance of the printer and the UV inks
Always keep the protective UV lid down during operation UV
light can be harmful with direct exposure to skin and eyes
Do not touch the print table or print head while the
printer is in use
Keep hair jewelry and loose clothing away from moving parts
Do not attempt to repair your printer unless the guide
specifically says to do so
Only certified Azon service technicians should disassemble
repair or access internal components
When performing maintenance always unplug the power
cord from the electrical outlet
Only use Azon UV Inks and cleaners with your printer
azonprinter.com MATRIX GETTING STARTED

Printer must be installed in an area large enough to
allow for normal operation of the printer. [minimum
1000 mm / 40in from each side of the printer]
After unpacking printer can be pushed to its
final destination , once set make sure wheels
are disabled in order to get best balance
possible. Additional balancing can be done
by rotating red wheel on each foot.
[ 6 of them in total ]
Red wheel for lowering fix foot
Wheel used for moving printer
Fixed foot [can be moved up/down for
balance ]
SITE PREPARATION GUIDE
SITE PREPARATION GUIDE
M A T R I X U V 1 2 0 6 / 1 2 0 6 C u b e j e t / 1 2 0 6 M o n s t e r j e t
Printer is shipped in wooden crate. Due to the delicate nature of the equipment, it is essential that you have the proper equipment
available for handling and moving the shipping crates. Before opening them, you should check the condition of the box. If it is
damaged, you should immediately inform us. All equipment must be uncrated by a qualified service engineer.
Printer with transport box Only Printer
Width 1500mm(59,05in) Width 1330mm(52,36in)
Length 2470mm(97,24in) Length2120mm(83,46in)
Height 1410-2040 mm
(55,51-80,31in)
Height 1120-1750 mm
(44,09-68,89in)
Weight: 600-700 kg Weight 350-450 kg
azonprinter.com MATRIX GETTING STARTED

Printer must be installed in an area large enough to
allow for normal operation of the printer. [minimum
1000 mm from each side of the printer]
After unpacking printer can be pushed to its
final destination , once set make sure wheels
are disabled in order to get best balance
possible. Additional balancing can be done
by rotating red wheel on each foot.
[ 6 of them in total ]
Red wheel for lowering fix foot
Wheel used for moving printer
Fixed foot [can be moved up/down for
balance ]
SITE PREPARATION GUIDE
SITE PREPARATION GUIDE
M A T R I X U V 1 8 0 6 / 1 8 0 6 C u b e j e t / 1 8 0 6 M o n s t e r j e t
Printer is shipped in wooden crate. Due to the delicate nature of the equipment, it is essential that you have the proper equipment
available for handling and moving the shipping crates. Before opening them, you should check the condition of the box. If it is
damaged, you should immediately inform us. All equipment must be uncrated by a qualified service engineer.
Printer with transport box Only Printer
Width 1500mm(59,05in) Width 1330mm(52,36in)
Length 3000mm(118,11in) Length2850mm(112,20in)
Height 1410-2040 mm
(55,51-80,31in)
Height 1120-1750 mm
(44,09-68,89in)
Weight: 700-800 kg Weight 450-550 kg
azonprinter.com MATRIX GETTING STARTED

Printer must be installed in an area large enough to
allow for normal operation of the printer. [minimum
1000 mm from each side of the printer]
After unpacking printer can be pushed to its
final destination , once set make sure wheels
are disabled in order to get best balance
possible. Additional balancing can be done
by rotating red wheel on each foot.
[ 6 of them in total ]
Red wheel for lowering fix foot
Wheel used for moving printer
Fixed foot [can be moved up/down for
balance ]
SITE PREPARATION GUIDE
SITE PREPARATION GUIDE
M A T R I X U V 1211/2511, CUBEJET 1211/2511, MONSTERJET 1211/ 2511
Printer is shipped in wooden crate. Due to the delicate nature of the equipment, it is essential that you have the proper equipment
available for handling and moving the shipping crates. Before opening them, you should check the condition of the box. If it is
damaged, you should immediately inform us. All equipment must be uncrated by a qualified service engineer.
Printer with transport box Only Printer
Width 1600mm(62,99in) Width 1860mm(73,22in)
Length 2600 mm(102,36in) Length 2200mm(86,61in)
/ 3500mm(137,79in)
Height 1410-2040 mm
(55,51-80,31in)
Height 1120-1750 mm
(44,09-68,89in)
Weight: 900-1100 kg Weight 400 kg /710 kg
azonprinter.com MATRIX GETTING STARTED

YOUR PRINTER IS DESIGNED TO OPERATE IN THE FOLLOWING ATMOSPHERIC CONDITIONS;
Working condition Shut-down conditions
[max shut down 1 month]
Storage condition
[without ink in system]
Temperature: 20-30 degrees Celsius 10-30 degrees Celsius 5-35 degrees Celsius
Humidity: 45-80% 45-80% 10-40%
The printer emit low levels of fumes and odor. If desired, customers may prepare a solvent-resistant, fire-resistant exhaust fan capable of
expelling air from the printer to the outside of the building, as well as all necessary duct work prior to the date of printer installation. The
customer should work with a heating, ventilation, and air conditioning contractor to ensure that the ventilation system works and
complies with local building codes.
WASH STATION
Wash station or suitable washing facilities must be provided to be used in the event of emergency, should chemical splashing o ccur
while system operators are handling inks. The provision of these facilities will help to reduce the risk of irritation and possible damage to
the eyes and/or skin.
SITE PREPARATION GUIDE
FLOOR REQUIREMENTS
When planning the print production area, it is important to ensure that the floor surface is solid, smooth, level, and free from any holes or
indentations. Floor covering material should be durable and easy to clean.
Floor load-bearing capabilities in the print production area are an essential consideration. This will require consulting the structural
engineer for the building in which the printer is to be installed. See the Specifications on page above for the shipping and weight of the
printer.
During installation, the printer will be leveled to ensure accurate media feeding. The printer and table feet can be adjusted to
compensate for a maximum floor slope. (elevation change)
azonprinter.com MATRIX GETTING STARTED

WARNING
Danger of electrical short, shock, electrocution, or fire
Connect to an electrical outlet that complies with this machine’s ratings (for voltage, frequency, and current)
Never use out of doors or in any location where exposure to water or high humidity may occur. Never touch with wet hands
Never allow any foreign object to get inside never expose to liquid spills
ever place any flammable object nearby, never use a combustible aerosol spray nearby, never use in any location where gases can accumulate
Handle the power cord, plug, and electrical outlet correctly and with care. Never use any article that is damaged
When using an extension cord or power strip, use one that adequately satisfies the machine’s ratings (for voltage, frequency, and current)
Connect to ground
Position so that the power plug is within immediate reach at all times
If sparking, smoke, burning odor, unusual sound, or abnormal operation occurs, immediately unplug the power cord, never use if any component is
damaged
Do not use the supplied power supply cord for other products
SITE PREPARATION GUIDE
OPERATING POWER REQUIREMENTS
Delta (USA/Canada) Configuration Wye (European) Configuration:
Voltage 110-120VAC 1 Phase 220-240VAC 1 Phase
Frequency 50 to 60 Hz 50 to 60 Hz
Current 30 Amps maximum steady state 30 Amps maximum steady state.
Circuit breaker 30 Amps slow blow 30 Amps slow blow
azonprinter.com MATRIX GETTING STARTED

Never place any object on
top or subject to damage
Never allow to get wet Never bend or twist with
undue force
Never make hot
Never pull with undue force Dust may cause fire Never bundle, bind, or roll up
SITE PREPARATION GUIDE
POWER CORD HANDLING
azonprinter.com MATRIX GETTING STARTED

HOST COMPUTER REQUIREMENTS
We recommend that you use provided RIP software
It is your responsibility to procure and configure computer hardware which, at the minimum, meets the software's basic computational
and data handling needs Provided RIP software is used to generate the print files which are downloaded to the Matrix
The following is the provided RIP computers suggested minimum hardware and software requirements
OPERATING SYSTEM
Windows 10
CPU
I5 Processor or Higher
OTHER SPEC
512 Gb Hard Drive
8 Gb RAM per CPU
4 Gb Graphic Card
1 USB Port
DVD-ROM drive required
Network Port TCP/IP
SITE PREPARATION GUIDE
CONECTIVITY
Type Purpose
USB Maintenance ,
Service
Network Printing
azonprinter.com MATRIX GETTING STARTED

Azon Matrix UV printer
Syringe 20 ml
Nozzle check sheet
Calibration sheet
Cleaning fluid
Print head cleaning fluid
Tube
Following items should be accounted for
IN THE BOX....
Do not attempt to start installation if
some of the items are missing
In case of item missing please contact your azon printer
representive
azonprinter.com MATRIX GETTING STARTED

Following items should be accounted for…….
Cleaning sticks [10 pcs]
Network Cable
Zero poition markings
UV Protective glasses
Power cord(depending on the
country)
Matrix DVD
Protective gloves [10 pcs]
Digital hygrometer/thermometer
Do not attempt to start installation if
some of the items are missing
In case of item missing please contact your azon printer representive
IN THE BOX....
azonprinter.com MATRIX GETTING STARTED

IN THE BOX....
Azon Matrix Series printer
1 pcs Check YES / NO
Cleaning liquid 250ml
1 pcs Check YES / NO
Printhead cleaning liquid 250ml
1 pcs Check YES / NO
Syringe 20ml
1 pcs Check YES / NO
Nozzle check sheet
1 pcs Check YES / NO
Calibration plate
2 pcs Check YES / NO
Tube for connect syringe and damper
1 pcs Check YES / NO
Cleaning sticks
10 pcs Check YES / NO
CAT5 UTP Patch cable 10m
1 pcs Check YES / NO
Zero positon yellow markings
5 pcs Check YES / NO
Uv protective glasses
1 pcs Check YES / NO
Power cable
1 pcs Check YES / NO
DVD with Software & documentation
1 pcs Check YES / NO
Protective gloves
10 pcs Check YES / NO
Digital hygrometer/thermometer
1 pcs Check YES / NO
azonprinter.com MATRIX GETTING STARTED
