Thank you for purchasing a Matrox Streaming Media Decoder (SMD-2) product. This product is
designed to decode large numbers of IP network video streams in several different resolutions and
formats.
Hardware supplied
1
 Matrox Streaming Media Decoder card
 1 Matrox cable (KX20 to dual-DVI)
Installation overview
To install your Matrox product, see “Installing your Matrox SMD-2 hardware”, page 5.
1 The hardware supplied with your Matrox product may vary depending on the SKU or part number of your product. For more
information, contact your Matrox representative.
Note: If your Matrox product is already partially or fully installed on your computer, some
or all the installation information in this guide may not apply to you. However, this
information may be useful if you need to reinstall your Matrox product.

Matrox User Guide 5
Installing your Matrox SMD-2 hardware
This section describes how to install your Matrox SMD-2 card. For information specific to your
computer, like how to remove its cover, see your system manual.
Before you begin
To avoid personal injury and to prevent damage to your computer or Matrox hardware, read the
following guidelines before installing your Matrox hardware.
Preventing damage to your graphics hardware
 Always turn off your computer, unplug it, then wait for it to cool before touching any of
the internal parts of your computer or installing your Matrox product.
 While your computer is turned off but still plugged in, some electrical current is supplied
to the motherboard. This current may prevent newly installed hardware from working
properly.
 Static electricity can severely damage electronic parts. Before touching any electronic
parts, drain static electricity from your body (for example, by touching the metal frame
of your computer).
 When handling a card, carefully hold it by its edges and avoid touching its circuitry.
 Always try to insert or remove your card as straight as possible.
Step-by-step installation
1Open your computer
Turn off your computer and open it.
Note: Before installing your Matrox SMD-2 card(s), make sure you have enough power in
your system to properly run the SMD-2 card. We recommend using a separate system for
the SMD-2 card(s). For more information, see “Product information”, page 8.

6 Matrox User Guide
2Choose an expansion slot
Most computers have different types of
expansion slots. Choose a PCI™ slot for
your Matrox card. Your card supports both
64-bit and 32-bit PCI slots. Your system
manual should identify the location of each
type of expansion slot in your computer.
3Insert your Matrox card
a Position your Matrox card over the
expansion slot you’ve chosen.
b Push the card in firmly and evenly until
it’s fully seated in the slot.
c Secure the bracket of your Matrox card
to the computer frame.
(Back of computer)
(×4)
(×16)
(×8)
(64-bit)
PCI
slots PCI Express
slots
(32-bit)
(×1)
WAR NING: Inserting your Matrox card
into the wrong type of slot could damage
your card, your computer, or both.
PCI card
32-bit
64-bit

Matrox User Guide 7
4Connect the power supply
Connect the +12V AUX connector to the
connector on the SMD-2 card.
If you don’t have a +12V AUX connector
you’ll need a PCI express video card power
adapter cable (sold separately).
Updating your firmware
After installing your SMD-2 hardware, make sure you’re using the latest firmware package for your
SMD-2 product. If you need to install the latest firmware package for your SMD-2 product, use the
Matrox Appliance Configuration Utility . For more information, see the help file for your Matrox
Appliance Configuration Utility. For the latest firmware package for your SMD-2 product, contact
your Matrox representative.
Your Matrox card is now installed. For information on connecting other Matrox hardware to your
SMD-2 product, see the user guide for that hardware.

8 Matrox User Guide
Product information
Specifications
Environmental
Matrox Streaming Media Decoder (SMD-2)
Streaming resolution support Megapixel, D1, CIF, VGA, HD
Codec support MJPEG, MPEG-1, MPEG-2, MPEG-4, H.264
Card type PCI 32-bit, 64-bit
Form factor ATX
Connectors 1× KX20
Maximum card dimensions
L:
12.28 " / 31.19 cm
H:
4.25 " / 10.80 cm
W:
1.52 " / 3.87 cm
Temperature, operational Operating: 10 to 35 ºC (50 to 95 ºF)
Temperature, non-operational
storage and transportation -40 to 65 ºC (-40 to 149 ºF)
Humidity, operational (indoor) 20 to 80% (non-condensing)
Humidity, non-operational storage
and transportation 10% to 95% (non-condensing)
Atmospheric pressure, operational 650hPa (3,580 meters / 11,745 feet)
to 1013hPa (0 meters / 0 feet)
Atmospheric pressure,
non-operational and transportation
192hPa (12,000 meters / 39,370 feet)
to 1020hPa (-50 meters / -164 feet)

Matrox User Guide 9
Digital flat panel information
 TMDS® (Transition Minimized Differential Signaling) encoding for DVI connectors
 DDWG (Digital Display Working Group) compliant DVI connector
 EDID (Extended Display Identification Data) 1.2, 1.3 (without the extended data block),
and 2.0 support
