Matsui MDIHOB13N User manual

BUILT-IN INDUCTION HOB
INSTRUCTION MANUAL
MDIHOB13N
Innebygd Induksjonskoketoppen
BRUKSANVISNING/INSTALLASJONSHÅNDBOK
Kiinteä Induktiolieden
KÄYTTÖ JA ASENNUSOPAS
Inbyggd Induktionshällen
BRUKS/INSTALLATIONSANVISNING
Indbygget Induktionskomfur
BRUGS OG INSTALLATIONSVEJLEDNING
NO
FI
SE
DK
Built-in Induction Hob
INSTRUCTION / INSTALLATION MANUAL
GB
MDIHOB13N_IB_5L_130730_Shaun.indb 1 30/07/2013 7:11 PM

MDIHOB13N_IB_5L_130730_Shaun.indb 2 30/07/2013 7:11 PM

Contents GB
Safety Warnings................................................................................................ 6
Unpacking....................................................................................................... 21
Product Overview............................................................................................ 22
TopView.................................................................................................... 22
Control Panel............................................................................................. 22
AWord on Induction Cooking.......................................................................... 23
Before UsingYour New Induction Hob............................................................. 23
Choosing the Right Cookware ......................................................................... 23
Using theTouch Controls................................................................................. 24
UsingYour Induction Hob................................................................................ 25
To Start Cooking ........................................................................................ 25
If the Display Flashes .................................................................... 26
WhenYou Have Finished Cooking.............................................................. 26
Locking the Controls........................................................................................ 27
To Lock the Controls................................................................................... 27
To Unlock the Controls............................................................................... 27
Excessive-Temperature Protection............................................................. 27
Detection of Small Articles........................................................................ 27
Auto Shutdown Protection........................................................................ 27
Using theTimer............................................................................................... 28
Timer Overview......................................................................................... 28
Using theTimer as a Minute Minder.......................................................... 28
Setting the Timer to Turn Cooking Zones O.............................................. 29
Cooking Guidelines.......................................................................................... 31
CookingTips.............................................................................................. 31
Heat Settings............................................................................................. 32
Cleaning and Maintenance..............................................................................33
Hints andTips.................................................................................................. 34
Failure Display and Inspection......................................................................... 35
Specications.................................................................................................. 35
Installation...................................................................................................... 36
Preparing theWorktop.............................................................................. 36
Ensuring AdequateVentilation.................................................................. 36
Fastening the Fixing Brackets.................................................................... 37
Connecting the Induction Hob to the Mains Power Supply........................ 38
Freestanding Installation and Connection................................................. 40
