Mavigard MG-400 Operating instructions

MG-400
COMMISSIONING, OPERATING AND MAINTENANCE MANUAL
MODEL: MAVIGARD SERIES
SUB MODEL: CONVENTIONAL SYSTEM
COMBINED GAS AND FIRE ALARM CONTROL PANEL

KK-642.014 Rev.No:1 01.08.12 Page | 2
CONTENTS
1. INTRODUCTION ----------------------------------------------------------------------------------------------------------------------------------------------- 3
2- WARNING------------------------------------------------------------------------------------------------------------------------------------------------------- 3
3- MOUNTING THE PANEL ------------------------------------------------------------------------------------------------------------------------------------- 3
4- PANEL INPUTS ------------------------------------------------------------------------------------------------------------------------------------------------- 4
4.1 Mains Power Supply------------------------------------------------------------------------------------------------------------------------------------ 4
4.2 Batteries --------------------------------------------------------------------------------------------------------------------------------------------------- 4
4.3 Channel Inputs ------------------------------------------------------------------------------------------------------------------------------------------- 4
4.3.1 Fire detectors and MCPs ------------------------------------------------------------------------------------------------------------------------ 4
4.3.2 4-20mA input-------------------------------------------------------------------------------------------------------------------------------------- 4
4.3.3 Connections of 4-20mA converter card----------------------------------------------------------------------------------------------------- 4
4.3.4 Two-wire detectors------------------------------------------------------------------------------------------------------------------------------- 5
4.3.5 Three-wire detectors ---------------------------------------------------------------------------------------------------------------------------- 5
4.3.6 Flame detectors ----------------------------------------------------------------------------------------------------------------------------------- 5
4.4 Remote control inputs --------------------------------------------------------------------------------------------------------------------------------- 5
5- PANEL OUTPUTS ---------------------------------------------------------------------------------------------------------------------------------------------- 5
5.1 Sounder outputs----------------------------------------------------------------------------------------------------------------------------------------- 5
5.2 24V DC Power Supply (Aux) Output ---------------------------------------------------------------------------------------------------------------- 5
5.3 Relay Outputs -------------------------------------------------------------------------------------------------------------------------------------------- 5
5.3.1 Low alarm relay:----------------------------------------------------------------------------------------------------------------------------------- 5
5.3.2 High Alarm relay:---------------------------------------------------------------------------------------------------------------------------------- 5
5.3.3 Over-range Relay:--------------------------------------------------------------------------------------------------------------------------------- 5
5.3.4 Fault relay:------------------------------------------------------------------------------------------------------------------------------------------ 6
6- CONTROL BUTTONS------------------------------------------------------------------------------------------------------------------------------------------ 6
7- PANEL INDICATORS------------------------------------------------------------------------------------------------------------------------------------------- 6
8- FUSES ------------------------------------------------------------------------------------------------------------------------------------------------------------ 7
9- POWERING THE PANEL-------------------------------------------------------------------------------------------------------------------------------------- 8
9.1 Normal ----------------------------------------------------------------------------------------------------------------------------------------------------- 8
9.2 Alarm ------------------------------------------------------------------------------------------------------------------------------------------------------- 8
9.3 Fault -------------------------------------------------------------------------------------------------------------------------------------------------------- 8
10 PANEL MENUS ------------------------------------------------------------------------------------------------------------------------------------------------ 8
10.1 Visualization -------------------------------------------------------------------------------------------------------------------------------------------- 8
10.2 Access Level 2------------------------------------------------------------------------------------------------------------------------------------------11
11 –OPERATING WITH REPEATER PANEL AND RELAY MODULE ------------------------------------------------------------------------------------18
12- SPECIFICATIONS: -------------------------------------------------------------------------------------------------------------------------------------------18
12.1 Mechanical Features:--------------------------------------------------------------------------------------------------------------------------------18
12.2 Electrical Features:-----------------------------------------------------------------------------------------------------------------------------------18
ANNEX-A CO NN EC T I O N SCHEME OF THE P A N E L -----------------------------------------------------------------------------------------------------19
ANNEX-B P A N E L DIMENSIONS --------------------------------------------------------------------------------------------------------------------------------20

KK-642.014 Rev.No:1 01.08.12 Page | 3
1. INTRODUCTION
MaviGard MG-400 is a 4 channel, 24 V DC operating voltage combined gas and fire alarm control panel.
Each channel can host 1 gas detector or 20 fire detectors with unlimited number of manual call points. Panel
power supply unit has an automatic battery charger and charging control circuit. Alarm and fault conditions are
showed on 8x40 character backlight LCD. Panel sounder outputs are supervised for open and short circuit
conditions. The panel has built-in buzzer. Settings to the panel are made by use of navigation buttons and
menu. The panel is microprocessor-controlled. Channels can be inhibited, sounder outputs and relays can be
tested,
Any channel can be disabled, sounder outputs and relays can be test. Gas detectors can be zeroed and
calibrated. These features are also told in the section of “Panel Menu” in detail. The panel is equipped with 2
units of 24 V DC 500 mA sounder outputs and has 4 voltage-free changeover contact relay outputs (Low
alarm relay, High alarm relay, over-range relay and fault relay. Panel also has 24 V DC 500 mA auxiliary
power supply output. By use of remote control inputs, alarm can be silenced and all the channels in the panel
can be disabled.
Producer-manufacturer or importer firms’ title, address, and telephone number
Manufacturer Firm:
MAVILI ELEKTRONIK TICARET VE SANAYI A.S.
SERIFALI MAHALLESI, KUTUP SOKAK NO: 27/1-2-4 UMRANIYE / ISTANBUL / TURKEY
TEL: [phone]
Service stations’ communication information that related spare parts have been provided
Authorized Services:
MAVILI ELEKTRONIK TICARET VE SANAYI A.S.
SERIFALI MAHALLESI, KUTUP SOKAK NO: 27/1-2-4 UMRANIYE / ISTANBUL / TURKEY
TEL: [phone]
TEKSIS TEKNIK ELEKTRONIK SIS.TIC. VE SAN. LTD. STI.
SERIFALI MAHALLESI, KUTUP SOKAK NO: 27/3 UMRANIYE / ISTANBUL / TURKEY
TEL: [phone]
Expected operation life which has been determined and announced by related ministry
This device’s expected operation life is 7 years.
2- WARNING
The equipment contains static-sensitivehigh quality electronic control equipment. Do not use the panel before
reading this manual. In case of any fault, only the technicians of the manufacturer or technicians authorized by
the manufacturer should repair or maintain the panel. Use the recommended cable types defined in this
manual for cabling of power supply, detection and sounder circuits. Do not remove any connections and do
not make any connections while mains power supply is connected. Panel’s earth connection must be made.
The cabinet must be connected to a suitable earth point.
Under no circumstances should voltage or current outside of the limits described in this manual be
used with system units. Otherwise, damage on panel may occur, which is not subject to maintenance
under warranty.
3- MOUNTING THE PANEL
MG-400; is not suitable for hazardous areas. Panels should be located into safe areas. With appropriate
protection material gas and fire detectors can be connected to the hazardous areas. To do that hazardous
areas should be checked and the protection material need to be select according to condition of this area.
While mounting the system in a hazardous area, experienced and educated technical team should be
assigned. Panel should be placed to an easy reachable, clean and dry place without forming any vibration.
The LCD on the panel should be located in flat wall on eye level and pay attention to mount inside of any
cabinet or near to high heat emitting devices. Screws or bolts of a minimum of 4mm diameter must be used
to mount the cabinet in 3 mounting points. Please check out Annex. B. Figure 2. Panel cable entries from
back and top of the panel are available for easy mounting.

KK-642.014 Rev.No:1 01.08.12 Page | 4
4- PANEL INPUTS
4.1 Mains Power Supply
The panel is designed to operate on 220 V AC 50Hz. Earth connections must be made to earth terminal and
earth resistor must be less than 10 Ohms. The mains power supply of the panel must be via an independent
self-resetting fuse rated 5A 220 V AC. This fuse must be separate from the other fuses and a caution note
should be written such as “ATTENTION! GAS ALARM CONTROL PANEL FUSE. DO NOT REMOVE”to
ensure safe operation of the panel.
Recommended cable types are 3x2.5 NYM or 3x2.5 NYA. Connections should be same as Annex.A Figure1.
Do not connect or disconnect the loop, mains supply input and PCB connections while the panel is energized
to avoid an electric shock.
4.2 Batteries
Batteries provide continuity of operation during a failure of the mains power supply. The panel has an
automatic battery charger circuit. The panel uses 2 units of 12V DC 7Ah dry type batteries. Connection
diagram can be seen in Annex.A Figure-2.
4.3 Channel Inputs
These inputs provide power to the gas or fire detectors and transmit the status of gas/fire alarm, short circuit
and open circuit. In each channel input 4-20mA or conventional fire detector connection can be made.
4.3.1 Fire detectors and MCPs
For each zone line at most 20 units of detector and infinite number of button can be connected.
The characteristicsof the cable are dependent on the length of the loop: for a loop of 0-500 metre long, use
1x2x0.8+0.8J-Y(st)Y cable, for a loop of 500-1500 metre long use 1x2x1.5+0.5J-Y(st)Y. A 6.8 kΩresistor
must be connected as an end-of-line element.
Channel jumper setting should be set as fire. If zener barrier will use, the jumper of zener barrier must be
adjust accordingly. Connections are seen as in Annex. A –Figure-3.
4.3.2 4-20mA input
It provides 28V DC supply voltage for both fire and gas detectors. It follows 4-20 mA analogue current input
via 100 Ohms resistor. It is possible to mount 2- or 3- wire gas or flame detectors, in either sink or source
mode. Control panel can make the tracking of the analogue values between 4mA-21.5mA. When the
currents exceed 21.5 mA, panel gives the fault of “OVERRANGE”. Connection can be seen from Annex. A
figure -9.
4.3.3 Connections of 4-20mA converter card
1- The jumper settings on both converter card and gas alarm control panel adjusted as “SOURCE”or
“SINK”. The point here is both adjustments should be same.
2- Before connecting 4-20 mA card to the panel, from the panel menu, channel device type must be
selected as “det 4-20 srce” or “det 4-20 sink”.
3- Before doing the signal connection of converter card to the panel, card is energized from the panel.
4- Voltmeter’s probes, are connected to (+) and (-) supply terminals of CON1 socket go to detector. Value
seen on Voltmeter is adjusted to 2V by using TP3(detector voltage potentiometer.)potentiometer.
5- Then converter card’s energy is turned off.When all the connections are made, it is reenergized.
6- Voltmeter’s probes are connected to the test points TP4 and TP3. Value seen on the voltmeter is
brought to zero by using TP4 (balance potentiometer)O. Make sure that 0 value see continuously.
7- Voltmeter’s probes are connected to the test points TP2 and TP1. Value seen on the voltmeter is
brought to 40mV by using TP2 (zero potentiometer).
8- After these settings applied, the measured value should be read as 0.

KK-642.014 Rev.No:1 01.08.12 Page | 5
4.3.4 Two - wire detectors
In Figure-8, Annex. A ; a sink current detector’s connection is shown. Appropriate jumper settings should
be selected.
4.3.5 Three - wire detectors
In Figure-9 Annex-A; a 3-wire detector’s connection is shown. Appropriate jumper settings should
be selected as sink or source.
4.3.6 Flame detectors
Jumper settings are adjusted according to detector is sink or source. Definitely do not select fire settings
4.4 Remote control inputs
Some of controls of gas alarm control panel can also be done remotely. These are:
· Alarm Silence / Reset - As/R: In case of alarm, to silence the sounders, switch is closed for one time.
If it is closed again, alarm situationis reset and system turns back to its initial position.
·Inhibiting All Channels - Inh: Inhibits all channels. In this case panel keeps tracking detectors. Yet, if
there is an alarm from any fire or gas detectors, it shows the situation only from LCD panel.
Connections should be as in figure- 7 Annex. A. Screening table should be used.
5- PANEL OUTPUTS
5.1 Sounder outputs
The panel has 2 sounder outputs, each rated 24V DC 500mA. Current consumption more than 500mA will
cause a fault condition in sounder line. Sounder circuits are continuously monitored for open and short
circuit faults by connecting the end of line resistor on the last device on the circuit. 2x1.5 mm²cable
should be used for cabling of sounder outputs. Connections should be made according to Annex-A
Figure-4. Polarised type sounders should be used. Otherwise, fire alarm control panel displays a fault
condition.
5.2 24V DC Power Supply (Aux) Output
The panel is equipped with an auxiliary 24V DC 500mA power supply output. The output is used to
energise external devices such as telephone dialler or gas detector. Overloading the output will cause
device malfunction or output fault respectively. Connections should be made according to Annex-A
Figure-5.
5.3 Relay Outputs
Panel has 4 volt free changeover relay outputs rated 1A at 30 V DC. These volt-free outputs, high alarm
relay (normally de-energized), low alarm relay (normally de-energized), over-range relay (normally de-
energized) and fault alarm (normally energized) relay. Connections should be made according to Annex-A
Figure-6.
5.3.1 Low alarm relay: Low alarm relay is activated when the detectors channel low limit
value exceeds in the medium. Features of low alarm relay; threshold, latching/non-latching, NO/NC
operating is adjusted by the user.
5.3.2 High Alarm relay: High alarm relay is activated when the detectors channel high limit
value exceeds in the medium. Features of low alarm relay; threshold, latching/non-latching, NO/NC
operating are adjusted by the user.
If channels include conventional fire alarm detectors, when detectors sends fire alarm signal, high
alarm relay will be activated.
5.3.3 Over-range Relay: If the gas level in the medium exceeds a fixed high limit (21.5 mA),
over- range relay is activated. Latching/non-latching,NO/NC operating is adjusted by the user.

KK-642.014 Rev.No:1 01.08.12 Page | 6
5.3.4 Fault relay: When fault condition or panel’s energy is cut off, it changes its position. When
the fault condition disappears, fault relay gets back to its initial position.
Important Note: Under no circumstances should voltage or current outside of 1A at 30 V DC used
with contacts. Otherwise, damage on panel may occur, which is not subject to maintenance under
warranty. If the relay outputs are used in an application requiring continuous high current, even
below the rated values, an appropriate contactor should be used between the device and the alarm
contacts. If not, main board of panel can blow or become damaged. Warranty excludes in this case.
6- CONTROL BUTTONS
Alarm silence
If thereis a gas or fire alarm at the panel, pressing “Alarm silence button” silences all sounder and relay
outputs which are programmed as latching. Buzzer keeps beeping discretely and the information of sounders
are silenced is seen on LCD screen.
Buzzer silence
Buzzer rings in case of alarm and fault situations, to silence buzzer, press “Buzzer silence” button.
Lamp test
By pressing “Lamp test” button, the control of all LEDs is made.
Reset
Reset button is used to reset the system when there is a gas or fire alarm situation in the system.
Up (+) and down (+) Buttons
“Up (+)”and “Down (-)”buttons, are used to make a pass through panel functions.
Enter Button
“Enter”button, is used to activate the selected function.
Exit Button
“Exit” button, is used to go back one menu up.
Microprocessor reset button
Microprocessor, is locked when it cannot run the system and “System fault” in front panel is lit. In such case,
by pressing microprocessor reset button system is restarted. Also after changing system configuration, this
button helps to start new configuration. (Annex-A Figure 11)
LCD backlight:
LCD contrast could adjust by a trim pot. (Annex-AFigure 10)
7- PANEL INDICATORS
Power On
Under normal conditions only the green “Power On” LED illuminates.
General Fault
If thereis a fault on the system except for system faults, “General Fault” LED Illuminates with related fault
LED.
System fault
The “System Fault” LED will illuminateif the softwareof the panel configurationhas not operated correctly.
Microprocessor button should be used.
Inhibit active
Light when channels are inhibited and which channels are inhibited on LCD screen.
Low Alarm
Low alarm shows detectors channel low limit value if exceeds and shows the low alarm relay is active.
High Alarm
High alarm shows detectors channel high limit value if exceeds and shows the high alarm relay is active.

KK-642.014 Rev.No:1 01.08.12 Page | 7
Over - Range
Shows the gas level in the medium exceeds a fixed high limit (21.5 mA), over-range relay is activated.
General Alarm
Shows if there is a gas or fire alarm from the detectors connected to the channels.
8- FUSES
Sounder 1 Fuse (F1)
F1 fuse; is self-resetting and activate on 500 mАcurrent overload.
Sounder 2 Fuse (F2)
F2 fuse; is self-resetting and activate on 500 mАcurrent overload.
System Fuse (F3)
F3; is self-resetting and activates on 4А current overload or a short circuit
on panel PCBs. On activation of the fuse the SMPS 24 V output fault LED indicator illuminates.
Battery Fuse (F4)
F4; is self-resetting and activates on 500 mАcurrent overload or a short circuit on battery inputs. Illuminating
of the respective LED indicator on SMPS and silk screen label means the batteries are disconnected.
24 V DC Auxiliary Power Supply Output Fuse (F5)
F5; is self-resetting and activates on 500 mАcurrent overload. On the fuse activation the 24 V DC Fault LED
illuminates.
Channel Fuses (F6, F7, F8, F9)
They are 100 mA self-resetting fuses. It gets activated in case of any short circuit in channels inputs. In this
condition system takes energy from the batteries.
Mains Fuse (F10)
is glass type and activates on 2Аcurrent overload, a short circuit or exceeding 220 V AC on mains supply
input. On the fuse activation, the POWER FAULT LED indicator on SMPS illuminates and power to the panel
is supplied from the batteries.

KK-642.014 Rev.No:1 01.08.12 Page | 8
9- POWERING THE PANEL
9.1 Normal
During normal mode, only green system is on LED lights. On the screen the gas levels read by channels is
9.2 Alarm
When the gas detectors exceed the levels of predetermined threshold levels in each channel, panel goes
into alarm mode. These alarms can be either low or high alarm level. In these situations each assigned output
is activated. Pressing Reset makes the system work in initial position.
9.3 Fault
In case of any fault condition at the panel leads to light “General Fault” LED, rings the buzzer ad fault relay
changes its switch. When fault condition disappears, panel automatically turns back to its normal operating
status.
10- PANEL MENUS
In normal mode, access level of the panel is 1. In order to see the panel configuration and reach the functions
of access level 2, first you need to main menu. To do this, in normal operating mode press “Enter” button.
Under the main menu there are 2 submenus. These are “Visualization” and “Access level 2” menus. These
menus are selected by using “Up (+)”and “Down (-)”buttons. Then, pressing “Enter”button results to enter the
selected submenu.
10.1 Visualization
When Visualizationfunction is selected, pressing “Enter”button pops up 4 sub visualizationfunction.
To enter these sub-functions, function is selected by using “Up (+)”and “Down (-)”buttons. Then, pressing
“Enter”button results to enter the selected sub-function.
*** Visualize ***
> Relays status
Sounders status
Signal levels
Configuration
-----------------------------------------------------------------
-
Enter –Ok Exit –Up
Menu

KK-642.014 Rev.No:1 01.08.12 Page | 9
10.1.1 Relay Activation Status
It enables to track the position of relay outputs of the panel.
*** RELAYS STATUS ***
Low Alarm Relay: Active
High Alarm Relay: Not Active
Over-range Relay: Not Active
Fault Relay: Active
-------------------------------------------------------------
-----
Exit –Pre Menu
10.1.2 Sounder Activation Status
It follows whether sounder outputs are active or not.
*** SOUNDERS STATUS ***
Sounder 1 : Not active
Sounder 2 : Active
-------------------------------------------------------------
-----
Menu
Exit –Pre
10.1.3 Signal Levels
Input of each channel’s signal level can be tracked.
*SIGNAL LEVELS *
Channel 1 :
00.0
mA
Channel 2 :
05.5
mA
Channel 3 :
10.7
mA
Channel 4 :
25.5
mA
-------------------------------------------------------------
-----
Exit –Pre Menu
10.1.4 Configuration
System operation is seen from the operating configuration of channels, sounders and relays. It is composed
of 4 sub-functions.
* CONFIGURATION *
> System
Common Relay settings
Sounder settings
Channel settings
Enter –Ok Exit –Pre-menu

KK-642.014 Rev.No:1 01.08.12 Page | 10
10.1.4.1 System
In this menu, panel’s language is shown.
* SYSTEM *
Language: English
Access Level 2 Password: Active
---------------------------------------------------------
----
Exit –Pre-menu
10.1.4.2 Common relay settings
It is possible to check how panel’s relay works (latching or non-latching and N/O or N/C)
*COMMON RELAY SETTINGS* Low
Alarm Relay : Latching / NO High
Alarm Relay: Non-latching / NC
Over-range Relay: Latching OK / NO
Fault Relay : Non-Latching / NO
---------------------------------------------------------------
---
Exit –Pre-menu
10.1.4.3 Sounder settings
It is possible to check how panel’s sounder outputs operates (latching or non-latching)
* SOUNDER SETTINGS*
Sounder 1 : Latching
Sounder 2 : Non-latching
------------------------------------------------------------
Exit –Pre-menu
10.1.4.4 Channel settings
Operating condition of all channels are monitored
*** CHANNEL SETTINGS ***
> Channel 1 configuration
Channel 2 configuration
Channel 3 configuration
Channel 4 configuration
Enter –Ok Exit–Pre-menu
For example, if channel 1 is selected, then pressing “Enter”makes to monitor all features of the channel.
