MaxiCosi Easy Fix Troubleshooting guide

Maxi-Cosi EasyFix
www.maxi-cosi.com
MALAYSIA
Planete Enfants Sdn. Bhd.
41 C, ss 22/23
Damansara Jaya
47 400 Petaling Jaya,
Selangor, Malaysia
Tel. [phone]
E-mail: [email protected]
MALTA
Rausi Company Limited
J.P.R. Buildings
Ta’ Zwejt Street
San Gwann Industrial Estate
San Gwann SGN 09, Malta
Tel. [phone]
Fax [phone]
E-mail: [email protected]
MÉXICO
D’bebé
Girardón # 84
Esq. Camino a Sta. Lucia
Col. Alfonso XIII Mixcoac
01420 México, D.F.
Mexico
Tel. [phone]
Fax [phone]
E-mail: [email protected]
NEDERLAND
Dorel Netherlands
P.O. Box 6071
5700 ET Helmond
www.maxi-cosi.com
NORGE
Dorel Netherlands
P.O. Box 6071
5700 ET Helmond
www.maxi-cosi.com
ÖSTERREICH
Dorel Germany
Vertrieb Österreich
Augustinusstraße 11b
50226 Frechen-Königsdorf
Tel. [phone]
Fax [phone]
www.maxi-cosi.com
POLAND
Poltrade Waletko
Spółka Jawna
41-500 Chorzów
Ul. Legnicka 84/86
Tel. (032) - 346 0081
Fax (032) - 346 0082
E-mail: [email protected]
www.poltradewaletco.pl
www.foteliki.com.pl
PORTUGAL
Dorel Portugal LDA
Parque Industrial da Varziela
Árvore, 4480 Vila do Conde
Tel. [phone]
Fax [phone]
E-mail: [email protected]
Rossiå (russia)
Carber Poriferra
107392 Moskva, Russia
1aå Pugahevskaå ul., 17
1st Pugachevskaya str. 17
RUS-107392 Moscow
Tel. [phone]
Fax. [phone]
E-mail: [email protected]
SCHWEIZ
DOREL Juvenile Switzerland SA
Chemin de la Colice 4
1023 CRISSIER
Tel. [phone]
Fax [phone]
E-mail: [email protected]
SINGAPORE
B.I.D. Trading
69, Kaki Bukit Avenue 1
Shun Li Industrial Park
Singapore 417947
Tel. [phone]
Fax [phone]
E-mail: [email protected]
SLOVAKIA
Libfin s.r.o.
Legionár
˘u˚72
276 01 Me˘lník
C
˘eská Republika
Tel. [phone]
Fax [phone]
E-mail: [email protected]
www.libfin.cz
SLOVENIA
Baby Center d.o.o.
Letali
š ka c. 3c
Ljubljana
Tel. [phone]
Fax [phone]
E-mail: [email protected]
www.baby-center.si
SOUTH AFRICA
Anchor International
Gold Reef Industrial Park
Unit C 1
Booysens Reserve
JHB.
Tel. 002711 – 835 – 3715/3716/2530
Fax 002711 – 835 – 3718
E-mail: [email protected]
SOUTH KOREA
Soyea Corporation
144-3 Sangdaewon-Dong, Jungwon-Gu,
Seongnam-City, Gyeonggi-Do,
KOREA
Tel: [phone]
Fax: [phone]
SVERIGE
Dorel Netherlands
P.O. Box 6071
5700 ET Helmond
www.maxi-cosi.com
TAIWAN
B & B Group/Topping Prosperity Inc.
4F, No. 2, Lane 222,
Tun Hwa North Road, Taipei
Tel. [phone]
Fax [phone]
E-mail [email protected]
THAILAND
Diethelm
Sukhumvit Road 2535
Bangchak
Prakanong
1050 Bangkok
Tel. [phone]
Fax [phone]
E-mail: [email protected]
E-mail: [email protected]
TÜRKIYE
Grup Ltd
Grup Baby Plaza
Kayışdağı Cad. Hal Karşısı No.7
Carrefour arkası
Küçükbakkalköy - ISTANBUL
Tel: [phone] (8 hat)
Fax: [phone]
www.grupbaby.com
UKRAINE
Europroduct
4th floor, 53b
Arnautskaya St
270023 Odessa
Tel. [phone]
Fax [phone]
E-mail: [email protected]
www.europroduct.com.ua
UNITED KINGDOM
Dorel U.K.
Hertsmere House
Shenley Road
Borehamwood, Hertfordshire
WD6 1TE
Tel. [phone]
Fax [phone]
DRU0375
Maxi-Cosi EasyFix
GB Instructions for use/Warranty 7 - 20
PL Instrukcja obsługi/Gwarancja 21 - 34
H Használati utasítás/Garancia 35 - 48
CZ Návod k použití/Záruka 49 - 62
EST Kasutusjuhend/Garantii 63 - 76
SLO Navodilo za uporabo/Garancija 77 - 90
RUS Руководство по эксплуатации/Гарантия 91 - 105
BUL Упътване за употреба/Гаранция 106- 120
2
GB Instructions for use/Warranty
PL Instrukcja obsługi/Gwarancja
HHasználati utasítás/Garancia
CZ Návod k použití/Záruka
EST Kasutusjuhend/Garantii
SLO Navodilo za uporabo/Garancija
RUS Руководство по эксплуатации/Гарантия
BUL Упътване за употреба/Гаранция
The safe world of Maxi-Cosi
Contentswww.maxi-cosi.com www.maxi-cosi.com 3
0098_GBA_EasyFix_COV_III 23-06-2006 12:09 Pagina 1

Illustrations Illustrations www.maxi-cosi.com
www.maxi-cosi.com
2
1
16 17
1
2
18
1
2
23
12
2
1
1
2
19
22
21
20
24 25 26
28
654
1 2
2
1
3
1
2
4
5 6 7 8
910
12
11 12
12
13 14 15
BELGIE
BELGIQUE/LUXEMBOURG
Dorel Benelux
Brussels Int. Trade Mart
Postbus/B.P. 301
1000 Brussel/Bruxelles
Tel. [phone]
Fax [phone]
www.maxi-cosi.com
BULGARIA
Nedelchev & Nedelchev Ltd.
Compl. Gotze Delchev
Ul. Silivria 16
Sofia 1404
Tel. [phone]
Fax [phone]
E-mail: [email protected]
www.nn-bg.com
C
˘ESKÁ REPUBLIKA
Libfin s.r.o.
Legionár
˘u˚72
276 01 Me˘lník
C
˘eská Republika
Tel. [phone]
Fax [phone]
E-mail: [email protected]
www.libfin.cz
CROATIA
MAGMA d.d.
Bastijanova 52a
10000 Zagreb
Croatia
Tel. [phone]
Fax [phone]
www.magma.hr
Media Commerce d.o.o.
CMP Savica ˘ Savica jug
Majstorska 5
1000 Zagreb
Tel. [phone] / 501
Fax [phone]
CURACAO
Mom & Co.
Promenade Shopping Center C3
Curacao
Tel. [phone]
Fax [phone]
E-mail: [email protected]
CYPRUS
Xen. J. Demetriades & Son Ltd.
156, Anexartisias Street
3604 Lemesos
Tel. [phone]
Fax [phone]
E-mail: [email protected]
www.demetriades.com.cy
DANMARK
BabySam A.m.b.A.
Egelund A 27-29
6200 Aabenraa
Denmark
Tel. [phone]
Fax [phone]
E-mail: [email protected]
DEUTSCHLAND
Dorel Germany
Augustinusstraße 11b
50226 Frechen-Königsdorf
Tel. [phone]
Fax [phone]
www.maxi-cosi.com
DUBAI
Golden Toys
P.O.Box 6761, Dubai
U.A.E.
Tel. [phone]
Tel. [phone]
Fax [phone]
E-mail: [email protected]
EESTI, LATVIA, LLETUVA
AS Greifto
Pärnu mnt. 139C
11317 Tallinn
Tel. [phone]
Fax [phone]
E-mail: [email protected]
ESPAÑA
Dorel Hispania S.A.
Pare Rodés No26
Torre A, 4ª Planta, Edificio Del Llac
Center
08208 Sabadell (Barcelona)
Tel. [phone]
Fax [phone]
FINLAND
Dorel Netherlands
P.O. Box 6071
5700 ET Helmond
www.maxi-cosi.com
FRANCE
Dorel France S.A.
Z.l./9 bd du Poitou - BP 905
49309 CHOLET CEDEX
Tel. [phone]
Fax [phone]
GREECE
Dionic S.A.
95 Aristotelous St.
136 71 Axarnes
Athens
Tel. [phone]
Fax [phone]
E-mail: [email protected]
www.unikid.gr
HONG KONG
Chup Shing Trading Co Ltd.
Block A, 7/F, Unit J
25-31 Kwai Fung Crescent
Marvel ind. Bldg.
Kwai Chung
Hong Kong
Tel. [phone]
Fax [phone]
HUNGARY
Recontra Kft.
Badacsonyi u. 24
1113 Budapest
Tel. [phone]
Fax [phone]
E-mail: [email protected]
ICELAND
Fífa ehf.
Husgagnahollin
Bildshofda 20
IS-110 Reykjavik
Tel. [phone]
E-mail: [email protected]
www.fifa.is
IRAN
Nowrouz Nia
Mirdamad Ave.-Valiasr Ave.
Eskan-Shopping Center
No. 13 Eskan - Maxi-Cosi
IRAN - 19696 TEHRAN
Tel. +98 - 21- 87 87 378
Fax +98 - 21 - 87 75 702
E-mail: [email protected]
ISRAEL
Shesek Ltd.
28B Halechi Street
Bnei Brak 51200
Tel. [phone]
E-mail: [email protected]
ITALIA
Dorel Italia S.P.A.
Via Verdi, 14
24060 Telgate (Bergamo)
Tel. [phone]
Fax [phone]
JAPAN
Combi
271, Kagiageshinden,
Iwatsuki-Shi Siatama
339-0025 Japan
Tel. [phone]
Fax [phone]
LEBANON
Gebran Geahchan & Sons
Azar Bldg.
Horch Tabet
Po Box 55134
Sin El Fil
Tel. [phone]
Fax [phone]
27
0098_GBA_EasyFix_COV_III 23-06-2006 12:09 Pagina 2

GB
English
Dear parents
Congratulations on your purchase of the Maxi-Cosi EasyFix.
Safety, user-friendliness, comfort and design played an important role in developing the Maxi-Cosi EasyFix.
This product meets the most stringent safety requirements.
Studies have shown that a large percentage of car seats are not used correctly. Therefore, please take the
time to read through this manual carefully. Your child’s safety can only be guaranteed if this product is
used according to these instructions.
Continuous research by our product development department, supported by intensive contact and
consultation with test people and consumers ensure that we kept fully up-to-date in the field of child
safety. If you have any questions or comments on the use of the Maxi-Cosi EasyFix, please do not hesitate
to contact us.
Dorel (see the back of the instruction manual for address and telephone number)
7
1
2
5
7
8
9
10
11
6
4
3
1. Base
2. Isofix connector
3. Anchor point
4. Colour indicator for the Maxi-Cosi CabrioFix
5. Isofix guides
6. Support leg control button
7. Support leg colour indicator
8. Support leg
9. Central button on the support leg with
colour indicator
10. Release lever for Maxi-Cosi CabrioFix
11. Blue belt clamp
0098_GBA_EasyFix_BW_III 23-06-2006 12:17 Pagina 7

GB
English
CONTENTS
1. IMPORTANT: READ FIRST! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
2. APPROVED CAR USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
3. INSTALLING AND REMOVING THE MAXI-COSI EASYFIX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
3.1 Using Isofix (yellow marking on the product) and support leg . . . . . . . . . . . . . . . . . . . . . . . . . . .10
3.2 Using a 3-point safety belt (blue marking on product) and support leg . . . . . . . . . . . . . . . . . . . .13
4. INSTALLING AND REMOVING THE MAXI-COSI CABRIOFIX . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
5. MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
6. GENERAL INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
7. WASTE SEPARATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
8. NEXT STAGE CAR SEAT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
9. CAR FITTING LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
10. WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
11. QUESTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
1. IMPORTANT: READ FIRST!
Read this instruction manual carefully and save it for future reference. Failure to follow the instructions in
this manual could result in serious injury to your child.
Use original accessories and manufacturer-approved parts only. Do not make any changes to the product.
If you have any problems or complaints, contact your retailer or importer.
Always check car fitting list before installation.
IMPORTANT! The Maxi-Cosi EasyFix is a safety product and is only safe if it is used in accordance with the
instructions.
IMPORTANT! The Maxi Cosi EasyFix may only be used in combination with the Maxi-Cosi CabrioFix. The
Maxi-Cosi CabrioFix can be recognised by the type indication on the belt protector and the two steel
spindles underneath the Maxi-Cosi CabrioFix. If you are in any doubt, contact the manufacturer.
8
0098_GBA_EasyFix_BW_III 23-06-2006 12:17 Pagina 8

GB
Instructions for use
Never leave a child unsupervised in the seat, either in the car or outside of the car.
Do not use the Maxi-Cosi EasyFix in a place where a frontal airbag is installed as this can be dangerous.
This does not apply to side airbags.
The Maxi-Cosi EasyFix may be used either on the passenger seat or on the back seat, but it should always
face backwards. Lock the rear seats that fold down.
The Maxi-Cosi EasyFix has been approved according to the most recent guidelines of the ECE R 44/04, the
European standard for car safety seats, and can be used in combination with the Maxi-Cosi CabrioFix,
suitable for children from birth to approximately 12 months (group 0+: 0 to 13 kg).
* The use of the support leg and / or Isofix, which ensure optimum safety and easy installation, mean
that the Maxi-Cosi EasyFix is not suitable for all types of cars. The Maxi-Cosi EasyFix is designated as
“semi-universal” and therefore suitable for installation in certain types of cars. See the enclosed car
fitting list (see Section 9: Car fitting list).
9
Maxi-Cosi CabrioFix +
Maxi-Cosi EasyFix
Maxi-Cosi CabrioFix
Suitability according to ECE R 44/04
Group Body weight of child Age
0+ 0 – 13 kg 0 – 12 months Semi-universal*
0+ 0 – 13 kg 0 – 12 months Universal
0098_GBA_EasyFix_BW_III 23-06-2006 12:17 Pagina 9

GB
English
2. APPROVED CAR USE
The Maxi-Cosi EasyFix is approved for 2 types of car use:
Installation with Isofix and support leg (see section 3.1);
For use in cars with approved Isofix anchor points (see Section 9: Car fitting list). Recognisable by the
yellow marking on the product and the yellow marking in the instruction manual.
ór
Installation using 3-point safety belt and support leg (see section 3.2);
For use in cars “fitted” with an automatic 3-point safety belt approved in accordance with ECE R16 or
equivalent standard (see Section 9: Car fitting list). Recognisable by the blue marking on the product and
the blue marking in the instruction manual.
3. INSTALLING AND REMOVING THE MAXI-COSI EASYFIX
3.1 Using Isofix (yellow marking on the product) and support leg
If your car is equipped with Isofix anchor points, you can install the Maxi-Cosi EasyFix using the Isofix
connectors in combination with the support leg. To check whether your car is suitable for Isofix attachment
and the support leg, see Section 9: Car fitting list.
* Check car fitting list
10
• Installed on seats fitted with Isofix Yes*
anchor points (located between seat
and seat back) & with room for the
support leg
•Isofix installation marking Yellow
•Frontal airbag No
•Side airbag Yes
Isofix class E
0098_GBA_EasyFix_BW_III 23-06-2006 12:17 Pagina 10

GB
Instructions for use
Only use the Maxi-Cosi EasyFix on a forward-facing seat equipped with Isofix anchor points. Read the car
manufacturer’s handbook before use.
Correct attachment to the Isofix anchor points is essential for the safety of your child. Also see the yellow
outlined sticker on the side of the Maxi-Cosi EasyFix. Never use a different installation method than the
one described here!
A. Preparing the Isofix
• Place the enclosed Isofix guides* (1) on both Isofix anchor points between the seat and the seat
back (2).
* Isofix guides make it easier to install using the Isofix system and prevent damage to the upholstery.
For cars with fold-down seat backs, the Isofix guides must be removed before folding down the seat.
Functional failures usually occur because the Isofix guides are dirty (dust, dirt, food particles, etc.).
This can be avoided by frequently checking the Isofix guides for dirt and cleaning them if necessary.
B. Installing with Isofix
• IMPORTANT! Secure any fold-down seats.
• IMPORTANT! Make sure the support leg is fully folded out (3,1) and that the indicator on the central
button is red (3,2).
• Press the central button on the support leg (4,1) and push the support leg backward as far as
possible (4,2).
• The Isofix connectors are now extended as far as possible (5) and the Maxi-Cosi EasyFix is ready to be installed.
• Place the Maxi-Cosi EasyFix on the seat of the car.
• Line up the Isofix connectors with the Isofix guides (6).
• Click both Isofix connectors into the Isofix anchor points (7).
• IMPORTANT! Make sure that both Isofix connectors are securely attached to thei Isofix anchor points:
there should be two audible clicks.
• Check to make sure the Maxi-Cosi EasyFix is securely installed by pulling on the Maxi-Cosi EasyFix. The
indicator on the central button should now be green (8).
• Place both hands on the Maxi-Cosi EasyFix and push it back as far as possible until it is situated firmly
against the seat back (you’ll hear a ‘rattling’ sound) (9).
• Check again to make sure the seat is secure by pulling on the Maxi-Cosi EasyFix.
9
8
7
6
5
4
3
21
11
0098_GBA_EasyFix_BW_III 23-06-2006 12:17 Pagina 11

GB
English
C. Adjusting the length of the support leg
• IMPORTANT! Always use the support leg to ensure the safe use of the Maxi-Cosi EasyFix.
• IMPORTANT! Make sure the support leg is fully folded out and locked at the hinge point (10).
• Keep the silver control button on the support leg pressed (11,1) and move the support leg downwards
until it reaches the floor of the car (11,2).
• IMPORTANT! Make sure the indicator at the base of the support leg is green (12).
• In some cases the Maxi-Cosi EasyFix may not be fully supported by the car seat, but entirely by the support leg.
• Release the control button and “click” the support leg into the locked position.
• Check to make sure the support leg is securely locked and stays in position by trying to move it up or
down without pressing the control button.
Checklist…
To ensure the optimum safety of your child, check the following after installation:
• Both Isofix connectors are securely attached to the Isofix anchor points: the indicator on the central
button on the support leg should be green.
• The support leg is fully folded out.
• The indicator on the base of the support leg is green.
• The entire Maxi-Cosi EasyFix is installed securely and firmly in the car (check by pulling on the Maxi-Cosi
EasyFix).
D. Removing the Maxi-Cosi EasyFix
• Restore the support leg to its start position by pressing the control button (13,1) and sliding the support
leg upwards (13,2).
• Disconnect the Isofix connectors by pressing the central button on the support leg (14). The indicator on
the central button on the support leg should be red. Considerable force may sometimes be needed in
orrder to release the buckle. If this is the case, try pushing the Maxi-Cosi EasyFix into the back of the
vehicle seat while pressing the release button.
• Remove the Maxi-Cosi EasyFix from the Isofix anchor points (15).
• Remove the Maxi-Cosi EasyFix from the car.
15
14
13
12
11
10
12
0098_GBA_EasyFix_BW_III 23-06-2006 12:17 Pagina 12

GB
Instructions for use
3.2 Using a 3-point safety belt (blue marking on product) and support leg
If your car is not equipped with Isofix anchor points, you can install the Maxi-Cosi EasyFix using a 3-point
safety belt in combination with the support leg. To check whether your car is suitable for installation using
a 3-point safety belt and support leg, see Section 9: Car fitting list.
* Provided there is a 3-point safety belt in the middle position of the back seat and there is enough room
for properly installing the support leg (see Section 9: Car fitting list).
Only install the Maxi-Cosi EasyFix on a forward-facing seat fitted with an automatic 3-point safety belt
approved in accordance with ECE R16 or equivalent standard.
The proper threading of the seat belt is essential to your child’s safety. The seat belt must be threaded
along the blue markings on the Maxi-Cosi EasyFix. See the sticker outlined in blue on the topside of the
Maxi-Cosi EasyFix.
Never thread the belt in any other way!
13
3
1212
• Installation with 3-point safety belt Yes
• Installation with 2-point safety belt No
• On passenger seat Yes
• On left/right side of back seat Yes
• In middle position of back seat Yes*
• Belt routing marking Blue
• Frontal airbag No
• Side airbag Yes
0098_GBA_EasyFix_BW_III 23-06-2006 12:17 Pagina 13

GB
English
A. Installing
• IMPORTANT! Make sure the Isofix connectors are retracted.
• Press the central button on the support leg (16,1) and pull the support leg forward as far as possible
(16,2).
• IMPORTANT! Secure any fold-down seats.
• IMPORTANT! On some seats, the belts are fitted so far forward that proper installation is not possible.
If this is the case, try another seat (see section 9: Car fitting list).
• Place the Maxi-Cosi EasyFix on the seat of the car (17) with the support leg folded out.
• Open the blue belt clamp by pulling the lever up (18,1). Pass the shoulder and lap belt together through
the belt opening (18,2).
• Pass the seat belts between the base and the blue belt clamp and then through the second belt
opening (19,1).
• Insert the seat belt into the belt buckle of the car (19,2).
• NOTE! Make sure that the seat belt is pulled tight and is not twisted.
• Fasten the belt clamp by pushing the lever down (20).
• Check that it is fastened correctly by pulling on the Maxi-Cosi EasyFix.
B. Adjusting the length of the support leg
• See section 3.1, point C: “Adjusting the length of the support leg”.
Checklist …
To ensure the optimum safety of your child, check the following after installation:
• The seat belt is as tight as possible and not twisted.
• The two belt parts pass through the belt openings in the base and under the blue belt clamp.
• The support leg is fully folded out.
• The indicator at the base of the support leg is completely green.
• In some cases the Maxi-Cosi EasyFix may not be fully supported by the car seat, but entirely by the
support leg.
• The Maxi-Cosi EasyFix as a whole has been installed in the car in a secure and stable manner by pulling
on the Maxi-Cosi EasyFix.
C. Removing the Maxi-Cosi EasyFix
• Restore the support leg to its start position by pressing the control button (21,1) and sliding the support
leg upwards (21,2).
• Loosen the seat belt (22,1) and open the blue belt clamp (22,2).
22
21
20
19
19
18
17
16
14
0098_GBA_EasyFix_BW_III 23-06-2006 12:17 Pagina 14
