maximal Maximal3DV User manual

Rev. 061307 More than just power.TM
Access Power Controllers
Installation Guide
Models Include:
Maximal3DV
- 12VDC @ 5A or 24VDC @ 5.4A.
- Sixteen (16) PTC protected outputs.
Maximal5DV
- 12VDC @ 9A.
- Sixteen (16) PTC protected outputs.
Maximal7DV
- 24VDC @ 9.4A.
- Sixteen (16) PTC protected outputs.

- 2 - Maximal3DV / Maximal5DV / Maximal7DV Access Power Controllers (PTC)
Table of Contents:
MaximalDV Series Overview ..........................................................................pg. 3
MaximalDV Series Configuration Chart............................................pg. 3
MaximalDV Series Features ......................................................pg. 3
MaximalDV Installation Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pg. 4
Maintenance ...................................................................pg. 5
Power Supply Board LED Diagnostics .............................................pg. 5
Access Power Controller LED Diagnostics ..........................................pg. 6
Power Supply Board Terminal Identification .......................................pg. 6
Access Power Controller Terminal Identification ....................................pg. 6
Power Supply Board Stand-by Battery Specifications ................................pg. 6
Power Supply Board Output Voltage Settings .......................................pg. 7
Access Power Controller Typical Application Diagram (for each ACM8CB) .............pg. 7
Maximal3DV and Maximal5DV Battery Hookup and Tamper Switch Installation ........pg. 8
Maximal7DV Battery Hookup and Tamper Switch Installation ........................pg. 9
NEC Power-Limited Wiring Requirements for Maximal3DV ..........................pg. 10
NEC Power-Limited Wiring Requirements for Maximal5DV ..........................pg. 11
NEC Power-Limited Wiring Requirements for Maximal7DV ..........................pg. 12
FACP Hook-Up Diagrams .......................................................pg. 13-14
Enclosure Dimensions ...........................................................pg. 16

Maximal3DV / Maximal5DV / Maximal7DV Access Power Controllers (PTC) - 3 -
MaximalDV Series Overview:
Altronix MaximalDV Access Power/Controllers distribute and switch power to access control systems and
accessories. They convert a 220VAC (working range 198VAC - 256VAC), 50/60Hz input into sixteen (16)
independently controlled 12VDC or 24VDC PTC protected outputs. The outputs are activated by an open col-
lector sink or normally open (NO) dry trigger input from an Access Control System, Keypad, Push Button, REX
PIR, etc. Units will route power to a variety of access control hardware devices including: Mag Locks, Electric
Strikes, Magnetic Door Holders, etc. The FACP Interface enables Emergency Egress, Alarm Monitoring, or may
be used to trigger other auxiliary devices. The fire alarm disconnect feature is individually selectable for any or
all of the sixteen (16) outputs.
MaximalDV Series Configuration Chart:
Altronix
Model Number
Power Supply
Board Output
Voltage Options
PTC Protected
Outputs
(auto-resettable)
Individual
Output
Rating (A)
220VAC 50/60Hz
Input Current
Draw (A)
Power Supply
Board Input
Fuse Rating
Maximal3DV 12VDC @ 5A
or 24VDC @ 5.4A 16
2.5A
1.5A
5A/ 250V
Maximal5DV 12VDC @ 9A 16 2.2A
Maximal7DV 24VDC @ 9.4A 16 3A
MaximalDV Series Features:
• Sixteen (16) independently trigger controlled outputs.
Output options:
a) Sixteen (16) Fail-Safe filtered and electronically regulated power outputs.
b) Sixteen (16) Fail-Secure filtered and electronically regulated power outputs.
c) Any combination of the above.
• Sixteen (16) Access Control System trigger inputs.
Input trigger options:
a) Sixteen (16) normally open (NO) dry trigger inputs.
b) Sixteen (16) open collector inputs.
c) Any combination of the above.
• Sixteen (16) unswitched filtered and electronically regulated aux. power outputs (outputs are rated @ 2.5A).
• Red LEDs on ACM8CB board indicate individual outputs are triggered (relays energized).
• Fire Alarm disconnect (latching or non-latching) is individually selectable for any or all of the
sixteen (16) outputs.
Fire Alarm disconnect input trigger options:
a) Normally open (NO) or normally closed (NC) dry trigger input.
b) Polarity reversal input from FACP signaling circuit.
• Green LED on ACM8CB board indicates FACP disconnect is triggered.
• FACP output relay indicates that FACP input is triggered
• Power supply input options:
a) Factory installed power supply provides common power for both ACM8CB boards and all connected
access control devices.
b) An optional external power supply may be connected to isolate the ACM8CB boards from the access
control devices.
• ACM8CB board main fuses are rated @ 10A. Output PTCs are rated @ 2.5A.
• Built-in charger for sealed lead acid or gel type batteries.
- Maximum charge current is 0.7A for AL600XB220 and AL1012XB220 power supply boards.
- Maximum charge current is 3.6A for AL1024XB2V power supply board.
• Automatic switch over to stand-by battery when AC fails.
• Zero voltage drop when unit switches over to battery backup (AC failure condition).
• Short circuit and thermal overload protection with auto reset.
• Green AC input and red DC output LED indicators on power supply board(s).
• AC fail and battery fail supervision (form “C” contact rated @ 1A/28VDC).
• Battery presence supervision (form “C” contact rated @ 1A/28VDC) .
• Enclosure accommodates up to four (4) 12VDC/12AH batteries.
Enclosure dimensions (H x W x D): 26” x 19” x 6.25” (660.4mm x 482.6mm x 158.8mm).

- 4 - Maximal3DV / Maximal5DV / Maximal7DV Access Power Controllers (PTC)
MaximalDV Installation Instructions:
Wiring methods should be in accordance with the National Electrical Code/NFPA 70/NFPA 72/ANSI, and
with all local codes and authorities having jurisdiction. Product is intended for indoor use only.
Power Supply Board LED Diagnostics (pg. 5)
Access Power Controller LED Diagnostics (pg. 6)
Power Supply Board Terminal Identification (pg. 6)
Access Power Controller Terminal Identification (pg. 6)
Power Supply Board Stand-by Battery Specifications (pg. 6)
Power Supply Board Output Voltage Settings (pg. 7)
Access Power Controller Typical Application Diagram (pg. 7)
FACP/Optional Power Supply Hook-up Diagrams (pgs. 13-14)
1. Mount unit in the desired location. Mark and predrill holes in the wall to line up with the top three keyholes
in the enclosure. Install three upper fasteners and screws in the wall with the screw heads protruding.
Place the enclosure’s upper keyholes over the three upper screws; level and secure. Mark the position of the
lower three holes. Remove the enclosure. Drill the lower holes and install three fasteners. Place the
enclosure’s upper keyholes over the three upper screws. Install the three lower screws and make sure to
tighten all screws (Enclosure Dimensions, pg.14).
Earth ground is connected to enclosure. Connect main incoming ground to earth (safety) ground lug.
2. Connect unswitched AC power (220VAC 50/60Hz) to the terminals marked [L, N] on power supply board.
Green branch wire connects to earth (safety) ground lug. Use 14 AWG or larger for all power connections.
Keep power-limited wiring separate from non power-limited wiring (220VAC 50/60Hz Input,
Battery Wires). Minimum 0.25” spacing must be provided.
CAUTION: Do not touch exposed metal parts. Shut branch circuit power before installing or
servicing equipment. There are no user serviceable parts inside. Refer installation and servicing to
qualified service personnel.
3. Select desired DC output voltage by setting SW1 to the appropriate position on the Maximalal3DV power
supply board, (Fig. 1, pg. 7). Maximal5DV power supply is factory set at 12VDC and Maximal7DV
power supply is factory set at 24VDC.
4. Measure output voltage of the unit before connecting any devices to ensure proper operation.
Improper or high voltage will damage these devices.
5. Output options (Fig. 2, pg. 7):
The unit will provide any combination of Fail-Safe and/or Fail-Secure switched power outputs.
(a) Fail-Safe Switched Power outputs:
For Fail-Safe operation connect the positive (+) input of the access control devices to terminal
marked [NC]. Connect the negative (–) input of the access control devices to terminal marked [COM].
(b) Fail-Secure Switched Power outputs:
For Fail-Secure operation connect the positive (+) input of the access control devices to terminal
marked [NO]. Connect the negative (–) input of the access control devices to terminal marked [COM].
6. Auxiliary Power outputs (unswitched):
Connect access control devices that require constant power to terminals marked [C] postive (+) and
[COM] negative (–).
7. Input trigger options (Fig. 2, pg. 7):
(a) Normally Open [NO] input trigger:
Inputs 1-8 are activated by normally open or open collector sink inputs.
Connect access control panel outputs, keypads, push buttons, REX PIRs, etc. to terminals marked
[IN] and [GND].
(b) Open Collector Sink inputs:
Connect the access control panel open collector sink positive (+) to terminals marked [IN] and the
negative (–) to terminals marked [GND].
8. Fire Alarm Interface options (Figs. 9-12, pg. 13-14):
A normally closed [NC] or normally open [NO] input trigger from a fire alarm control panel or a polarity
reversal input from an FACP signaling circuit will affect selected outputs. To enable FACP Disconnect for
an output turn the corresponding switch(es) [SW1-SW8] OFF on each ACM8CB board. To disable FACP
disconnect for an output turn the corresponding switch(es) [SW1-SW8] ON on each ACM8CB board.
(a) Normally Open [NO] input:
For non-latching hook-up refer to Fig. 9, pg. 13. For latching hook-up refer to Fig. 10, pg. 13.
(b) Normally Closed [NC] input:
For non-latching hook-up refer to Fig. 11, pg. 14. For latching hook-up refer to Fig. 12, pg. 14.
(c) FACP Signaling Circuit input trigger:
Connect the positive (+) and negative (–) from the FACP signaling circuit output to the terminals marked
[+ INP –]. Connect the FACP EOL to the terminals marked [+ RET –] (polarity is referenced in an alarm
condition). Jumper located next to TRG LED must be cut (Fig. 2a, pg. 7 and Fig. 8, pg. 13).
9. FACP Dry form “C” output (Fig. 2b, pg. 7):
FACP form “C” contacts can be use to trigger reporting or signaling devices. These contact switch
upon a fire alarm input trigger to the ACM8CB boards.

Maximal3DV / Maximal5DV / Maximal7DV Access Power Controllers (PTC) - 5 -
10. Stand-by Battery Connections (Fig. 3, pg. 8):
For Access Control applications batteries are optional. If batteries are not used, a loss of AC will result in
the loss of output voltage. Batteries must be lead acid or gel type. Connect one (1) 12VDC battery to the
terminals marked [+ BAT –] for 12VDC operation (Fig. 3a, pg. 8). Use two (2) 12VDC batteries wired in
series for 24VDC operation.
11. Battery and AC Supervision outputs (Figs. 3-4, pgs. 8-9):
It is required to connect supervisory trouble reporting devices to outputs marked [AC Fail, BAT FAIL]
and [Power Fail] supervisory relay outputs marked [NC, C, NO] to appropriate notification devices.
Use 22 AWG to 18 AWG for AC Fail & Low/No Battery reporting.
12. Installation of tamper switch (Figs. 3-4, pgs. 8-9):
Mount UL Listed tamper switch (Honeywell Model 112 or equivalent) at the top of the enclosure. Slide the
tamper switch bracket onto the edge of the enclosure approximately 2” from the right side
(Figs. 3b and 4a, pgs. 8-9). Connect tamper switch wiring to the Access Control Panel input or the
appropriate reporting device. To activate alarm signal open the door of the enclosure.
13. Multiple power supply inputs (Fig. 2, pg. 7):
When using an additional external power supply, jumpers J1 and J2 located on corresponding ACM8CB
boards must be cut (Fig. 2c, 2d, pg. 7 and Fig. 7, pg. 12). Connect power for the ACM8CB boards to the
terminals marked [– Power +] and connect power for the access control devices to the terminals marked
[– Control +]. When using DC power supplies polarity must be observed. When using AC power supplies
polarity needs not to be observed (Fig. 2d, pg. 7). All field wiring connections must be made employing
suitable gauge CM or FPL jacketed wire (or equivalent substitute) (Figs. 5a and 6a, pgs. 10-11).
Maintenance:
Unit should be tested at least once a year for the proper operation as follows:
FACP Supervision: To ensure proper connection and operation of the Fire Alarm disconnect
hookup. Please follow the appropriate procedure below:
Normally Open Input: Placing a short between terminals marked [T] and [+ INP] will trigger the
Fire Alarm Disconnect. Remove the short to reset.
Normally Closed Input: Remove the wire from terminal marked [INP –] will trigger the Fire Alarm
Disconnect. Replace the wire to terminal marked [INP –] to reset.
FACP Signal Circuit Input: It is necessary to trigger the Fire Alarm System.
In all of the above scenarios the green TRG LED of the ACM8CBs will
illuminate. All outputs selected for Fire Alarm Disconnect will activate
releasing locking devices.
Note: All outputs [OUT 1 - OUT 8] must be in a normal (de-energized)
condition prior to testing. When the unit is configured for Normally Open
(Fig. 10, pg. 13) or Normally Closed (Fig. 12, pg. 14) latching operation it
is necessary to reset the Fire Alarm Disconnect by activating the
Normally Closed reset switch.
Output Voltage Test: Under normal load conditions the DC output voltage should be checked
for proper voltage level
(Power Supply Board Stand-by Battery Specifications, pg. 7).
Battery Test: Under normal load conditions check that the battery is fully charged, check
specified voltage at the battery terminals and at the board terminals marked
[+ BAT –] to ensure that there is no break in the battery connection wires.
Note: AL600XB220 and AL1012XB220 Power Supply Board maximum
charge current is 0.7A.
AL1024XB2V Power Supply Board maximum charge current is 3.6A.
Expected battery life is 5 years; however, it is recommended to change
batteries within 4 years or less if necessary.
Power Supply Board LED Diagnostics:
LED Power Supply Status
Red (DC) Green (AC)
ON ON Normal operating condition.
ON OFF Loss of AC. Stand-by battery supplying power.
OFF ON No DC output. Short circuit or thermal overload condition.
OFF OFF No DC output. Loss of AC. Discharged battery.
Red (Bat) Battery Status
ON Normal operating condition.
OFF Battery fail/low battery.

- 6 - Maximal3DV / Maximal5DV / Maximal7DV Access Power Controllers (PTC)
Access Power Controller LED Diagnostics:
LED ON OFF
LED 1- LED 8 (Red) Output relay(s) energized. Output relay(s) de-energized.
Trg (Green) FACP input triggered (alarm condition). FACP normal (non-alarm condition).
Power Supply Board Terminal Identification:
Terminal Legend Function/Description
L, G, N Connect 220VAC 50/60Hz to these terminals: L to hot, N to neutral.
+ DC –
Maximal3DV - 12VDC @ 5A or 24VDC @ 5.4A to ACM8CB boards.
Maximal5DV - 12VDC @ 9A to ACM8CB boards.
Maximal7DV - 24VDC @ 9.4A to ACM8CB boards.
AC FAIL
NC, C, NO
Indicates loss of AC power, e.g. connect to audible device or access control panel.
Relay normally energized when AC power is present. Contact rating 1A @ 28VDC.
AC or brownout fail is reported within 1 minute of event.
BAT FAIL
NC, C, NO
Indicates low battery condition, e.g. connect to access control panel. Relay normally
energized when DC power is present. Contact rating 1A @ 28VDC. A removed bat-
tery is reported within 5 minutes. Battery reconnection is reported within 1 minute.
Low battery threshold:
12VDC output threshold set @ approximately 10.5VDC.
24VDC output threshold set @ approximately 21VDC.
+ BAT –
Stand-by battery connections. Connect one (1) 12VDC battery to the terminals
marked [+ BAT –] for 12VDC operation (Fig. 3a, pg. 8).
Use two (2) 12VDC batteries wired in series for 24VDC operation (Fig. 4, pg. 9).
Access Power Controller Terminal Identification:
Terminal Legend Function/Description
– Power + 12VDC or 24VDC input from power supply board.
– Control + Not applicable.
TRIGGER INPUT 1-
INPUT 8 IN, GND
From normally open and/or open collector sink trigger inputs
(request to exit buttons, exit pir’s, etc.).
OUTPUT 1-
OUTPUT 8
NC, C, NO, COM
12VDC to 24VDC trigger controlled outputs:
Fail-Safe [NC positive (+) & COM Negative (–)],
Fail-Secure [NO positive (+) & COM Negative (–)],
Auxiliary output [C positive (+) & COM Negative (–)]
When using AC power supplies polarity needs not to be observed.
NC, C, NO convert to dry form “C” 5A 24VAC/VDC rated dry outputs when fuses
are removed. Contacts shown in a non-triggered state.
FACP INTERFACE
T, + INPUT –
Fire Alarm Interface trigger input from FACP. Trigger inputs can be normally open,
normally closed from an FACP signaling circuit output (Figs. 8-12, pgs. 13-14).
FACP INTERFACE
NC, C, NO Form “C” relay contact rated @ 1A/28VDC for alarm reporting.
Power Supply Board Stand-by Battery Specifications:
Altronix
Model: Power Supply Board Battery 20 Min. of Backup
4 hr. of
Backup
24 hr. of
Backup
Maximal3DV
AL600XB220
(Refer to Fig. 1a, pg. 7 for Switch
[SW1] location and position)
12VDC/40AH* N/A 5.0A N/A
24VDC/40AH* N/A 5.4A 0.7A
Maximal5DV AL1012XB220
(Factory set at 12VDC) 12VDC/12AH 9.0A
Battery capacity
for emergency
stand-by:
at least 20 min.
N/A
Maximal7DV AL1024XB2V
(Factory set at 24VDC)
24VDC/12AH 7.7A 1.2A 200mA
24VDC/65AH* N/A 7.7A 1.2A
*Note: Additional battery enclosure required (Figs. 5-7, pgs. 10-12).

Maximal3DV / Maximal5DV / Maximal7DV Access Power Controllers (PTC) - 7 -
Power Supply Board Output Voltage Settings:
+ DC ---
SW1
OFF - 24V
ON - 12V
ON
Fig. 1a - Maximal3DV Power Supply Board
Fig. 1b
ON
OFF - 24V
ON - 12V
Access Power Controller Typical Application Diagram
(for each ACM8CB):
Fig. 2
NC
NO
C
Normally Open (N.O.)
Door Releasing
Device
Access Control Panel
Output
Relay
Mag.
Lock
MAG.
LOCK
Electric
Strike
Electromagnetic
Door Holders
AC or DC
Power
Supply
(optional)
AC or DC
Power
Supply
(req'd.)
FACP
(Fire Alarm
Control
Panel)
UL Listed
Power Supply
For this application
corresponding
fuse F8 must be
removed.
Keypad
NC C NO COM
OUTPUT 1
LED1
F1
NC C NO COM
OUTPUT 2
IN GND
1
IN GND
2
IN GND
3
IN GND
4
IN GND
5
IN GND
6
IN GND
7
MAIN
IN GND
8
LED2 LED3 LED4 LED5 LED6 LED7 LED8
J2
FACP
NC C NO COM
OUTPUT 3
NC C NO COM
OUTPUT 4
NC C NO COM
OUTPUT 5
NC C NO COM
OUTPUT 6
NO C NC + INP --- T + RET -
NC C NO COM
OUTPUT 7
NC C NO COM
OUTPUT 8
--- +
Power
--- +
Control
F2 F3 F6 F7 F8
F4 F5
J1
J3
FACP INTERFACE
10A 250V
FACP Dry
Form "C" Output
NO C NC
FACP
1 2 3 4
ON
1 2 3 4
ON
Enabled
Disabled
FACP Interface
SW1-SW8
ON
1
ON
1
J2
--- +
Control
J1
Intact = One P/S Input
Cut = Dual P/S Input
NC C NO COM
OUTPUT 8
J3
Intact = DC Input
Cut = AC Input
TRG
FACP
Intact = Dry Input
Cut = Wet Input
LED1 LED2 LED3 LED4 LED5 LED6 LED7 LED8
Fig. 2b
Fig. 2a

- 8 - Maximal3DV / Maximal5DV / Maximal7DV Access Power Controllers (PTC)
Line Neutral
Input
220VAC
50/60Hz
Optional
12VDC Battery*
*12VDC operation:
For 12VDC operation only a single battery is needed.
Connect red battery lead to terminal marked [+ BAT]
and to the [positive (+)] terminal of the battery.
Connect black battery lead to terminal
marked [BAT –] and to the
[negative (–)] terminal
of the battery.
Optional
12VDC Battery*
Tamper Switch
24VDC operation
Wire
Strap
(from
Enclosure
to Door)
+ BAT ---
Optional
12VDC
Battery*
LG N
LOW BAT
NC C NO NC C NO
AC FAIL
--- BAT + --- DC +
Ground Lug
NC C NO COM OUTPUT 1
LED1
F1
NC C NO COM OUTPUT 2
IN GND
1
IN GND
2
IN GND
3
IN GND
4
IN GND
5
IN GND
6
IN GND
7
MAIN
IN GND
8
LED2 LED3 LED4 LED5 LED6 LED7 LED8
J2
TRG
NC C NO COM OUTPUT 3
NC C NO COM OUTPUT 4
NC C NO COM OUTPUT 5
NC C NO COM OUTPUT 6
NO C NC + INP --- T + RET -
NC C NO COM OUTPUT 7
NC C NO COM OUTPUT 8
--- +
Power
--- +
Control
F2 F3 F6 F7 F8
F4 F5
J1
J3
FACP INTERFACE
10A 250V
1 2 3 4
ON
1 2 3 4
ON
LED1 LED2 LED3 LED4 LED5 LED6 LED7 LED8
NC C NO COM OUTPUT 1
LED1
F1
NC C NO COM OUTPUT 2
IN GND
1
IN GND
2
IN GND
3
IN GND
4
IN GND
5
IN GND
6
IN GND
7
MAIN
IN GND
8
LED2 LED3 LED4 LED5 LED6 LED7 LED8
J2
TRG
NC C NO COM OUTPUT 3
NC C NO COM OUTPUT 4
NC C NO COM OUTPUT 5
NC C NO COM OUTPUT 6
NO C NC + INP --- T + RET -
NC C NO COM OUTPUT 7
NC C NO COM OUTPUT 8
--- +
Power
--- +
Control
F2 F3 F6 F7 F8
F4 F5
J1
J3
FACP INTERFACE
10A 250V
1 2 3 4
ON
1 2 3 4
ON
LED1 LED2 LED3 LED4 LED5 LED6 LED7 LED8
Fig. 3 - Maximal3DV and Maximal5DV
Fig. 3a
Fig. 3b
Edge of
Enclosure
to Access Control Panel
or U.L. Listed
Reporting Device
Enclosure
Honeywell
Model 112
Tamper Switch
or equivalent
(Not Included)

Maximal3DV / Maximal5DV / Maximal7DV Access Power Controllers (PTC) - 9 -
Fig. 4 - Maximal7DV
+ DC ------ BAT +
DCAC
5A 250V
15
AC DELAY
15A 32V
BAT FAIL
NC C NO NC C NO
AC FAIL
Power Supply Board
L G N
Line Neutral
Input
220VAC
50/60Hz
Tamper Switch
**24VDC operation: Connect two (2) 12VDC batteries in series
12VDC
Rechargeable
Battery**
(Optional)
12VDC
Rechargeable
Battery**
(Optional)
Ground Lug
NC C NO COM OUTPUT 1
LED1
F1
NC C NO COM OUTPUT 2
IN GND
1
IN GND
2
IN GND
3
IN GND
4
IN GND
5
IN GND
6
IN GND
7
MAIN
IN GND
8
LED2 LED3 LED4 LED5 LED6 LED7 LED8
J2
TRG
NC C NO COM OUTPUT 3
NC C NO COM OUTPUT 4
NC C NO COM OUTPUT 5
NC C NO COM OUTPUT 6
NO C NC + INP --- T + RET -
NC C NO COM OUTPUT 7
NC C NO COM OUTPUT 8
--- +
Power
--- +
Control
F2 F3 F6 F7 F8
F4 F5
J1
J3
FACP INTERFACE
10A 250V
1 2 3 4
ON
1 2 3 4
ON
LED1 LED2 LED3 LED4 LED5 LED6 LED7 LED8
NC C NO COM OUTPUT 1
LED1
F1
NC C NO COM OUTPUT 2
IN GND
1
IN GND
2
IN GND
3
IN GND
4
IN GND
5
IN GND
6
IN GND
7
MAIN
IN GND
8
LED2 LED3 LED4 LED5 LED6 LED7 LED8
J2
TRG
NC C NO COM OUTPUT 3
NC C NO COM OUTPUT 4
NC C NO COM OUTPUT 5
NC C NO COM OUTPUT 6
NO C NC + INP --- T + RET -
NC C NO COM OUTPUT 7
NC C NO COM OUTPUT 8
--- +
Power
--- +
Control
F2 F3 F6 F7 F8
F4 F5
J1
J3
FACP INTERFACE
10A 250V
1 2 3 4
ON
1 2 3 4
ON
LED1 LED2 LED3 LED4 LED5 LED6 LED7 LED8
Fig. 4a
Edge of
Enclosure
to Access Control Panel
or U.L. Listed
Reporting Device
Enclosure
Honeywell
Model 112
Tamper Switch
or equivalent
(Not Included)

- 10 - Maximal3DV / Maximal5DV / Maximal7DV Access Power Controllers (PTC)
NEC Power-Limited Wiring Requirements for Maximal3DV:
Power-limited and non power-limited circuit wiring must remain separated in the cabinet. All power-limited
circuit wiring must remain at least 0.25” away from any non power-limited circuit wiring. Furthermore, all
power-limited circuit wiring and non power-limited circuit wiring must enter and exit the cabinet through differ-
ent conduits. One such example of this is shown below. Your specific application may require different conduit
knockouts to be used. Any conduit knockouts may be used. For power-limited applications use of conduit is
optional. All field wiring connections must be made employing suitable gauge CM or FPL jacketed wire (or
equivalent substitute).
Note: Refer to wire handling drawing below for the proper way to install the CM or FPL jacketed wire (Fig. 5a).
External
Jacketed
Shield
Incorrect Wire
Handling
Correct Wire
Handling
Pull back
external jacketed
shield approx. 1/2”.
Wire
Insulation
Solid Copper
Conductors
Fig. 5
Fig. 5a
Supervisory
Connections
(power-limited)
Input
220VAC, 50/60Hz
(non power-limited)
Optional Battery
Enclosure
(non power-limited)
Battery
Connections
(non power-limited)
ACM8CB
outputs
(non power-
limited)

Maximal3DV / Maximal5DV / Maximal7DV Access Power Controllers (PTC) - 11 -
NEC Power-Limited Wiring Requirements for Maximal5DV:
Power-limited and non power-limited circuit wiring must remain separated in the cabinet. All power-limited
circuit wiring must remain at least 0.25” away from any non power-limited circuit wiring. Furthermore, all
power-limited circuit wiring and non power-limited circuit wiring must enter and exit the cabinet through differ-
ent conduits. One such example of this is shown below. Your specific application may require different conduit
knockouts to be used. Any conduit knockouts may be used. For power-limited applications use of conduit is
optional. All field wiring connections must be made employing suitable gauge CM or FPL jacketed wire (or
equivalent substitute).
Note: Refer to wire handling drawing below for the proper way to install the CM or FPL jacketed wire (Fig. 6a).
External
Jacketed
Shield
Incorrect Wire
Handling
Correct Wire
Handling
Pull back
external jacketed
shield approx. 1/2”.
Wire
Insulation
Solid Copper
Conductors
Fig. 6
Fig. 6a
Supervisory
Connections
(power-limited)
Input
220VAC, 50/60Hz
(non power-limited)
Optional Battery
Enclosure
(non power-limited)
Battery
Connections
(non power-limited)
ACM8CB
outputs
(non power-
limited)

- 12 - Maximal3DV / Maximal5DV / Maximal7DV Access Power Controllers (PTC)
NEC Power-Limited Wiring Requirements for Maximal7DV:
Power-limited and non power-limited circuit wiring must remain separated in the cabinet. All power-limited
circuit wiring must remain at least 0.25” away from any non power-limited circuit wiring. Furthermore, all
power-limited circuit wiring and non power-limited circuit wiring must enter and exit the cabinet through differ-
ent conduits. One such example of this is shown below. Your specific application may require different conduit
knockouts to be used. Any conduit knockouts may be used. For power-limited applications use of conduit is
optional. All field wiring connections must be made employing suitable gauge CM or FPL jacketed wire (or
equivalent substitute).
Note: Refer to wire handling drawing below for the proper way to install the CM or FPL jacketed wire (Fig. 7a).
External
Jacketed
Shield
Incorrect Wire
Handling Correct Wire Handling
Pull back
external jacketed
shield approx. 1/2”.
Wire
Insulation
Solid Copper
Conductors
Fig. 7a
Supervisory
Connections
(power-limited)
Input
220VAC, 50/60Hz
(non power-limited)
Optional Battery
Enclosure
(non power-limited)
Battery
Connections
(non power-limited)
ACM8CB
outputs
(non power-
limited)
Fig. 7

Maximal3DV / Maximal5DV / Maximal7DV Access Power Controllers (PTC) - 13 -
CUT
JUMPER
FROM FACP
OUTPUT
CIRCUIT
+
--
FACP
OUTPUT EOL
TRG
NO C NC
FACP INTERFACE
FACP Hook-Up Diagrams:
Fig. 8 Polarity reversal input from FACP signaling circuit output (polarity is referenced in alarm condition):
N.O. TRIGGER
INPUT
TRG
NO C NC
FACP INTERFACE
Fig. 9 Normally Open - Non-Latching FACP trigger input:
N.C. RESET
SWITCH
N.O.
TRIGGER
INPUT
JUMPER
TRG
NO C NC
Fig. 10 Normally Open FACP Latching trigger input with reset:

- 14 - Maximal3DV / Maximal5DV / Maximal7DV Access Power Controllers (PTC)
JUMPER
N.C. DR
Y
TRIGGER
INPUT
TRG
NO C NC
FACP INTERFACE
Fig. 11 Normally Closed - Non-Latching FACP trigger input:
N.C. TRIGGER
INPUT
N.C. RESET
SWITCH
JUMPER
TRG
Fig. 12 Normally Closed - Latching FACP trigger input with reset:
FACP Hook-Up Diagrams (cont’d):

Maximal3DV / Maximal5DV / Maximal7DV Access Power Controllers (PTC) - 15 -
Notes:

- 16 - Maximal3DV / Maximal5DV / Maximal7DV Access Power Controllers (PTC)
Enclosure Dimensions (H x W x D approximate):
26” x 19” x 6.25” (660.4mm x 482.6mm x 158.8mm)
TOP
LEFT RIGHT
BOTTOM
1.25”
(31.75mm)
1.25”
(31.75mm)
1.25”
(31.75mm)
0.85”
(21.59mm)
0.85”
(21.59mm)
1”
(25.4mm)
0.85”
(21.59mm)
1”
(25.4mm)
0.85”
(21.59mm)
8.9”
(226.06mm)
19”
(482.6mm)
19”
(482.6mm)
19”
(
482.6mm
)
2”
(50.8mm)
2”
(50.8mm)
2”
(50.8mm)
6.25”
(158.75mm)
6.25”
(158.75mm)
4”
(101.6mm)
4”
(101.6mm)
2”
(50.8mm)
4”
(101.6mm)
8.9”
(226.06mm)
8.4”
(213.36mm)
7”
(177.8mm)
7”
(177.8mm)
7”
(177.8mm)
8.4”
(213.36mm)
8.5”
(215.9mm)
8.5”
(215.9mm)
7.5”
(190.5mm)
10”
(254mm)
1.5”
(38.1mm)
1.5”
(38.1mm)
1.5”
(38.1mm)
26”
(660.4mm)
26”
(660.4mm)
7.5”
(190.5mm)
5”
(127mm)
26”
(660.4mm)
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA | phone: [phone] | fax: [phone]
website: www.altronix.com | e-mail: [email protected] | Lifetime Warranty | Made in U.S.A.
IIMaximal3DV/5DV/7DV Series G26R MEMBER
