MaxLite FLS Series User manual

Operating Instructions FLS Series
MaxLite LED Small Floo Fixtures
• To reduce the risk of death, personal injury or property damage from
fire, electric shock, falling parts, cuts/abrasions, and other hazards
read all warnings and instructions included with and on the fixture
box and all fixture labels.
• Before installing, servicing, or performing routine maintenance upon
this equipment, follow these general precautions.
• Commercial installation, service and maintenance of luminaires
should be performed by a qualified licensed electrician.
• For Residential installation: If you are unsure about the installation or
maintenance of the luminaires, consult a qualified licensed electrician
and check your local electrical code.
• DO NOT INSTALL DAMAGED PRODUCT!
• This fixture is intended to be connected to a properly installed and
grounded UL listed junction box.
WARNING:
• Risk of Fire - Supply conductors (power wires) connecting the fixture
must be rated minimum 90. If uncertain consult an electrician.
• Risk of fire or electric shock. installation requires knowledge of
luminaires electrical systems.
• Risk of Fire/Electric Shock - If not qualified, do not attempt installation. Contact a qualified electrician.
• Do not use in high humidity conditions.
• Keep away from flammable and explosive environment.
• Don’t cover the fixture with insulation liner or similar material.
• Don’t install where fixture is loose or only partially supported.
• Don’t impact or exert pressure on the fixture surface face or rear, as damage may occur.
CAUTION:
• For your safety read and understand instructions completely before starting installation.
• To prevent wiring damage or abrasion, do not expose wiring to edges of sheet metal or other sharp
objects.
• Before attempting installation, check your local electrical code, as it
sets the wiring standards for your locality.
NOTES:
• If luminaire (fixture) is to be switched from a wall switch, make sure black power supply wire is
connected to the switch. DO NOT connect the white supply wire to the switch.
• Make certain no bare wires are exposed outside the wire nut connectors.
• Do not make or alter any open holes in an enclosure of wiring or electrical components during
kit installation.
Mo el:
FLSxx/G2 Series
Operating characteristics:
Operating temperature: -30°C to 40°C
Input voltage range: 120-277V 50/60 HZ
Page: 1
REV: 8/02/18
®
Picture is for illustration purposes only.
Your model may vary.
General Safety Information

1.) Inspect components to ensure that male and
female port threads and sealing surfaces are free
of burs, nicks and scratches or any foreign material.
2.) Thread fixture into flat mounting
surface (Fig. 1). Please see detailed diagrams of
mounting trunnions below (Fig. 2).
Installation Instructions
Operating Instructions FLS Series
MaxLite LED Small Floo Fixtures
®
3.) Using a wrench, adjust luminaire to desired
aiming angle and tighten screw (Fig. 3)
4.) Inspect to ensure that the screw is seated flat
on the mounting surface.
5.) Connect power to fixture (Fig. 4), referencing
wiring diagram below. Make sure the power
supply is disconnected before installing.
Page: 2
REV: 8/02/18
15W/20W 40W
50W

Operating Instructions FLS Series
MaxLite LED Small Floo Fixtures
®
Page: 3
REV: 8/02/18
Installation Instructions (Continue )
WARNING:
For models with photocell, please make sure the photocell is on the top.
CORRECT:
WRONG:
6.) For models with a photocell: Remove black sensor cap to use the photocell. If no photocell
is needed the cap can be left in place.

Operating Instructions FLS Series
MaxLite LED Small Floo Fixtures
®
Page: 4
REV: 8/02/18
MaxLite Inc. warrants its products for a minimum period of FIVE (5) years from the date of original purchase from
MaxLite or its authorized distributor/dealer (the “Warranty Period”), as follows: If a Product fails to operate during the
Warranty Period as a result of defects in materials or workmanship, MaxLite will, at its option, repair it, replace it with
the same or like Product.
Limitation of Liability
THE FOREGOING WARRANTY IS EXCLUSIVE, AND IS THE SOLE REMEDY FOR ANY AND ALL CLAIMS,
WHETHER IN CONTRACT, IN TORT OR OTHERWISE ARISING FROM THE FAILURE OF PRODUCT AND IS IN
LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ALL WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, WHICH WARRANTIES ARE HEREBY
EXPRESSLY DISCLAIMED TO THE EXTENT PERMITTED BY LAW AND, IN ANY EVENT, SHALL BE LIMITED TO
THE WARRANTY PERIOD SPECIFIED ABOVE. THE LIABILITY OF MAXLITE SHALL BE LIMITED TO THE TERMS
OF THE EXPRESS WARRANTY SET FORTH HEREIN. IN NO EVENT WILL MAXLITE BE LIABLE FOR ANY
SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES INCLUDING, WITHOUT LIMITATION, DAMAGES
RESULTING FROM LOSS OF USE, PROFITS, BUSINESS OR GOODWILL, LABOR COSTS, REMOVAL OR
INSTALLATION COSTS, DECREASE IN THE LIGHT OUTPUT OF THE LAMP, AND/OR DETERIORATION IN THE
LAMP’S PERFORMANCE, WHETHER OR NOT MAXLITE HAS BEEN ADVISED OF THE POSSIBILITY THEREOF.
UNDER NO CIRCUMSTANCES SHALL MAXLITE’S ENTIRE LIABILITY FOR A DEFECTIVE PRODUCT EXCEED
THE PURCHASE PRICE OF THAT PRODUCT. WARRANTY SERVICES PROVIDED UNDER THESE TERMS AND
CONDITIONS DO NOT ENSURE THE UNINTERRUPTED OPERATION OF PRODUCTS; MAXLITE SHALL NOT BE
LIABLE FOR DAMAGES CAUSED BY ANY DELAYS INVOLVING WARRANTY SERVICE.
This Limited Warranty gives you specific legal rights and you may also have other rights that may vary from state to
state. Because some states or jurisdictions do not allow the exclusion or limitation of liability for consequential or
incidental damages, this limitation may not apply to you.
Warranty Information
