MaxLite ModMAX 97374 User manual

Operating Instructions ModMAX Series
MaxLite LED ModMAX Fixtures
Page: 1
REV: 1/11/17
®
• To reduce the risk of death, personal injury or property damage from fire,
electric shock, falling parts, cuts/abrasions, and other hazards read all
warnings and instructions included with and on the fixture box and all
fixture labels.
• Before installing, servicing, or performing routine maintenance upon
this equipment, follow these general precautions.
• Commercial installation, service and maintenance of luminaires
should be performed by a qualified licensed electrician.
• For Residential installation: If you are unsure about the installation
or maintenance of the luminaires, consult a qualified licensed electrician
and check your local electrical code.
• DO NOT INSTALL DAMAGED PRODUCT!
• This fixture is intended to be connected to a properly installed and
grounded UL listed junction box.
WA NING:
RIS OF ELECTRICALSHOC
• Turn off electrical power at fuse or circuit breaker box before wiring fixture
to the power supply.
• Turn off the power when you perform any maintenance.
• Verify that supply voltage is correct by comparing it with the luminaire label
information.
• Make all electrical and grounded connections in accordance with the National Electrical
Code and any applicable local code requirements.
• All wiring connections should be capped with UL approved wire connectors.
CAUTION:
RIS OF INJURY
• Wear gloves and safety glasses at all times when removing luminaire from carton, installing,
servicing or performing maintenance.
• Avoid direct eye exposure to the light source while it is on.
• Account for small parts and destroy packing material, as these may be hazardous to children.
CAUTION:
RIS OF FIRE
• eep combustible and other materials that can burn away from luminaire and lamp/lens.
• MIN 90°C SUPPLY CONDUCTORS.
Input ating: 120V-277V 50/60Hz
Operating Temperature: -22°F to 122°F
Wet Location ated
General Safety Information
Illustrations on the manual are for
installation purposes only. It may not
be identical to the fixture purchased.
© Copyright 2017. MaxLite, Inc. All Rights Reserved.
12 York Ave, West Caldwell, NJ 07006 Tel: [phone] Fax: [phone] Email: [email protected]

Operating Instructions ModMAX Series
MaxLite LED ModMAX Fixtures
®
General Wiring Diagram
210W:
420W:
WA NING:
1. All driver units must be individually connected to the AC supply (120-277 VAC):
Black = Line
White = Neutral
Green = Ground
2. Line connection to be made to switch lead from source.
Page: 2
REV: 1/11/17
© Copyright 2017. MaxLite, Inc. All Rights Reserved.
12 York Ave, West Caldwell, NJ 07006 Tel: [phone] Fax: [phone] Email: [email protected]

Operating Instructions ModMAX Series
MaxLite LED ModMAX Fixtures
®
General Wiring Diagram
630W:
Flood Mount Installation
Main Flood Mount Bracket Orientation Instructions:
Ensure that the main flood bracket is attached facing
the correct direction (Fig. 4). If the direction is incorrect,
remove the M10X20 wrench bolts and M10 internal tooth
washers connecting the main bracket to the two side
brackets (Fig. 5). Turn the main bracket 180 degrees, then
reconnect it to the side brackets using the M10X20 wrench
bolts and M10 internal tooth washers.
*Fig. 4 & 5 show 630w model.
Page: 3
REV: 1/11/17
© Copyright 2017. MaxLite, Inc. All Rights Reserved.
12 York Ave, West Caldwell, NJ 07006 Tel: [phone] Fax: [phone] Email: [email protected]

Flood Mount Installation
Leveling Instructions:
For Side Bracket Leveling:
Use an M10 hex wrench to loosen the M10X20 wrench bolts that
fasten the left and right side brackets to the main flood mounting
bracket. Rotate the side brackets until the desired orientation is
achieved. The range of rotation is determined by the banana slots.
Lock the side brackets in place by tightening the M10X20 wrench
bolts (Fig. 6). Ensure all wrench bolts are tightened. The 420W
version is shown in Fig. 6. Other wattages have differently shaped
side brackets, but follow the same steps.
For Module Leveling:
Use an M10 hex wrench to loosen the M10X20 wrench
bolts that fasten the modules to the side brackets. Rotate
the modules until the desired orientations are achieved.
The range of rotation is determined by the banana slots.
Lock the modules in place by tightening the M10x20
wrench bolts (Fig. 7). Ensure all wrench bolts are
tightened. The 420 W version is shown in Fig. 7. Other
wattages have differently shaped side brackets, but
follow the same steps.
Operating Instructions ModMAX Series
MaxLite LED ModMAX Fixtures
®
Flood Mounting Instructions
1. Drill holes for mounting using template below:
Page: 4
REV: 1/11/17
© Copyright 2017. MaxLite, Inc. All Rights Reserved.
12 York Ave, West Caldwell, NJ 07006 Tel: [phone] Fax: [phone] Email: [email protected]

Flood Mounting Instructions
Operating Instructions ModMAX Series
MaxLite LED ModMAX Fixtures
®
2. Use appropriate bolt size to mount either method. Secure and torque per selected bolt
specifications (Fig. 9 & 10)
3. Follow connecting power procedures after mounting.
4. Restore power.
Highbay Mount Installation:
Leveling Instructions:
For Module Leveling:
Use an M10 hex wrench to loosen the M10X20 wrench bolts that fasten the modules to the side
bracket. Rotate the modules until the desired orientations are achieved. The range of rotation is
determined by the banana slots. Lock the modules in place by tightening the M10X20 wrench
bolts (Fig. 11).The 420 W version is shown in Fig. 11. Other wattages have differently shaped
side brackets, but follow the same steps. Ensure all wrench bolts are tightened.
Page: 5
REV: 1/11/17
© Copyright 2017. MaxLite, Inc. All Rights Reserved.
12 York Ave, West Caldwell, NJ 07006 Tel: [phone] Fax: [phone] Email: [email protected]

420W Highbay Mount Installation:
Operating Instructions ModMAX Series
MaxLite LED ModMAX Fixtures
®
Highbay Mounting Instructions:
1. Drill holes for mounting using template below:
2. Use appropriate bolt size to mount either method. Secure and torque per selected bolt specifications
(Fig. 13 & 14).
3. Follow connecting power procedures after mounting.
4. Restore power.
Page: 6
REV: 1/11/17
© Copyright 2017. MaxLite, Inc. All Rights Reserved.
12 York Ave, West Caldwell, NJ 07006 Tel: [phone] Fax: [phone] Email: [email protected]

Page: 7
REV: 1/11/17
© Copyright 2017. MaxLite, Inc. All Rights Reserved.
12 York Ave, West Caldwell, NJ 07006 Tel: [phone] Fax: [phone] Email: [email protected]
Pole Mount Instructions
1. Use four 5/16”x1-1/4” bolts, with lock washers, flat washers, and hex lock nuts to secure the main
flood bracket to the Pole Mount Tenon Bracket: (Fig. 15)
Operating Instructions ModMAX Series
MaxLite LED ModMAX Fixtures
®
2. Feed the power supply cable from the fixture through the cable gland in the pole mount bracket, and
tighten the cable gland (Fig. 16). Make wiring connections inside the pole following Fig. 1/2/3.

Page: 8
REV: 1/11/17
© Copyright 2017. MaxLite, Inc. All Rights Reserved.
12 York Ave, West Caldwell, NJ 07006 Tel: [phone] Fax: [phone] Email: [email protected]
Operating Instructions ModMAX Series
MaxLite LED ModMAX Fixtures
®
Pole Mount Instructions
3. Place the fixture/pole mount bracket assembly onto the pole and fix it in place using the six M8 set
screws on the sides of the pole mount bracket. (Fig. 17)
4. Restore Power.

Operating Instructions ModMAX Series
MaxLite LED ModMAX Fixtures
®
© Copyright 2017. MaxLite, Inc. All Rights Reserved.
12 York Ave, West Caldwell, NJ 07006 Tel: [phone] Fax: [phone] Email: [email protected]
MaxLite Inc. warrants its products for a minimum period of FIVE (5) years from the date of original purchase from
MaxLite or its authorized distributor/dealer (the “Warranty Period”), as follows: If a Product fails to operate during the
Warranty Period as a result of defects in materials or workmanship, MaxLite will, at its option, repair it, replace it with
the same or like Product.
Please refer to Maxlite’s website (at http://maxlite.com/resources/warranties) for the complete
terms and conditions of our warranty.
Limitation of Liability
THE FOREGOING WARRANTY IS EXCLUSIVE, AND IS THE SOLE REMEDY FOR ANY AND ALL CLAIMS,
WHETHER IN CONTRACT, IN TORT OR OTHERWISE ARISING FROM THE FAILURE OF PRODUCT AND IS IN
LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ALL WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, WHICH WARRANTIES ARE HEREBY
EXPRESSLY DISCLAIMED TO THE EXTENT PERMITTED BY LAW AND, IN ANY EVENT, SHALL BE LIMITED TO
THE WARRANTY PERIOD SPECIFIED ABOVE. THE LIABILITY OF MAXLITE SHALL BE LIMITED TO THE TERMS
OF THE EXPRESS WARRANTY SET FORTH HEREIN. IN NO EVENT WILL MAXLITE BE LIABLE FOR ANY
SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES INCLUDING, WITHOUT LIMITATION, DAMAGES
RESULTING FROM LOSS OF USE, PROFITS, BUSINESS OR GOODWILL, LABOR COSTS, REMOVAL OR
INSTALLATION COSTS, DECREASE IN THE LIGHT OUTPUT OF THE LAMP, AND/OR DETERIORATION IN THE
LAMP’S PERFORMANCE, WHETHER OR NOT MAXLITE HAS BEEN ADVISED OF THE POSSIBILITY THEREOF.
UNDER NO CIRCUMSTANCES SHALL MAXLITE’s ENTIRE LIABILITY FOR A DEFECTIVE PRODUCT EXCEED
THE PURCHASE PRICE OF THAT PRODUCT. WARRANTY SERVICES PROVIDED UNDER THESE TERMS AND
CONDITIONS DO NOT ENSURE THE UNINTERRUPTED OPERATION OF PRODUCTS; MAXLITE SHALL NOT BE
LIABLE FOR DAMAGES CAUSED BY ANY DELAYS INVOLVING WARRANTY SERVICE.
This Limited Warranty gives you specific legal rights and you may also have other rights that may vary from state to
state. Because some states or jurisdictions do not allow the exclusion or limitation of liability for consequential or
incidental damages, this limitation may not apply to you.
Page: 9
REV: 1/11/17
Warranty Information
