MaxLite CPL Series User manual

• To reduce the risk of death, personal injury or property damage from
fire, electric shock, falling parts, cuts/abrasions, and other hazards
read all warnings and instructions included with and on the fixture
box and all fixture labels.
• Before installing, servicing, or performing routine maintenance upon
this equipment, follow these general precautions.
• Commercial installation, service and maintenance of luminaires
should be performed by a qualified licensed electrician.
• DO NOT INSTALL DAMAGED PRODUCT!
• This fixture is intended to be connected to a properly installed and
grounded UL listed junction box.
WARNING:
RISK OF ELECTRICAL SHOCK
• Turn off electrical power at fuse or circuit breaker box before wiring fixture to the power supply.
• Turn off the power when you perform any maintenance.
• Verify that supply voltage is correct by comparing it with the luminaire label information.
• Make all electrical and grounded connections in accordance with the National Electrical Code
and any applicable local code requirements.
• All wiring connections should be capped with UL approved wire connectors.
CAUTION:
RISK OF INJURY
• Wear gloves and safety glasses at all times when removing luminaire from carton, installing, servicing
or performing maintenance.
• Avoid direct eye exposure to the light source while it is on.
• Account for small parts and destroy packing material, as these may be hazardous to children.
CAUTION:
RISK OF FIRE
• Keep combustable and other materials that can burn away from luminaire and lamp/lens
• Do not mount to flammable or combustible surfaces.
• MIN 75°C SUPPLY CONDUCTORS.
Input Rating: 120V-277V 50/60Hz
Operating Temperature: -40°F to 104°F
Models:
CPL Series
Operating Instructions CPL Series
MaxLite LED Low-Profile Parking Garage & Canopy Luminaire
®
Picture is for illustration purposes
only. Your model may vary.
General Safety Information
© Copyright 2023. MaxLite, Inc. All Rights Reserved.
340 Changebridge Rd, STE 201, Pine Brook, NJ 07058 Tel: [phone] Fax: [phone] Email: [email protected]
Page: 1
REV: 04/17/23

General Wiring Diagram
Operating Instructions CPL Series
MaxLite LED Low-Profile Parking Garage & Canopy Luminaire
®
CAUTION: Turn off electrical power at fuse or circuit breaker box before wiring
fixture to the power supply.
Connecting panels to AC source supply:
All units must be individually connected to
the AC supply.
Black = Line
White = Neutral
Green = Ground
CCT Selectable Models CCT & Wattage Selectable Model
© Copyright 2023. MaxLite, Inc. All Rights Reserved.
340 Changebridge Rd, STE 201, Pine Brook, NJ 07058 Tel: [phone] Fax: [phone] Email: [email protected]
Page: 2
REV: 04/17/23

Operating Instructions CPL Series
MaxLite LED Low-Profile Parking Garage & Canopy Luminaire
®
CCT and Wattage Switch
1. Unfasten the M6x20MM hex screw with an Allen wrench and open the fixture. (Fig. 1, Fig. 2)
2. Select the desired CCT and Wattage level (Fig. 3)
Note: Wattage switch on model CPL60UWCSBCR Only
3. Close the fixture and secure it with the hex screw loosened in step 1. (Fig. 4)
© Copyright 2023. MaxLite, Inc. All Rights Reserved.
340 Changebridge Rd, STE 201, Pine Brook, NJ 07058 Tel: [phone] Fax: [phone] Email: [email protected]
Page: 3
REV: 04/17/23

Operating Instructions CPL Series
MaxLite LED Low-Profile Parking Garage & Canopy Luminaire
®
Installation
Surface Mount:
1. Unfasten and remove the screw from the surface
mount plate. (Fig. 1)
2. Slide the surface mount plate out and up to remove it
from the fixture. The metal ring needs to be removed
from the metal bracket holding it in place. (Fig. 2)
3. Mount the surface mount plate onto the J-box. (Fig. 3)
4. Secure the fixture onto the surface mount plate by sliding
the metal ring back into place under the metal bracket on
the fixture. (Fig. 4)
5. Wire fixture (according to diagram above.)
6. Lift the fixture and slide it back into place, secure it to
the surface mount plate with the screw removed in
step 1. (Fig. 5)
© Copyright 2023. MaxLite, Inc. All Rights Reserved.
340 Changebridge Rd, STE 201, Pine Brook, NJ 07058 Tel: [phone] Fax: [phone] Email: [email protected]
Page: 4
REV: 04/17/23

Installation
Pendant Mount:
1. Remove the 3/4" NPT plug. (Fig. 1)
Note: Before screwing the pipe into the fixture, add one (1) washer nut onto the pipe.
Screw the pipe into the fixture and feed the wires through it. (Fig. 2)
3. Secure the pipe by tightening the washer nut. (Fig. 2)
Operating Instructions CPL Series
MaxLite LED Low-Profile Parking Garage & Canopy Luminaire
®
© Copyright 2023. MaxLite, Inc. All Rights Reserved.
340 Changebridge Rd, STE 201, Pine Brook, NJ 07058 Tel: [phone] Fax: [phone] Email: [email protected]
Page: 5
REV: 04/17/23

Operating Instructions CPL Series
MaxLite LED Low-Profile Parking Garage & Canopy Luminaire
®
c-Max Installation Instructions
1. Unfasten the M6x20MM hex screw with an Allen wrench and open the fixture. (Fig. 1, Fig. 2)
2. Remove the silicone plug from the USB-C receptacle. (Fig. 3)
3. Install the sensor and secure it with the screw included with it. (Fig. 4, Fig. 5)
4. Replace the silicone plug over the screw on the sensor. (Fig. 6)
© Copyright 2023. MaxLite, Inc. All Rights Reserved.
340 Changebridge Rd, STE 201, Pine Brook, NJ 07058 Tel: [phone] Fax: [phone] Email: [email protected]
Page: 6
REV: 04/17/23

Operating Instructions CPL Series
MaxLite LED Low-Profile Parking Garage & Canopy Luminaire
®
CCT Selectable Models With EM
CCT & Wattage Selectable Model With EM
© Copyright 2023. MaxLite, Inc. All Rights Reserved.
340 Changebridge Rd, STE 201, Pine Brook, NJ 07058 Tel: [phone] Fax: [phone] Email: [email protected]
Page: 7
REV: 04/17/23

Operating Instructions CPL Series
MaxLite LED Low-Profile Parking Garage & Canopy Luminaire
®
EM Installation (Model Numbers with Suffix -E2)
1. Use a flat head screwdriver to remove the knockout cap from the back of the EM extension box (Fig. 1).
2. Remove the twelve (12) M4 hex head screws and set aside for later use. Separate the fixture and EM
extension cover from the EM extension box (Fig. 2).
3. Drill mounting holes in the EM extension box in the four (4) corners of the extension box.
4. Drill through the raised hole locations on the junction box template in the center of the box that correspond to
the mounting points on the intended junction box. (Fig. 3).
5. Fasten the EM extension box to the junction box with screws, and secure it to the ceiling using four (4) bolts in
the four drilled locations from step 3.
6. Pull the input wires through the hole in the back of the EM extension box and wire the fixture according to the
wiring diagrams above.
7. Place the EM extension cover and canopy fixture back in place and secure it with the twelve (12) M4 screws
removed in step 1 (Fig. 4).
© Copyright 2023. MaxLite, Inc. All Rights Reserved.
340 Changebridge Rd, STE 201, Pine Brook, NJ 07058 Tel: [phone] Fax: [phone] Email: [email protected]
Page: 8
REV: 04/17/23

Operating Instructions CPL Series
MaxLite LED Low-Profile Parking Garage & Canopy Luminaire
®
Visual Comfort Lens Installation (Optional Accessory)
1. Attach the Visual Comfort lens to the four (4) corners of the fixture and secure it with the four (4) included screws.
15" Beauty Plate Dimensions (Optional Accessory)
© Copyright 2023. MaxLite, Inc. All Rights Reserved.
340 Changebridge Rd, STE 201, Pine Brook, NJ 07058 Tel: [phone] Fax: [phone] Email: [email protected]
Page: 9
REV: 04/17/23

MaxLite Inc. warrants its products for a minimum period of TEN (10) years from the date of original purchase from
MaxLite or its authorized distributor/dealer (the “Warranty Period”), as follows: If a Product fails to operate during the
Warranty Period as a result of defects in materials or workmanship, MaxLite will, at its option, repair it, replace it with
the same or like Product.
Please refer to Maxlite’s website (at http://maxlite.com/resources/warranties) for the complete
terms and conditions of our warranty.
Limitation of Liability
THE FOREGOING WARRANTY IS EXCLUSIVE, AND IS THE SOLE REMEDY FOR ANY AND ALL CLAIMS,
WHETHER IN CONTRACT, IN TORT OR OTHERWISE ARISING FROM THE FAILURE OF PRODUCT AND IS IN
LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ALL WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, WHICH WARRANTIES ARE HEREBY
EXPRESSLY DISCLAIMED TO THE EXTENT PERMITTED BY LAW AND, IN ANY EVENT, SHALL BE LIMITED TO
THE WARRANTY PERIOD SPECIFIED ABOVE. THE LIABILITY OF MAXLITE SHALL BE LIMITED TO THE TERMS
OF THE EXPRESS WARRANTY SET FORTH HEREIN. IN NO EVENT WILL MAXLITE BE LIABLE FOR ANY
SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES INCLUDING, WITHOUT LIMITATION, DAMAGES
RESULTING FROM LOSS OF USE, PROFITS, BUSINESS OR GOODWILL, LABOR COSTS, REMOVAL OR
INSTALLATION COSTS, DECREASE IN THE LIGHT OUTPUT OF THE LAMP, AND/OR DETERIORATION IN THE
LAMP’S PERFORMANCE, WHETHER OR NOT MAXLITE HAS BEEN ADVISED OF THE POSSIBILITY THEREOF.
UNDER NO CIRCUMSTANCES SHALL MAXLITE’S ENTIRE LIABILITY FOR A DEFECTIVE PRODUCT EXCEED
THE PURCHASE PRICE OF THAT PRODUCT. WARRANTY SERVICES PROVIDED UNDER THESE TERMS AND
CONDITIONS DO NOT ENSURE THE UNINTERRUPTED OPERATION OF PRODUCTS; MAXLITE SHALL NOT BE
LIABLE FOR DAMAGES CAUSED BY ANY DELAYS INVOLVING WARRANTY SERVICE.
This Limited Warranty gives you specific legal rights and you may also have other rights that may vary from state to
state. Because some states or jurisdictions do not allow the exclusion or limitation of liability for consequential or
incidental damages, this limitation may not apply to you.
