MAXPhotonics MFSC 3000W Series User manual

Maxphotonics Co.,Ltd.
MFSC 3000W-4000W CW Fiber Laser Series

Copyright Notation
Copyright © Maxphotonics Co., Ltd (hereafter referred to as
Maxphotonics). All rights reserved. You may not copy, modify, transmit or
publish this publication, in any form, in any media or by any means, without
the prior written permission of Maxphotonics, except as allowed under
applicable copyright laws. Permitted copies shall bear the same copyright
and proprietary notices that were contained on the original version.
Maxphotonics believes that the information provided is accurate and
reliable; however Maxphotonics makes no warranty, representation,
expression or implication that this document can be used as reference
in other occasions. Furthermore, Maxphotonics does not assume
responsibility for any infringement of patents or other rights of third parties
due to use of the information contained in this document. Maxphotonics
shall not be liable for errors contained in this document or for direct or
indirect damages of relevant equipment.
Maxphotonics and the Maxphotonics Logo are registered trademarks of
Maxphotonics Co., Ltd., and the Logo does not break any regulations
of Trademark law.Maxphotonics grants no rights for patent or other
intellectual property mentioned herein.
All information contained in this document is subject to change and
revision without notice.
Subject to change without notice.
Maxphotonics Co.,Ltd.
Address: Maxphotonics Industrial Park, 3rd Furong Road,
Furong Industrial Area, Shajing, Baoan, Shenzhen, China.518125
E-Mail: [email protected]
http://en.maxphotonics.com

1
Preface
Thank you for using the MFMC Series CW fiber laser from Maxphotonics.
We compile this document for you in order that the laser is used and
maintained properly. Due to the limited level of the writers, coupled with
time constraints, there are some careless mistakes in this document, your
understanding and suggestion to help us make an improvement will be
much appreciated . Thank you again for using Maxphotonics' products.
Please take time to read and understand this User's Guide and familiarize
yourself with the operating and maintenance instructions before you use
the product. We strongly recommend that the operator read the Section 2
titled “Safety Information” prior to operating the product.
This User's Guide should stay with the product to provide you and all future
users and owners of the product with important operating, safety and other
information.
We identify the parts to which you need to pay special attention in the
document with underscore. Please notice those information to prevent the
unnecessary damages.

2
Company Profile
As a large laser manufacturer founded in 2004, Maxphotonics Co., Ltd.
specializes in research and development, production and sales of lasers
and ancillary products. Maxphotonics owns a number of independent
intellectual property rights and patents as well as high-power pulsed fiber
laser, high-power fiber laser and high-power fiber amplifier etc.
So far, with intellectual property rights and patents, Maxphotonics owns
industrial pulsed fiber laser series, CW fiber laser series,QCW laser
series,fiber laser for scientific researches, tunable fiber laser, fiber
amplifier, ASE light source, etc. Those products are widely applied to fields
of laser marking, 3D print，DTS system and scientific research.
Maxphotonics offers laser, relevant solution and ancillary facility to
domestic and foreign customers. We adhere to the enterprise mission
statement of ''Maxphotonics leads the industry'', take customer satisfaction
as the start point, completely implement ISO9001 quality management
system, introduce ERP information management system and provide all-
round pre-sales and after-sales service for customers.
Relying on excellent ability of product design and development, we carry
out all-round exchanges and cooperation with international famous
laser companies and various research institutions of China, continuously
increase the investment of science research, constantly update
diversification of production types, lead the trend of the industry and create
maximum value for customers, so as to strive perseveringly for the world-
class laser manufactures and forge ahead.
More informations，please visit our website：
http://en.maxphotonics.com

CONTENT 3
Company Profile ……………………………………………………………… 2
Chapter 1 Characteristic Description ………………………………… 5
Chapter 2 General Safety Information ……………………………… 6
1-Safety Conventions ………………………………………………………… 6
2-Laser Protection …………………………………………………………… 7
3-Reference Standard ……………………………………………………… 8
4-General Safety Instructions ……………………………………………… 9
5-Additional Safety Information …………………………………………… 14
Chapter 3 Product Description ………………………………………… 15
1-Features ……………………………………………………………………… 15
2-Module Configuration ……………………………………………………… 15
3-Laser Model Designation Codes ……………………………………… 15
4-Certification ………………………………………………………………… 16
5-Front Panel Description …………………………………………………… 16
6-Back Panel Description …………………………………………………… 17
7-Optical Output Terminal …………………………………………………… 17
Chapter 4 Specification …………………………………………………… 18
1-Optical Characteristic Parameters ……………………………………… 18
2-General Characteristic Parameters …………………………………… 19
3-Water Cooling Condition ………………………………………………… 20
4-Structural Layout …………………………………………………………… 21

CONTENT
4
Chapter 5 Unpacking Guide ……………………………………………… 22
1-Unpacking Steps …………………………………………………………… 22
2-Packing List ………………………………………………………………… 24
Chapter 6 Operation Guide ……………………………………………… 25
1-Notice ………………………………………………………………………… 25
2-Electrical Power Connection …………………………………………… 25
3-Extension Interface ………………………………………………………… 25
4-Start Steps …………………………………………………………………… 27
5-Mode Description …………………………………………………………… 27
6-Monitor Software …………………………………………………………… 28
7-Error List ……………………………………………………………………… 28
Chapter 7 Fiber Connector Inspection and Cleaning Guide …… 30
1-Notice ………………………………………………………………………… 30
2-Operating Procedures …………………………………………………… 31
Chapter 8 Service and Maintenance ………………………………… 35
1-Maintenance Notes ………………………………………………………… 35
2-Service Statements ………………………………………………………… 36
Chapter 9 Warranty Statements………………………………………… 37
1-General Items ……………………………………………………………… 37
2-Warranty Limitations ……………………………………………………… 37

5
MFSC Series CW Fiber Laser products provide a wide range of
wavelength from 1060nm to 1100nm.The lasers are water-cooled and
maintenance-free and with a wall plug efficiency of more than 30% and
deliver high efficiency, high reliability and high performance.
Maxphotonics' MFSC Series CW Fiber Laser Series are Class 4 laser
products and are designed and tested with safety. By following this User
Guide and applying sound laser safety practices, it will be a safe and
reliable device.
Laser light exhibits unique characteristics that may pose safety hazards.
Therefore, the laser light can’t be normally associated with other light
sources, and all operators and people near the laser must be aware of
these special hazards.
In order to ensure the safe operation and optimal performance of the
product, please follow all warnings and safety instructions in this guide
during process of operation, maintenance and service.
For ensuring the safety of operators, operators are urged not to open
the equipment privately at all times. There are no user serviceable
parts, equipment or assemblies associated with this product. Lasers of
unauthorized disassembly shall not be subject to warranty.
Chapter 1
Characteristic Explain

6
Chapter 2
General Safety Information
1-Safety Conventions
All safety warning symbols during operating process of the laser include:
SYMBOLS DESCRIPTION
WARNING: Refers to a potential Electrical Hazard to
human body. It requires a procedure that, if not correctly
followed, may result in bodily harm to you and/or others.
Do not proceed beyond the WARNING sign until you
completely understand and meet the required conditions.
CAUTION：Refers to a potential hazard on product. It
requires a procedure that, if not correctly followed, may
result in damage to the product or components. In order
to ensure normal use of equipment, do not violate the
requirement of the CAUTION sign.
WARNING:Refers to a potential Laser Hazard.The symbol
represents laser radiation. The symbol is pasted on laser
output end.
NO SYMBOL
IMPORTANT：Refers to any information regarding the
operation of the product. Please do not overlook this
information.

7
Chapter 2 General Safety Information
NOTE :
◎ This device is classified as a high power Class IV laser instrument. It may
emit up to 4000W average power from 1060nm to 1100nm. This level of
light may cause damage to the eye and skin. Despite the radiation being
invisible, the beam may cause irreversible damage to the retina. Laser
safety eyewear is not provided with this instrument, but must be worn at all
times while the laser is operational.
2-Laser Protection
1、Laser Protection Requirements
You must wear the safety protective glasses while operating the laser,
and rationally select the safety protective glasses according to the lasing
wavelength of the laser. If the device is a tunable laser or Raman product,
it emits light over a range of wavelengths and the end user should confirm
the laser safety eyewear used protects against light emitted by the device
over its entire range of wavelength.
2、Laser Protective Equipment Suppliers
Maxphotonics recommends material or equipments provided by following
laser protective equipment suppliers for you, including LaserVision USA,
Kentek Corporation, Rochwell Laser Industries, etc. All the supplier
information is provided by Maxphotonics only for the convenience to use,
so Maxphotonics assumes no responsibility for any problem caused by
using the products of abovementioned suppliers.

8Chapter 2 General Safety Information
3-Reference Standard
Anti-interference Performance on Electromagnetic Compatibility：
EN 61000-6-4:2007 + A1:2011
EN 61000-6-2:2005 + AC: 2005
EN 61000-3-2:2014
EN 61000-3-3:2013
Power Supply Security:
EN 61010-1:2010
EN60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013
Laser Security:
EN 60825-1:2014
CDRH 21 CFR 1040.10
NOTE:
◎ In accordance with relevant EU and national standards and requirements,
the laser must be classified according to its output power and laser
wavelength. All MFSC-3000W-4000W-Series laser products with high power
belong to Class 4 products (according to article 8, EN 60825-1).

9
Chapter 2 General Safety Information
4-General Safety Instructions
1、Specular Reflection
There are often numerous secondary laser beams produced at various
angles in the output port of the laser. These divergent beams are produced
when the primary beam of laser reflects off a smooth surface, and they are
called specular reflections. Although these secondary beams may be less
powerful than the total power emitted from the primary beam, the intensity
may be great enough to cause damage to the eyes and skin as well as
surface of materials.
WARNING:
◎ You must exercise caution to avoid/minimize specular reflections as
these laser radiations are invisible!
2、Safety Instructions of Accessories
Optical accessories relevant to the laser, such as light-sensitive elements
that may be damaged from exposure to the laser light, video cameras,
photomultipliers and photodiodes, need related protections.
WARNING :
◎ The Maxphotonics MFSC laser light is strong enough to cut or weld
metal, burn skin, clothing and paint. In addition, this light can ignite
volatile substances such as alcohol, gasoline, ether and other solvents.
During the operating process, the flammable materials around the laser
must be isolated.
3、Optical Operating Instructions
We strongly recommend that you read the following procedures before
operating the laser:

10 Chapter 2 General Safety Information
1、Never look directly into the laser output port when the power is turned
on.
2、Avoid positioning the laser and all optical output components at eye
level.
3、Equip with laser beam casing.
4、Remove the end-cover before switch ON the laser. Or else the output
head will be damaged irreversibly.
5、Ensure that all personal protective equipment is suitable for the output
power and wavelength range of the laser.
6、Use the laser in a room with access controlled by door interlocks. Post
warning signs. Limit the safety areas to operate the laser.
7、Please do not operate the laser in darkened environments.
8、Do not turn on the laser without an optical coupling fiber or an optical
output connector.
9、Carry out commissioning, calibration and focusing at low output power
and then increase the output power gradually when the calibrating and
focusing work is done.
10、Do not install or detach cutting heads or collimators when the laser is
active
11、Make sure that the laser is shut down and the power is off before you
install or detach cutting heads or collimators.
12、If the equipment is operated in a manner not specified in this
document, the protection devices and performance of the equipment may
be impaired and the warranty will be voided.
CAUTION:
◎ The output of the laser is delivered through a lens with an anti-reflection

11
Chapter 2 General Safety Information
coating. If the backward-stage light path of your laser has the optical
lens, please strictly inspect the lens of the output head and the backward-
stage lens of the laser, and ensure that there is no dust and any other
impurity on the lens. Please note that any macroscopic attachment may
cause extreme damage to lens or burn the laser or any backward-stage
light path equipment.
◎ For cleaning instructions of the lens, please refer to the "Optical Fiber
Connector Inspection and Cleaning Guide".
◎ Hot or molten pieces of metal may be produced when the laser is under
operation. Exercise caution if debris is produced in operation.
◎ When you carry out commissioning and calibration of the laser output,
you must set the laser output at low power level and then gradually
increase the output power during checking the quality of the light spot
emitted from the laser via an infrared viewer.
WARNING:
◎ Make sure that the individual protective equipment meets the output
power and wavelength range of the laser.
◎ Never look directly into the optical fiber or the collimator, and make
sure you wear the safety protective glasses in each operation.
4、Electrical Operating Instructions
We strongly recommend that you read the following procedures before
operating the laser:
1、Make sure the shell of this equipment is properly grounded. Any
interruption of the ground loop may result in personal injury.
2、Make sure the power source connecting equipment is properly
grounded.
3、In order to further reduce fire hazard, replace the line fuses (if

12 Chapter 2 General Safety Information
applicable) with the same types and ratings. The use of other fuses or
material is prohibited.
4、Make sure that the input AC voltage of the laser is the voltage of
the normal AC mains (Three-phase four-wire 380V AC), and wires are
connected accurately. Any incorrect wiring method may cause damage to
people or instrument.
5、The equipment does not have any part which can be maintained by
operators, and all the maintenance operations must be finished by the
professionals of Maxphotonics Co., Ltd.
6、To prevent electrical shock, do not remove enclosure, detach the laser
without permission and damage the relevant signs. Any product with
unauthorized dismounting shall not be subject to warranty.
WARNING:
◎ The input voltage of the laser is triple-phase AC current (380V AC),
which may cause risk of electric shock. All the relevant cables and
connection wires have potential hazards.
5、Environment Conditions and Precautions
For ensuring the safety of the laser working area, suitable enclosures
shall be applied, including but not limited the laser safety signs and the
interlocking devices. Corresponding operators must be trained and
examined and know the normal safety specifications for operating the
laser.
Meanwhile, it is important that the output components shall not be installed
at eye level.
Because of interaction of the laser and the metal material, the radiation of
high-level ultraviolet light or visible light may be produced. Make sure that
the laser is provided with the protective cover to prevent the eyes or other
parts of human bodies from damage by radiation.

13
Chapter 2 General Safety Information
We recommend that you comply with the following operating
measures to prolong the service life of the laser:
1、Do not expose the laser to a high moisture environment.
2、The device is equipped with cooling fans. Make sure that there is
sufficient airflow to cool the laser, any objects or debris that cover the
ventilation holes must be removed at all times.
3、Operation at higher temperature will accelerate aging, increase
threshold current and lower slop efficiency. If the device is overheated,
stop operations and contact Maxphotonics.
4、Ensure that the work surface is properly vented. There may be gases,
sparks and debris generated from the interaction between the laser and
the work surface, and they could pose additional safety hazard.
CAUTION :
◎ The device may be damaged with incautious operation.

14 Chapter 2 General Safety Information
5-Additional Safety Information
For additional information regarding Laser Safety, please refer to
the list below:
Laser Institute of America(LIA)
13501 Ingenuity Drive, Suite 128
Orlando,Florida 32826
Phone:[phone],Fax: [phone]
Toll Free:1 800 34 LASER
American National Standards Institute
ANSI Z136.1, American National Standard for the Safe Use of Lasers
(Available through LIA)
International Electro-technical Commission
IEC 60825-1,Edition 1.2
Center for Devices and Radiological Health
21 CFR 1040.10 - Performance Standards for Light-Emitting Products
US Department of Labor - OSHA
Publication 8-1.7 - Guidelines for Laser Safety and Hazard Assessment.
Laser Safety Equipment
Laurin Publishing
Laser safety equipment and Buyer’s Guides

15
1-Features
MFSC Series CW fiber lasers are compact and efficient and high-quality
laser output lasers developed for industrial application. They are mainly
applied to the fields of puching, welding, cutting, etc.
Main Features:
1、High-quality laser output
2、High power, high efficiency
3、High reliability, long service life
4、Compact, rugged package
5、Extension programming interface
Applications:
1、Industrial applications
2、Scientific research
2-Module Configuration
Maxphotonics offers many configurable modes. This manual will give
complete instructions for all modes, please refer to section 6.3-6.6.
3-Laser Model Designation Codes
Chapter 3
Product Description

16 Chapter 3 Product Description
4 - Certification
Maxphotonics certifies that this equipment has been thoroughly tested
and inspected and meets published specifications prior to shipping. Upon
receiving your equipment, check whether the packaging and accessories
have been damaged in transit. If damage is apparent, please contact
Maxphotonics immediately.
5- Front Panel Description
M - F - S - C - XXX - XX
1 - 2 - 3 - 4 - 5 - 6
1Manufacturer’s code M means Maxphotonics
2Gain media of the
laser F means Fiber Laser
3Laser mode S means Single Mode
4Laser state C means Continue Wave
5Maximum output
power
XXXX W means the maximum output power of
the laser
6Additional message Can be null
Items Function Description
MAIN SWITCH 380V main power switch of
laser
KEY SWITCH Power switch of laser
EMERGENCY
STOP SWITCH Emergency stop
START Start laser (on-off signal of
hardware)
ALARM Abnormal situation light of
laser
ACTIVE Normal situation light of
laser
POWER Power light of laser

17
Chapter 3 Product Description
6-Back Panel Description
7-Optical Output Terminal
1、Optical Output Head
The optical output head come with a protective window that can be
replaced if damaged. Make sure that the end cap of the QBH head is
removed prior to use and is usually arranged with the laser.
Please refer to “Fiber Connector Inspection and Cleaning Guide” about
the cleaning method.
Optical Output Head (QBH head)
Items Function Description
CTRL External control
connector
RS232 RS232 connector
AC380 380V AC power input
WATER OUT Water cooling output
port
WATER IN Water cooling input port
OPTICAL
OUTPUT QBH output

18
Chapter 4
Specification
1-Optical Characteristic Parameters
No. Characteristics Test Conditions Min. Nom. Max. Unit
1Operation Mode CW/Modulated
2Polarization Random
3
Output Power of MFSC-3000W 100% CW 3000 W
Output Power of MFSC-4000W 100% CW 4000 W
4 Tuning Range of Output Power 10 100% %
5Emission Wavelength 100% CW 1070 1080 1090 nm
6Spectrum Width(3dB) 100% CW 3 4 nm
7Short-term Power Instability 100% CW >1h 1 2 %
8Long-term Power Instability 100% CW >24h 3 5 %
9Beam Quality M²
50um-QBH
Output 1.1 1.4 %
100um-QBH
Output 2.8 3.6 %
10 Laser Switching ON Time 10% → 90% Output 100 150 μs
11 Laser Switching OFF Time 90% → 10% Output 100 150 μs
12 Modulation Rate 100% Output 5 KHz
13 Red Guide Laser Power 100% Output 200 μW
14 Feeding Fiber Cable Length 50um-QBH
Output 15 m
15 Feeding Fiber Core Size 50（100/200 optional） μm
16
Feeding Fiber Cable Bending
Radius
200 mm
17 Output Connector Standard QBH（LOC）
