MAXPhotonics MFSQ QCW Series User manual

MFSQ-150/1500W QCW Fiber Laser Series
Maxphotonics Co.,Ltd.

Copyright Notation
Copyright © Maxphotonics Co ., Ltd ( here after referred to as Maxphotonics). All
rights reserved. You may not copy, modify, transmit or publish this publication,
in any form, in any media or by any means, without the prior written permission
of Maxphotonics, except as allowed under applicable copyright laws. Permitted
copies shall bear the same copyright and proprietary notices that were contained
on the ori ginal version.
Maxphotonics believes that the information provided is accurate and reliable;
however Maxphotonics makes no warranty, representation,expression or
implication that this document can be used as reference in other occasions.
Furthermore, Maxphotonics does not assume responsibility for any infringement
of patents or other rights of third parties due to use of the information contained
in this document. Maxphotonics shall not be liable for errors contained in this
document or for direct or indirect damages of relevant equipment.
Maxphotonics and the Maxphotonics Logo are registered trademarks of
Maxphotonics Co., Ltd., and the Logo does not break any regulations of
Trademark law.Maxphotonics grants no rights for patent or other intellectual
property mentioned herein.
All information contained in this document is subject to change and revision
without notice.
Subject to change without notice.
Maxphotonics Co.,Ltd.
Address: Maxphotonics Industrial Park, 3rd Furong Road,
Furong Industrial Area, Shajing, Baoan, Shenzhen, China.518125
E-Mail: [email protected]
http://en.maxphotonics.com

1
Preface
Thank you for using the MFSQ QCW Fiber Laser Series . We compile this
document for you in order that the laser is used and maintained properly. Due
to the limited level of the writers, coupled with time constraints, there may be
some careless mistakes in this document, and your understanding will be much
appreciated. Thank you again for using Maxphotonics' products.
Please take time to read and understand this User's Guide and familiarize
yourself with the operating and maintenance instructions before you use the
product. We strongly recommend that the operator read the Section titled “Safety
Information” prior to operating the product.
This User's Guide should stay with the product to provide you and all future
users and owners of the product with important operating, safety and other
information.
We identify the parts to which you need to pay special attention in the document
with underscore. Please notice those information to avoid the unnecessary
damages.

2
Company Prole
Found in 2004, Maxphotonics is one of the first fiber laser manufacturers in
China. It is also the first in China to realize independent intellectual property
rights and vertical integration in the core technologies of ber lasers and optical
devices. One of the national high-tech enterprises. Maxphotonics has developed
into an internationally renowned laser manufacturer that develops, manufactures
and sells fiber lasers and core optical components. It is the second largest
domestic ber laser manufacturer in the domestic market.
Maxphotonics specializes in the research, development, production and sales of
ber lasers, including pulsed ber lasers, continuous ber lasers and direct diode
lasers. It also implements pump sources, combiners, fiber gratings, isolators,
laser output heads, and stripping. Optical devices such as molds, acousto-optic
modulators, and pattern matchers are produced autonomously. Products are
widely used in marking, engraving, cutting, drilling, cladding, welding, surface
treatment, rapid prototyping and additive manufacturing processes.
More informations，please visit our website：
http://en.maxphotonics.com

CONTENT 3
Company Prole ………………………………………………………………… 2
Chapter 1 Characteristic Explain ………………………………………… 5
Chapter 2 General Safety Information …………………………………… 6
1-Safety Conventions …………………………………………………………… 6
2-Laser Protection ……………………………………………………………… 7
3-General Safety Instructions ………………………………………………… 8
4-Additional Safety Information ……………………………………………… 12
Chapter 3 Product Description ……………………………………………… 14
1-Features………………………………………………………………………… 14
2-Laser Model Designation Codes …………………………………………… 15
3-Certication …………………………………………………………………… 15
Chapter 4 Specication ……………………………………………………… 16
1-Optical Characteristic Parameters ………………………………………… 16
2-General Characteristic Parameters ………………………………………… 17
3-Structural Layout ……………………………………………………………… 18
Chapter 5 Operation Guide ………………………………………………… 19
1-DB25 Control Interface Pin Function ……………………………………… 19
2-Quick Wiring Guide …………………………………………………………… 20
3-Front Panel Indicator Color ………………………………………………… 20
4-Software Operation Instructions …………………………………………… 20
5-Software Function …………………………………………………………… 21

CONTENT
4
6-Maximum Pulse Width And Maximum Frequency Calculation ………… 28
Chapter 6 Service and Maintenance ……………………………………… 29
1-Maintenance Notes …………………………………………………………… 29
2-Service Statements …………………………………………………………… 30
Chapter 7 Warranty Statements …………………………………………… 31
1-General Items ………………………………………………………………… 31
2-Warranty Limitations ………………………………………………………… 31

5
The MFSQ QCW Fiber Laser Series products are characterized by high reliabilty
and high performance with the central emission wavelength of 1080nm. They are
high-effecient, air-cooled and maintenance-free, which make them ideal tools for
industrial laser marking, engraving etc..
Maxphotonics' MFSQ QCW Fiber Laser Series are Class 4 laser products and
are designed and tested with safety. By following this User Guide and applying
sound laser safety practices, it will be a safe and reliable device.
Laser light exhibits unique characteristics that may pose safety hazards.
Therefore, the laser light can't be treated as normal light sources, and all
operators and people near the laser must be aware of these special hazards.
In order to ensure the safe operation and optimal performance of the product,
please follow all warnings and safety instructions in this guide during process of
operation, maintenance and service.
For ensuring the safety of operators, operators are urged not to open the
equipment privately at all times. There are no user serviceable parts, equipment
or assemblies associated with this product. Lasers of unauthorized disassembly
shall not be subject to warranty.
Chapter 1
Characteristic Explain

6
Chapter 2
General Safety Information
1-Safety Conventions
All safety warning symbols during operating process of the laser include:
SYMBOLS DESCRIPTION
WARNING: Refers to a potential Electrical Hazard to
human body. It requires a procedure that, if not correctly
followed, may result in bodily harm to you and/or others.
Do not proceed beyond the WARNING sign until you
completely understand and meet the required conditions.
CAUTION：Refers to a potential hazard on product. It
requires a procedure that, if not correctly followed, may
result in damage to the product or components. In order
to ensure normal use of equipment, do not violate the
requirement of the CAUTION sign.
WARNING:Refers to a potential Laser Hazard.The symbol
represents laser radiation. The symbol is pasted on laser
output end.
NO SYMBOL
IMPORTANT：Refers to any information regarding the
operation of the product. Please do not overlook this
information.

7
Chapter 2 General Safety Information
NOTE :
◎This device is classified as a high power Class IV laser instrument which
emits light with the wavelength of 1080nm and the optical output power is up
to 1500W. This level of light may cause damage to the eye and skin. Despite the
radiation being invisible, the beam may cause irreversible damage to the retina.
The manufacturer of the laser system is responsible for the safety compliance
according to the applicable standards and regulations.
2-Laser Protection
1、Laser Protection Requirements
You must wear the safety protective glasses while operating the laser, and
rationally select the safety protective glasses according to the lasing wavelength
of the laser. If the device is a tunable laser or Raman product, it emits light
over a range of wavelengths and the end user should conrm the laser safety
eyewear used protects against light emitted by the device over its entire range
of wavelength.
2、Laser Protective Equipment Suppliers
Maxphotonics recommends material or equipments provided by following laser
protective equipment suppliers for you, including LaserVision USA, Kentek
Corporation, Rochwell Laser Industries, etc. All the supplier information is
provided by Maxphotonics only for the convenience to use, so Maxphotonics
assumes no responsibility for any problem caused by using the products of
abovementioned suppliers.

8Chapter 2 General Safety Information
3-General Safety Instructions
In order to ensure the safe operation and optimal performance of the product,
please follow these warnings and cautions in addition to the other information
contained elsewhere in this document.
1、Specular Reflection
There are often numerous secondary laser beams produced at various angles
in the output port of the laser. These divergent beams are produced when the
primary beam of laser reects off a smooth surface, and they are called specular
reflections. Although these secondary beams may be less powerful than the
total power emitted from the primary beam, the intensity may be great enough to
cause damage to the eyes and skin as well as surface of materials.
WARNING:
◎You must exercise caution to avoid/minimize specular reflections as these
laser radiations are invisible!
2、Safety Instructions of Accessories
Optical accessories relevant to the laser, such as light-sensitive elements
that may be damaged from exposure to the laser light, video cameras,
photomultipliers and photodiodes, need related protections.
WARNING :
◎The Maxphotonics MFSC laser light is strong enough to cut or weld metal,
burn skin, clothing and paint. In addition, this light can ignite volatile substances
such as alcohol, gasoline, ether and other solvents. During the operating
process, the ammable materials around the laser must be isolated.

9
Chapter 2 General Safety Information
3、Optical Operating Instructions
We strongly recommend that you read the following procedures before
operating the laser:
1、Never look directly into the laser output port when the power is turned on.
2、Avoid positioning the laser and all optical output components at eye level.
3、Ensure that all personal protective equipment is suitable for the output power
and wavelength range of the laser.
4、Do not install or detach cutting heads or collimators when laser is active.
5、It is forbidden to turn on the laser during the mounting of fiber or cutting
head. Carry out commissioning, calibration and focusing at low output power
and then increase the output power gradually when the calibrating and focusing
work is done.
6、Marking on highly reflective materials is feasible, but you must make the
laser out of focus, or else you may damage the laser.
7、For collimated outputs, maintaining a clean output lens is essential. Always
close (re-cap) the collimator after use. Do not touch the output lens and do not
clean it with any solvents.Cleaning with the special solvent and cleaning buds is
allowed as described later on in th is manual.
WARNING:
◎Make sure that the individual protective equipment meets the output power
and wavelength range of the laser.
◎Never look directly into the optical ber or the collimator, and use appropriate
laser safety eyewear when operating this device.
◎Optical damage may result from failure to comply with the above instructions.
Such damage is not covered by the warranty.

10 Chapter 2 General Safety Information
WARNING:
◎Use of controls or adjustments or performance of procedures other than those
set forth in this User's Guide and related documents may result in hazardous
radiation exposure.
4、Electrical Operating Instructions
MFSQ QCW Fiber Laser Series module supply voltage:220VAC:
WARNING:
◎Make sure the shell of this equipment is properly grounded. Any interruption
of the ground loop may result in personal injury.
◎Make sure that the input DC voltage of the laser is the voltage of the normal
DC mains, and wires are connected accurately. Any incorrect wiring method may
cause damage to people or instrument.
◎Before supplying the power to the device, make sure that the correct voltage
of the DC power source is used. Failure to use the correct voltage could cause
damage to the device.
◎No operator serviceable parts inside. Refer all servicing to qualified
Maxphotonics personnel.
◎To prevent short circuit, do not remove shell, detach the laser without
permission and damage the relevant signs. Any product with unauthorized
dismounting shall not be subject to warranty.
Cable color Circuit connection
Brown L
Blue N
Kelly Laser Shell

11
Chapter 2 General Safety Information
5、Environment Conditions and Precautions
We strongly recommend that you read the following procedures before
operating the laser :
1、Do not expose the laser to a high moisture/high temperature environment.
Install the laser in the cabinet with the function of temperature-humidity control
and dust-free.
2、Laser Module has at least three fans at the rear panel for active cooling.
Make sure that there is at least 5cm between fan protector and external objects,
and with sufcient airow to cool the device.
3、Before switching on the device make sure that environmental temperature
and humidity are within a specied range.
WARNING:
◎Optical damage may result from failure to comply with the above instructions.
Such damage is not covered by the warranty.
6、Routine Maintenance
1、Avoid the impaction on the shipper rod of worktable when the laser is
working.
2、The laser and optical lens are fragile, please handle with care.
3、Stop running once device failure, and provide professional treatment.
4、Please follow a set sequence of on-off.
5、The limitation on surface of marking machine is within the working area.
6、Keep the device clean and indoor.

12 Chapter 2 General Safety Information
7、Safety Labels and Labeling Locations
The following shows the pictures of tags and their positions on the product :
4-Additional Safety Information
For additional information regarding Laser Safety, please refer to the list
below:
Laser Institute of America(LIA)
13501 Ingenuity Drive, Suite 128
Orlando,Florida 32826
Phone:[phone],Fax: [phone]
Toll Free:1 800 34 LASER
American National Standards Institute
ANSI Z136.1, American National Standard for the Safe Use of Lasers
(Available through LIA)
International Electro-technical Commission
Pictures of label Label name Label location
Light Emission Top Cover
CAUTION Top Cover
CAUTION

13
Chapter 2 General Safety Information
IEC 60825-1,Edition 1.2
Center for Devices and Radiological Health
21 CFR 1040.10 - Performance Standards for Light-Emitting Products
US Department of Labor - OSHA
Publication 8-1.7 - Guidelines for Laser Safety and Hazard Assessment.
Laser Safety Equipment
Laurin Publishing
Laser safety equipment and Buyer’s Guides

14
1-Features
The MFSQ QCW Fiber Laser Series is one of the cutting-edge products of
Maxphotonics. Its emergence is revolutionary for the integration of high speed,
high resolution laser welding systems.
Compact, stand-alone, easy-to-use design that can be integrated directly into
the user's device. Low power consumption, practical and durable design for
laboratory and market applications.
Main Features:
1、High beam quality
2、Alternative the lamp-pumped laser
3、High photoelectric conversion efciency
4、Pulse and continuous selectable
5、High pulse power, stable energy, and high peak power
Applications:
1、Industrial applications
2、Scientic research
Chapter 3
Product Description

15
Chapter 3 Product Description
Model Model Coding Rules
MFSQ-150/1500W Maxphotonics 150/1500w QCW Fiber Laser
2-Laser Model Designation Codes
3 - Certification
Maxphotonics certifies that this equipment has been thoroughly tested and
inspected and meets published specications prior to shipping. Upon receiving
your equipment, check whether the packaging and accessories have been
damaged in transit. If damage is apparent, please contact Maxphotonics
immediately.

16
Chapter 4
Specication
1-Optical Characteristic Parameters
No. Characteristics Test Conditions Min. Nom. Max. Unit
1
Pulsed Mode Max
Power
1500 W
2Pulse Mode
Average Power 150 W
3CW Mode Max
Power 250 W
4Maximum Pulse
Energy 15 J
5
Tuning Range of
Output Power
10 100 %
6Modulation Rate 15000 Hz
7Pulse Width 0.05 50 ms
8Duty cycle range 050 %
9Emission
Wavelength 100% CW 1070 1080 1090 nm
10 Optical efciency 10~100%linear
tting 65 %
11
Whole Machine
Electro-optic
Efciency
10~100%linear
tting 27 %
12 Spectrum
Width(3dB) 100%CW 3nm
13 Short-term Power
Instability 100%CW>1h 2 %
14 Beam Quality M2 100%CW 1.3(20um)
15 Laser Switching
ON Time 10%→90%
Output 50 100 μs
16 Laser Switching
OFF Time 90%→10%
Output 50 100 μs

17
Chapter 4 Specication
2-General Characteristic Parameters
No. Characteristics Test
Conditions Min. Nom. Max. Unit
1Operating Voltage 170 220 260 VAC
2Rated Power 100%Output 3KW
3Operating Ambient
Temperature 10 40 ℃
4
Operating Ambient
Relative Humidity
10 85 %
5Cooling Method Air-cooling
6Storage Temperature -10 60 ℃
7Dimensions 510.5*448*131.5mm (D x W x H)
(Without Handle) mm
8Weight 34 kg
17 Red Guide Laser
Power 100%CW 100 μW
18 Feeding Fiber
Cable Length 10 m
19
Feeding Fiber Cable
Bending Radius
200 mm
20 Feeding Fiber
Core Size 20 ,50 μm
21 Output Connector Standard QBH（LOC）

18 Chapter 4 Specication
3-Structural Layout
Standard isolated output head dimensions:（Unit：mm）
Laser module dimensions:（Unit：mm）
