Maxsisun PB PRO Series User manual

Follow Maxsisun on Social Media and happily grow with us.
Instagram Amazon Store
[email protected]
Contact us via Amazon or eBay message
www.maxsisun.com
Contact Us:
Copyright ©MAXSISUN 2020. All rights reserved.
MADE IN CHINA
Manual Version：2020-12-04
PB PRO SERIES
PB1000 Pro PB1500 Pro
PB2000 Pro PB4000 Pro
Remote Control LED Grow Light
Facebook

MAXSISUN
PB Pro Series
One remote can control multiple lights
Daisy chain function available
Samsung LEDs
Mean Well Driver
SAFETY INFORMATION
Dear Customer
Thank you for shopping with MAXSISUN. Please read and follow the instructions below before installing and
using your light. If you have any concerns, please contact us via [email protected].
Safety Warnings and Recommendations:
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
Cleaning:
Disconnect the power cord. Using a clean, soft, lint-free cloth to wipe the light. Please be aware of getting
moisture or damage in any openings.
Legal Disclaimer:
MAXSISUN products are to be used for lawful purposes only. It is the responsibility of you as the purchaser
to know and abide by all laws on the use of MAXSISUN products.
MAXSISUN will NOT be held liable for any unlawful state or federal activity arising out of the use of our
products. By purchasing a MAXSISUN product, you agree to these terms and conditions, confirming that
you, as the purchaser, are attesting to the lawful use of our product and are thereby solely responsible for
acting in conformance with all applicable regulations.
Do NOT use a damaged power cord.
Do NOT look directly at the LED bulbs when the light is operating.
Do NOT use the light near flammable, explosive or reactive substances.
Do NOT attempt to open, rewire or reconfigure any components of the light system. It will void the warranty
and could cause severe injury or death.
Hang light securely so that it cannot fall.
Only use the supplied power cord comes with the light.
Indoor use only. The light is certified for use in damp and dry locations.
Always disconnect power from the light before moving or cleaning it.
Check and adhere to all local rules and regulations when installing.
The minimum required distances between lights is 4 inches (10cm), and between the light and combustible
materials is 16 inches (40cm) such as walls, ceilings, movable partitions, and the like.
The maximum temperature of the installed environment that will ensure safe operation of the light. A
mechanical ventilation or cooling system is required to maintain the temperature within the growing space
below 104°F (or 40°C) when the light is operating.
01
MAXSISUN PB Pro Series 02MAXSISUN PB Pro Series

ON
ID
ALL
Power on the light.
OFF
Power off the light.
(Standby mode)
Connect remote to
light.
Tips: To save your electricity bill, please
turn off the switch of the light if long time
no use.
To control all groups.
CONNECT REMOTE TO LIGHT(S)
BEFORE USE
1. Long-press [ID] and turn on
the switch. The light will blinks
if the connection succeeds.
2. Press [ALL]. Select the brightness
you want. Repeat for all lights.
1. Install batteries in the remote. 2. Plug the light into an outlet.
Turn off its switch.
1
2
03MAXSISUN PB Pro Series 04MAXSISUN PB Pro Series
QUICK START GUIDE
GROUPING: SET DIFFERENT BRIGHTNESS FOR MULTIPLE LIGHTS
1. Connect one remote to all
lights (ex. 10 lights). Turn off
their switches.
2. Put 5 lights into group 1:
Long-press [1] and turn on 5
lights’ switches. These lights
will blink if the connection
succeeds.
3. Put the rest of 5 lights into
group 2: Long-press [2] and
turn on their switches. These
lights will blink if the connection
succeeds.
3
2
1
22
1
1
1. Turn off its switch. 2. Long-press [5] and turn on its
switch. The light will blinks if the
connection succeeds.
CHANGE ONE LIGHT TO OTHER GROUP
(Ex. From Group 1 to Group 5)
4
2
1
1. Turn off the switch over 15
seconds.
2. Long-press [ID] and turn on
the switch over 5 seconds. The
connection will succeed.
3.Press [ON] to turn on the
light.
CONNECT REMOTE TO LIGHT WHICH IS IN STANDBY MODE
5
2
1
1
1
4. Press [1]. Select the brightness
for group 1.
5. Press [2]. Select the brightness
for group 2.
6. Press [ALL]. Select the brightness
for all lights.
1
1
1

PB1000 Pro PPFD MAP - Tested in a 2x2 ft Grow Tent
µmol/m²/s Height: 12"
Extremely bright, do not stare at operating lamp.
For flowering stage: use all channels with 100% brightness.
This light includes IR (Infrared) LEDs which look dim, they are not faulty LEDs.
For safety, total true wattage of extra connected lights MUST less than 600W.
05
MAXSISUN PB Pro Series 06MAXSISUN PB Pro Series
PB1000 Pro PB1000 Pro SPECIFICATION
Model:
Feature:
Actual Power Draw:
LED Quantities:
Total Harmonic Distortion:
Input:
Frequency:
Package Includes:
PB1000 Pro
Remote Control
100W±3% at 120V
350pcs
＜15%
AC100-240V~ 0.95A
50-60Hz
1 x PB1000 Pro; 2 x Hanging Kits; 2 x Rope Hangers; 1 x 6 ft Power Cord; 1 × Remote (with 2pcs AAA batteries)
HID Replacement:
Vegetative Coverage at 18":
Flowering Coverage at 14":
Use for:
Dimensions:
Item Weight:
Lifespan:
200W HPS/MH
2.5 × 2.5 ft
2 × 2 ft
all stages grow and flowering
12 x 10.8 x 2.1 inches
3.9 lbs
≥100,000 hours
PB1000 Pro USING SUGGESTIONS
PB1000 Pro
3-5 Days Acclimation Period
Seedlings/Young Vegetative
Vegetative Stage
Flowering Stage
Height (above plants' canopy)
24"-28"
20"-24"
16"-20"
12"-16"
Using Hours
18 on / 6 o
18 on / 6 o
18 on / 6 o
12 on / 12 o
Brightness
40%
60%
100%
100%
PB1000 Pro SPECTRUM
NOTE:
354 484 522 462 367
515 724 873 738 541
595 867 1085 884 625
540 782 884 797 585
407 530 599 588 480
µmol/m²/s Height: 18"
444 474 484 472 449
470 511 547 521 488
511 557 632 560 526
478 526 554 538 513
455 478 494 479 450
380
0.4
0.0
1.0
0.2
0.8
0.6
440 560 680 730 800
2 ft
2 ft

07MAXSISUN PB Pro Series 08MAXSISUN PB Pro Series
PB1500 Pro PPFD MAP - Tested in a 2x2 ft Grow Tent
µmol/m²/s
PB1500 Pro PB1500 Pro SPECIFICATION
Model:
Feature:
Actual Power Draw:
LED Quantities:
Total Harmonic Distortion:
Input:
Frequency:
Package Includes:
PB1500 Pro
Remote Control
150W±3% at 120V
490pcs
＜15%
AC100-240V~ 1.42A
50-60Hz
1 x PB1500 Pro; 2 x Hanging Kits; 2 x Rope Hangers; 1 x 6 ft Power Cord; 1 × Remote (with 2pcs AAA batteries)
HID Replacement:
Vegetative Coverage at 20":
Flowering Coverage at 16":
Use for:
Dimensions:
Item Weight:
Lifespan:
300W HPS/MH
3 × 3 ft
2.5 × 2.5 ft
all stages grow and flowering
16 x 10.8 x 2.4 inches
6.3 lbs
≥100,000 hours
PB1500 Pro USING SUGGESTIONS
PB1500 Pro
3-5 Days Acclimation Period
Seedlings/Young Vegetative
Vegetative Stage
Flowering Stage
Height (above plants' canopy)
26"-30"
22"-26"
18"-22"
14"-18"
Using Hours
18 on / 6 o
18 on / 6 o
18 on / 6 o
12 on / 12 o
Brightness
40%
60%
100%
100%
PB1500 Pro SPECTRUM
Extremely bright, do not stare at operating lamp.
For flowering stage: use all channels with 100% brightness.
This light includes IR (Infrared) LEDs which look dim, they are not faulty LEDs.
For safety, total true wattage of extra connected lights MUST less than 600W.
NOTE:
µmol/m²/s Height: 18"Height: 12"
610 755 807 725 601
854 1071 1149 1037 837
930 1198 1313 1190 925
791 1022 1097 1005 829
570 680 747 707 638
620 643 655 615 565
665 709 725 687 654
698 739 744 710 672
633 679 692 663 644
535 566 570 569 560
380
0.4
0.0
1.0
0.2
0.8
0.6
440 560 680 730 800
2 ft
2 ft

Height: 12"
09
MAXSISUN PB Pro Series 10MAXSISUN PB Pro Series
PB2000 Pro PPFD MAP - Tested in a 4x2 ft Grow Tent
PB2000 Pro PB2000 Pro SPECIFICATION
Model:
Feature:
Actual Power Draw:
LED Quantities:
Total Harmonic Distortion:
Input:
Frequency:
Package Includes:
PB2000 Pro
Remote Control
200W±3% at 120V
700pcs
＜15%
AC100-240V~ 1.9A
50-60Hz
1 x PB2000 Pro; 2 x Hanging Kits; 2 x Rope Hangers; 1 x 6 ft Power Cord; 1 × Remote (with 2pcs AAA batteries)
HID Replacement:
Vegetative Coverage at 22":
Flowering Coverage at 18":
Use for:
Dimensions:
Item Weight:
Lifespan:
400W HPS/MH
4 × 3.5 ft
3.5 × 3 ft
all stages grow and flowering
24 x 10.8 x 2.4 inches
8.9 lbs
≥100,000 hours
PB2000 Pro USING SUGGESTIONS
PB2000 Pro
3-5 Days Acclimation Period
Seedlings/Young Vegetative
Vegetative Stage
Flowering Stage
Height (above plants' canopy)
28"-32"
24"-28"
20"-24"
16"-20"
Using Hours
18 on / 6 o
18 on / 6 o
18 on / 6 o
12 on / 12 o
Brightness
40%
60%
100%
100%
PB2000 Pro SPECTRUM
Extremely bright, do not stare at operating lamp.
For flowering stage: use all channels with 100% brightness.
This light includes IR (Infrared) LEDs which look dim, they are not faulty LEDs.
For safety, total true wattage of extra connected lights MUST less than 600W.
NOTE:
380
0.4
0.0
1.0
0.2
0.8
0.6
440 560 680 730 800
2 ft 4 ft
µmol/m²/s
360 523 697 760
450 732 995 1105
513 842 1150 1557
450 733 985 1107
324 497 658 756
771 674 492 335
1105 978 690 430
1548 1117 790 475
1095 958 695 440
740 659 508 359
786
1138
1676
1120
773
Height: 18"µmol/m²/s
449 553 660 778
465 599 709 869
482 620 801 914
452 576 691 845
444 555 649 766
772 669 557 457
863 698 587 461
909 733 605 482
844 672 563 458
770 614 535 449
795
895
996
877
787

11MAXSISUN PB Pro Series 12MAXSISUN PB Pro Series
PB4000 Pro PPFD MAP - Tested in a 4x4 ft Grow Tent
PB4000 Pro PB4000 Pro SPECIFICATION
Model:
Feature:
Actual Power Draw:
LED Quantities:
Total Harmonic Distortion:
Input:
Frequency:
Package Includes:
PB4000 Pro
Remote Control
400W±3% at 120V
1400pcs
＜15%
AC100-240V~ 3.8A
50-60Hz
1 x PB4000 Pro; 2 x Hanging Kits; 2 x Rope Hangers; 1 x 6 ft Power Cord; 1 × Remote (with 2pcs AAA batteries)
HID Replacement:
Vegetative Coverage at 28":
Flowering Coverage at 24":
Use for:
Dimensions:
Item Weight:
Lifespan:
800W HPS/MH
5 × 5 ft
4 × 4 ft
all stages grow and flowering
24 x 21.6 x 2.4 inches
17.5 lbs
≥100,000 hours
PB4000 Pro USING SUGGESTIONS
PB4000 Pro
3-5 Days Acclimation Period
Seedlings/Young Vegetative
Vegetative Stage
Flowering Stage
Height (above plants' canopy)
34"-38"
30"-34"
26"-30"
22"-26"
Using Hours
18 on / 6 o
18 on / 6 o
18 on / 6 o
12 on / 12 o
Brightness
40%
60%
100%
100%
PB4000 Pro SPECTRUM
Extremely bright, do not stare at operating lamp.
For flowering stage: use all channels with 100% brightness.
This light includes IR (Infrared) LEDs which look dim, they are not faulty LEDs.
For safety, total true wattage of extra connected lights MUST less than 600W.
NOTE:
380
0.4
0.0
1.0
0.2
0.8
0.6
440 560 680 730 800
240 327 419 488 488 473 417 337 241
372 590 862 988 950 965 887 614 377
527 964 1465 1630 1677 1715 1543 1029 557
633 1205 1825 2121 2151 2205 1981 1297 662
693 1320 1943 2212 2561 2284 2041 1345 680
664 1221 1914 2200 2229 2284 2011 1329 668
626 1155 1663 1868 1910 1951 1735 1145 556
397 669 970 1114 1178 1131 1075 737 382
257 371 350 564 607 584 527 384 248
405 471 548 604 616 608 560 495 421
490 597 707 780 810 792 733 615 494
573 720 870 965 1106 982 892 753 590
632 806 1094 1417 1460 1434 1121 833 645
655 835 1243 1477 1612 1489 1266 875 666
633 810 1102 1442 1472 1450 1119 832 653
581 744 902 1108 1135 1108 909 762 585
486 608 725 801 825 811 738 626 505
420 485 558 606 640 631 580 490 425
4 ft
4 ft
Height: 12"µmol/m²/s Height: 18"µmol/m²/s

1. Attach the clips on the
ends of the hanging wires to
each of the hanging holes
on the light.
2. Attach two adjustable
ropes, via the carabiners, to
each of the hanging wires’
carabiners.
3. Attach opposite ends of
adjustable ropes’ hangers
to a safety mounting
position.
4. Adjust the light to your
desired location by using
the adjustable ropes.
180 days full warranty | 3 years limited warranty
What Is Covered
MAXSISUN lights are warranted against defects in materials and craft for three (3) years from the original date of purchase.
During the warranty period, MAXSISUN will either repair or replace any covered defective product. Within the first 180
days, MAXSISUN will bear all costs associated with the repair, replacement, and return of the faulty product. After 180
days, the customer will assume responsibility for shipping the defective product back to MAXSISUN for the remainder of
the warranty period. MAXSISUN will, in turn, assume liability for up to $50.00 per light of the shipping fees associated with
returning the repaired or replaced product to the purchaser. Return shipping fees above $50.00 will be the responsibility of
the purchaser.
What Is Not Covered
(1) This warranty does not cover any damage, deterioration, malfunction resulting from any alteration, modification, improper
or unreasonable use or maintenance, misuse, abuse, neglect, exposure to excess moisture, fire, lightning, power surges,
or other acts of nature.
(2) This warranty does not cover any damage, deterioration, malfunction resulting from the installation, removal, unauthorized
tampering, repairs attempted by anyone unauthorized by MAXSISUN to make such repairs. Any other cause which
does not relate directly to a defect in materials and quality of this product is not covered.
90 Days Money Back Guarantee
MAXSISUN is so confident in the performance of our cutting edge lights that we oer a full 90 days money-back guarantee.
If you are unsatisfied with your purchase for any reason, we will gladly accept a return and provide a refund less shipping
fees.
Eligibility requirements are as follows:
Valid for the first purchase of MAXSISUN products only.
Valid for the original purchaser only.
Valid for up to two lights.
90 days begins from the date of purchase.
The returned products must be in “like new” condition and in original packaging.
Oer valid for returns only. Exchanges are subject to a 30 days return policy and restocking fee.
Oer valid for direct purchasers only. Customers purchasing via authorized resellers are subject to policies of the reseller.
Returns
Returns not qualifying for the 90 Days Money Back Guarantee can still be returned within 30 days from the date of purchase.
Pending the below conditions are met, the purchaser will receive a refund:
30 days begins from date of purchase.
Valid for the original purchaser only.
The product must be in “like new” condition and in original packaging.
How To Obtain Warranty Service
To enforce the rights under this warranty, the purchaser must notify MAXSISUN of a warranty claim by sending an email to
[email protected]. At this time, the purchaser will be called upon to provide proof of purchase. The MAXSISUN
representative will either attempt to assist in trouble-shooting, request photos showing the defect, and provide more
detailed return instructions. Upon receipt and review of the defective product, MAXSISUN will repair or replace, and
return within five (5) business days. To obtain refund service, upon receipt and review of the returned product, MAXSISUN
will issue return credit within three (3) business days.
This section will help you in the process of evaluating “how high” and “how many hours” will be best suited
for each stage of plant growth. Hang the light at a minimum of 12 inches from light and plant canopy. Less
than 12 inches distance may burn plants. Start high, adjust as plants acclimate.
Seedlings - You will need to hang the light high due to the delicate nature of seedlings. We recommend a
break-in period of about a week while a seed has broken the surface. The first set of real leaves should be
present while the seedling has been above ground for about a week.
Clones - Clones are a little bit hardier than fresh seedlings, but still, need to be given gentle light as they
are entirely rootless when first cut, and need to conserve energy and moisture to transition into a rooting
stage.
Vegetative - The deeper red spectrum is utilized less by the plant than when it is in flower. It uses high
levels of white light that are essential for creating lush, thick plants that have tight internodal spacing and
minimal stretching.
Flowering - The plant has much work to do and is preforming many complex biological processes in producing
flowers and fruits. Because of this, the plant now requires large amounts of light.
Late Flower - Most rapid development has stopped, and the plant is gearing up for the scene in which the
large flowers and fruits will mature or ripen.
13MAXSISUN PB Pro Series 14MAXSISUN PB Pro Series
MOUNTING INSTRUCTIONS
USING SUGGESTIONS
WARRANTY
