Maxxair SKYMAXX 97500 Manual

INSTALLATION, OPERATION AND
MAINTENANCE INSTRUCTIONS FOR
MAXXAIR®SKYMAXX 97500 & 97510
READ AND SAVE THESE INSTRUCTIONS
NOTE: Refer to Installation Instructions, Information and Operation Guides regarding the model you have
purchased.
The SKYMAXX ROOFLIGHT installs into a standard caravan roof opening of 15.75 in. x 15.75 in.
(400 mm x 400 mm).
To determine if your roof opening is correctly sized, simply remove the interior ceiling garnish trim ring of
your existing roof vent and measure the ceiling opening or verify the opening is large enough by sliding
the Rooflight interior ceiling flange into the opening.
The Rooflight is designed for a minimum roof thickness 0.90 inches to 2.36 inches maximum
(23 mm to 60 mm).
The LED lighted Rooflight requires a minimum 12 Volt DC, 2 amp service. Confirm that the circuit you
intend to use will accommodate the additional load. Circuit must be fused and use appropriate gauge
stranded wire for electrical connections.
NOTE: Wall Control for LED lights must be provided by installer.
NOTE: THE ROOFLIGHT MUST BE CLOSED PRIOR TO TRANSPORTING OR MOVING THE CARAVAN.
WARNING! TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS,
OBSERVE THE FOLLOWING:
a) Use this unit only in the manner intended by AIRXCEL, INC. If you have questions, contact the
manufacturer.
b) Before servicing or cleaning the unit, switch power off at service panel and lock the service
disconnecting means to prevent power from being switched on accidentally. When the service
disconnecting means cannot be locked, securely fasten a prominent warning device, such as a
tag, to the service panel.
CAUTION! FOR GENERAL VENTILATION USE ONLY. DO NOT USE TO EXHAUST HAZARDOUS
OR EXPLOSIVE MATERIALS OR VAPORS.
P/N: 11B90014 07-2019

This page intentionally left blank

INSTALLATION INSTRUCTIONS
STEP 1
Rooflight Model
Roof Opening
00-97500, 00-97510
15.75 in. x 15.75 in.
(400 mm x 400 mm)
Refer to the above table for roof size opening. If you are
replacing another type already installed, remove the old existing
roof vent. Remove all old roof sealant for a minimum of 2 inches
(5 cm) entirely around the roof opening.
STEP 2
Measure the thickness of the roof opening. NOTE: For curved
roofs, measure the thickest part of the roof.
VEHICLE ROOF
THICKNESS
LENGTH OF
SCREW
1 –1.5 in. (23 –40 mm)
40 mm
1.5 –2.25 in. (40 –60 mm)
60 mm
STEP 3
Prior to installing the SKYMAXX ROOFLIGHT over the roof
opening, apply a continuous strip of a flexible non-hardening
sealing compound (e.g. SikaLastomer-710) to the underside of
the flange in the grooved space.
CAUTION! When installing your SKYMAXX ROOFLIGHT,
only use a caulking/sealant compatible with the flange (plastic
product) and the roof surface. DO NOT use materials
containing solvents such as or similar to Xylene, Toluene,
Methyl Ethyl Ketone (MEK), Acetate or Acetone as they can
damage the flange. Also, Polysulfide (Thiokol) type sealants
must be avoided.
If in doubt, please contact the manufacturer of your caravan for
further information.
STEP 4
Insert the SKYMAXX ROOFLIGHT into the roof opening with the
hinged section facing the front of the vehicle with the ceiling
flange centered in the opening. Press down on the flange to
compress the sealant to seal to the roof.
STEP 5
After the SKYMAXX ROOFLIGHT has been installed, remove
the excess caulk that may have squeezed out. Using a sealer
such as Dicor self-leveling lap sealant or similar caulking, apply a
bead (approximately 0.25 in./5 mm dia.) along the outside edge
of the flange all the way around the Rooflight.
THIS COMPLETES THE ROOF TOP PORTION OF THE
INSTALLATION
Skip to page 4 for interior installation of SKYMAXX
Plus

STEP 6
Insert the ceiling flange into the opening, lining up the flanges.
STEP 7
Referring to the screw lengths in the table of STEP 2, use the
proper length screws depending on your roof thickness to secure
the ceiling flange to the rooftop flange, taking care not to
overtighten the screws to avoid cracking or deforming the ceiling
flange and rooftop flange.
STEP 8
Optional: Install the screws to secure the ceiling flange to the
caravan ceiling. If the ceiling flange does not lay flat to the
ceiling, you may want to install screws to prevent gapping.
STEP 9
To assemble the Interior Shroud to the Ceiling Flange, line up
the flanges with the channels on the Ceiling Flange. Secure in
place by pressing firmly on the Interior Shroud. This ensures that
the clips on the Interior Shroud will engage the channels on the
ceiling flange to lock it in place.
This completes the installation of the MAXXAIR
SKYMAXX ROOFLIGHT
OPERATION OF YOUR MAXXAIR SKYMAXX ROOFLIGHT
To open the Rooflight for ventilation, separate the screen and
shade by moving the pull bars in opposite directions. Note: The
screen/ shade opening and closing action is manual. Depress
the button on the Rooflight frame to release the handle and raise
the lid by using the handle. Raise the lid to the desired opening
using the slots in the sides of the rooftop flange to position the
lid. After securing the Rooflight in the desired position, pull the
screen and shade together. The amount of screen versus shade
can be adjusted to your preference.
To close the SKYMAXX ROOFLIGHT, move the handle from the
slot and pull the handle toward the open side of the Rooflight.
Push the handle above the button which will lock the Rooflight lid
closed.
NOTE: THE ROOFLIGHT MUST BE CLOSED PRIOR TO
TRANSPORTING OR MOVING THE CARAVAN.
USER SERVICING INSTRUCTIONS
Cleaning of your MAXXAIR SKYMAXX ROOFLIGHT may be
achieved with mild soap and water only. DO NOT USE
ABRASIVE CLOTH ON ROOFLIGHT COVER.
It is advisable when the Rooflight is open to keep the screen
and/or shade covering the Rooflight opening.
Should you have questions, please contact AIRXCEL/MAXXAIR
Customer Service at 316.832.4357 or [e-mail].

FOR INSTALLATION OFSKYMAXX PLUS ROOFLIGHT
WARNING! TO REDUCE THE RISK OF FIRE, ELECTRIC
SHOCK, OR INJURY TO PERSONS, OBSERVE THE
FOLLOWING:
Installation work and electrical wiring must be done by qualified
person(s) in accordance with all applicable codes and standards,
including fire-rated construction.
CAUTION! Disconnect main vehicle power before connecting
12 volt DC power to the MAXXAIR ROOFLIGHT!
STEP 6
Insert the 12 volt DC power supply wires into the large diameter
hole in the ceiling flange, allowing 4 to 6 inches of wire to hang
out. Note: Red wire from the wall control and black wire from the
negative terminal.
STEP 7
Insert the ceiling flange into the opening, lining up the flanges.
STEP 8
Referring to the screw lengths in the table of STEP 2, use the
proper length screws depending on your roof thickness to secure
the ceiling flange to the rooftop flange, taking care not to
overtighten the screws to avoid cracking or deforming the ceiling
flange and rooftop flange.
STEP 9
Optional: Install the screws to secure the ceiling flange to the
caravan ceiling. If the ceiling flange does not lay flat to the
ceiling, you may want to install screws to prevent gapping.
STEP 10
Using the supplied wire splices, connect the 12 volt DC power
supply wires to the LED light wires. Red wire from the wall
control to the red wire (pos) on the LED lights, and the black wire
from the negative terminal.
STEP 11
To assemble the Interior Shroud to the Ceiling Flange, line up
the flanges with the channels on the Ceiling Flange. Make sure
the power wires slide to the inside of the interior assembly and
do not become pinched or entangled. Secure in place by
pressing firmly on the Interior Shroud. This ensures that the clips
on the Interior Shroud will engage the channels on the ceiling
flange to lock it in place.
This completes the installation of the MAXXAIR
SKYMAXX Plus ROOFLIGHT.

OPERATION OF YOUR MAXXAIR SKYMAXX ROOFLIGHT
To open the Rooflight for ventilation, separate the
screen and shade by moving the pull bars in opposite
directions. Note: The screen/ shade opening and
closing action is manual. Depress the button on the
Rooflight frame to release the handle and raise the lid
by using the handle. Raise the lid to the desired
opening using the slots in the sides of the rooftop
flange to position the lid. After securing the Rooflight in
the desired position, pull the screen and shade
together. The amount of screen versus shade can be
adjusted to your preference.
To close the SKYMAXX ROOFLIGHT, move the
handle from the slot and pull the handle toward the
open side of the Rooflight. Push the handle above the
button which will lock the Rooflight lid closed.
If passive ventilation is not needed, the vent inserts
can be changed out with the blank inserts in the
hardware package.
SKYMAXX Plus ROOFLIGHT
The LED lights are controlled by a wall control.
NOTE: THE ROOFLIGHT MUST BE CLOSED PRIOR TO
TRANSPORTING OR MOVING THE CARAVAN.
USER SERVICING INSTRUCTIONS
Cleaning of your MAXXAIR SKYMAXX ROOFLIGHT
may be achieved with mild soap and water only. DO
NOT USE ABRASIVE CLOTH ON ROOFLIGHT
COVER.
It is advisable when the Rooflight is open to keep the
screen and/or shade covering the Rooflight opening.
Should you have questions, please contact
AIRXCEL/MAXXAIR Customer Service at
316.832.4357 or r[email protected]
* * * * SKYMAXX 2 YEAR LIMITED WARRANTY * * * *
AIRXCEL, INC. - RV PRODUCTS DIVISION / MAXXAIR VENTILATION SOLUTIONS WARRANTY:
These products are warranted to be free of manufacturing defects, regardless of ownership for a period of
two (2) years from the original date of purchase. You must keep your original sales receipt. This Limited
Warranty does not include “Acts of God,” failure due to misuse, improper installation or accidental /
incidental damages. Please call your AIRXCEL / MAXXAIR Distributor if you have any questions or need
assistance. Please have your original sales receipt readily available. This limited warranty does not cover
labor or any freight costs for the return of the product to or from AIRXCEL, INC. or costs associated with
installation, removal or reinstallation of the product.
For WARRANTY INFORMATION on products purchased in Australia or New Zealand,
please visit www.coastrv.com.au • www.coastrv.co.nz

This page intentionally left blank

For additional product information please visit www.AIRXCEL.com
AIRXCEL, INC. - RV Products Division / MAXXAIR
3050 N. St. Francis St. • Wichita, KS 67219 • 316.832.3400
PLACE CONSUMER LABEL HERE
