Mayline DUAL XR BASE User manual

NOTE: Hardware for attaching Top, Control Box, and
Hand Control is included with the Base.
1. Align the holes in the Top with the holes in the
ounting Plates and secure in place with eight #10 x
3/4 Screws.
2. Align the holes in the Control Box with the holes in
the underside of the Top and attach it with four #10 x
3/4 Screws.
3. Place the Switch in a comfortable and accessible
location on the underside of the Top and attach it with
two #6 x 5/8 Screws.
4. Route the column cables and the switch cable away
from moving components and secure them in place
with Cable Clamps and Screws.
ASSE BLY INSTRUCTIONS
for DUAL XR BASE with
SINGLE TOP
I551 REV. 06 6-2016
(1)
Switch cable OVER
Cross Channel

NOTE: Hardware for attaching Top, Control Box, and
Hand Control is included with the Base.
1. Place both Top and Keyboard face down onto a
clean/protected surface.
2. Align the holes in the DataCenter with the holes in
the Top and Keyboard. Secure the DataCenter with
#10 x 3/4 Screws supplied with the mechanism.
3. Place the switch cord over the top of the base Cross
Channel.
4. Align the holes in the Top with the holes in the
ounting Plates and secure in place with eight #10 x
3/4 Screws.
5. Choose a desired location for the Control Box and
attach with two #8 x 1 3/4" Screws.
6. Place the Switch in a comfortable and accessible
location on the underside of the Top and attach it with
two #6 x 5/8 Screws. The switch UST be attached
toward the left side of the top.
7. Route the column cables and the switch cable away
from moving components and secure them in place
with Cable Clamps and Screws.
ASSE BLY INSTRUCTIONS
for DUAL XR BASE with
DATACENTER TOP
(2)
Switch cable OVER
Cross Channel
