Mayline TechWorks Series User manual

COMPONENTS:
REF. # QTY. DESCRIPTION PART No.
1 1 TOP CALL~~**
2 2 SPREADER CALL~~**
3 2 UPPER LEG ASSEMBLY A7104**
4 2 LOWER LEG ASSEMBLY A7603**
Fig. 2
1. Select height for table using the
holes in the Upper Leg (3). See
Fig. 1
2. Insert Screws (E3) through
Lower Leg (4) and Upper Leg (3) at
the desired height (six places).
Secure using Lock Washer (E5)
and Hex Nut (E4) two places in
FRONT as shown. Screws only at
REAR. Do not tighten hardware at
this time.
3. Repeat steps 1 and 2 for the
other leg.
Fig. 1
** Denotes Color Code
~~Denotes Size
NOTE: Please count and inspect all pieces before disposing of any carton or packing materials.
When ordering components, specific color and/or size information may be required.
Contact a Mayline Customer Service Representative. 1-800-822-8037
ASSEMBLY INSTRUCTIONS
TechWorks Tables
REF. # QTY. DESCRIPTION PART No.
E1 16 1/4-20 X 1/2 SCREW X352*
E2 4 GLIDE Q588*
E3 12 5/16-18 X 3 1/2 SCREW X241*
E4 12 5/16-18 HEX NUT T130*
E5 12 LOCK WASHER W77*
E6 4 HOLE PLUG F639*
HARDWARE BAG (PART No. A7071) *for individual item, order that part number
FRONT
REAR

Fig. 3
5. Place Top (1) upside down.
Place leg assembly onto the Top.
Align holes in leg assembly with
inserts in the top. See Fig. 4
6. Fasten Leg Assembly to Top
using Screws (E1).
7. Screw Glides (E2) into threaded
holes in Lower Leg (4).
8. Tighten all hardware.
Fig. 4
9. Flip table into an upright position.
10. Insert Hole Plugs (E6) into
lower front of table legs.
FRONT
REAR
4. Place Spreaders (2) in position
over inserted screws at REAR as
shown in Fig. 3. Secure using Lock
Washers (E5) and Hex Nuts (E4) in
eight places. Do not tighten hardware
at this time.
