MAYO 6000 Series User manual

TARE and HD TARE
ELEVATING CONVEYOR
6000 SERIES
OPERATOR'S MANUAL
TARE
HD TARE

MAYO MANUFACTURING, INC. LIMITED WARRANTY
THE FOLLOWING WARRANTIES FOR MACHINERY, EQUIPMENT OR PARTS SOLD BY MAYO MANU-
FACTURING, INC. ARE IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED, OR THOSE
WARRANTIES IMPOSED BY STATUE, INCLUDING, BUT NOT LIMITED TO ANY AND ALL IMPLIED
WARRANTIES OR MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE AND OF ANY
AND ALL OTHER WARRANTY OBLIGATIONS ON THE PART OF MAYO MANUFACTURING, INC. (The
Company).
The Company warrants the machinery, equipment or parts delivered against faulty workmanship or the use
of parts delivered against faulty workmanship or the use of defective materials for a period of one (1) year
from the date of shipment.
The Company's warranties set forth above are the only warranties made by the Company and shall not be
enlarged, diminished or affected by, and no obligation or liability shall arise out of the Company's rendering
technical or other advice or service in connection with the machinery, equipment or parts.
Parts or components furnished to the Company by third persons are guaranteed only to the extent of the
original manufacturer's guarantee to the Company, a copy of which will be supplied to the Purchaser upon
written request to the Company.
LIABILITY
THE COMPANY'S SOLE AND EXCLUSIVE MAXIMUM LIABILITY, AND PURCHASER'S SOLE AND EX-
CLUSIVE REMEDY under the above warranty shall be, at the Company's option, the repair, or replacement
of the machine, equipment or part which is found to be defective due to faulty workmanship or defective
materials, and is returned by the Purchaser to the Company within the warranty period. Shipment both
ways and in transit damage shall be at the purchaser's risk and expense. If the Company elects to repair or
replace the machine, equipment, or part, the Company will have a reasonable time within which to do so.
The remedies set forth above are available upon the following conditions:
1. Purchaser has promptly notied Company upon discovery that the machinery, equipment, or parts are
defective due to faulty workmanship or defective materials; and
2. Purchaser provides Company with a detailed description of the deciencies; and
3. Company's examination discloses that the alleged deciencies exist and were not caused by accident,
re, misuse, neglect, alteration, or any other hazard or by Purchaser's improper installation, use or
maintenance.
Such repair or replacement shall constitute fullment of all Company's liability to Purchaser, whether based
on contract or tort.
This warranty does not apply to any machine that has been altered outside the factory in any way so as,
in the judgement of Mayo, to affect its operation, reliability or safety, or which has been subject to misuse,
neglect or accident.
In the event the Company breach any other provisions of the Purchase Agreement, the Company's EX-
CLUSIVE MAXIMUM LIABILITY AND PURCHASER'S EXCLUSIVE REMEDY, whether in contract or tort,
otherwise shall not in any event exceed the contract price for the particular machine, piece of equipment or
parts involved.
IN NO EVENT SHALL COMPANY BE LIABLE TO ANYONE FOR SPECIAL, COLLATERAL, INCIDENTAL,
OR CONSEQUENTIAL DAMAGES FOR BREACH OF ANY PROVISIONS OF THIS CONTRACT OR WAR-
RANTY. SUCH EXCLUDE DAMAGES INCLUDE, BUT ARE NOT LIMITED TO, costs of REMOVAL AND
REINSTALLATION OF ITEMS, Loss of GOODWILL, LOSS OF PROFITS, LOSS OF USE OR INTERRUP-
TION OF BUSINESS.
WARRANTY VOID IF NOT REGISTERED

MAYO MANUFACTURING, INC.
TARE and HD TARE ELEVATING CONVEYOR 6000 SERIES
DEALER INSPECTION REPORT
SAFETY
______ All Decals Installed
______ Lights, Reectors and SMV Clean
______ Review Operating and Safety Instructions
______ Tire Pressure Checked
______ Wheel Bolts Torqued
______ Inspect Electrical System
______ Lubricate Machine
______ Conveyor Tensioned and Aligned
______ Speed Reducer Gearbox Oil Level Checked
WARRANTY REGISTRATION FORM & INSPECTION REPORT
I have thoroughly instructed the buyer on the above described equipment which review included the Operator’s
Manual content, equipment care, adjustments, safe operation and applicable warranty policy.
Date _______________________________ Dealer’s Rep. Signature____________________________
Signature ____________________________
The above equipment and Operator’s Manual have been received by me and I have been thoroughly instructed
as to care, adjustments, safe operation and applicable warranty policy.
Date ________________________________ Owner's Signature ________________________________
WARRANTY REGISTRATION (Please Print)
This form must be lled out by the dealer and signed by both the dealer and the customer at the time of
delivery.
Customer’s Name __________________________ Dealer's Name___________________________
Address __________________________________ Address ________________________________
City, State/Prov., Code _______________________ City, State/Prov., Code_____________________
Phone Number ( _____ ) ___________________
Contact Name _____________________________
Conveyor Model____________________________
Serial Number _____________________________
Delivery Date ______________________________
WHITE YELLOW PINK
MAYO MFG., INC. DEALER CUSTOMER

SERIAL NUMBER LOCATION
Always give your dealer the serial number of your Mayo Tare and HD Tare Elevating Conveyor when order-
ing parts or requesting service or other information.
The serial number plate is located where indicated. Please mark the number in the space provided for easy
reference.
Model
Serial Number
SERIAL NUMBER LOCATION
TARE
HD TARE

TABLE OF CONTENTS
SECTION DESCRIPTION PAGE
1 Introduction ................................................................ 1
2 Safety.................................................................... 2
2.1 General Safety....................................................... 3
2.2 Equipment Safety Guidelines ................................ 4
2.3 Storage Safety....................................................... 4
2.4 Safety Training....................................................... 5
2.5 Safety Signs .......................................................... 5
2.6 Preparation ............................................................ 6
2.7 Installation Safety .................................................. 6
2.8 Lock-Out Tag-Out Safety ....................................... 6
2.9 Operating Safety.................................................... 7
2.10 Maintenance Safety............................................... 7
2.11 Electrical Safety..................................................... 8
2.12 Tire Safety ............................................................. 8
2.13 Transport Safety .................................................... 8
2.14 Employee Sign-Off Form ....................................... 9
3 Safety Sign Locations ........................................11
4 Operation............................................................ 15
4.1 To the New Operator or Owner............................ 15
4.2 Machine Components.......................................... 16
4.3 General Operation Theory ................................... 17
4.4 Machine Break-In ................................................ 18
4.5 Pre-Operation Checklist ...................................... 18
4.6 Controls ............................................................... 19
4.7 Machine Installation & Preparation...................... 20
4.8 Operating............................................................. 22
4.9 Transport ............................................................. 27
4.10 Storage ................................................................ 29
5 Service and Maintenance.................................. 31
5.1 Service................................................................. 31
5.2 Maintenance ........................................................ 37
6 Trouble Shooting ............................................... 43
 7 Specications .................................................... 45
7.1 Mechanical .......................................................... 45
7.2 Bolt Torque........................................................... 46
7.3 Electrical Schematic ............................................ 47
8 Index ................................................................... 49

1
1 INTRODUCTION
Congratulations on your choice of a Mayo 6000 Series Tare and HD Tare Elevating Conveyor and welcome to
Mayo's quality line of potato handling equipment. This equipment is designed and manufactured to meet the
needs of a discriminating buyer in the agricultural industry for the loading, unloading, processing and storing of
harvest yields.
Safe, efficient and trouble free operation of your new Mayo Tare and HD Tare Elevating Conveyor requires that
you, and anyone else who will be operating or maintaining the Tare and HD Tare Elevating Conveyor, read,
understand and practice ALL of the Safety, Operation, Maintenance and Trouble Shooting recommendations
contained within this Operator's Manual.
This manual applies to the Tare and HD Tare Elevating Conveyor Model 6000 manufactured by Mayo. Certain
options may be available to specically tailor the Conveyor to your operation and may not be included in this
manual. Please contact the manufacturer regarding additional information about these options. Use the Table
of Contents and Index as a guide to nd specic information.
Keep this manual handy for frequent reference and so that it will be passed on to new operators or owners. Call
your Mayo dealer if you need assistance, information or additional copies of this manual.
MACHINE ORIENTATION - The hopper end of the Tare and HD Tare Elevating Conveyor is the front. All electri-
cal controls are on the left side.
TARE
HD TARE

2
The Safety Alert symbol identies
important safety messages on your
Mayo Tare and HD Tare Elevating
Conveyor and in the manual. When
you see this symbol, be alert to the
possibility of personal injury or death.
Follow the instructions in the safety
message.
2 SAFETY
SAFETY ALERT SYMBOL
If you have any questions not answered in this manual or require additional copies or the manual is damaged,
please contact your dealer or Mayo, P.O. Box 497, Bus Highway 2, East Grand Forks, Minnesota, 56721.
(Telephone) 218-773-1234, (FAX) 218-773-6693 or toll free at 1-800-223-5873.
Accidents Disable and Kill
Accidents Cost You Money
Accidents Can Be Avoided
Why is SAFETY important to you?
This Safety Alert symbol means
ATTENTION! BECOME ALERT!
YOUR SAFETY IS INVOLVED!
3 Big Reasons
DANGER -Indicates an imminently hazardous situ-
ation that, if not avoided, will result in
death or serious injury. This signal word
is to be limited to the most extreme situa-
tions, typically for machine components
that, for functional purposes, cannot be
guarded.
WARNING - Indicates a potentially hazardous situ-
ation that, if not avoided, could result
in death or serious injury, and includes
hazards that are exposed when guards
are removed. It may also be used to
alert against unsafe practices.
CAUTION - Indicates a potentially hazardous situ-
ation that, if not avoided, may result in
minor or moderate injury. It may also be
used to alert against unsafe practices.
SIGNAL WORDS:
Note the use of the signal words DANGER,
WARNING and CAUTION with the safety
messages. The appropriate signal word for each
message has been selected using the following
guide-lines:
A AIGUIEN QUE SI LO LEA PARA
QUE LE TRADUZCA LAS MIDIDAS DE
SEGURIDAD.

3
2.1 GENERAL SAFETY
1. Read and understand the Oper-
ator's Manual and all safety
signs before supplying power
to, operating, maintaining or
adjusting the Conveyor.
2. Only trained, competent persons shall operate the
Conveyor. An untrained operator is not qualied to
operate this machine.
3. Provide a rst-aid kit for use in
case of an accident. Store in a
highly visible place.
4. Provide a re extinguisher for use in
case of an accident. Store in a highly
visible place.
5. Install and properly secure all guards
and shields before operating.
6. Wear appropriate
protective gear.
This list includes
but is not limited
to:
- Protective
shoes with slip
resistant soles
- Protective
glasses or goggles
- Heavy gloves
- Hearing protection
7. Turn machine OFF, shut down and lockout power
supply, relieve hydraulic pressure and wait for all
moving parts to stop before servicing, adjusting,
maintaining, repairing or cleaning. (Safety lockout
devices are available through your Mayo dealer
parts department).
8. Know the emergency medical center number for
your area.
9. Review safety related items with all operators
annually.
SAFETY
YOU are responsible for the SAFE operation and
maintenance of your Mayo Tare and HD Tare Elevat-
ing Conveyor. YOU must ensure that you and any-
one else who is going to operate, maintain or work
around the Conveyor be familiar with the operating
and maintenance procedures and related SAFETY
information contained in this manual. This manual
will take you step-by-step through your working day
and alerts you to all good safety practices while op-
erating the Conveyor.
Remember, YOU are the key to safety. Good safety
practices not only protect you but, also the people
around you. Make these practices a working part of
your safety program. Be certain that EVERYONE op-
erating this machine is familiar with the procedures
recommended and follows safety precautions. Re-
member, most accidents can be prevented. Do not
risk injury or death by ignoring good safety practic-
es.
• Read and understand the Operator's Manual
and all safety signs before supplying power to,
operating, maintaining or adjusting the Conveyor.
• Conveyorownersmustgiveoperatinginstructions
to operators or employees before allowing them
to operate the Conveyor, and at least annually
thereafter.
• Themost importantsafetydeviceonthisequip-
ment is a SAFE operator. It is the operator’s re-
sponsibility to read and understand ALL Safety
and Operating instructions in the manual and to
follow these. Most accidents can be avoided.
• Apersonwhohasnotreadandunderstoodallop-
erating and safety instructions is not qualied to
operate this machine. An untrained operator ex-
poses himself and bystanders to possible serious
injury or death.
• Do not modify the equipment in any way.
Unauthorized modication may impair the func-
tion and/or safety and could affect the life of the
equipment.
• ThinkSAFETY!WorkSAFELY!

4
2.2 EQUIPMENT SAFETY GUIDELINES
1. Safety of the operator and bystanders is one of the
main concerns in designing and developing a ma-
chine. However, every year many accidents oc-
cur which could have been avoided by a few sec-
onds of thought and a more careful approach to
handlingequipment.You,theoperator,canavoid
many accidents by observing the following pre-
cautions in this section. To avoid personal injury
or death, study the following precautions and insist
those working with you, or for you, follow them.
2. In order to provide a better view, certain photo-
graphs or illustrations in this manual may show an
assembly with a safety shield removed. However,
equipment should never be operated in this condi-
tion. Keep all shields in place. If shield removal
becomes necessary for repairs, replace the shield
prior to use.
3. Replace any safety sign or instruction sign that is
not readable or is missing. Location of such safety
signs is indicated in this manual.
4. Never use alcoholic beverages or drugs which
can hinder alertness or coordination while oper-
ating this equipment. Consult your doctor about
operating this machine while taking prescription
medications.
5. Under no circumstances should young chil-
dren be allowed to work with this equipment.
Do not allow persons to operate or assemble
this unit until they have read this manual and
have developed a thorough understanding of
the safety precautions and of how it works.
Review the safety instructions with all users
annually.
6. This equipment is dangerous to children and per-
sons unfamiliar with its operation. The operator
should be a responsible, properly trained and
physically able person familiar with farm machin-
ery and trained in this equipment's operations.
If the elderly are assisting with farm work, their
physical limitations need to be recognized and
accommodated.
7. Never exceed the limits of a piece of machinery. If
its ability to do a job, or to do so safely, is in ques-
tion - DON'T TRY IT.
8. Do not modify the equipment in any way.
Unauthorized modication result in serious injury
or death and may impair the function and life of the
equipment.
9. In addition to the design and conguration of this
implement, including Safety Signs and Safety
Equipment, hazard control and accident preven-
tion are dependent upon the awareness, concern,
prudence, and proper training of personnel in-
volved in the operation, transport, maintenance,
and storage of the machine. Refer also to Safety
Messages and operation instruction in each of the
appropriate sections of the auxiliary equipment
and machine Manuals. Pay close attention to the
Safety Signs affixed to the auxiliary equipment
and the machine.
2.3 STORAGE SAFETY
1. Store the Elevating Conveyor on a rm level
surface.
2. If required, make sure the unit is rmly blocked
up.
3. Make certain that all mechanical locks are safely
and positively connected before storing.
4. Store away from areas of human activity.
5. Do not allow children to play on or around the
stored Elevating Conveyor.
6. Lock out power by turning off master control panel
or junction box and padlocking the door shut to
prevent electrocution or unauthorized start up of
the Elevating Conveyor.

5
2.4 SAFETY TRAINING
1. Safety is a primary concern in the design and man-
ufacture of our products. Unfortunately, our efforts
to provide safe equipment can be wiped out by a
single careless act of an operator or bystander.
2. In addition to the design and conguration of
equipment, hazard control and accident preven-
tion are dependent upon the awareness, con-
cern, prudence and proper training of personnel
involved in the operation, transport, maintenance
and storage of this equipment.
3. It has been said, "The best safe-
ty feature is an informed, care-
ful operator." We ask you to be
that kind of an operator. It is the
operator's responsibility to read
and understand ALL Safety and Operating instruc-
tions in the manual and to follow these. Accidents
can be avoided.
4. Working with unfamiliar equipment can lead to
careless injuries. Read this manual, and the
manual for your auxiliary equipment, before
assembly or operating, to acquaint yourself
with the machines. If this machine is used by
any person other than yourself. It is the ma-
chine owner's responsibility to make certain
that the operator, prior to operating:
a. Reads and understands the operator's
manuals.
b. Is instructed in safe and proper use.
5. Know your controls and how to stop pilers, clod
hoppers, conveyors and any other auxiliary equip-
ment quickly in an emergency. Read this manual
and the one provided with your other equipment.
6. Train all new personnel and review instructions
frequently with existing workers. Be certain only a
properly trained and physically able person will op-
erate the machinery. A person who has not read
and understood all operating and safety instruc-
tions is not qualied to operate the machine. An
untrained operator exposes himself and bystand-
ers to possible serious injury or death. If the elderly
are assisting with farm work, their physical limita-
tions need to be recognized and accommodated.
2.5 SAFETY SIGNS
1. Keep safety signs clean and legible at all times.
2. Replace safety signs that are missing or have be-
come illegible.
3. Replaced parts that displayed a safety sign should
also display the current sign.
4. Safety signs displayed in section 3 each have a
part number in the lower right corner. Use this part
number when ordering replacement safety signs.
5. Safety signs are available from your authorized
Distributor or Dealer Parts Department or the
factory.
How to Install Safety Signs:
• Besurethattheinstallationareaiscleananddry.
• Besuretemperatureisabove50°F(10°C).
• Determineexactposition before you removethe
backing paper. (See Section 3).
• Removethesmallestportionofthesplitbacking
paper.
• Alignthesignoverthespeciedareaandcareful-
ly press the small portion with the exposed sticky
backing in place.
• Slowly peel back the remaining paper and care-
fully smooth the remaining portion of the sign in
place.
• Smallair pockets can be pierced with a pin and
smoothed out using the piece of sign backing
paper.

6
2.7 INSTALLATION SAFETY
1. Disconnect and remove all mechanical locks, an-
chor chains and any other transport devices that
would hinder or prohibit the normal functioning of
the Elevating Conveyor upon start up. Serious
damage to the machine and/or personal injury to
the operator and bystanders may result from at-
tempting to operate the machine while mechanical
locking devices are still attached.
2. Position the machine on rm, level ground before
operating.
3. Block up machine to level the frame before using.
Use a level to be sure.
4. Have at least one extra person available to as-
sist when elevating, moving or positioning to other
equipment.
5. Make certain that sufficient amperage, at the prop-
er voltage and frequency (60Hz) is available before
connecting power. If you are uncertain, have a li-
censed electrician provide power to the machine
by following ANSI/NFPA 70 Wiring Standard.
6. If using the Elevating Conveyor as part of material
handling system, anchor securely to other equip-
ment before starting.
2.8 LOCK-OUT TAG-OUT SAFETY
1. Establish a formal Lock-Out Tag-Out program for
your operation.
2. Train all operators and service personnel before
allowing them to work around the Tare and HD
Tare Elevating Conveyor.
3. Provide tags at the work site and a sign-up sheet
to record tag out details.
4. Do not climb on unit unless motors are OFF and
the power locked out at the master panel. Never
perform any maintenance or service work while
power is connected. Keep others away.
2.6 PREPARATION
1. Never operate the Tare and HD Tare Elevating
Conveyor and auxiliary equipment until you have
read and completely understand this manual, the
auxiliary equipment Operator's Manual, and each
of the Safety Messages found on the safety signs
on the Conveyor and auxiliary equipment.
2. Personal protec-
tion equipment in-
cluding hard hat,
safety glasses,
safety shoes, and
gloves are recom-
mended during
assembly, instal-
lation, operation,
adjustment, main-
taining, repairing, removal, or moving the imple-
ment. Do not allow long hair, loose tting clothing
or jewelery to be around equipment.
3. PROLONGED EXPOSURE
TO LOUD NOISE MAY CAUSE
PERMANENT HEARING LOSS!
Motors or equipment attached
can often be noisy enough to
cause permanent, partial hear-
ing loss. We recommend that you wear hearing
protection on a full-time basis if the noise in the
Operator's position exceeds 80db. Noise over
85db on a long-term basis can cause severe hear-
ing loss. Noise over 90db adjacent to the Operator
over a long-term basis may cause permanent, to-
tal hearing loss. NOTE: Hearing loss from loud
noise (from tractors, chain saws, radios, and other
such sources close to the ear) is cumulative over
a lifetime without hope of natural recovery.
4. Clear working area of debris, trash or hidden ob-
stacles that might be hooked or snagged, causing
injury, damage or tripping.
5. Operate only in daylight or good articial light.
6. Be sure machine is properly anchored, adjusted
and in good operating condition.
7. Ensure that all safety shielding and safety signs
are properly installed and in good condition.
8. Before starting, give the machine a "once over" for
any loose bolts, worn parts, cracks, leaks, frayed
belts and make necessary repairs. Always follow
maintenance instructions.

7
2.9 OPERATING SAFETY
1. Read and understand the Operator’s Manual and
all safety signs before operating, maintaining, ad-
justing or repairing the Elevating Conveyor.
2. Turn machine OFF, shut down and lock out pow-
er supply (safety lockout devices are available
through your Mayo dealer parts department), re-
lieve hydraulic pressure and wait for all moving
parts to stop before servicing, adjusting, maintain-
ing or repairing.
3. Install and properly secure all guards and shields
before operating.
4. Keep hands, feet, hair and clothing away from all
moving parts.
5. Clear the area of bystanders, especially small chil-
dren, before starting.
6. Make sure all control switches are in the off posi-
tion before connecting power supply.
7. Establish a formal lock-out tag-out program for
your operation.
8. Before supplying electrical power to the machine,
be sure that you have adequate amperage at the
proper phase and voltage to run it by following
ANSI/NFPA 70 Wiring Standard. If you do not know
or are unsure, consult a licensed electrician.
9. Stay away from overhead obstructions and power
lines when raising the discharge end. Electrocution
can occur without direct contact. Post an observer
at the discharge end to guide the operator.
10. Do not stand between the frame and other struc-
tures or machines when raising the Elevating
Conveyor. Keep others away.
11. Keep the working area clean and dry.
12. Contact Mayo at [phone] or 1 (800) 223-
5873 if you have any questions.
13. Review safety instructions annually.
2.10 MAINTENANCE SAFETY
1. Read and understand all the information contained
in the Operator's Manual regarding operating, ser-
vicing, adjusting, maintaining and repairing.
2. Turn machine OFF, shut down and lock out pow-
er supply (safety lockout devices are available
through your Mayo dealer parts department) and
wait for all moving parts to stop before servicing,
adjusting, maintaining or repairing.
3. Exercise extreme caution when working around,
or with, high-pressure hydraulic systems. De-
pressurize the system before working on it.
4. Follow good shop practices:
- Keep service area clean
and dry.
- Be sure electrical out-
lets and tools are properly
grounded.
- Use adequate light for the
job at hand.
5. Wear heavy gloves and eye protection when
searching for suspected hydraulic leaks. Use a
piece of wood or cardboard as a backstop instead
of hand to isolate and identify a leak. A high pres-
sure concentrated stream of hydraulic uid can
pierce the skin. If such happens, seek immediate
medical attention as infection and toxic reaction
could develop.
6. Make sure all guards and doors are in place and
properly secured when operating the Elevating
Conveyor.
7. Do not work on the Elevating
Conveyor electrical system unless
the power cord is unplugged or the
power supply is locked out. Lock-
out tag-out power source before per-
forming any maintenance work.

8
2.11 ELECTRICAL SAFETY
1. Have only a qualied licensed electrician sup-
ply power by following the ANSI/NFPA 70 Wiring
Standard.
2. Make certain that the Elevating Conveyor is prop-
erly grounded at the power source.
3. Make certain that all electrical switches are in
the OFF position before plugging the Elevating
Conveyor in.
4. Turn machine OFF, shut down and lock out
power supply (safety lockout devices are avail-
able through your Mayo dealer parts depart-
ment), relieve hydraulic pressure and wait for
all moving parts to stop before servicing, ad-
justing, maintaining or repairing.
5. Disconnect power before resetting any motor or
breaker overload.
6. Replace any damaged electrical plugs, cords,
switches and components immediately.
7. Do not work on the Elevating Conveyor electrical
system unless the power cord is unplugged or the
power supply is locked-out tagged-out.
2.12 TIRE SAFETY
1. Inate tires to proper pressure as specied on the
side wall of each tire. Do not overinate or under-
inate.
2. Failure to follow proper procedures when mount-
ing a tire on a wheel or rim can produce an explo-
sion which may result in serious injury or death.
3. Do not attempt to mount a tire unless you have the
proper equipment and experience to do the job.
4. Have a qualied tire dealer or repair service per-
form required tire maintenance.
2.13 TRANSPORT SAFETY
1. Make certain that you are in compliance with local,
state/provincial and federal regulations regard-
ing transporting agricultural equipment on pub-
lic roadways. Install auxiliary light bar on rear of
frame and turn lights on before moving.
2. Use pilot vehicles ahead of and behind the unit
when transporting on a public highway.
3. Make certain that all wheels and tires are in good
repair and that tires are inated to proper pressure.
Do not under-inate or overinate.
4. Fully retract all telescoping conveyor sections and
secure before transporting.
5. Make certain that all mechanical locks and integral
anchor chains are safely and positively connected
before loading or transporting.
6. Raise and secure both jack stands.
7. Lower Conveyor to the fully down position before
moving or transporting.
8. Wrap up and bind to the frame all loose hydraulic
and electrical ends.
9. Be sure that any necessary SMV (slow moving ve-
hicle) signs, reectors and lights required by law
are in proper place and are clearly visible to on-
coming and overtaking traffic.
10. Be sure that the Elevating Conveyor is positive-
ly hitched to the towing vehicle. Use a proper
safety chain to assure a safe hitch hook-up when
transporting.
11. Adhere to local regulations regarding maximum
weight, width and length.
12. Do not exceed 20 MPH (32 Km/H). Reduce speed
on rough roads and surfaces.
13. Do not allow anyone to ride on the Elevating
Conveyor or towing vehicle during transport.
14. Always use hazard ashers on the towing vehicle
when transporting.

9
2.14
DATE EMPLOYEE'S SIGNATURE EMPLOYER'S SIGNATURE

10

11
3 SAFETY SIGN LOCATIONS
The types of safety signs and locations on the equipment are shown in the illustrations that follow. Good safety
requires that you familiarize yourself with the various Safety Signs, the type of warning and the area, or particu-
larfunctionrelatedtothatarea,thatrequiresyourSAFETYAWARENESS.
•ThinkSAFETY!WorkSAFELY!
REMEMBER - If Safety Signs have been damaged, removed, become illegible or parts replaced without safety
signs, new signs must be applied. New safety signs are available from your authorized dealer.
B
A
A
C
B
A
E
G
F

12
The types of safety signs and locations on the equipment are shown in the illustrations that follow. Good safety
requires that you familiarize yourself with the various Safety Signs, the type of warning and the area, or particu-
larfunctionrelatedtothatarea,thatrequiresyourSAFETYAWARENESS.
•ThinkSAFETY!WorkSAFELY!
REMEMBER - If Safety Signs have been damaged, removed, become illegible or parts replaced without safety
signs, new signs must be applied. New safety signs are available from your authorized dealer.
C D
A
A
