Maytag 3LMEDC315FW User manual

W11049661E
ELECTRIC OR GAS DRYER USE AND CARE GUIDE
3LMEDC315FW 3LMEDC415FW
USO DE LA SECADORA ELÉCTRICA O DE GAS
Y GUÍA DE CUIDADO
GUIDE D’UTILISATION ET D’ENTRETIEN DU SÈCHE-LINGE
ÉLECTRIQUE OU À GAZ
GUIDA ALL’USO E ALLA MANUTENZIONE
DELL’ASCIUGATRICE ELETTRICA O A GAS
ELEKTRO- ODER GASTROCKNER – BEDIENUNGS-
UND PFLEGEANLEITUNG
Table of Contents (Original Instructions)
DRYER SAFETY ......................................................................... 2
SPECIFICATIONS....................................................................... 4
CHECK YOUR VENT SYSTEM FOR GOOD AIR FLOW........... 4
CONTROL PANEL & FEATURES............................................... 5
CYCLE GUIDE............................................................................ 6
USING YOUR DRYER ................................................................ 7
DRYER CARE............................................................................. 9
TROUBLESHOOTING.............................................................. 11
WARRANTY.............................................................................. 13
ASSISTANCE OR SERVICE..................................................... 14
Índice de contenido (instrucciones originales)
Table des matières (Instructions d’origine)
Sommario (Istruzioni originali)
Inhaltsverzeichnis (Originalanweisungen)
SEGURIDAD DE LA SECADORA ............................................ 15
ESPECIFICACIONES ............................................................... 17
REVISE EL SISTEMA DE VENTILACIÓN PARA COMPROBAR
SI EL FLUJO DE AIRE ES ADECUADO .................................. 17
PANEL DE CONTROL Y CARACTERÍSTICAS ....................... 18
GUÍA DE CICLOS..................................................................... 19
USO DE LA SECADORA.......................................................... 20
CUIDADO DE LA SECADORA................................................. 22
SOLUCIÓN DE PROBLEMAS.................................................. 24
GARANTÍA................................................................................ 26
ASISTENCIA O SERVICIO ....................................................... 27
SÉCURITÉ DU SÈCHE-LINGE ................................................ 28
SPÉCIFICATIONS..................................................................... 30
VÉRIFICATION D’UNE CIRCULATION D’AIR ADÉQUATE
POUR LE SYSTÈME D’ÉVACUATION..................................... 30
TABLEAU DE COMMANDES ET CARACTÉRISTIQUES ....... 31
GUIDE DE PROGRAMMES ..................................................... 32
UTILISATION DU SÈCHE-LINGE ............................................ 33
ENTRETIEN DU SÈCHE-LINGE .............................................. 35
DÉPANNAGE ............................................................................ 37
GARANTIE................................................................................ 39
ASSISTANCE OU SERVICE APRÈS-VENTE........................... 40
SICUREZZA DELL’ASCIUGATRICE........................................ 41
SPECIFICHE............................................................................. 43
CONTROLLO DEL SISTEMA DI SFIATO PER IL CORRETTO
FLUSSO DELL’ARIA................................................................. 43
PANNELLO COMANDI E FUNZIONI....................................... 44
GUIDA AI CICLI........................................................................ 45
USO DELL’ASCIUGATRICE..................................................... 46
MANUTENZIONE DELL’ASCIUGATRICE ............................... 48
RICERCA GUASTI.................................................................... 50
GARANZIA................................................................................ 52
SERVIZIO DI ASSISTENZA ..................................................... 53
SICHERHEITSHINWEISE ........................................................ 54
SPEZIFIKATIONEN .................................................................. 56
ÜBERPRÜFEN IHRES ABLUFTSYSTEMS AUF GUTE
LUFTZIRKULATION ................................................................. 56
BEDIENFELD UND FUNKTIONEN.......................................... 57
PROGRAMMLEITFADEN......................................................... 58
VERWENDEN DES TROCKNERS ........................................... 59
PFLEGE DES TROCKNERS .................................................... 61
STÖRUNGSBEHEBUNG.......................................................... 63
GARANTIE................................................................................ 65
UNTERSTÜTZUNG ODER KUNDENDIENST ......................... 66

2
DRYER SAFETY
WARNING –
RISK OF FIRE/FLAMMABLE MATERIALS
This is an additional safety alert symbol that alerts you to the risk of re.

3
FOR YOUR SAFETY
1. DO NOT USE OR STORE PETROL OR OTHER FLAMMABLE MATERIALS IN THIS APPLIANCE OR NEAR THIS APPLIANCE.
2. DO NOT SPRAY AEROSOLS IN THE VICINITY OF THIS APPLIANCE WHILE IT IS IN OPERATION.
3. DO NOT MODIFY THIS APPLIANCE.
■Remove all objects from pockets, such as lighters and
matches, before placing items in the dryer.
■Before the dryer is removed from service or discarded, remove
the doors to the drying compartment.
■Do not reach into the dryer if the drum is moving. A door
switch is fitted for your safety.
■Do not install or store the dryer where it will be exposed to the
weather.
■Do not tamper with controls.
■Do not continue to use this appliance if it appears to be faulty.
■Do not repair or replace any part of the dryer or attempt any
maintenance unless specifically recommended in this Use and
Care Guide. Repairs and servicing should only be
carried out by competent service personnel.
■Do not use fabric softeners or products to eliminate static
unless recommended by the manufacturer of the fabric
softener or product. Follow their instructions.
■Clean dryer lint screen before or after each load.
Do not operate dryer without lint screen in place.
■Keep area around the exhaust and inlet openings and
adjacent surrounding areas free from the accumulation of lint,
dust, and dirt.
■The interior of the dryer and exhaust vent should be cleaned
periodically by qualified service personnel.
■See Installation Instructions for earthing instructions.
■WARNING: The appliance must not be supplied through an
external switching device, such as a timer, or connected to a
circuit that is regularly switched on and off by a utility.
■Do not dry unwashed items in this dryer.
■The final part of a tumble dryer cycle occurs without heat (cool
down cycle) to ensure that the items are left at a
temperature that ensures the items will not be damaged.
■Items such as foam rubber (latex foam), shower caps,
waterproof textiles, rubber backed articles, and clothes
or pillows fitted with foam rubber pads must only be dried on a
clothesline.
■If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified person
in order to avoid a hazard.
■WARNING: Never stop a tumble dryer cycle before the end
of the drying cycle unless all items are quickly removed and
spread out so that the heat is dissipated.
IMPORTANT SAFETY INSTRUCTIONS
WARNING: To reduce the risk of fire, electric shock, or injury to persons when using the dryer, follow basic precautions,
including the following:
SAVE THESE INSTRUCTIONS
■Read all instructions before using the dryer.
■Keep a minimum clearance of 100 mm (4") between the rear
of the dryer and any wall.
■The operation of this appliance may affect the operation of
other types of appliances which take their air supply for safe
combustion from the same room. There has to be adequate
ventilation to replace exhausted air and thus avoid the back-
flow of gases into the room from appliances burning other
fuels, including open fires, when operating the tumble dryer.
If in doubt, consult the appliance manufacturers.
■Do not obstruct the air supply to the dryer (see Installation
Instructions for minimum clearances).
■Do not place items exposed to cooking oils in your dryer.
Oil-affected items can ignite spontaneously, especially when
exposed to heat sources such as in a tumble dryer. The
items become warm causing an oxidation reaction in the oil.
Oxidation creates heat. If the heat cannot escape, the items
can become hot enough to catch fire. Piling, stacking, or
storing oil-affected items can prevent heat from escaping and
so create a fire hazard.
■To reduce the risk of fire due to contaminated loads, the final
part of a tumble dryer cycle occurs without heat (cool down
period). Avoid stopping a tumble dryer before the end of the
drying cycle unless all items are quickly removed and spread
out so that the heat is dissipated.
■If it is unavoidable to dry in the dryer items that have been
soiled with substances such as cooking oil, acetone, alcohol,
petrol, kerosene, spot removers, turpentine, waxes and
wax removers, or that have been contaminated by hair care
products, they should be washed in hot water with an extra
amount of detergent before being dried in the dryer. These
items may give off vapours that could ignite or explode. Such
washing will reduce, but not eliminate, the hazard.
■This appliance is not intended for use by persons (including
children under 8 years of age) with reduced physical, sensory,
or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instructions
concerning use of the appliance by persons responsible for
their safety.
■Cleaning and user maintenance by children must be
supervised.
■Children should be supervised to ensure that they do not play
with the appliance.
■Children less than 3 years of age should be kept away from
the appliance unless continuously supervised.
■The dryer should not be used if industrial chemicals have been
used for cleaning.
4
IMPORTANT SAFETY INSTRUCTIONS
precautions, including the following:
WARNING:
Read all instructions before using the dryer.
Keep a minimum clearance of 100 mm (4 in.) between the
rear of the dryer and any wall.
The operation of this appliance may affect the operation of
other types of appliances which take their air supply for safe
combustion from the same room. There has to be adequate
ventilation to replace exhausted air and thus avoid the
back-ow of gases into the room from appliances burning
other fuels, including open res, when operating the tumble
dryer. If in doubt, consult the appliance manufacturers.
Do not obstruct the air supply to the dryer (see Installation
Instructions for minimum clearances).
Do not place items exposed to cooking oils in your dryer.
Oil-affected items can ignite spontaneously, especially when
exposed to heat sources such as in a tumble dryer. The
items become warm causing an oxidation reaction in the oil.
Oxidation creates heat. If the heat cannot escape, the items
can become hot enough to catch re. Piling, stacking or
storing oil-affected items can prevent heat from escaping
and so create a re hazard.
If it is unavoidable to dry in the dryer items that have been
soiled with substances such as cooking oil, acetone, alcohol,
petrol, kerosene, spot removers, turpentine, waxes and wax
removers, or that have been contaminated by hair care
products, should be washed in hot water with an extra
amount of detergent before being dried in the dryer. These
items may give off vapours that could ignite or explode. Such
washing will reduce, but not eliminate, the hazard.
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instructions concerning
use of the appliance by persons responsible for their safety.
Children should be supervised to ensure that they do not
play with the appliance.
The dryer should not be used if industrial chemicals have
been used for cleaning.
Before the dryer is removed from service or discarded,
remove the doors to the drying compartment.
Do not reach into the dryer if the drum is moving. A door
switch is tted for your safety.
Do not install or store the dryer where it will be exposed
to the weather.
Do not tamper with controls.
Do not continue to use this appliance if it appears to be
faulty.
Do not repair or replace any part of the dryer or attempt
any maintenance unless specically recommended in this
Use and Care Guide. Repairs and servicing should only
be carried out by competent service personnel.
Do not use fabric softeners or products to eliminate static
unless recommended by the manufacturer of the fabric
softener or product. Follow their instructions.
Clean dryer lint screen before or after each load. Do not
operate dryer without lint screen in place.
Keep area around the exhaust and inlet openings and
adjacent surrounding areas free from the accumulation of
lint, dust, and dirt.
The interior of the dryer and exhaust vent should be
cleaned periodically by qualied service personnel.
See Installation Instructions for earthing instructions.
Do not dry unwashed items in this dryer.
Items such as foam rubber (latex foam), shower caps,
waterproof textiles, rubber backed articles and clothes or
pillows tted with foam rubber pads must only be dried
on a clothesline.
SAVE THESE INSTRUCTIONS
WARNING: Never stop a tumble dryer cycle before the
end of the drying cycle unless all items are quickly removed
and spread out so that the heat is dissipated.
To reduce the risk of re, electric shock, or injury to persons when using the dryer, follow basic
The nal part of a tumble dryer cycle occurs without heat
(cool down cycle) to ensure that the items are left at a
temperature that ensures the items will not be damaged.
If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualied
person in order to avoid a hazard.

4
CHECK YOUR VENT SYSTEM FOR GOOD AIR FLOW
Good air flow
Along with heat, dryers require good air flow to efficiently dry
laundry. Proper venting will reduce your drying times and
improve your energy savings. See Installation Instructions.
The venting system attached to the dryer plays a big role
in good air flow.
Service calls caused by improper venting are not covered by
the warranty and will be paid by the customer, regardless of
who installed the dryer.
To maintain good air flow:
Good Better
USE AUTOMATIC DRY CYCLES FOR BETTER FABRIC CARE AND ENERGY SAVINGS
Use the Automatic Dry cycles to provide the most energy savings and enhanced fabric care from the dryer. During Automatic Dry cycles,
drying air temperature or moisture level are sensed in the load. This sensing occurs throughout the drying cycle and the dryer shuts off
when the load reaches the selected dryness. The Energy Preferred cycle will provide optimal energy savings.
With Timed Dry, the dryer runs the amount of time set and sometimes results in shrinkage, wrinkling, and static due to over-drying. Use
Timed Dry for the occasional damp load that needs a little more drying time or when using the drying rack.
■Clean your lint screen before each load.
■Replace plastic or foil vent material with 102 mm (4")
diameter heavy, rigid vent material.
■
4"
102 mm
Use the shortest length of vent possible.
■Use no more than four 90° elbows in a vent system;
each bend and curve reduces air flow.
■Remove lint and debris from the exhaust hood.
■Remove lint from the entire length of the vent system
at least every 2 years. When cleaning is complete, be
sure to follow the Installation Instructions supplied with
your dryer for final product check.
■Clear away items from the front of the dryer.
SPECIFICATIONS
Models 3LMEDC315FW
3LMEDC415FW
Rated Voltage 220–240 V 2N~
Rated Frequency 50 Hz
Rated Current 20 A
Dry Linen Capacity
(Maximum) 15 kg (33 lb)
IEC Capacity 7 kg (15 lb)
Height 1067 mm (42")
Width 737 mm (29")
Depth 706 mm (2713⁄16")
Fire Hazard
Use a heavy metal vent.
Do not use a plastic vent.
Do not use a metal foil vent.
Failure to follow these instructions can result in
death or fire.
NOTE: The noise level of the dryer is below 70 dB(A).
These units are sold in multiple regions with different requirements
for measuring capacity. Below are a few of the valid forms of
measure posted on this product:
Dry Linen Capacity: A weight measure in load size that reflects the
volumetric size of the dryer drum.
IEC Capacity: The capacity measure that represents the maximum
capacity of dry linens and textiles which the manufacturer declares
can be treated in a specific cycle.
IMPORTANT: This appliance is intended to be used in
household and similar applications such as:
■Staff kitchen areas in shops, offices, and other working
environments
■Farm houses
■By clients in hotels, motels, and other residential-type
environments
■Bed and breakfast-type environments
■Areas for communal use in blocks of flats or in launderettes.

5
CONTROL PANEL & FEATURES
WRINKLE CONTROL FEATURE (on some models)
When you are unable to remove a load of clothes from the dryer
as soon as it stops, wrinkles can form. The Wrinkle Control
feature periodically tumbles, rearranges, and fluffs the load to
help keep wrinkles from forming.
■Get 40 minutes of heat-free, periodic tumbling at the end
of a cycle. Turn the Wrinkle Control knob to on or off at any
time before the cycle has ended.
DRYER CYCLE KNOB
Use your Dryer Cycle Knob to select available cycles on
your dryer. Turn the knob to select a cycle for your laundry load.
See “Cycle Guide” for detailed descriptions of cycles.
TIMED DRY
Will run the dryer for the approximate time on the control.
On models with a selectable temperature knob, you may
choose a setting based on the fabrics in your load. Drying
time and temperature will depend on your dryer model.
AUTOMATIC DRY
Senses moisture in the load or air temperature and shuts off
when the load reaches the selected dryness level. Gives the
best drying in the shortest time. Drying time will vary based
on fabric type, load size, and dryness setting.
1
2
3TEMPERATURE
Select a drying temperature based on the fabrics in your load.
If you are unsure of the temperature to select for a load, select
the lower setting rather than the higher setting.
START/STOP
The Cycle Signal produces an audible sound when the drying
cycle is finished. Promptly removing clothes at the end of the
cycle reduces wrinkling.
Turn the START/STOP knob to select the desired setting
(On or Off). Press the START/STOP knob to start the dryer.
NOTE: When the Wrinkle Control setting is selected,
the tone will sound every 5 minutes until the clothes
are removed or the Wrinkle Control setting ends.
2 31
4
4
Not all features and options are available on all models.
Appearance may vary.
2 4

6
Not all cycles and settings are available on all models.
Note: Government energy certifications for the Maytag Gas and Electric models were based on the Timed Dry cycle with the Maximum
drying temperature setting. The as - shipped defaults of Auto Dry, Accura Dry, or Automatic Dry, Normal cycle, Low heat, Wrinkle Shield were
not used.
CYCLE GUIDE – AUTOMATIC DRY CYCLES
CYCLE GUIDE – TIMED DRY CYCLES
Not all cycles and settings are available on all models.
TIMED DRY – Will run the dryer for the approximate time on the control.
NOTE: If loads do not seem as dry as you would like, select More Dry next time you dry a similar load. If loads seem drier than you like, select
Less Dry next time you dry a similar load.
Setting the Drying Temperature
If your dryer has multiple heat settings:
A High temperature setting may be used for drying
heavyweight items such as towels and work clothes.
A Low to Medium temperature setting may be used for drying
medium-weight items such as sheets, blouses, dresses,
underwear, permanent press fabrics, and some knits.
Use the No Heat setting for foam, rubber, plastic,
or heat-sensitive fabrics.
Line-dry bonded or laminated fabrics.
NOTE: If you have questions about drying temperatures
for various loads, refer to the care label directions.
Items to Dry: Cycle: Temperature: Available Options: Cycle Details:
Jeans, heavy work
clothes, towels More Dry High Wrinkle Control/ Wrinkle Prevent
Temperature
Cycle Signal
Automatic cycles give the best drying in the
shortest time. Drying time varies based on
fabric type, load size, and dryness setting.
Select a drying temperature based on the
fabrics in your load. If you are unsure of the
temperature to select for a load, select the
lower setting rather than the higher setting.
Work clothes,
medium-weight
fabrics, sheets
Normal
or Energy
Preferred
Medium Wrinkle Control/
Wrinkle Prevent
Temperature
Cycle Signal
Casual, shirts, pants,
lightweight items,
synthetics, delicates,
athletic wear
Delicate or
Less Dry Low Wrinkle Control/ Wrinkle Prevent
Temperature
Cycle Signal
Items to Dry: Cycle: Temperature: Available Options: Cycle Details:
Large or heavy items such
as thick towels
or robes
Heavy Dry Any Temperature Choose High to dry large or heavy loads.
Any load Damp Dry/
Freshen Up Any Temperature Dries items to a damp level or for items that do not require an entire drying cycle.
Rubber, plastic,
heat-sensitive fabrics Air Fluff/ Air Dry No Heat Temperature No-heat drying.

7
USING YOUR DRYER
1. Clean the lint screen
Clean the lint screen before each load. Pull the lint screen out
of its holder. Roll lint off the screen with your fingers. Do not rinse
or wash screen to remove lint. Push the lint screen firmly back into
place.
For additional cleaning information, see “Dryer Care.”
2. Load the dryer
Place laundry in the dryer. Close the door.
NOTE: Your model may have a different door than the one shown.
Some models have drop-down doors.
Do not tightly pack the dryer; clothes should be able to tumble
freely.
WARNING: To reduce the risk of fire, electric shock, or injury to
persons, read the Important Safety Instructions before operating this
dryer.
Before using your dryer, wipe the dryer drum with a damp cloth
to remove dust from storing and shipping.
WARNING
Fire Hazard
No washer can completely remove oil.
Do not dry anything that has ever had any type of oil on
it (including cooking oils).
Items containing foam, rubber, or plastic must be dried
on a clothesline or by using an Air Cycle.
Failure to follow these instructions can result in death
or fire.

8
5. Press START/STOP to begin cycle
Press and hold the START/STOP knob to begin the cycle.
To end the cycle early, turn the START/STOP knob to Off.
Promptly remove garments after cycle has completed to reduce
wrinkling. Use the Wrinkle Control feature to avoid wrinkling when
you are unable to remove a load from the dryer as soon as it stops.
4. Set cycle settings and options
Select cycle settings and options by turning the knob to the
desired position.
NOTE: Not all options and settings are available with all cycles.
Temperature
Turn the Temperature knob to change the drying temperature
setting. See “Setting the Drying Temperature.”
Wrinkle Control feature (on some models)
Get 40 minutes of heat-free, periodic tumbling at the end of a
cycle. Turn the Wrinkle Control knob to select NO to turn off at
any time before the cycle has ended.
3. Select the desired cycle
Select the desired cycle for your load. See the “Cycle Guide”
for more information about each cycle.
AUTOMATIC DRY Cycles
You can select a different dryness level, depending on your
load, by turning the knob to dryness level.
Selecting More Dry, Normal, Energy Preferred, or Less Dry
automatically adjusts the dryness level at which the dryer will
shut off. Once a dry level is set, it cannot be changed without
stopping the cycle.
Automatic Dry cycles give the best drying in the shortest time.
Drying time varies based on fabric type, load size, and dryness
setting.
NOTE: More Dry removes more load moisture. Less Dry removes
less moisture and is used for loads you may want to put on a
hanger to complete drying.

9
DRYER CARE
Keep dryer area clear and free from items that would
block the air flow for proper dryer operation. This includes
clearing piles of laundry in front of the dryer.
Cleaning the lint screen
Every load cleaning
The lint screen is located in the dryer. A screen blocked by lint
can increase drying time.
To clean:
1. Pull the lint screen out of its holder. Roll lint off the screen
with your fingers. Do not rinse or wash screen
to remove lint. Wet lint is hard to remove.
2. Push the lint screen firmly back into place.
IMPORTANT:
■Do not run the dryer with the lint screen loose,
damaged, blocked, or missing. Doing so can cause
overheating and damage to both the dryer and fabrics.
■If lint falls off the screen into the dryer during removal,
check the exhaust hood and remove the lint. See
“Venting Requirements” in the Installation Instructions.
■Clean space where
lint screen is located, as
needed. Using a vacuum,
gently remove any lint that
has accumulated outside
of the lint screen.
As-needed cleaning
Laundry detergent and fabric softener residue can build up
on the lint screen. This buildup can cause longer drying times
for your clothes or cause the dryer to stop before your load is
completely dry. The screen is probably clogged if lint falls off
while the screen is in the dryer.
Clean the lint screen with a nylon brush every 6 months,
or more frequently, if it becomes clogged due to a residue
buildup.
To wash:
1. Roll lint off the screen with your fingers.
2. Wet both sides of lint screen with hot water.
3. Wet a nylon brush with hot water and liquid detergent.
Scrub lint screen with the brush to remove residue buildup.
4. Rinse screen with hot water.
5. Thoroughly dry lint screen with a clean towel.
Reinstall screen in dryer.
Cleaning the dryer interior
To clean dryer drum
1. Apply a liquid, nonflammable household cleaner to the
stained area of the drum and rub with a soft cloth until
stain is removed.
2. Wipe drum thoroughly with a damp cloth.
3. Tumble a load of clean cloths or towels to dry the drum.
NOTE: Garments that contain loose dyes, such as denim
blue jeans or brightly colored cotton items, may discolor the
dryer interior. These stains are not harmful to your dryer and
will not stain future loads of clothes. Dry these items inside
out to avoid drum staining.
Removing accumulated lint
From inside the dryer cabinet
Lint should be removed every 2 years, or more often,
depending on dryer usage. Cleaning should be done
by a qualified servicer.
From the exhaust vent
Lint should be removed every 2 years, or more often,
depending on dryer usage.
Cleaning the dryer location
Explosion Hazard
Keep flammable materials and vapors, such as
gasoline, away from dryer.
Place dryer at least 18 inches (46 cm) above the
floor for a garage installation.
Failure to do so can result in death, explosion,
or fire.

10
Vacation, storage, and moving care
Non-Use or Storage Care
Operate your dryer only when you are at home. If you will be on
vacation or not using your dryer for an
extended period of time, you should:
1. Unplug dryer or disconnect power.
2. (For gas dryers only): Close shut-off valve to gas
supply line.
3. Clean lint screen. See “Cleaning the lint screen.”
Moving Care
For power supply cord-connected dryers:
1. Unplug the power supply cord.
2. Make sure leveling legs are secure in dryer base.
3. Use tape to secure dryer door.
For direct-wired dryers:
1. Turn off power at fuse or breaker box.
2. Disconnect wiring.
3. Make sure leveling legs are secure in dryer base.
4. Use tape to secure dryer door.
For gas dryers:
1. Unplug or disconnect power to dryer.
2. Close shut-off valve in gas supply line.
3. Disconnect gas supply line pipe and remove fittings
attached to dryer pipe.
4. Cap the open fuel supply line.
5. Make sure leveling legs are secure in dryer base.
6. Use tape to secure dryer door.
Reinstalling the Dryer
Follow the Installation Instructions to locate, level,
and connect the dryer.
Changing the drum light
(on some models)
1. Unplug dryer or disconnect power.
2. Open the dryer door. Locate the light bulb cover
on the back wall of the dryer. Using a Phillips-head
screwdriver, remove the screw located in the lower
right-hand corner of the cover. Remove the cover.
3. Turn bulb counterclockwise. Replace the bulb with
a 10 W appliance bulb only. Replace the cover and
secure with the screw.
4. Plug into a grounded outlet or reconnect power.

11
First try the solutions suggested here to possibly avoid the cost of a service call.
If you experience Possible Causes Solution
Clothes are not drying
satisfactorily; drying times
are too long
Lint screen or lint screen housing is clogged
with lint. Clean lint screen before each load. Clean space where lint screen is located, as needed. Using a vacuum, gently remove
any lint that has accumulated outside of the lint screen.
The Air Fluff/Air Dry cycle or No Heat
temperature setting has been selected. Select the right cycle for the types of garments being dried. See “Cycle Guide.”
Load too large and heavy to dry quickly. Separate the load to tumble freely.
Exhaust vent or outside exhaust hood
clogged with lint, restricting air movement. Run the dryer for 5–10 minutes. Hold your hand under the outside exhaust hood to check air movement. If you do not
feel air movement, clean exhaust system of lint or replace
exhaust vent with heavy metal or flexible metal vent. Make sure
vent is not crushed or kinked. See Installation Instructions.
Fabric softener sheets blocking the grille. Use only one fabric softener sheet and use it only once.
Exhaust vent not the correct length. Check that the exhaust vent is not too long or has
too many turns. Long venting will increase drying times.
Make sure vent is not crushed or kinked. See Installation
Instructions.
Exhaust vent diameter not the
correct size. Use 102 mm (4") diameter vent material.
Dryer located in a room with
temperature below 7ºC (45ºF). Proper operation of dryer cycles requires temperatures above 7ºC (45ºF).
Dryer located in a closet without adequate
opening. Closet doors must have ventilation openings at the top and bottom of the door. The front of the dryer requires a minimum
of 25 mm (1") of airspace and, for most installations, the rear
of the dryer requires 127 mm (5").
See Installation Instructions.
Dryer will not run Door not closed completely. Make sure the dryer door is closed completely.
Start/Stop knob not turned to On setting. Turn START/STOP knob to On setting.
Start/Stop knob not pressed firmly
or held long enough. Press and hold the START/STOP knob until you hear the dryer drum moving.
Household fuse is blown or circuit breaker
has tripped. Electric dryers use 2 household fuses or circuit breakers. The drum may be turning, but you may not have heat.
Replace both fuses or reset the circuit breaker. If the
problem continues, call an electrician.
Incorrect power supply. Electric dryers require 240 V power supply. Check with
a qualified electrician.
Wrong type of fuse. Use a time-delay fuse.
Unusual sounds Dryer had a period of non-use. If the dryer hasn’t been used for awhile, there may be a
thumping sound during the first few minutes of operation.
A coin, button, or paper clip is caught
between the drum and front or rear of
the dryer.
Check the front and rear edges of the drum for small
objects. Clean out pockets before laundering.
It is a gas dryer. The gas valve clicking is a normal operating sound.
The four legs are not installed, or the dryer is
not level front to back and side to side. The dryer may vibrate if not properly installed. See Installation Instructions.
Clothing knotted or balled up. When balled up, the load will bounce, causing the dryer
to vibrate. Separate the load items and restart the dryer.
No heat Household fuse is blown or circuit breaker
has tripped. The drum may be turning, but you may not have heat.
Electric dryers use 2 household fuses or circuit breakers.
Replace both fuses or reset the circuit breaker.
If the problem continues, call an electrician.
Supply line valve not open. For gas dryers, make sure the supply line valve is open.
Incorrect power supply. Electric dryers require 240 V power supply.
Check with a qualified electrician.
TROUBLESHOOTING

12
TROUBLESHOOTING
First try the solutions suggested here to possibly avoid the cost of a service call.
If you experience Possible Causes Solution
Cycle time too short Automatic cycle ending early. The load may not be contacting the sensor strips.
Level the dryer.
Use Timed Dry for very small loads. Change the Dry Level
setting on Automatic Dry cycles.
Increasing or decreasing the Dry Level setting will change
the amount of drying time in a cycle.
Lint on load Lint screen clogged. Lint screen should be cleaned before each load.
Stains on load or drum Dryer fabric softener not properly used. Add dryer fabric softener sheets at the beginning of the
cycle. Fabric softener sheets added to a partially dried
load can stain your garments.
Drum stains are caused by dyes in clothing (usually blue
jeans). These will not transfer to other clothing.
Loads are wrinkled Load not removed from dryer at the end
of the cycle. Select Wrinkle Control feature to tumble the load without heat to avoid wrinkling.
Dryer tightly packed. Dry smaller loads that can tumble freely to reduce the
chance of wrinkles forming.
Odors You have recently been painting, staining,
or varnishing in the area where your dryer
is located.
If so, ventilate the area. When the odors or fumes are
gone from the area, rewash and dry the clothing.
The electric dryer is being used for the
first time. The new electric heating element may have an odor. The odor will be gone after the first cycle.
Load is too hot Laundry items removed from the dryer
before the end of the cycle. Allow Cool Down cycle to finish before removing laundry from dryer. All cycles are cooled slowly to reduce
wrinkling and make it easier to handle. Items removed
before Cool Down may feel very warm.
A high temperature cycle was used,
or a separate temperature control was
set on High.
Select a lower temperature and use an automatic drying
cycle. These cycles sense the temperature or the moisture
level in the load and shut off when the load reaches the
selected dryness. This reduces overdrying.
EU representative: Whirlpool Management EMEA Srl Via Pisacane 1, 20016 Pero (MI) Italy
Manufacturer: Whirlpool Corporation, 2000 N M 63, Benton Harbor, MI 49022 U.S.A.
For more information, visit us at www.whirlpool.com/accessories or contact the dealer from whom you purchased your dryer or an
authorized service company.
LATIN AMERICA SERVICE
For other countries in Latin America, see our Warranty Card Latin America and visit our Whirlpool Latinoamerica website
www.whirlpool-latam.com.

13
IF YOU NEED SERVICE:
1. Before contacting us to arrange service, please determine whether your product requires repair. Some questions can be addressed
without service. Please take a few minutes to review the Troubleshooting or Problem Solver section of the Use and Care Guide, or
visit https://www.maytag.com/product_help.
2. All warranty service is provided exclusively by our authorized Maytag Service Providers. In the U.S. and Canada, direct all requests for
warranty service to:
Maytag Customer eXperience Center
In the U.S.A. call 1-800-344-1274. In Canada call 1-800-807-6777.
If outside the 50 United States or Canada, contact your authorized Maytag dealer to determine if another warranty applies.
MAYTAG LAUNDRY
LIMITED WARRANTY
ATTACH YOUR RECEIPT HERE. PROOF OF PURCHASE IS
REQUIRED TO OBTAIN WARRANTY SERVICE.
Please have the following information available when you call the
Customer eXperience Center:
ɃName, address and telephone number
ɃModel number and serial number
ɃA clear, detailed description of the problem
ɃProof of purchase including dealer or retailer name and address
TEN YEAR LIMITED WARRANTY
WHAT IS COVERED WHAT IS NOT COVERED
FIRST YEAR LIMITED WARRANTY (PARTS AND LABOR)
For one year from the date of purchase, when this major appliance
is installed, operated, and maintained according to instructions
attached to or furnished with the product, Maytag brand of
Whirlpool Corporation or Whirlpool Canada LP (hereafter “Maytag”)
will pay for factory specied parts and repair labor to correct defects
in materials or workmanship that existed when this major appliance
was purchased.
SECOND THROUGH TENTH YEAR LIMITED WARRANTY
(DRUM MOTOR AND STAINLESS STEEL BASKET ONLY -
LABOR NOT INCLUDED)
In the second through tenth years from the date of original
purchase, when this major appliance is installed, operated, and
maintained according to instructions attached to or furnished
with the product, Maytag will pay for factory specied parts for
the following components to correct non-cosmetic defects in
materials or workmanship in these parts that prevent function of this
major appliance and that existed when this major appliance was
purchased. This is a limited 10 year warranty on the below named
parts only and does not include repair labor.
ɃDrum (Side Walls Only)
ɃDrive Motor
YOUR SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED
WARRANTY SHALL BE PRODUCT REPAIR AS PROVIDED HEREIN.
Service must be provided by a Maytag designated service company.
This limited warranty is valid only in the United States or Canada
and applies only when the major appliance is used in the country in
which it was purchased. This limited warranty is effective from the
date of original consumer purchase. Proof of original purchase date
is required to obtain service under this limited warranty.
1. Commercial, non-residential, multiple-family use, or use inconsistent
with published user, operator, or installation instructions.
2. In-home instruction on how to use your product.
3. Service to correct improper product maintenance or installation,
installation not in accordance with electrical or plumbing codes, or
correction of household electrical or plumbing (i.e. house wiring,
fuses, or water inlet hoses).
4. Consumable parts (i.e. light bulbs, batteries, air or water lters, etc.).
5. Conversion of your product from natural gas or propane gas or
reversal of appliance doors.
6. Damage from accident, misuse, abuse, re, oods, acts of God, or
use with products not approved by Maytag.
7. Repairs to parts or systems to correct product damage or defects
caused by unauthorized service, alteration, or modication of the
appliance.
8. Cosmetic damage including scratches, dents, chips, and other
damage to appliance nishes unless such damage results from
defects in materials and workmanship and is reported to Maytag
within 30 days.
9. Discoloration, rust, or oxidation of surfaces resulting from caustic
or corrosive environments, including but not limited to, high salt
concentrations, high moisture or humidity, or exposure to chemicals.
10. Pick-up or delivery. This product is intended for in-home repair.
11. Travel or transportation expenses for service in remote locations
where an authorized Maytag servicer is not available.
12. Removal or reinstallation of inaccessible appliances or built-in xtures
(i.e. trim, decorative panels, ooring, cabinetry, islands, countertops,
drywall, etc.) that interfere with servicing, removal, or replacement of
theproduct.
13. Service or parts for appliances with original model/serial numbers
removed, altered, or not easily determined.
The cost of repair or replacement under these excluded
circumstances shall be borne by the customer.
DISCLAIMER OF IMPLIED WARRANTIES
IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR IMPLIED WARRANTY OF FITNESS FOR A
PARTICULAR PURPOSE, ARE LIMITED TO TEN YEARS OR THE SHORTEST PERIOD ALLOWED BY LAW. Some states and provinces do not
allow limitations on the duration of implied warranties of merchantability or tness, so this limitation may not apply to you. This warranty gives you
specic legal rights, and you also may have other rights that vary from state to state or province to province.
DISCLAIMER OF REPRESENTATIONS OUTSIDE OF WARRANTY
Maytag makes no representations about the quality, durability, or need for service or repair of this major appliance other than the representations
contained in this Warranty. If you want a longer or more comprehensive warranty than the limited warranty that comes with this major appliance,
you should ask Maytag or your retailer about buying an extended warranty.
LIMITATION OF REMEDIES; EXCLUSION OF INCIDENTAL AND CONSEQUENTIAL DAMAGES
YOUR SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT REPAIR AS PROVIDED HEREIN. MAYTAG
SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES. Some states and provinces do not allow the exclusion or limitation of
incidental or consequential damages, so these limitations and exclusions may not apply to you. This warranty gives you specic legal rights, and
you also may have other rights that vary from state to state or province to province.
01/14

14
Assistance or Service
Before calling for assistance or service, please check “Troubleshooting” or visit www.maytag.com/help.
It may save you the cost of a service call. If you still need help, follow the instructions below.
When calling, please know the purchase date and the complete model and serial number of your appliance.
This information will help us to better respond to your request.
Maytag Brand Appliances
Customer eXperience Center
553 Benson Road
Benton Harbor, MI 49022-2692
1-800-344-1274
You can write with any questions or concerns at:
Our consultants provide assistance with
Please include a daytime phone number in your correspondence.
Maytag Brand Appliances
Customer eXperience Centre
Unit 200-6750 Century Ave
Mississauga, Ontario L5N 0B7
1-800-807-6777
In the U.S.A. In the U.S.A. and Canada
Features and specifications on our full line of appliances.
Installation information.
Specialized customer assistance (Spanish speaking,
hearing impaired, limited vision, etc.).
If you need replacement parts or to order accessories
We recommend that you use only FSP® Factory Specified Parts.
These parts will fit right and work right because they are made with the same precision
used to build every new MAYTAG®appliance.
To locate FSP® replacement parts or accessories go to www.maytagpartsonline.com.
Questions? Call us toll free at 1-800-344-1274 or in Canada call 1-800-807-6777.
Use and maintenance procedures.
Accessory and repair parts sales.
Referrals to local dealers, repair parts distributors,
and service companies. Maytag designated service
technicians are trained to fulfill the product warranty and
provide after-warranty service, anywhere in the United
States and Canada.

15
SEGURIDAD DE LA SECADORA
Si no sigue las instrucciones de inmediato, usted puede
morir o sufrir una lesión grave.
Si no sigue las instrucciones, usted puede morir o sufrir
una lesión grave.
Todos los mensajes de seguridad le dirán el peligro potencial, le dirán cómo reducir las posibilidades de sufrir una lesión y lo que
puede suceder si no se siguen las instrucciones.
Su seguridad y la seguridad de los demás es muy importante.
Hemos incluido muchos mensajes importantes de seguridad en este manual y en su electrodoméstico. Lea y obedezca siempre
todos los mensajes de seguridad.
ADVERTENCIA
PELIGRO
Este es el símbolo de alerta de seguridad.
Este símbolo le llama la atención sobre peligros potenciales que pueden ocasionar la muerte o una lesión a
usted y a los demás.
Todos los mensajes de seguridad irán a continuación del símbolo de advertencia de seguridad y de la palabra
“PELIGRO” o “ADVERTENCIA”. Estas palabras significan:
PRECAUCIÓN – RIESGO DE INCENDIO/
DE MATERIALES INFLAMABLES
Éste es un símbolo adicional de la alarma de la seguridad que las alarmas usted al riesgo de incendio.

16
PARA SU SEGURIDAD
1. NO UTILICE NI GUARDE GASOLINA NI OTROS MATERIALES INFLAMABLES EN ESTE EQUIPO NI CERCA DE ÉL.
2. NO PULVERICE AEROSOLES EN LAS PROXIMIDADES DE ESTE APARATO MIENTRAS ESTÉ EN FUNCIONAMIENTO.
3. NO MODIFIQUE EL APARATO.
■Retire todos los objetos que haya en los bolsillos, como
mecheros y cerillas, antes de introducir las prendas en la
secadora.
■Antes de retirar del servicio o desechar la secadora, extraiga la
puerta de su compartimento.
■No introduzca las manos en la secadora si el tambor está en
movimiento. Hay un interruptor de puerta para su seguridad.
■No instale ni almacene la secadora donde esté expuesta a la
intemperie.
■No manipule los mandos.
■Interrumpa el uso del equipo si presenta algún fallo.
■No repare ni reemplace ninguna pieza de la secadora ni
intente realizar ningún mantenimiento a menos que se
recomiende específicamente en la Guía de uso y cuidado. Las
reparaciones y el mantenimiento deben estar exclusivamente a
cargo de técnicos competentes.
■No utilice suavizantes ni productos para eliminar la estática a
menos que lo recomiende el fabricante del suavizante o del
producto. Siga sus instrucciones.
■Limpie el filtro de pelusas de la secadora antes o después
de cada carga. No use la secadora sin el filtro de pelusas
instalado.
■Mantenga la zona alrededor de la salida, de las aberturas de
ventilación y de las zonas adyacentes sin pelusas, polvo ni
suciedad.
■La limpieza periódica del interior de la secadora y de la salida
de aire debe estar a cargo de personal de servicio cualificado.
■Consulte en las instrucciones de instalación el método de
conexión a tierra.
■ADVERTENCIA: La alimentación del equipo no debe
suministrarla ningún dispositivo de conmutación externo, como
un temporizador, ni conectarse a algún circuito que un servicio
público encienda y apague periódicamente.
■No seque en la secadora objetos sin lavar.
■La parte final del ciclo de la secadora sucede sin calor (ciclo
de enfriamiento) para garantizar que los objetos queden a una
temperatura que no les provoque daños.
■Los productos con gomaespuma (espuma de látex), gorros
de ducha, tejidos impermeables, tejidos con revestimiento de
goma y prendas o almohadas con gomaespuma solo deben
secarse en un tendedero.
■Si se daña el cable de suministro eléctrico, deberá sustituirlo
el fabricante, su personal de servicio o una persona cualificada
para evitar riesgos.
■ADVERTENCIA: No detenga la secadora antes de finalizar
el ciclo de secado a no ser que saque y extienda todos los
artículos rápidamente para disipar el calor.
INSTRUCCIONES IMPORTANTES DE SEGURIDAD
ADVERTENCIA: Para reducir los riesgos de incendio, descarga eléctrica o daños personales al utilizar la secadora, adopte precau-
ciones básicas, incluidas las siguientes:
CONSERVE ESTAS INSTRUCCIONES
■Lea todas las instrucciones antes de utilizar
la secadora.
■Mantenga una separación de 100 mm (4") como mínimo entre
la parte posterior de la secadora y la pared.
■El funcionamiento de este equipo puede afectar al de otros
tipos de aparatos que aspiren del mismo recinto el aire para
una combustión segura. En el lugar donde se utilice la secadora
debe haber una ventilación adecuada que sustituya el aire de
salida y evite así el reflujo de gases al recinto, procedentes de
aparatos que quemen otros combustibles o de chimeneas. Si
tiene alguna duda, consulte al fabricante del equipo.
■No obstruya la entrada de aire a la secadora (consulte las
separaciones mínimas en las instrucciones de instalación).
■No coloque artículos que hayan estado expuestos a aceites
de cocina en su secadora. Los objetos que hayan estado en
contacto con aceite pueden inflamarse de manera espontánea,
sobre todo si se exponen a fuentes de calor, como una
secadora. Los objetos se calientan y provocan una reacción de
oxidación en el aceite. La oxidación crea calor. Si el calor no
tiene salida, los objetos pueden calentarse lo suficiente como
para arder. Apilar o almacenar artículos contaminados con
aceite puede impedir la salida del calor y crear así un riesgo de
incendio.
■Para reducir el riesgo de incendio debido a cargas
contaminadas, la parte final de un ciclo de secadora se
produce sin calor (periodo de enfriamiento). No detenga la
secadora antes de finalizar el ciclo de secado a no ser que
saque y extienda todos los artículos rápidamente para disipar
el calor.
■Si es inevitable secar en la secadora objetos que se hayan
contaminado con sustancias tales como aceite de cocina,
acetona, alcohol, gasolina, queroseno, quitamanchas,
aguarrás, ceras o quitaceras, o que se hayan contaminado con
productos para el cabello, se deben lavar en agua caliente
con una cantidad adicional de detergente antes de secarlos.
Dichos elementos pueden desprender vapores capaces
de arder o estallar. El lavado indicado reducirá, aunque no
eliminará, el riesgo.
■Este equipo no está pensado para que lo utilicen personas
(incluidos niños de menos de 8 años de edad) con discapacidad
física, sensorial o mental, o con falta de experiencia y de
conocimientos, a menos que estén supervisadas o reciban
instrucciones adecuadas sobre la utilización del equipo por parte
de personas responsables de su seguridad.
■Se debe supervisar la limpieza y el mantenimiento de usuario
realizados por niños.
■Es necesaria la supervisión de los niños para asegurarse de
que no jueguen con el equipo.
■Es necesario mantener alejados del equipo a los niños
menores de 3 años, salvo que reciban una supervisión
constante.
■No se debe utilizar la secadora si se han empleado productos
químicos industriales para la limpieza.
4
IMPORTANT SAFETY INSTRUCTIONS
precautions, including the following:
WARNING:
Read all instructions before using the dryer.
Keep a minimum clearance of 100 mm (4 in.) between the
rear of the dryer and any wall.
The operation of this appliance may affect the operation of
other types of appliances which take their air supply for safe
combustion from the same room. There has to be adequate
ventilation to replace exhausted air and thus avoid the
back-ow of gases into the room from appliances burning
other fuels, including open res, when operating the tumble
dryer. If in doubt, consult the appliance manufacturers.
Do not obstruct the air supply to the dryer (see Installation
Instructions for minimum clearances).
Do not place items exposed to cooking oils in your dryer.
Oil-affected items can ignite spontaneously, especially when
exposed to heat sources such as in a tumble dryer. The
items become warm causing an oxidation reaction in the oil.
Oxidation creates heat. If the heat cannot escape, the items
can become hot enough to catch re. Piling, stacking or
storing oil-affected items can prevent heat from escaping
and so create a re hazard.
If it is unavoidable to dry in the dryer items that have been
soiled with substances such as cooking oil, acetone, alcohol,
petrol, kerosene, spot removers, turpentine, waxes and wax
removers, or that have been contaminated by hair care
products, should be washed in hot water with an extra
amount of detergent before being dried in the dryer. These
items may give off vapours that could ignite or explode. Such
washing will reduce, but not eliminate, the hazard.
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instructions concerning
use of the appliance by persons responsible for their safety.
Children should be supervised to ensure that they do not
play with the appliance.
The dryer should not be used if industrial chemicals have
been used for cleaning.
Before the dryer is removed from service or discarded,
remove the doors to the drying compartment.
Do not reach into the dryer if the drum is moving. A door
switch is tted for your safety.
Do not install or store the dryer where it will be exposed
to the weather.
Do not tamper with controls.
Do not continue to use this appliance if it appears to be
faulty.
Do not repair or replace any part of the dryer or attempt
any maintenance unless specically recommended in this
Use and Care Guide. Repairs and servicing should only
be carried out by competent service personnel.
Do not use fabric softeners or products to eliminate static
unless recommended by the manufacturer of the fabric
softener or product. Follow their instructions.
Clean dryer lint screen before or after each load. Do not
operate dryer without lint screen in place.
Keep area around the exhaust and inlet openings and
adjacent surrounding areas free from the accumulation of
lint, dust, and dirt.
The interior of the dryer and exhaust vent should be
cleaned periodically by qualied service personnel.
See Installation Instructions for earthing instructions.
Do not dry unwashed items in this dryer.
Items such as foam rubber (latex foam), shower caps,
waterproof textiles, rubber backed articles and clothes or
pillows tted with foam rubber pads must only be dried
on a clothesline.
SAVE THESE INSTRUCTIONS
WARNING: Never stop a tumble dryer cycle before the
end of the drying cycle unless all items are quickly removed
and spread out so that the heat is dissipated.
To reduce the risk of re, electric shock, or injury to persons when using the dryer, follow basic
The nal part of a tumble dryer cycle occurs without heat
(cool down cycle) to ensure that the items are left at a
temperature that ensures the items will not be damaged.
If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualied
person in order to avoid a hazard.

17
REVISE EL SISTEMA DE VENTILACIÓN PARA COMPROBAR SI EL FLUJO DE
AIRE ES ADECUADO
Flujo de aire adecuado
Además de calor, las secadoras necesitan un buen flujo de
aire para realizar un secado eficaz. Una ventilación adecuada
reduce los tiempos de secado y aumenta el ahorro de energía.
Consulte las instrucciones de instalación.
El sistema de ventilación de la secadora desempeña un papel
fundamental para lograr un flujo de aire correcto.
La garantía no cubre las llamadas al servicio técnico respecto
a la ventilación incorrecta y correrán a cargo del cliente, con
independencia de quién haya instalado la secadora.
Para mantener un flujo de aire adecuado:
Bien Mejor
UTILICE CICLOS DE SECADO AUTOMÁTICO PARA UN MEJOR CUIDADO DE LA
ROPA Y PARA AHORRAR ENERGÍA
Use los ciclos de Automatic Dry (secado automático) para conseguir de la secadora el máximo ahorro energético y el mejor cuidado de
la ropa. Durante los ciclos de secado automático, en la carga se detecta la temperatura del aire de secado o el nivel de humedad.
Esa detección se produce a lo largo de todo el ciclo de secado y la secadora se apaga cuando la carga alcanza el secado seleccionado.
El ciclo de Energy Preferred (ahorro de energía) permite un óptimo ahorro de energía.
Con Timed Dry (secado programado), la secadora funciona durante el tiempo fijado y, en algunos casos, el exceso de secado puede
provocar encogimiento o arrugas de la ropa y la acumulación de electricidad estática. Use el secado programado ocasionalmente con
cargas húmedas que requieran tiempo de secado adicional o cuando emplee la rejilla de secado.
■Limpie el filtro de pelusas antes de cada carga.
■Sustituya el material del conducto de ventilación de plástico
o de lámina por un material pesado y rígido de 102 mm (4")
de diámetro.
■
4"
102 mm
Use el conducto de ventilación más corto que sea posible.
■No utilice codos de más de 90° en el sistema de
ventilación, ya que cada codo y curva restringe el flujo de
aire.
■Retire de la campana de salida las pelusas y desechos.
■Retire las pelusas del sistema de ventilación en toda su
extensión al menos cada dos años. Cuando finalice la
limpieza, consulte las instrucciones de instalación
suministradas con la secadora para la comprobación final de
producto.
■Retire los objetos que pueda haber delante de la secadora.
ESPECIFICACIONES
Modelos 3LMEDC315FW
3LMEDC415FW
Voltaje nominal 220–240 V 2N~
Frecuencia nominal 50 Hz
Corriente nominal 20 A
Capacidad de ropa
seca (máxima) 15 kg (33 lb)
Capacidad IEC 7 kg (15 lb)
Altura 1067 mm (42")
Anchura 737 mm (29")
Profundidad 706 mm (2713⁄16")
NOTA: El nivel de ruido de la secadora es inferior a 70 dB(A).
Estas unidades se venden en distintas regiones con distintos requisi-
tos en cuanto a medición de capacidad. A continuación se indican
algunas formas de medición válidas especificadas en este producto:
Capacidad de ropa seca: Medición de peso según tamaño de
carga que refleja la capacidad volumétrica del tambor de la secadora.
Capacidad IEC: Medida que indica la capacidad máxima de tejidos
y ropa secos que el fabricante declara que pueden tratarse en un
ciclo específico.
IMPORTANTE: Este equipo se ha diseñado para uso doméstico y
aplicaciones parecidas, como:
■Zonas de cocina de personal en tiendas, oficinas y otros
entornos de trabajo
■Casas rurales
■Por parte de clientes de hoteles, moteles y otros entornos de tipo
residencial
■Pensiones
■Zonas de uso común en bloques de pisos o en lavanderías.

18
PANEL DE CONTROL Y CARACTERÍSTICAS
Función WRINKLE CONTROL (CONTROL DE
ARRUGAS) (en algunos modelos)
Si por alguna razón no retira la carga de ropa de la secadora en
cuanto esta se detiene, pueden formarse arrugas. La función
Wrinkle Control (control de arrugas) gira, reordena y esponja la
carga periódicamente para impedir la formación de arrugas.
■Ejecuta 40 minutos de rotación periódica sin calor al final
del ciclo. Gire el mando de Wrinkle Control (control de
arrugas) a On (encendido) u Off (apagado) en cualquier
momento antes de que termine el ciclo.
MANDO DE CICLOS DE SECADORA
Utilice el mando de ciclos de secadora para seleccionar los
ciclos disponibles. Gire el mando para seleccionar un ciclo para
la carga de ropa. Consulte “Guía de ciclos” para obtener una
descripción detallada de cada ciclo.
TIMED DRY (secado programado)
Hace funcionar la secadora durante el tiempo fijado en
el control. En los modelos con selector de temperatura,
puede elegir un ajuste basado en el tipo de tejido de la
carga. El tiempo y la temperatura de secado dependerán del
modelo de secadora.
1
2
3
AUTOMATIC DRY (secado automático)
Detecta la humedad de la carga o la temperatura del aire
y se apaga cuando la carga alcanza el nivel de secado
seleccionado. Ofrece el mejor secado en el tiempo más
breve. El tiempo de secado varía en función del tipo de
tejido, el tamaño de la carga y el ajuste de sequedad.
TEMPERATURE (temperatura)
Seleccione la temperatura de secado en función del tipo de
tejido de la carga. Si tiene dudas sobre la temperatura que
debe seleccionar para una carga, elija el ajuste más bajo y no el
más alto.
START/STOP (inicio/parada)
Cycle Signal (señal de ciclo) emite un sonido cuando concluye
el ciclo de secado. Si la ropa se retira de inmediato al final del
ciclo, se reduce la formación de arrugas.
Gire el mando START/STOP (inicio/parada) para seleccionar el
ajuste que desee (On u Off). Presione el mando START/STOP
(inicio/parada) para poner en marcha la secadora.
NOTA: Si se selecciona el ajuste Wrinkle Control (control de
arrugas), el sonido se emite cada 5 minutos hasta que se retira
la ropa o finaliza el ajuste.
2 31
4
4
No todas las funciones y opciones están disponibles en todos los modelos.
El aspecto puede variar.
2 4

19
No todos los ciclos y ajustes están disponibles en todos los modelos.
Nota: Las certificaciones energéticas oficiales de los modelos Maytag de gas y eléctricos se basan en el ciclo Timed Dry (secado programado)
con el ajuste de temperatura de secado máxima. No se emplearon las funciones predeterminadas, tal como se enviaron, de Auto Dry (secado auto),
Accura Dry (secado Accura), ni Automatic Dry (secado automático), ciclo Normal, Low heat (calor bajo) o Wrinkle Shield (protección contra arrugas).
GUÍA DE CICLOS: CICLOS DE SECADO AUTOMÁTICO
GUÍA DE CICLOS: CICLOS DE TIMED DRY (SECADO PROGRAMADO)
No todos los ciclos y ajustes están disponibles en todos los modelos.
TIMED DRY (secado programado) - Hace funcionar la secadora durante el tiempo fijado en el control.
NOTA: Si la carga parece menos seca de lo que desea, seleccione More Dry (más seco) la próxima vez que seque una carga parecida. Si la
carga parece más seca de lo que desea, seleccione Less Dry (más seco) o Very Dry (muy seco) la próxima vez que seque una carga parecida.
Ajuste de la temperatura de secado
Si la secadora dispone de varios ajustes de calor:
Se puede utilizar un ajuste de temperatura High (alta) para secar
artículos pesados, como toallas y ropa de trabajo.
Se puede emplear un ajuste de temperatura Low (baja) a
Medium (media) para secar artículos de peso medio, como
sábanas, blusas, vestidos, ropa interior, tejidos con planchado
permanente y algunos tejidos de punto.
Utilice el ajuste No Heat (sin calor) para tejidos de espuma,
goma, plástico o sensibles al calor.
Tejidos aglomerados o laminados para secar tendidos.
NOTA: Si tiene dudas sobre la temperatura de secado de
distintas cargas, consulte las instrucciones de la etiqueta de
cuidados.
Artículos para
secar: Ciclo: Temperature (temperatura): Opciones disponibles: Detalles del ciclo:
Vaqueros, ropa de
trabajo gruesa, toallas More Dry
(más seco) High (alta) Wrinkle Control/Wrinkle Prevent (control de arrugas/
prevención de arrugas)
Temperature (temperatura)
Cycle Signal
(señal de ciclo)
Los ciclos automáticos ofrecen el mejor
secado en el tiempo más breve. El tiempo
de secado varía en función del tipo de
tejido, el tamaño de la carga y el ajuste de
secado.
Seleccione la temperatura de secado en
función del tipo de tejido de la carga. Si
tiene dudas sobre la temperatura que debe
seleccionar para una carga, elija el ajuste
más bajo y no el más alto.
Ropa de trabajo,
tejidos de grosor
medio, sábanas
Normal o Energy
Preferred (ahorro
de energía)
Medium (media) Wrinkle Control/Wrinkle
Prevent (control de arrugas/
prevención de arrugas)
Temperature (temperatura)
Cycle Signal
(señal de ciclo)
Ropa sport, camisas,
pantalones, artículos
ligeros, prendas
sintéticas, tejidos
delicados, ropa
deportiva
Delicate
(delicado) o
Less Dry
(menos seco)
Low (baja) Wrinkle Control/Wrinkle
Prevent (control de arrugas/
prevención de arrugas)
Temperature (temperatura)
Cycle Signal
(señal de ciclo)
Artículos para
secar: Ciclo: Temperature (temperatura): Opciones disponibles: Detalles del ciclo:
Artículos grandes o
pesados, como toallas
o albornoces gruesos
Heavy Dry (secado
intensivo) Cualquiera Temperature (temperatura) Elija High (alta) para secar cargas grandes o pesadas.
Cualquier carga Damp Dry/Freshen
Up (secado húmedo/
reacondicionamiento)
Cualquiera Temperature (temperatura) Seca los artículos dejándolos húmedos
cuando no se necesita un ciclo de
secado completo.
Goma, plástico, tejidos
sensibles al calor Air Fluff/Air Dry (esponjamiento/
secado por aire)
No Heat (sin
calor) Temperature (temperatura) Secado sin calor.

20
USO DE LA SECADORA
1. Limpie el filtro de pelusas
Limpie el filtro de pelusas antes de cada carga. Retire el filtro de
pelusas de su soporte. Retire las pelusas del filtro con los dedos. No
enjuague ni lave el filtro para eliminar las pelusas. Introduzca el filtro
con firmeza para devolverlo a su sitio.
Si desea más información sobre limpieza, consulte “Cuidado de la
secadora”.
2. Cargue la secadora
Coloque la ropa en la secadora. Cierre la puerta.
NOTA: Su modelo puede tener una puerta distinta de la que
aparece en la ilustración. Algunos modelos tienen puertas
abatibles.
No acumule una cantidad de ropa excesiva en la secadora, la ropa
tiene que girar con libertad.
ADVERTENCIA: Para reducir el riesgo de incendio, descarga
eléctrica o daños personales al utilizar esta secadora, siga las
instrucciones importantes de seguridad antes de utilizar la secadora.
Antes de utilizar la secadora, limpie el tambor con un paño húmedo
para eliminar el polvo acumulado durante el almacenamiento y el
transporte.
