MayTech MTF 160 User manual

MTF 160 160 SIZE MINI RACE QUAD
User Manual
V1.0
Disclaimer and Warning
Thank you for purchasing the MTF160.
Please read this instruction manual carefully before using this product. By using this product, you hereby agree to this disclaimer and signify that you have read it in
full.
Please mount and use this product as per this manual strictly. As the manufacturer has no control over use, setup, final assembly, modification (including use other
parts such as motor, ESC, propeller etc), no liability shall be assumed nor accepted for any resulting damage or injury.
As it may cause wireless interference in the living environment, please take effective measures to avoid it.
Any parts of this manual is subjected to change without prior notice.
Any problems while mounting this frame, please contact us or authorized agents
Introdction
MTF160 is a micro racer for FPV hobbyists. It is a highly integrated product with highly flexible control. Combo with motor 1104-4000KV, propeller 3x2" as well as
the popular high quality 10A esc with BLHeli firmware (support ONESHOT ultra high speed). Flight range of remote control more than 1000 meters.
To gain the quality and real-time shoot for FPV, MTF160 also combines 5.8G 32CH 200mW transmitter with 1/3" CMOS lens, which supports 127 or wider 160°
shootings and every moment brings you the exciting FPV experience.
The default firmware of FC is CleanFlight, It can be used after connected the battery, receiver and set the
remote control. MTF160 supports to be flashed Openpilot, there will be with the different experience for you!
MTF160 Power Set
Flight Controller
CC3D (Pre-tuned CleanFlight)
Motor
1104/4000KV
Weight:110g
(Excluding Battery)
Propellor
3 x 2”
Transmitter
5.8G 200mW/32CH
ESC
10A (BLHeli FW)
Battery
(Excluded)
Support 2~3S
Lens
1/3” CMOS Lens FOV:160 Deg
3S 1200~1600 (25-30C
Box List
MTF160 frame 1pcs
Propeller 3020 2 Pair
5.8G antennas 1pcs
Screw M2x6 for propeller 10pc

Switch frequency selection
Dial Switch 12345 to choose the required FR/CH for 32 channels
Installation
1. Mount the 5.8G antenna a picture shows
2. Mount the propeller properly as picture shows
Connection diagram
[1] Negative solder pad for esc signal
[2] Solder pad for esc signal wire
[3] Positive solder pad for battery voltage
[4] Solder pad for esc signal wire
[5] Negative solder pad for esc signal
[6] Negative solder pad for battery voltage
[7] +5V
[8] GND
[9] 5.8G frequency-selection dial switch
[10] 5.8G antennas pedestal
[11] Solder pad for esc signal wire
[12] Negative solder pad for esc signal
[13] Negative solder pad for esc signal
[14] Solder pad for esc signal wire
[15] Positive solder pad for battery voltage
[16] Negative solder pad for battery voltage
[17]+5V
[18] GND
[19] Flight controller
[20] Positive solder pad for battery voltage
[21] Negative solder pad for battery voltage

[1] Solder pad for esc signal wire
[1] Negative solder pad for battery voltage
[2] Positive solder pad for battery voltage
[2] Negative solder pad for esc signal
[3] Negative solder pad for battery voltage
[3] Positive solder pad for battery voltage
[4] Negative solder pad for esc signal
[4] Solder pad for esc signal wire
[5] Solder pad for motor
[5] Solder pad for motor
