Service Information
A
A
PROTECTOR
REAR WINDOW
GLASS
A-A Section
Category S
Repair Guidance
Ref. No.
R064/16
Page
1 of 3
Coverage
Distributor only Please inform your dealers
Date Issued
July 22, 2016
Please convey this information to your Director General Manager
Warranty Dept. Parts Dept. Training Dept. Field Rep.
Date Revised
Applicable Model
Applicable Countries or Specifications
CX-3 (DK)
Worldwide
Subject: Rattle Noise from rear spoiler when closing liftgate
DESCRIPTION
Some vehicles may exhibit a rattle noise from the rear spoiler when closing the liftgate.
CAUSE
Depending on assembly variation of the rear spoiler, the clearance between the rear spoiler outer
panel and the inner bracket is smaller. As a result they interfere and exhibit a vibration noise during
the liftgate closing.
MASS PRODUCTION CHANGE
1. The thickness of the four protectors between the rear spoiler and the rear window glass has
been increased to give tension to the rear spoiler and to suppress the vibration.
2. Portions of the inner bracket, where the clearance between this and the outer panel is the
smallest, have been cut off a little to increase the clearance.
SUBJECT VIN RANGE & DATE OF MODIFICATION
CX-3 (DK)
Japan Built
Spec.
SUBJECT VIN RANGE
Date of Modification
Australia
JM0 DK **** **
100001 - 114676
November 1, 2015
General (R.H.D.)
JM6 DK **** **
General (L.H.D.)
JM7 DK **** **
Europe
JMZ DK **** **
100001 - 133643
US (2016 MY)
JM1 DK **** **
100001 - 122700
Thailand Built
Spec.
Beginning VIN
Date of Modification
Australia
MM0 DK **** **
100001 - 100200
October 5, 2015
Thailand
MM8 DK **** **

R064/16
Page 2 of 3
Front
Rear spoiler
Protector
Protector
Protector
Protector
REPAIR PROCEDURE
When you receive a customer complaint on this concern, use the following repair procedure.
1. Remove the rear spoiler according to the procedure in the workshop manual “REAR
SPOILER REMOVAL”.
2. Remove the protectors from the rear spoiler as shown below and clean the relevant area using
the genuine part cleaner.
3. Attach the improved protectors to the rear spoiler as shown above.
4. Install the rear spoiler according to the procedure in the workshop manual “REAR SPOILER
INSTALLATION”.
PARTS INFORMATION
Part Number
Part Name
Q’ty
Remark
D1YB-51-954
PROTECTOR
1
One set contains four improved
protectors.
D651-68-162A
CLIP, TRIM
1
-
EG21-51-SJ3
CLIP
2
CLIP contains a packing. (Packing is
NOT reusable part.)
Improved
protector
Old
protector
2mm
3.5 mm

R064/16
Page 3 of 3
WARRANTY INFORMATION
Assembly group
S - Body
Subassembly group
19 - SPOILERS
Symptom Code
83 (Unusual vibration)
Damage Code
97 (Improper clearance)
Causal Part No.
D1YB-51-954
Q’ty
1
Operation No.
XXM4MXRX
Labor hours
0.6 hours
Period Covered
Normal Warranty Period
Prior Approval
necessary
NO
NOTE: Claim the TRIM CLIP (D651-68-162A) and CLIP (EG21-51-SJ3) as a related part
number.
Kimiaki Inooka
Manager, Technical Information Gr.
Technical Service Dept.
Mazda Motor Corporation
2F51814433, 151-022 (MC Internal Use)
