MB Tanner Racing Products Deluxe RaceScale User manual

For Further Technical Assistance Please Contact
Tanner Racing Products by MB
10 Cooperative Way Wright City, MO 63390
P.O. Box 110 Foristell, MO 63348
1-800-467-2464 Fax [phone]
www.tannerracing.com
www.mittlerbros.com
Deluxe RaceScale
Instructions
Racing Products
By
1. Replace shocks with solid struts.
2. Fill vehicle with all uids.
3. To activate the CG mode press the up or down arrow and select Center Of
Gravity.
4. To adjust wheel base go into the CG menu and change the value to the
nearest inch using the up or down arrows.
5. Place vehicle on scales.
6. Select “store weight”, this will store total vehicle and front weights. If the CG
displays OVER, then the CG calculation has gone over 100 inches. You will
then need to try again.
7. Raise the rear of the vehicle 10 inches.
8. CG number will appear on the screen.
9. To turn off the CG mode go back to the CG menu and turnoff the CG function.
Center of Gravity Instructions
15” Pads

1. Set all scale pads out individually.
2. Plug the cables into the scale pads.
3. Turn the scales on by pushing the On/Off Button. The scales will turn on and
read Tanner Racescales and show you the level of the battery. If the battery
is low you may want to charge the unit.
4. ZERO the system by pushing the UP or DOWN Arrow and selecting Zero all
pads. If you are not using all pads you may individually Zero each pad. After
you highlight the choice on the menu you may select it by pushing the OK
button. This will then display zero’s on the locations selected.
5. Put your vehicle on the scales and the weights will register, the %’s and totals
will show on the displays.
6. Shut the scales OFF by pushing the ON/OFF button for 2 seconds and the
scales will turn off.
7. Remove the cables from the scale pads and put the unit away. If the scale
needs charging you can plug the AC adapter into the scale and the battery
voltage bar will display on the top display.
1. With your vehicle on the scales access the memory feature by pressing “^”
on the control box.
2. Scroll down to “Memory” and select Car A or Car B.(There are 10 memory
slots available for A & B)
3. You may now use the OK button to toggle between live weight and memory
weight. When you have a memory weight on the screen you can use the up
and down arrows to scroll through stored weights.
4. To store a weight to memory you must be in memory mode, then hold down
the OK button for 2 seconds. You will then be prompted to store the vehicles
weight.
Push this button to turn unit ON
Push and hold for 2 seconds to turn Unit OFF
Select this button as the OK button during the
menu functions.
Push this button to enter into the menu.
This button will also allow you to scroll up.
Push this button to enter into the menu.
This button will also allow you to scroll down.
On/Off/Ok
Button Operation
Scaling Instructions
Memory Function Instructions
