MBW 2000 User manual

OPERATOR’SSAFETY
AND SERVICE MANUAL
MBW, Inc.
250 Hartford Rd • PO Box 440
Slinger, WI 53086-0440
Phone: [phone]
Fax: [phone]
Email: [e-mail]
Website: www.mbw.com
MBW (UK) Ltd.
Units 2 & 3 Cochrane Street
Bolton BL3 6BN, England
Phone: [phone]
Fax: [phone]
MBW FRANCE S.A.R.L.
Z.A. d’Outreville
11 rue Jean Baptiste Néron,
60540 BORNEL
FRANCE
Phone: [phone]
Fax: [phone]
Email: mbwfranc[email protected]
L18702/ 12.11.T
©MBW, Inc. 2008
Printed in the USA
2000, 2018 AP2000+
& 3550
This manual covers the following serial numbers
and higher for each model listed:
2000........................................2064575.
2018........................................2180100.
3550........................................3551200.
VIBRATORY PLATES

TABLE OFCONTENTS
Safety Information . . . . . . . . . . . . . . . . . . . . . . 1
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety Decals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . 3
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . 4
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Before Starting & Operating . . . . . . . . . . . . . . . . . . . . 5
Starting Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Operating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Stopping Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Lifting/Transporting . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Maintenance Schedule . . . . . . . . . . . . . . . . . . . . . . . . 6
Fluid Levels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Engine Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Engine Speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Cleaning Plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Belt Adjustment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Checking Exciter Oil . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Changing Exciter Oil. . . . . . . . . . . . . . . . . . . . . . . . . . 7
Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Torque Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Service Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Exciter Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
(2000) Exciter Disassembly . . . . . . . . . . . . . . . . . . . . 9
(2000) Exciter Assembly . . . . . . . . . . . . . . . . . . . . . 10
(3550) Exciter Disassembly . . . . . . . . . . . . . . . . . . . 10
(3550) Exciter Assembly . . . . . . . . . . . . . . . . . . . . . 10
Exciter installation . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Parts Replacement Cycles and Tolerances . . . . . . . 11
Replacement Parts . . . . . . . . . . . . . . . . . . . . . 12
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2000 & 2018 EXCITER ASSEMBLY . . . . . . . . . . . . 14
3550 Exciter Assembly. . . . . . . . . . . . . . . . . . . . . . . 16
ENGINE ASSEMBLY 2000/2018 . . . . . . . . . . . . . . . 18
ENGINE ASSEMBLY 3550 . . . . . . . . . . . . . . . . . . . 20
ROLLCAGE ASSEMBLY . . . . . . . . . . . . . . . . . . . . . 22
2018 ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

CALIFORNIA PROPOSITION 65 WARNING
Engine exhaust and some of its constituents are
known in the state of California to cause cancer,
birth defects, and other reproductive harm.
WARNING

- 1 -
SAFETY INFORMATION
Introduction
This Safety Alert Symbol is used to call attention
to items or operations which may be dangerous
to those operating or working with this
equipment. The symbol can be found
throughout this manual and on the unit. Please read these
warnings and cautions, along with all decals, carefully
before attempting to operate the unit. Make sure every
individual who operates or works with this equipment is
familiar with all safety precautions.
WARNING
GENERAL WARNING. Indicates information
important to the proper operation of the
equipment. Failure to observe may result in
damage to the equipment and/or severe bodily
injury or death.
CAUTION
GENERAL CAUTION. Indicates information
important to the proper operation of the
equipment. Failure to observe may result in
damage to the equipment.
Safety Precautions
LETHAL EXHAUST GAS: An internal
combustion engine discharges carbon
monoxide, a poisonous, odorless, invisible
gas. Death or serious illness may result if
inhaled. Operate only in an area with proper
ventilation. NEVER OPERATE IN A
CONFINED AREA!
DANGEROUS FUELS: Use extreme caution
when storing, handling and using fuels, as
they are highly volatile and explosive in vapor
state. Do not add fuel while engine is running.
Stop and cool the engine before adding fuel.
DO NOT SMOKE!
SAFETY GUARDS: It is the owner's
responsibility to ensure that all guards and
shields are in place and in working order.
IGNITION SYSTEMS: Breakerless, magneto,
and battery ignition systems can cause severe
electrical shocks. Avoid contacting these
units or their wiring.
SAFE DRESS: Do not wear loose clothing,
rings, wristwatches, etc. near machinery.
NOISE PROTECTION: Wear OSHA specified
hearing protection devices.
EYE PROTECTION: Wear OSHA specified
eye shields, safety glasses, and sweat bands.
FOOT PROTECTION: Wear OSHA specified
steel-tipped safety shoes.
HEAD PROTECTION: Wear OSHA specified
safety helmets.
DUST PROTECTION: Wear OSHA specified
dust mask or respirator.
OPERATOR: Keep children and bystanders
off and away from the equipment.
REFERENCES: For details on safety rules and regulations
in the United States, contact your local Occupational Safety
and Health Administration (OSHA) office. Equipment
operated in other countries must be operated and serviced
in accordance and compliance with any and all safety
requirements of that country. The publication of these
safety precautions is done for your information. MBW does
not by the publication of these precautions, imply or in any
way represent that these are the sum of all dangers present
near MBW equipment. If you are operating MBW
equipment, it is your responsibility to insure that such
operation is in full accordance with all applicable safety
requirements and codes. All requirements of the United
States Federal Occupational Safety and Health
Administration Act must be met when operated in areas that
are under the jurisdiction of that United States Department.
Safety Decals
Carefully read and follow all safety decals. Keep them in
good condition. If decals become damaged, replace as
required. If repainting the unit, replace all decals. Decals
are available from authorized MBW distributors. Order the
decal set listed on the following page(s).

- 2 -




CAUTION
AP3550=254 lbs (115 kg)
GP5800=300 lbs (136 kg)
16402
GP2000=165 lbs (75 kg)
AP2000=193 lbs (88 kg)
GP3550=226 lbs (103kg)
Machine may fall and cause injury or damage if
lifted improperly. Lift by handles or rollcage only.


 
  
 

 
  
  

  
 

  
 





13483
CAUTION
Wear approved hearing protection,
foot protection, eye protection and
head protection.
STOP
Read the Operating Instructions
before operating this piece of
equipment.
Keep unauthorized and untrained
people away from this
equipment.
ROTATING & MOVING PARTS!
Make sure all guards and safety
devices are in place.
Failure to comply could result in serious
bodily injury.
SHUT OFF the motor before servic-
ing or cleaning.
DO NOT RUN in an enclosed area.
The engine produces carbon
monoxide, a POISONOUS GAS.
MODEL SERIAL NO
SERIAL NOMODEL
M-B-W INC.
SLINGER, WI 53086
GROUND POUNDER DIV.
18724
2000
2000
19791
WARNING
OPERATION OF THIS EQUIPMENT MAY
CREATE SPARKS THAT CAN START FIRES
AROUND DRY VEGETATION. A SPARK
ARRESTER MAY BE REQUIRED. THE
OPERATOR SHOULD CONTACT LOCAL FIRE
AGENCIES FOR LAWS OR REGULATIONS
RELATING TO FIRE PREVENTION
Safety Decals (Decal Set #12100)
01066
16402
13482
12573
13483
18724 - 2000
19451 - 2018
18703 - 3550
19791

- 3 -
SPECIFICATIONS
AP2000 GP2000 AP2018 GP2018
CENTRIFUGAL FORCE 2475 lbf (1123 kg) 3250 lbf (1474 kg) 2475 lbf (1123 kg) 3250 lbf (1474 kg)
EXCITER (VPM) 4400 5050 4400 5050
TRAVEL SPEED 90 ft/min(28 m/min) 120 ft/min(36 m/min) 90 ft/min(28 m/min) 120 ft/min(36 m/min)
COMPACTION DEPTH 12 in (30 cm) 14 in (36 cm) 12 in (30 cm) 14 in (36 cm)
WIDTH x LENGTH x HEIGHT 20 x 22 x 21 in
(51 x 56 x 53 cm)
20 x 22 x 21 in
(51 x 56 x 53 cm)
20 x 22 x 18 in
(51 x 56 x 46 cm)
20 x 22 x 18 in
(51 x 56 x 46 cm)
OPERATING WEIGHT
(HONDA)
168 lbs (76 kg) no water
193 lbs (88 kg) full water 165 lbs (75 kg) 168 lbs (76 kg) no water
178 lbs (81 kg) full water 163 lbs (74 kg)
ENGINE SPEED 3400 (RPM) 3400 (RPM) 3400 (RPM) 3400 (RPM)
WATER TANK CAPACITY 3 gal (11.3 l) 1 gal (4)
NOISE LEVEL 84 - 94 dBA 84 - 94 dBA 84 - 94 dBA 84 - 94 dBA
ENGINE OPTIONS
HONDA GX160 (163 cm)³
ROBIN EX13 (126 cm)³
ROBIN EX17 (169 cm)³
BRIGGS 550 (127 cm)³
$3
AP2000
Specifications subject to change without notice.
- No universal method or formula has been accepted for determining “Compaction Force”. All manufactures employ
their own method or formula.

- 4 -
SPECIFICATIONS
AP3550 GP3550
CENTRIFUGAL FORCE 3550 lbf (1610 kg) 3550 lbf (1610 kg)
EXCITER (VPM) 4400 4400
TRAVEL SPEED 110 ft/min(34 m/min) 110 ft/min(34 m/min)
COMPACTION DEPTH 18 in (46 cm) 18 in (46 cm)
WIDTH x LENGTH X HEIGHT 21 x 22 x 22.2 in
(53 x 56 x 56.3 cm)
21 x 22 x22.2 in
(53 x 56 x 56.3 cm)
OPERATING WEIGHT (HONDA) 229 lbs (104 kg) no water
254 lbs (115 kg) full water 226 lbs (103 kg)
ENGINE SPEED 3400 (RPM) 3400 (RPM)
WATER TANK CAPACITY 3 gal (11.3 l)
NOISE LEVEL 84 - 94 dBA 84 - 94 dBA
ENGINE OPTIONS
HONDA GX160 (163 cm)³
ROBIN EX13 (126 cm)³
ROBIN EX17 (169 cm)³
AP3550
Specifications subject to change without notice.
- No universal method or formula has been accepted for determining “Compaction Force”. All manufactures employ
their own method or formula.

- 5 -
LIFT & SECURE HERE
OPERATION
Introduction
MBW equipment is intended for use in very severe
applications. They are powered by four cycle engines and
are available in different sizes and a selection of engines.
This parts manual contains only standard parts. Variations
of these parts as well as other special parts are not included.
Contact your local MBW distributor for assistance in
identifying parts not included in this manual.
Before Starting & Operating
• HANDLE INSTALLATION - Refer to ROLLCAGE
ASSEMBLY, page 22. Install handle by removing handle
attachment nuts. Reinstall handle attachment nut
through the handle bushings from the inside in. Make
sure nylon bushings inside the handle stay in place.
• REMEMBER! It is the owner’s responsibility to
communicate information on the safe use and proper
operation of this unit to the operators.
• Review ALL of the Safety Precautions listed on page 1 of
this manual.
• Familiarize yourself with the operation of the machine
and confirm that all controls function properly.
• Know how to STOP the machine in case of an
emergency.
• Make sure hands, feet, and clothing are at a safe
distance from any moving parts.
• OIL LEVEL - Check the oil level in the engine. For more
information see “Lubrication” under the respective
engine’s “Owners Manual” or the Maintenance section of
this manual.
• AIR CLEANER - Check to ensure element is in good
condition and properly installed.
• FUEL SUPPLY - The engines on MBW equipment
require an automotive grade of clean, fresh, unleaded
gasoline.
• FUEL FILTER - If clogged or damaged, replace.
Starting Engine
1. Open fuel valve.
2. Turn engine switch to “ON”.
3. Set throttle to idle.
4. Choke engine if necessary (you may not need to
choke a warm engine).
5. Pull starter rope repeatedly until engine starts.
6. Move choke lever to open position.
7. Allow engine to warm up for one or two minutes.
Operating
1. Open throttle fully.
2. Compactor will begin vibrating and moving in a
forward direction.
3. Maximum compaction of soil has been reached when
excessive kickback is noticed in the compactor. The
number of passes needed to reach compaction level
desired will depend on soil type and moisture.
4. When using the compactor on asphalt use the water
sprinkling system to keep the plate bottom form
adhering to the hot asphalt.
Stopping Engine
1. Move throttle to idle position.
2. Let engine idle for one or two minutes.
3. Turn switch on engine to “STOP” position.
4. Turn off fuel valve.
Lifting/Transporting
1. The unit can be lifted by the handles on the sides of
the unit or by the roll cage.
2. The unit must be transported in the upright position.
DO NOT lay machine on its
side or top.
3. Secure or tie down unit
using the lift handles or roll
cage.
WARNING
Always stop the engine before:
Adding fuel.
Leaving the equipment unattended for any
amount of time.
Before making any repairs or adjustments to the
machine.

- 6 -
MAINTENANCE
WARNING
Always exercise the stopping procedure before
servicing or lubricating the unit.
After servicing the unit, replace and fasten all
guards, shields, and covers to their original
positions before resuming operation.
CAUTION
Always verify fluid levels and check for leaks after
changing fluids.
Do not drain oil onto ground, into open streams,
or down sewage drains.
Maintenance Schedule
1. Check all hardware after the first 5 hours of use, then follow the maintenance schedule.
Fluid Levels
1. MBW #01058 ---- 6-Pack (8 oz. bottles)
MBW #17320 ---- 1 quart (32 oz.)
Engine Maintenance
Refer to the engine Owner’s Manual for maintenance
intervals and procedures.
Engine Speed
1. Engine speed is factory set according to the speeds
listed in the Specifications section of this manual. Do
not tamper with the governor setting.the governor
establishes safe operating limits which must not be
exceeded.
2. Refer to the engine Owner’s Manual for procedure on
setting operating and idle speed.
3. The engine operating speed should be set to 3400
RPM.
4. The engine idle speed must not exceed 1800 rpm. If
the idle speed is greater than 1800 RPM the clutch
may not disengage.
Cleaning Plate
Remove any excess debris which may get into the housing
of the unit.
Belt Adjustment
If any belt stretch develops follow these steps:
Reference engine assembly page.
1. Remove 4 flange bolts securing roll cage assembly to
engine deck and remove roll cage assembly. See
figure 1.
SYSTEM MAINTENANCE EACH USE EVERY 50
HOURS
EVERY 250
HOURS YEARLY
Engine Refer to engine operator/owner manual X
Exciter Check oil level X
Check for oil leaks X
Change oil XX
Tighten Bolts1XX
Hardware Check and tighten as needed1XX
Shockmounts Check for cracks or tears XX
SYSTEM FLUID VOLUME RECOMMENDED OIL
Exciter 6 oz (2000 Plate)
8 oz. (3550 Plate) MBW Ground Pounder®Exciter Oil1
Engine Refer to engine operator/owner manual

- 7 -
Axis1Axis1
Axis1Axis1Axis1Axis1Axis1
1"
7/8" OIL LEVEL
.75 OIL LEVEL
2000 PLATE
DIP STICK
PLATE
EXCITER SHAFT
3550
FIGURE 2
EXCITER SHAFT
DIP STICK
2. Apply moderate thumb pressure to belt about half
way between pulleys. When properly adjusted the
belt should deflect approximately 3/8” (9mm). If the
belt is adjusted correctly reinstall belt guard and
hardware.
3. To adjust belt tension loosen (do not remove) the (4)
engine bolts.
4. Push engine towards the back of the plate. While
holding pressure on the engine retighten the (4)
engine bolts.
5. Recheck belt tension as described in step 2 and
readjust if necessary until the proper tension is
reached.
6. Reinstall roll cage assembly.
Checking Exciter Oil
WARNING
Exciter and oil is hot after machine has been
running. Allow machine to cool before servicing
unit.
1. Let exciter cool before checking oil.
2. Place plate on a level surface.
3. Remove roll cage assembly by removing (4) flange
screws securing roll cage to engine deck. If machine
is equipped with water tank disconnect hose from
spray bar on front of plate. Now entire roll cage
assembly, including roll cage, handle, water tank and
belt guard, can be removed (see Figure 1).
4. Clean all dirt and debris from exciter to prevent
contamination of exciter oil.
5. Remove pipe plug from top of exciter housing.
6. Rotate exciter shaft so a metal dip stick can be
inserted into exciter (see Figure 2).
7. Place a clean metal rod through the oil fill hole as
shown in figure 2.
8. Exciter should have approximately 3/4” (2000 plate)
7/8 to 1” (3550 plate) oil.
9. If oil need to be added, refer to Fluid Levels page of
this section for type of oil to be used. DO NOT
OVERFILL, over filling can cause excessive heat in
exciter.
10. Apply pipe sealant to pipe plug and reinstall into top
of exciter housing.
11. Reinstall roll cage assembly and re-attach hose to
spray bar.
Changing Exciter Oil
WARNING
Exciter and oil is hot after machine has been
running. Allow machine to cool before servicing
unit.
1. Let exciter cool before changing oil.
2. Remove roll cage assembly by removing (4) flange
screws securing roll cage to engine deck. If machine
is equipped with water tank disconnect hose from
spray bar on front of plate. Now entire roll cage
assembly, including roll cage, handle, water tank and
belt guard, can be removed (see Figure 1).
3. Remove 1/2” hex head cap screws and lock washers
from side of bottom plate. Remove belt and engine
deck assembly. Refer to figure 3
OIL FILL/DRAIN HOLE
FIGURE 1
FLANGE SCREWS
PIPE PLUG

- 8 -
ASSEMBLY
ENGINE DECK
1/2" HEX HEAD
CAP SCREWS OPTIONAL OIL DRAIN
(3550 PLATE ONLY)
FIGURE 3
PIPE PLUG
OIL FILL/ DRAIN
HOLE
4. Clean all dirt and debris from exciter to prevent
contamination of exciter oil.
5. Remove pipe plug from top of exciter housing. Tilt
plate housing upside down to drain oil from housing.
6. (Optional 3550 Only) Remove oil drain screw and
brass washer from exciter rear cover. Tilt bottom
plate housing on it’s side to drain oil from housing.
After draining oil, return bottom plate housing to the
upright position and replace oil drain screw and
brass washer.
7. Return plate housing to the upright position.
8. Fill exciter with MBW Ground Pounder® exciter oil to
level specified in the Fluid Levels section of this
manual.
9. Apply pipe sealant to pipe plug and reinstall into top
of exciter housing.
10. Reinstall engine deck assembly, belt and roll cage
assembly. If equipped with water tank reattach hose
to spray bar.

- 9 -
SERVICE
Assembly and disassembly should be performed by a
service technician who has been factory trained on MBW
equipment. The unit should be clean and free of debris.
Pressure washing before disassembly is recommended.
• Prior to assembly, wash all parts in a suitable cleaner or
solvent.
• Check moving parts for wear and failure. Refer to the
Replacement section in this manual for tolerance and
replacement cycles.
• All shafts and housings should be oiled prior to pressing
bearings. Also, ensure that the bearings are pressed
square and are seated properly.
• All bearings should be replaced when rebuilding any
exciter or gearbox.
• All gaskets and seals should be replaced after any
disassembly.
Torque Chart
Service Tools
Exciter Removal
1. Remove roll cage assembly, engine deck assembly
and belt. Refer to Changing Exciter Oil, page 7.
2. Remove 4 5/8-11 exciter bolts, washers, lock
washers and nuts. If unit has exciter shims (7) make
note of location to assure proper placement during
reassembling.
3. Clean exciter and drain oil as described in Changing
Exciter Oil section of this manual before proceeding
with disassembly.
(2000) Exciter Disassembly
Refer to 2000 & 2018 EXCITER ASSEMBLY, page 14.
for exciter disassembly.
1. Remove flange screw (23) and washer (8) securing
the pulley (19) to the exciter shaft (20).
2. Slide pulley off of exciter shaft. be sure not to lose
shaft key (17).
3. Remove 6 flange screws (23) from rear cover plate
(2) and remove cover, opposite of pulley end.
4. Support exciter assembly on outside diameter of
exciter housing (1) and press exciter shaft out of
housing.
5. Remove 6 flange screws (22) from front cover plate
(18) and remove front cover.
Note: If bearings have failed and need to be replace
then proceed with bearing removal steps. If
bearings do not need replacing skip to step #9.
6. Support exciter housing (1) and press out front
bearing (4).
7. Remove front bearing (4) inner race from exciter shaft
by supporting O.D. of race and pressing exciter shaft
thru.
8. Remove snap ring (6) and press rear bearing (5) off
of shaft (20).
9. When reassembling always replace, oil seal (13) and
front & rear cover gaskets (10 & 11).
SIZE GRADE 2 GRADE 5 GRADE 8
1/4-20 49 in•lbs 76 in•lbs 9 ft•lbs
1/4-28 56 in•lbs 87 in•lbs 10 ft•lbs
5/16-18 8 ft•lbs 13 ft•lbs 18 ft•lbs
5/16-24 9 ft•lbs 14 ft•lbs 20 ft•lbs
3/8-16 15 ft•lbs 23 ft•lbs 33 ft•lbs
3/8-24 17 ft•lbs 26 ft•lbs 37 ft•lbs
7/16-14 24 ft•lbs 37 ft•lbs 52 ft•lbs
7/16-20 27 ft•lbs 41 ft•lbs 58 ft•lbs
1/2-13 37 ft•lbs 57 ft•lbs 80 ft•lbs
1/2-20 41 ft•lbs 64 ft•lbs 90 ft•lbs
9/16-12 53 ft•lbs 82 ft•lbs 115 ft•lbs
5/8-11 73 ft•lbs 112 ft•lbs 159 ft•lbs
5/8-18 83 ft•lbs 112 ft•lbs 180 ft•lbs
3/4-16 144 ft•lbs 200 ft•lbs 315 ft•lbs
1-8 188 ft•lbs 483 ft•lbs 682 ft•lbs
1-14 210 ft•lbs 541 ft•lbs 764 ft•lbs
1-1/2-6 652 ft•lbs 1462 ft•lbs 2371 ft•lbs
M 6 3 ft•lbs 4 ft•lbs 7 ft•lbs
M 8 6 ft•lbs 10 ft•lbs 18 ft•lbs
M 10 10 ft•lbs 20 ft•lbs 30 ft•lbs
CONVERSIONS
in•lbs x 0.083 = ft•lbs
ft•lbs x 12 = in•lbs
ft•lbs x 0.1383 = kg•m
ft•lbs x 1.3558 = N•m
Part No. Description
17320 Ground Pounder® Exciter Oil
016129 Rubber Test Mat
12100 Decal Set

- 10 -
(2000) Exciter Assembly
Refer to 2000 & 2018 EXCITER ASSEMBLY, page 14.
for exciter disassembly.
1. Prior to assembly, clean all parts in a suitable solvent
or cleaning solution. When a complete disassembly
is done it is recommended that all seals, gaskets and
bearings are replaced.
Note: If replacing bearings proceed to step #2, if not
replacing bearings skip to step #6.
2. Press front bearing (4) inner race onto exciter shaft,
pulley end.
3. Press front bearing (4) into exciter housing (1).
4. Press rear bearing (5) onto exciter shaft, opposite
pulley end, use care to press on I.D. of bearing only.
5. Install snap ring (6) onto exciter shaft.
6. Press exciter shaft assembly into exciter housing (1).
Use care to properly support O.D. of housing and
guide shaft into bearing already in housing.
7. Press oil seal (13) into front cover (18), Seal to be
press in until bottoming out on inside flange of front
cover.
8. Install new gasket (10), front cover (18) and 6 flange
screws (22). Torque flange screws to 13 ft.-lbs.
9. Install new gasket (11), rear cover (2) and 6 flange
screws (23). Torque flange screws to 13 ft.-lbs.
10. Grease oil lip seal (13) and exciter shaft. Install key
(17) on exciter shaft and slide pulley (19) onto shaft.
11. Install washer (8) and flange screw (23), torque
flange screw to 13 ft.-lbs.
12. Fill exciter with MBW Ground Pounder® exciter oil to
level specified in the Fluid Levels section of this
manual.
(3550) Exciter Disassembly
Refer to 3550 Exciter Assembly, page 16. for exciter
disassembly.
1. Remove flange screw (26) and washer (14) securing
the pulley (2) to the exciter shaft (19).
2. Slide pulley off of exciter shaft. be sure not to lose
shaft key (15).
Note: To aid in removal of rear cover you will need
two 5/16-18 bolts, minimum grade 5.
3. Remove 6 flange screws (26) from rear cover plate
(4). To press rear cover (4) off of housing, thread two
5/16-18 grade 5 bolts into thread holes on cover. Turn
bolts in with wrench or ratchet to press cover out.
When pressing cover off try to keep even pressure on
both side to ensure cover comes out straight.
4. Support exciter assembly on outside diameter of
exciter housing (1) and press exciter shaft out of
housing.
5. Remove 6 flange screws (25) from front cover plate
(3) and remove front cover.
Note: If bearings have failed and need to be replace
then proceed with bearing removal step 6. If
bearings do not need replacing skip to step #9.
6. Support exciter housing (1) and press out front
bearing (12) from inside out.
7. Remove retainer plate (6) by removing 2 cap screws
(24).
8. Remove snap ring (8).
9. Remove bearing (11) from rear cover (4) with 1/4”
punch.Tap the bearing out thru the holes for caps
screws (24). Be sure to alternate between holes to
avoid cocking the bearing.
10. Remove snap ring (9).
11. Remove bearing (11) inner race from exciter shaft by
supporting O.D. of race and pressing exciter shaft
thru.
12. When reassembling always replace sealing washer
(5), oil seal (10) and front & rear cover gaskets (17 &
18).
(3550) Exciter Assembly
Refer to 3550 Exciter Assembly, page 16. for exciter
assembly.
1. Prior to assembly, clean all parts in a suitable solvent
or cleaning solution. When a complete disassembly
is done it is recommended that all seals, gaskets and
bearings are replaced.
Note: If replacing bearings proceed to step #2, if not
replacing bearings skip to step #6.
2. Press front bearing (12) into exciter housing (1).
3. Press bearing (11) inner race onto exciter shaft (19).
4. Install snap ring (9) onto exciter shaft.
5. Support I.D. and O.D. of bearing (12) and press
exciter shaft into bearing.
6. Check felt filter (13) to be sure it is not blocked or
deteriorating, Replace if damaged.
FIGURE 4
SPIROL PIN
REAR COVER 11/16"

- 11 -
7. Check and set end of spirol pin (23) to be 11/16” from
inside of rear cover (4). See Figure 4.
8. Press bearing (11) into rear cover (4) and install snap
ring (8) and gasket (18).
Note: To aid in assembly of rear cover you will need
three, 5/16-18 x 2-1/2 minimum length bolts, to aid in
alignment of rear cover.
9. Apply oil to I.D. of exciter housing and O.D. of rear
cover.
10. Set rear cover (4) and new gasket (18) on exciter
housing and install three alignment bolts into exciter
housing.
CAUTION
Be sure that the inner bearing race is properly
aligned to slide into the bearing. If proper align-
ment is not maintained the shaft may push the
front bearing out of the housing.
11. Carefully press or tap the rear cover (4) down to seat
on the exciter housing. Use care to keep cover
straight when installing to prevent damaging housing
or cover.
12. Remove the three alignment bolts and install six
flange screws (26) securing the rear cover. Torque
flange screws to 13 ft.-lbs.
13. Use medium strength thread lock when installing
retainer plate (6) with 2 cap screws (24).
14. Install oil drain cap screw (24) and brass washer (27).
15. Press oil seal (10) into front cover (3), Seal to be
press in until flush with front cover.
16. Install sealing washer (5).
17. Install new gasket (17), front cover (3) and 6 flange
screws (25). Torque flange screws to 13 ft.-lbs.
18. Install new gasket (18), rear cover (6) and 6 flange
screws (25). Torque flange screws to 13 ft.-lbs.
19. Grease oil lip seal (10) and exciter shaft. Install key
(15) on exciter shaft and slide pulley (2) onto shaft.
20. Install washer (14) and flange screw (26), torque
flange screw to 13 ft.-lbs.
21. Fill exciter with MBW Ground Pounder® exciter oil to
level specified in the Fluid Levels section of this
manual.
Exciter installation
Refer to exciter assembly pages for each unit.
1. Clean exciter mounting bars on bottom plate. If unit
was equipped with exciter shims (3) replace to
original position and set exciter assembly in place on
mounting bars.
2. Check to make sure exciter sits flat on mounting bars,
if not shim (3) as needed.
3. Install 4 5/8-11 exciter bolts, washers, lock washers,
and 5/8-11 nuts. Torque exciter bolts to 150 ft.-lbs.
4. Reinstall engine deck, belt and roll cage assembly. If
equipped with water tank reattach hose to spray bar.
Adjust belt as describer in Belt Adjustment section of
this manual.
Parts Replacement Cycles and Tolerances
Bearings Replace anytime a bearing is rough, binding, discolored or removed from housing or
shaft.
Clutch Replace clutch if it does not disengage below 1800 rpm.
Engine Components Refer to your engine manufacturer’s Owner’s Manual.
Hardware Replace any worn or damaged hardware as needed. Replacement hardware should
be grade 5 and zinc plated unless otherwise specified.
Safety Decals Replace if they become damaged or illegible.
Seals & Gaskets Replace if a leak is detected and at every overhaul or tear down.
V-Belts Replace if cracked, torn, or stretched to the point the belt won’t tension properly.
Exciter Oil Replace once every season or every 250 hours. Use 6 oz. (2000 plate), 8 oz. (3550
plate) Ground Pounder ® exciter oil.

- 12 -
MBW, Inc.
250 Hartford Rd • PO Box 440
Slinger, WI 53086-0440
Phone: [phone]
Fax: [phone]
Email: [e-mail]
Website: www.mbw.com
MBW (UK) Ltd.
Units 2 & 3 Cochrane Street
Bolton BL3 6BN, England
Phone: [phone]
Fax: [phone]
Contact Information
MBW FRANCE S.A.R.L.
Z.A. d’Outreville
11 rue Jean Baptiste Néron,
60540 BORNEL
FRANCE
Phone: [phone]
Fax: [phone]
Email: [email protected]
REPLACEMENT PARTS
The warranty is stated in this book on page26. Failure to
return the Warranty Registration Card renders the warranty
null and void.
MBW has established a network of reputable distributors/
dealers with trained mechanics and full facilities for
maintenance and rebuilding, and to carry an adequate parts
stock in all areas of the country. Their sales engineers are
available for professional consultation. If you cannot locate
an MBW distributor in your area, contact MBW or one of our
Sales Branches listed below.
When ordering replacement parts, be sure to have the
following information available:
• Model and Serial Number of machine when ordering
MBW parts
• Model and Serial Number of engine when ordering
engine parts
• Part Number, Description, and Quantity
• Company Name, Address, Zip Code, and Purchase
Order Number
• Preferred method of shipping
REMEMBER - You own the best! If repairs are needed,
use only MBW parts purchased from authorized
MBW distributors.
The unit’s serial number can be found in the following
locations:
• The model/serial number decal is located on the deck
behind the engine.
• The serial number is stamped on the engine deck in the
back left corner, top of exciter housing and on bottom
plate exciter mounting bar.
Write Model Number here
Write Serial Number here
DECAL SERIAL NO.
STAMPED SERIAL NO.

- 13 -
This page intentionally left blank.

- 14 -





























2000 & 2018 EXCITER ASSEMBLY

- 15 -
ITEM PART NO. DESCRIPTION QTY
1. 00201 EXCITER HOUSING 1
2. 00206 REAR COVER 1
3. 00259 SHIM, EXCITER (AS REQUIRED)
4. 01004 CYLINDRICAL ROLLER BEARING 1
5. 01070 BALL BEARING 1
6. 01071 RETAINING RING, EXTERNAL 1
7. 01072 FILTER, FELT 1
8. 01099 WASHER 1
9. 01191 RETAINING RING, INTERNAL 1
10. 06096 GASKET 1
11. 06097 GASKET 1
12. 13451 WASHER, 5/8, A325, STRUCTURAL 4
13. 17179 OIL SEAL 1
01002 OIL SEAL, SERIAL NO. 2064574 & LOWER
14. 18696 HHCS, 5/8-11 X 5-3/4, GRADE 8 4
15. 18697 BASEPLATE 1
16. 18701 HEX NUT, 5/8-11, GRADE 8 4
17. 19135 KEY, 1/4” SQ. X 3/4 SQUARE ENDS 1
01283 KEY, 1/4” SQ. X 1-1/4 ROUND ENDS, SERIAL NO. 2064574 & LOWER
18. 19628 FRONT COVER 1
00005 FRONT COVER, SERIAL NO. 2064574 & LOWER
19. 19629 PULLEY, 4-3/8 DIA x 1.0 I.D., AP2000 (ASPHALT VERSION) 1
19630 PULLEY, 3-7/8 DIA x 1.0 I.D., GP2000 (SOIL VERSION & AP2000+) 1
00003 PULLEY, 4-3/8 DIA x 1-1/8 I.D., AP2000 (ASPHALT PLATE) SER. NO. 2064574 & LOWER
00348 PULLEY, 3-7/8 DIA x 1-1/8 I.D., GP2000 (SOIL & 2000+ PLATE) SER. NO. 2064574 & LOWER
20. 19835 EXCITER SHAFT 1
00202 EXCITER SHAFT, SERIAL NO. 2064574 AND LOWER
21. F0205SP SPIROL PIN, 1/8 X 5/8 LG. 1
22. F051806FWS FLANGE LOCKING SCREW, 5/16-18 X 3/4 LG. 6
23. F051808FWS FLANGE LOCKING SCREW, 5/16-18 X 1 LG 7
24. F0612SP PIN, SPIROL 1
25. F0618SPP SOCKET PIPE PLUG, 3/8-18 3
26. F10LW LOCKWASHER, 5/8, ZP 4
SERVICE PARTS:
00062 WASHER SEAL, PULLEY ( NOT SHOWN) SERIAL NO. 2064574 AND LOWER
REPLACEMENT KIT:
19836 EXCITER ASSEMBLY (DOES NOT INCLUDE ITEMS 8, 17, 19 & 23)
19837 EXCITER ASM. ASPHALT (INCLUDES ITEMS 8, 17, 19 & 23) SERIAL NO. 2064574 & BELOW
19838 EXCITER ASM. SOIL (INCLUDES ITEMS 8, 17, 19 & 23) SERIAL NO. 2064574 & BELOW
18757 BOTTOM PLATE, AP/GP2000 (INCLUDES ITEMS: 3, 12, 14, 15, 16, 24, 25 & 26)

- 16 -































3550 Exciter Assembly

- 17 -
ITEM PART NO. DESCRIPTION QTY
1. 00001 EXCITER HOUSING 1
2. 00006 REAR COVER 1
3. 00066 RETAINER PLATE 1
4. 00259 SHIM EXCITER (AS REQUIRED)
5. 01000 RETAINING RING, INTERNAL 1
6. 01001 RETAINING RING, EXTERNAL 1
7. 01004 CYLINDRICAL ROLLER BEARING 1
8. 01005 SPHERICAL ROLLER BEARING 1
9. 01072 FILTER, FELT 1
10. 01099 WASHER 1
11. 06096 GASKET 1
12. 06098 GASKET 1
13. 17179 OIL SEAL 1
01002 OIL SEAL, SERIAL NO. 3551199 & LOWER
14. 18577 BASE PLATE 1
15. 18700 HHCS, 5/8-11 X 6 GRADE 8 4
16. 18701 HEX NUT, 5/8-11, GRADE 8 ZP 4
17. 19135 KEY, 1/4” SQ. X 3/4 SQUARE ENDS 1
01283 KEY, 1/4” SQ. X 1-1/4 ROUND ENDS, SERIAL NO. 3551199 & LOWER
18. 19628 FRONT COVER 1
00005 FRONT COVER, SERIAL NO. 3551199 & LOWER
19. 19629 PULLEY, EXCITER 4-3/8 DIA x 1.0 I.D. 1
00003 PULLEY, 4-3/8 DIA x 1-1/8 I.D., SERIAL NO. 3551199 & LOWER
20. 19912 EXCITER SHAFT 1
18692 EXCITER SHAFT, SERIAL NO. 3551199 & LOWER
21. F0205SP SPIROL PIN, 1/8 X 5/8 LG. 1
22. F051804HCS HEX HEAD CAP SCREW, 5/16-18 X 1/2LG. 3
23. F051806FWS FLANGE LOCKING SCREW, 5/16-18 X 3/4 LG. 6
24. F051808FWS FLANGE LOCKING SCREW, 5/16-18 X 1 LG 7
25. F05BFW WASHER, BRASS, 5/16 1
26. F0612SP SPIROL PIN 1
27. F0618SPP SOCKET PIPE PLUG, 3/8-18 3
28. F10LW LOCKWASHER, 5/8 4
29. F10PW WASHER, 5/8 4
SERVICE PARTS:
00062 WASHER SEAL, PULLEY (NOT SHOWN) SERIAL NO. 2064574 & LOWER
REPLACEMENT KIT
19913 EXCITER ASSEMBLY ( COMPLETE)
18758 BOTTOM PLATE, AP/GP3550 (INCLUDES ITEMS:7. 19, 20, 21, 27, 28, 29 & 30)
